Service Manual
TOP NEXT
ORDER NO.SIMMC 0401005A1
E1
Microwave Oven
NN-P994 NN-T994SF
NN-T984SF NN-T964SF
NN-H964 NN-H944
NN-H934 NN-H924
NN-H914 NN-S954
NN-S944 NN-S934
NN-S924 NN-S914
APH(USA)
CPH(CANADA)
Please file and use this specified manual together with the service manual for Model NN-S560BF/WF
(ORDER NO. SIMMC0001002C3).
1/5/2009
Page 1 of 4
Advertisement
Related Manuals for Philips NN-P994 NN-T994SF
Summary of Contents for Philips NN-P994 NN-T994SF
- Page 1 Page 1 of 4 Service Manual TOP NEXT ORDER NO.SIMMC 0401005A1 Microwave Oven NN-P994 NN-T994SF NN-T984SF NN-T964SF NN-H964 NN-H944 NN-H934 NN-H924 NN-H914 NN-S954 NN-S944 NN-S934 NN-S924 NN-S914 APH(USA) CPH(CANADA) Please file and use this specified manual together with the service manual for Model NN-S560BF/WF (ORDER NO.
- Page 2 Page 2 of 4 © 2004 Shanghai Matsushita Microwave Oven Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law. 1/5/2009...
- Page 3 Page 3 of 4 1/5/2009...
- Page 4 Page 4 of 4 TOP NEXT 1/5/2009...
- Page 5 Page 1 of 1 1/5/2009...
-
Page 6: Parts List
Page 1 of 4 4.2 PARTS LIST TOP PREVIOUS NEXT NOTE: 1. When ordering replacement part(s), please use part number(s) shown in this part list. Do not use description of the part. 2. Important safety notice: Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacture’s specified parts. - Page 7 Page 2 of 4 F00076H30BAP NAME PLATE S924BF APH F00076H30HAP NAME PLATE S924WF APH F00076H50BAP NAME PLATE S914BF APH F00076H50HAP NAME PLATE S914WF APH F00076H10BAP NAME PLATE S934BF APH F00076H10HAP NAME PLATE S934WF APH F00076Q20BAP NAME PLATE S924BFW APH F00076Q20HAP NAME PLATE S924WFW APH F00334W00AP...
- Page 8 Page 3 of 4 J61784T00AP MICRO SWITCH (SHORT SWITCH) (D3V-1G-2C25) A606Y6G00AP H.V.INVERTER (U) F65856K10AP INVERTER BRACKET P994 APH, T9*4SF APH F65856K50AP INVERTER BRACKET P994 CPH, H9*4 APH/CPH, S9*4 APH 2M261-M32F MAGNETRON 2M261-M32G MAGNETRON B62308250AP FUSE F62315G10XN FUSE HOLDER J692Y4T00CPR NOISE FILTER F63265G60AP TURNTABLE MOTOR F900C4T60CP...
- Page 9 Page 4 of 4 TOP PREVIOUS NEXT 1/5/2009...
- Page 10 Page 1 of 1 1/5/2009...
- Page 11 Page 1 of 1 4.3.1 NN-H9*4 APH/CPH, NN-S9*4 APH TOP PREVIOUS NEXT Ref. No. Part No. Part Name & Description Pcs/Set Remarks F603L6G30AP D.P.CIRCUIT H964BF/WF APH F603L6G60AP D.P.CIRCUIT H944BF/WF/BFW/WFW APH, H924BF/WF/BFW/WFW APH F603L6G30CP D.P.CIRCUIT H964BF/WF CPH F603L6G40AP D.P.CIRCUIT S954BF/WF APH F603L6G70AP D.P.CIRCUIT S944BF/WF/BFW/WFW APH, S924BF/WF/BFW/WFW APH...
- Page 12 Page 1 of 1 1/5/2009...
- Page 13 Page 1 of 2 4.3.2 NN-P994 APH/CPH, NN-T9*4 APH TOP PREVIOUS NEXT Ref. No. Part No. Part Name & Description Pcs/Set Remarks F603L6G00AP D.P.CIRCUIT (AU) P994 APH F603L6G00CP D.P.CIRCUIT (AU) P994 CPH F603L6G10AP D.P.CIRCUIT (AU) T994SF APH, T984SF APH F603L6Q00AP D.P.CIRCUIT (AU) T964SF APH F800L4M60BCP CONTROL PANEL (AU)
- Page 14 Page 2 of 2 F891P6G00BAP DOOR OPENING BUTTON P994BF APH/CPH F891P6G00HAP DOOR OPENING BUTTON P994WF APH/CPH F80724M60SCP DOOR OPENING BUTTON T9*4SF APH F80375K00AP COOK BUTTON SPRING P994 APH/CPH, T9*4SF APH TOP PREVIOUS NEXT 1/5/2009...
- Page 15 Page 1 of 1 1/5/2009...
-
Page 16: Wiring Materials
Page 1 of 1 4.4 WIRING MATERIALS TOP PREVIOUS NEXT Ref. No. Part No. Part Name & Description Pcs/Set Remarks F030A6G30AP LEAD WIRE HARNESS F030A6G30CP LEAD WIRE HARNESS F030E6G30AP H.V.LEAD WIRE F030E6G30CP H.V.LEAD WIRE TOP PREVIOUS NEXT 1/5/2009... - Page 17 Page 1 of 1 1/5/2009...
-
Page 18: Packing And Accessories
Page 1 of 2 4.5 PACKING AND ACCESSORIES TOP PREVIOUS NEXT Ref. No. Part No. Part Name & Description Pcs/Set Remarks F00036J00AP INSTRUCTION MANUAL P994SF/BF/WF APH, T9*4SF APH, H964BF/WF APH F00036J00CP INSTRUCTION MANUAL P994SF/BF/WF CPH, H964BF/WF CPH F00036J30AP INSTRUCTION MANUAL S954BF/WF APH F00036J50AP INSTRUCTION MANUAL... - Page 19 Page 2 of 2 F01026H50BAP PACKING CASE, PAPER S914BF APH F01026H50HAP PACKING CASE, PAPER S914WF APH F01026H10BAP PACKING CASE, PAPER S934BF APH F01026H10HAP PACKING CASE, PAPER S934WF APH F01026Q20BAP PACKING CASE, PAPER S924BFW APH F01026Q20HAP PACKING CASE, PAPER S924WFW APH F01044W00AP UPPER FILLER P994 APH/CPH, T9*4SF APH...
- Page 20 Page 1 of 1 1/5/2009...
-
Page 21: Door Assembly
Page 1 of 1 4.6 DOOR ASSEMBLY TOP PREVIOUS NEXT Ref. No. Part No. Part Name & Description Pcs/Set Remarks F3018-1200 DOOR KEY A F302A6G00SAP DOOR A (U) P994SF APH/CPH F302A6G00BAP DOOR A (U) P994BF APH/CPH F302A6G00HAP DOOR A (U) P994WF APH/CPH F302A5W00SAP DOOR A (U) T9*4SF APH... - Page 22 Page 1 of 3 5.6 PARTS LIST TOP PREVIOUS Ref. No. Part No. Part Name & Description Pcs/Set Remarks BZ310 AEFBAT2001 BUZZER 2.0KHz C221 AECUU06F103Z CHIP CAPACITOR 0.01µF/50V C222, C486 AECUU06F103Z CHIP CAPACITOR 0.01µF/50V (P994 APH/CPH, T994/T984SF APH) C484 AECUU06F103Z CHIP CAPACITOR 0.01µF/50V (P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH)
- Page 23 Page 2 of 3 AERZ271KD10A VARSITOR D26, D27 AERZ102KD10A VARSITOR D180-D183 AESQPY1112H CHIP-LED D184-D189 AESQPY1112H CHIP-LED (P994 APH/CPH, T9*4SF APH, H964 APH/CPH, S954 APH) MN101C54CFS L.S.I. (P994 APH/CPH, T9*4SF APH, H964 APH/CPH, S954 APH) MN101C589ER L.S.I. (H944/H934/H924/H914 APH, S944/S934/S924/S914 APH) IC480 AEICUPC358G2 (P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH)
- Page 24 Page 3 of 3 R340 AERJ06J473R CHIP RESISTOR 47K, 1/10W, 5% R440 AERJ06J512R CHIP RESISTOR 5.1K, 1/10W, 5% R486 AERJ06J684R CHIP RESISTOR 680K, 1/10W, 5% (P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH) R10, R11, R311 AERDS2TJ102T CARBON RESISTOR 1K, 1/4W, 5% R12, R180 AERDS2TJ103T CARBON RESISTOR...
