AR-C260P
DIGITAL FULL COLOUR PRINTER
OPERATION MANUAL
(for general information)
• BEFORE USING

THE PRODUCT

• MANAGING THE MACHINE
• OPERATION CONDITION
SETTINGS
• PRINTING FROM THE
OPERATION PANEL
• PERIPHERAL DEVICES
• SPECIFICATIONS
Be sure to become thoroughly familiar with this manual to
gain the maximum benefit from the product.
Before installing this product, be sure to read the
installation requirements and cautions sections.
Be sure to keep all operation manuals handy for reference
including this manual, and operation manuals for any
optional equipment which has been installed.
MODEL
Page
1-1
2-1
3-1
4-1
5-1
6-1
