- Page 1 Industry-leading Flat Panel Displays Have assembly and installation done by a qualified electrician. Simulated pictures on screen. Specifications are subject to change without notice. Printed in Japan ASIA05S-01...
- Page 2 (in this case, black or silver) to match their surroundings. Panasonic flat panel displays provide all that and more. Our quest to lead the industry in image quality and innovative functions has led to a new lineup of eleven models in five sizes and two cabinet colours.
- Page 3 Create a customised system that meets your exact needs. Combined with the superb image quality, this level of flexibility makes Panasonic flat panel displays a high-performance solution to a range of applications. * TH-37PWD8 series and 32LHD7 series are equipped with dual function slots.
- Page 4 Front protection glass Long Service Life of 60,000 Hours Industry’s Highest Level of Dark-Area Contrast — A new drive circuit and inner panel improvements give Panasonic plasma panels a long service life of approximately 60,000 hours* New Real Black Drive System brightness.
- Page 5 Multi-Function Slots In addition to the fixed input interface, the Panasonic flat panel display has three (or two) interchangeable slots that let you add different combinations of optional terminal boards. This gives you the flexibility to add digital or analogue capabilities, as necessary, and to customise your system for specific needs.
- Page 6 Plasma System Solutions Digital Signage/Narrowcasting System Complete with Touch Panel Easy, interactive content distribution system for retail chains and public spaces such as shopping malls, office buildings and hotels • Constructing a Multi-Language Environment System Configuration In contrast with conventional methods, in which several information Content production and panels are prepared in different languages, this digital system allows delivery, System control...
- Page 7 An Endless Array of Applications In-Store Display Shopping Mall, Panama Amusement Education School, Addis Ababa, Ethiopia TESCO, London, UK Information Sunset Stations Casino, Las Vegas, USA (30 units of 65˝ displays) TV Production Bowling Alley, Tokyo, Japan Asahi Broadcasting Corporation, Osaka, Japan Ritsumeikan University, Kusatsu, Japan Hospitality Sumitomo Mitsui Bank,...
- Page 8 Wide Plasma Display Wide Plasma Display Remote Control TH-32LHD7WK/WS Supplied Remote Control for PHD8/PWD8 series 220 - 240 V AC, 50/60 Hz (Comes with every Panasonic Plasma Display model.) 165 W Remote Control Functions 0.4 W Power On Save On: 0.8 W Power Off Save Off: 1.0 W...
- Page 9 Dimensions (Unit: mm) TH-65PHD8WK 1554 1471 239.4 42.5 1434 TH-50PHD8WK/WS 1210 1148 1106 TH-42PHD8WK/WS TH-42PWD8WK/WS 1020 TH-37PWD8WK/WS TH-32LHD7WK/WS 53.2 53.2 698.6 697.7 51.9 Preset Input Signals With the optional 1554 pedestal attached. 1075.2 Signal name NTSC PAL60 SECAM Modified NTSC 525 (480)/60i 525 (480)/60p 625 (575)/50i...
-
Page 10: Mounting Options
Mounting Options Wall-hanging bracket TY-WK65PV7 TY-WK42PV7 Unit: mm Unit: mm 1554 177.5 1075.2 1320 50˝ model 42˝ model 1210 1020 91.5 34.5 Wall-hanging bracket (angled) TY-WK42PR7 Unit: mm 50˝ model 42˝ model 37˝ model 0° 5° 10° 15° 20° 0° 5°...
