The VARI❋LITE VLX3 Wash Luminaire is the next step in
Vari-Lite's solid-state lighting journey. A step that gives
designers one of the most versatile LED lighting tools to
meet any demanding production or lighting need – from
small to large venues, concert touring, or television
studio.
Based on Philips Vari-Lite's award-winning VLX Wash
luminaire technology, the VLX3 wash gives you all the
benefits of LED technology with the best visual
performance characteristics of traditional automated
luminaires. Using three powerful LED engines, the VLX3
wash offers stunning colors and intensity, multi-year
source life and high reliability. Combined with low
energy consumption and maintenance costs, the
VARI*LITE VLX3 wash continues to elevate the bar for all
other LED fixtures.
Three, replaceable custom 120 watt RGBW LED chipsets
provide output that offers three times the efficacy of
comparable tungsten sources. The total system provides
approximately greater than 6,000 lumens of white light
output, and the 10,000 hour source life of the chip
ensures that lamp replacement costs are a thing of the
past. The luminaire offers 70% lumen intensity
maintenance over that time guarantees that the VLX3
wash will remain powerful and bright well into the future.
With an optical system from the leader in automated
lighting, color mixing is smooth, natural, and free of
"color shadowing" effects associated with other LED
fixtures. Additionally, the VLX3 wash offers a dynamic
CRI adjustment, a continuously adjustable color
temperature white range between approximately 3000
and 9000 Kelvin, and seamless color mixing that all
combine to create a single source that behaves like
familiar arc or tungsten luminaires without the
associated costs and inefficiencies inherent in those
systems.
Beam size control is achieved by the use of an optical
zoom system that offers a zoom range from
approximately 15 to 55 degrees. Accessory mounting
points are included allowing the attachment of additional,
aftermarket beam control devices such as an extendible
top hat.
All movements are smooth, silent, and accurate under
the control of the time-proven Vari-Lite three-phase
motor system with a full 540 degrees of pan and 240
degrees of tilt control.
The luminaire offers five-pin DMX in and thru connectors
and a backlit menu panel for easy installation and
operation. Control is achieved through a variety of DMX
consoles and output devices. Large, rugged
handles insure easy installation, and subdued
style and understated lines allow for seamless
integration into any lighting rig or stage setting.
Pan and tilt transport/service locks and low
fixture weight make moving the VLX3 wash
as simple and efficient as it is to operate.
The VLX3 wash. Only from Philips Vari-Lite.
Accelerating LED lighting even faster.
Programmable Functions
Intensity Control: Smooth, high resolution dimming control of R, G, B, and W LED's.
Color Mixing System: Three x 120 watt, replaceable custom RGBW LED chipsets. Each chipset contains high
density red, green, blue, and white LED emitters.
Optics: Beam size control is achieved by the use of an optical zoom system that provides
continuously variable field angle from approximately 15° to 55°.
Strobe: High speed with multiple strobe effects.
Pan and Tilt: Smooth, time-controlled continuous motion by way of a pair of three-phase stepper motor
systems.
Range: Pan - 540°, Tilt - 240°.
Accuracy: 0.3° resolution.
Description
Source: Three x 120 watt, replaceable custom RGBW chipsets.
Color Temp. White: Variable between approximately 3000 and 9000 Kelvin.
CRI: Dynamically adjustable
Manufacturer Rated Life: In excess of 10,000 hours. (at full RGBW)
Output: Approximately 6,000 lumens (white light).
Power Requirements: Standard AC power distribution from 100-240VAC, 50/60Hz. The unit requires up to 7A
depending on the AC supply voltage.
Operational Temperature: -20° to 122°F (-29° to 50°C)
Cooling: Variable forced air cooling.
Control: Completely compatible with a wide variety of DMX512 lighting control consoles.
DMX Channels: 23 channels.
Mounting Position: May be mounted and operated in any orientation.
Spacing: Hangs on 21.50 inch (54.6 cm) centers.
Weight: 44 lbs. (20.0 kg.)
Ordering Information
Luminaires:
20.9703.0001 VLX3 Wash Luminaire, Black
20.9703.0001 .02 VLX3 Wash Luminaire, White
Accessories:
22.9620.0194 Safety Cable Assembly
28.8500.0054 USB Luminaire Programming Kit
55.6840.0001 Truss Hook, Mega-Clamp (For round and square pipe.)
55.6841.0001 Truss Hook, Mega-Claw (For 2" round pipe.)
