20mm 2-speed motor drill
Hide thumbs Also See for HP2032:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual See also: Instruction Manual
T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
Model HP2032/HP2033 are sister versions of the existing
model HP2030/HP2031.
And they are designed for more professional use
than HP2030/HP2031. Their brief benefit is:
*More strong housing than HP2030/HP2031 by aluminum
gear housing and Cam housing.
HP2032
-------
Drill chuck with key
HP2033
-------
Keyless drill chuck
S
pecification
Voltage (V)
100
115
200
220
230
240
No load speed
Chuck ability
Max. drilling capacities
(L / H)
Net weight
Cord length
S
tandard equipment
Chuck key
S13------------------------1 pc.
Key holder
12-------------------------1
Depth
gauge---------------------------1 pc.
Plastic carrying
case------------------1 pc.
[Note] The standard equipment may differ from country to country.
< Note > The standard equipment for the tool shown may be differ from country to country.
O
ptional accessories
T.C.T. Hammer Bit 5.0-70 ~19.0-220
Hole Saw Ass'y 79mm, 95mm
Blow out bulb 64
HP2032, HP2033
20mm 2-speed motor drill
Current (A)
Cycle (Hz)
7.6
50/60
6.6
50/60
3.8
50/60
50/60
3.4
50/60
3.3
50/60
3.2
Low speed
Rotations
per minute
High speed
Low speed
Blows
per minute
High speed
Concrete
Steel
Wood
(HP2032 only)
pc.(HP2032 only)
31mm
(1-1/4")
Continuous Rating (W)
Input
Output
720
330
330
720
330
720
330
720
720
330
720
330
0-850 rpm
0-2900 rpm
0-9400 rpm
0-3200 rpm
1.5-13mm
L: N/A H: 20mm
L: 13mm
H: 8mm
L: 40mm
H:25mm
2.5kg
2.5m
PRODUCT
P 1 / 8
Width 75mm (2-15/16")
Max.
Output(W)
620
620
620
620
620
620
