AUDIO/VIDEO CONTROL RECEIVER
RX-7032VSL
RX-7032V
SURROUND
STANDBY
STANDBY/ON
DSP
SPEAKERS ON/OFF
SURROUND/ DSP
OFF
1
2
DVD MULTI
DVD
VCR
SUBWOOFER OUT ON/OFF
PHONES
AUDIO/VIDEO CONTROL RECEIVER
MASTER VOLUME
TV SOUND/DBS
CD
TAPE/CDR
FM
AM
SETTING
ADJUST
QUICK SPEAKER
SETUP
EXIT
PUSH OPEN
INSTRUCTIONS
RM-SRX7032R
REMOTE CONTROL
CATV/DBS
VCR
TV
AUDIO
DVD MULTI
DVD
CD
FM/AM
TV/DBS
VCR
TAPE/CDR
ANALOG/DIGITAL
INPUT
SURROUND
DSP
SURR/DSP
ANALOG
OFF
DIRECT
EX/ES
BASS BOOST
FRONT•L
FRONT•R
1
2
3
MENU
CD DISC
TEST
CENTER
SUB WOOFER
4
5
6
ENTER
MIDNIGHT
SURR•L
SURR•R
7/P
8
9
MODE
SOUND
DIGITAL EQ
SURR BACK
BASS BOOST
0
10/0
+10
RETURN
FM MODE
100+
CA TV/DBS
CONTROL
+
+
+
ANALOG DIRECT
CH/
LEVEL TV VOL
VOLUME
TV/VIDEO
VCR
T APE/CDR
TA/NEWS/INFO
CONTROL
CONTROL
MUTING
/REW
FF/
REC PAUSE
SLEEP
DISPLAY
DIMMER
MODE
A/V CONTROL RECEIVER
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1007-006A[B]

Advertisement

Table of Contents
loading

Summary of Contents for JVC rx-7032vsl

  • Page 1 AUDIO/VIDEO CONTROL RECEIVER RX-7032VSL RM-SRX7032R REMOTE CONTROL CATV/DBS AUDIO RX-7032V AUDIO/VIDEO CONTROL RECEIVER DVD MULTI FM/AM MASTER VOLUME TV/DBS TAPE/CDR ANALOG/DIGITAL INPUT SURROUND STANDBY SURROUND SURR/DSP ANALOG DIRECT ∗ ∗ STANDBY/ON EX/ES BASS BOOST FRONT•L FRONT•R MENU ∗ ∗ CD DISC...
  • Page 2 Warnings, Cautions and Others IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.
  • Page 3: Safety Instructions

    No obstructions in 15 cm from the back Bottom: No obstructions, place on the level surface. In addition, maintain the best possible air circulation as illustrated. Spacing 15 cm or more RX-7032VSL Front Wall or obstructions Stand height 15 cm or more Floor...
  • Page 4 Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference.
  • Page 5: Table Of Contents

    Using Preset Tuning ..............20 COMPU LINK Remote Control System ..39 Selecting the FM Reception Mode ........... 21 Operating JVC’s Audio/Video Components ... 40 Receiving FM Stations with RDS ..........21 Searching for a Program by PTY Codes ........22 Operating Audio Components ..........
  • Page 6: Parts Identification

    Parts Identification buttons (14, 42 – 46) CATV/DBS , VCR , TV , AUDIO Remote Control 2 Source selection buttons (14, 15, 16, 18, 20, 21, 35, 37, 38) DVD MULTI, DVD, CD*, FM/AM*, TV/DBS, VCR, TAPE/CDR* * When you press one on these source selection buttons on the remote control, the receiver automatically turns on.
  • Page 7: Front Panel

    Front Panel RX-7032V AUDIO/VIDEO CONTROL RECEIVER MASTER VOLUME SURROUND STANDBY STANDBY/ON SPEAKERS ON/OFF SURROUND/ DSP BASS BOOST DVD MULTI TV SOUND/DBS TAPE/CDR SUBWOOFER OUT ON/OFF ANALOG DIRECT SETTING ADJUST MULTI JOG QUICK SPEAKER SETUP EXIT PUSH – OPEN PUSH SET PHONES MIDNIGHT EX / ES...
  • Page 8 Display Window DUAL ANALOG DIGITAL AUTO 96/24 MULTI NEWS INFO TUNED STEREO AUTO MUTING ONE TOUCH OPERATION SLEEP LINEAR PCM NEO:6 VIRTUAL SB MIDNIGHT MODE PRO LOGIC DIGITAL EQ SUBWFR DIGITAL 3D - PHONIC HEADPHONE SPEAKERS 1 2 BASS BOOST INPUT ATT VOLUME ¡...
  • Page 9: Rear Panel

    Rear Panel VIDEO AUDIO DIGITAL IN SUBWOOFER COMPU LINK-4 VIDEO S-VIDEO SUBWOOFER CENTER RIGHT LEFT (SYNCHRO) ANTENNA FRONT SURR TV SOUND DIGITAL 1 (DVD) (REAR) RIGHT LEFT LOOP (REC) DIGITAL 2 (CD) CAUTION : SPEAKER IMPEDANCE (PLAY) DIGITAL 3 (TV) FM 75 CAUTION : SPEAKER IMPEDANCE COAXIAL...
  • Page 10: Getting Started

    Getting Started This section explains how to connect audio/video components and speakers to the receiver, and how to connect the power supply. If the remote control cannot transmit signals or operate the receiver Before Installation correctly, replace the batteries. Use two LR6(AM3)/L40(15A) type dry-cell batteries.
  • Page 11: Connecting The Speakers

    AM (MW) Antenna Connections Basic connecting procedure 1 Twist and remove the insulation at Turn the loop until you have the the end of each speaker signal cable best reception. (not supplied). 2 Open the speaker terminal. ANTENNA AM (MW) Loop LOOP Antenna (supplied) Snap the tabs on the loop into the slots...
  • Page 12 Front speakers 1 Front speakers 2 Center speaker Right Left Right Left Surround back speakers* Right / Left CAUTION : SPEAKER IMPEDANCE CAUTION : SPEAKER IMPEDANCE SINGLE USE See Instruction Manual For – – Connection – – RIGHT LEFT LEFT LEFT LEFT RIGHT...
  • Page 13: Connecting Audio/Video Components

    Connecting Audio/Video Components Cassette deck To listen to the sound after connection, press TAPE/CDR. When connecting individual components, refer also to the manuals supplied with them. You can connect either a cassette deck or a CD recorder to the TAPE/CDR jacks. When connecting an CD recorder to the TAPE/ Analog Connections CDR jacks, see below.
  • Page 14 Video component connections TV and/or DBS tuner To listen to the sound after connection, press TV SOUND/DBS (or Use the cables with RCA pin plugs (not supplied). TV/DBS on the remote control). Connect the white plug to the audio left jack, the red plug to the audio right jack, and the yellow plug to the video jack.
  • Page 15 DVD player • When you connect a DVD player with its analog discrete • When you connect a DVD player with stereo output jacks: output (5.1-channel reproduction) jacks: To listen to the sound after connection, press DVD. To listen to the sound after connection, press DVD MULTI. AUDIO VIDEO VIDEO...
  • Page 16: Digital Connections

    Digital Connections Digital output terminal This receiver is equipped with four DIGITAL IN terminals—one You can connect any digital components which have an optical digital coaxial terminal and three digital optical terminals—and one digital input terminal. DIGITAL OUT (optical) terminal on the rear. Digital optical cable (not supplied) IMPORTANT: between digital optical terminals...
  • Page 17: Basic Operations

    Basic Operations The following operations are commonly used when you play any sound sources. Operations hereafter will be explained using the buttons on the front panel. You can also use the buttons on the remote control for the same functions if they have the same and similar names/marks. Selecting the Source to Play Daily Operational Procedure RX-7032V...
  • Page 18: Adjusting The Volume

    Speaker and signal indicators on the display Selecting different sources for picture and sound By checking the following indicators, you can easily confirm which speakers you are activating and which signals are coming into this While watching pictures from a video source, you can listen to receiver.
  • Page 19: Selecting The Front Speakers

    Remote Selecting the Front Speakers Activating and Adjusting the Remote Subwoofer Sound When you have connected two pairs of the front speakers, you can select which to use. You can cancel the subwoofer sound even though you have connected a subwoofer and have set “SUB WOOFER” to “YES” RX-7032V AUDIO/VIDEO CONTROL RECEIVER (see page 29).
  • Page 20: Setting The Dynamic Range

    2. Press INPUT DIGITAL (or ANALOG/DIGITAL Setting the Dynamic Range INPUT on the remote control) to select “DGTL AUTO.” You can enjoy a powerful sound at night using the Midnight Mode. The DIGITAL AUTO indicator lights up on the display. RX-7032V AUDIO/VIDEO CONTROL RECEIVER DIGITAL AUTO...
  • Page 21: Turning Analog Direct On And Off

    Turning Analog Direct On and Off Changing the Source Name Remote You can enjoy the sound closer to the original source by overriding When you have connected an CD recorder to the TAPE/CDR IN the sound adjustments such as speaker output level adjustments (see jacks or a DBS tuner to the TV SOUND/DBS IN jacks on the rear page 30), Digital Equalization (see page 30), Surround and DSP panel, change the source name which will be shown on the display.
  • Page 22: Reinforcing The Bass

    Using the Sleep Timer The following basic operations are possible only using the remote control. Using the Sleep Timer, you can fall asleep while listening to music. When the shut-off time comes, the receiver turns off automatically. BASS BOOST Reinforcing the Press SLEEP repeatedly.
  • Page 23: Receiving Radio Broadcasts

    Receiving Radio Broadcasts You can browse through all the stations or use the preset function to go immediately to a particular station. Tuning in to Stations Manually Remote Using Preset Tuning RX-7032V AUDIO/VIDEO CONTROL RECEIVER RX-7032V AUDIO/VIDEO CONTROL RECEIVER 1. Press FM or AM to select the band. Once a station is assigned to a channel number, the station can be The last received station of the selected band is tuned in.
  • Page 24: Selecting The Fm Reception Mode

    To tune in to a preset station Selecting the FM Reception Mode On the front panel: RX-7032V AUDIO/VIDEO CONTROL RECEIVER RX-7032V AUDIO/VIDEO CONTROL RECEIVER When an FM stereo broadcast is hard to receive or noisy, you can 1. Press FM or AM to select the band. change the FM reception mode while receiving an FM broadcast.
  • Page 25: Searching For A Program By Pty Codes

    Notes: Searching for a Program by PTY • RDS is not available for AM (MW) broadcasts. Codes • Not all FM stations provide RDS signals, nor do all RDS stations provide the same services. If in doubt, check with local radio One of the advantages of the RDS service is that you can locate a stations for details on RDS in your area.
  • Page 26: Switching To A Program Of Your Choice Automatically

    Switching to a Program of Your When the current source is other than “FM” Choice Automatically If a station starts broadcasting the program you CASE 3 have selected while listening to current source is Another convenient RDS service is called “Enhanced Other other than “FM”...
  • Page 27: Basic Settings

    Basic Settings Some of the following settings are required after connecting and positioning your speakers while others will make operations easier. You can use QUICK SPEAKER SETUP to easily set up your speaker configuration. 3. Press in MULTI JOG (PUSH SET). Setting the Speakers Configuration Remote “ROOM SIZE?”...
  • Page 28: Basic Setting Items

    Speakers (channels) number and size Basic Setting Items You can find how each of the speaker size is defined according to the number of connected speakers (speaker channel (CH) number) On the following pages, you can adjust the following items: you select.
  • Page 29: Basic Procedure

    Basic Procedure : shows the initial setting in the following tables. RX-7032V AUDIO/VIDEO CONTROL RECEIVER Setting the Speakers To obtain the best possible surround effect from the Surround and DSP modes, register the setting about the speaker arrangement after all connections are completed. •...
  • Page 30: Setting The Speaker Distance

    Setting the Speaker Distance Setting the Bass Sounds The distance from your listening point to the speakers is another You can adjust subwoofer and bass sounds precisely according to important element to obtain the best possible sound of the Surround your preference.
  • Page 31: Selecting Main Or Sub Channel-Dual Mono

    7 Low frequency effect attenuator—LFE ATTENUATE Setting the Digital Input Terminals If the bass sound is distorted while playing back software When you use the digital input terminals, register which components encoded with Dolby Digital or DTS, set the LFE level to you have connected to the digital input terminals.
  • Page 32: Adjusting Sound

    Adjusting Sound You can make sound adjustment to your preference after completing basic setting. Basic Setting Items Basic Procedure On the following pages, you can adjust the items listed below: RX-7032V AUDIO/VIDEO CONTROL RECEIVER • You can adjust only the items applicable to the current sound mode.
  • Page 33: Adjusting The Equalization Patterns

    Adjusting the Equalization Patterns Adjusting the Speaker Output Levels You can adjust the equalization patterns to your preference. You can adjust the speaker output levels. The test tone comes out of • Once you have made adjustment, it is memorized for each source. each speaker except subwoofer to check the output level balance when using the Surround mode.
  • Page 34: Adjusting The Sound Parameters For The Surround And Dsp Modes

    Adjusting the Sound Parameters for the You can also use the remote control for adjusting the speaker Surround and DSP Modes output level. You can adjust the Surround and DSP sound parameters to your When using the remote control, you can make an adjustment preference.
  • Page 35: Using The Surround Modes

    Using the Surround Modes This unit activates a variety of Surround modes automatically. The basic settings and adjustments stored (see pages 24 to 31) are applied. Reproducing Theater Ambience Introducing the Surround Modes In a movie theater, many speakers are located on the walls to Dolby Digital* reproduce impressive multi-surround sounds, reaching you from all Dolby Digital is a digital signal compression method, developed...
  • Page 36 6.1-channel signal discretely to avoid interference with each • If the surround speakers and center speaker are deactivated, channel. JVC’s original 3D-PHONIC processing (which has been DTS-ES Matrix 6.1ch has been designed to add an extra surround developed to create the surround effect through the front speakers channel to DTS Digital Surround 5.1-channel.
  • Page 37: Surround Modes Applicable To The Various Software

    Surround Modes Applicable to the Various Software Available Surround modes vary depending on the speaker settings and the incoming signals. The table below shows the relation of the Surround modes and the incoming signals (with the surround back speakers and EX/ES setting). •...
  • Page 38: Activating The Surround Modes

    Activating the Surround Modes Activating the Surround Modes Available Surround modes vary depending on the speaker settings RX-7032V AUDIO/VIDEO CONTROL RECEIVER and the incoming signals. (See page 34.) Activating one of the Surround modes for a source automatically recalls the memorized settings and adjustments (see pages 24 to 31.) You can also use the buttons on the remote control for the same 1.
  • Page 39: Using The Dsp Modes

    • If surround speakers are set to “NONE” in the speaker setting, “3D H PHONE” appears on the display and the DSP and JVC’s original 3D-PHONIC processing (which has been HEADPHONE indicators also light up. developed to create the surround effect through the front speakers only) is used.
  • Page 40: Activating The Dsp Modes

    ALL Channel Stereo mode Activating the DSP Modes This mode can reproduce a larger stereo sound field using all the connected (and activated) speakers. This mode cannot be used Activating one of the DSP modes for a source automatically without activating the surround speakers. recalls the memorized settings and adjustments (see pages 24 to •...
  • Page 41: Using The Dvd Multi Playback Mode

    Using the DVD MULTI Playback Mode This receiver provides the DVD MULTI playback mode for reproducing the analog discrete output mode of the DVD player. Activating the DVD MULTI Playback Mode Connection diagram RX-7032V AUDIO/VIDEO CONTROL RECEIVER 1. Press DVD MULTI so that “DVD MULTI” VIDEO appears on the display.
  • Page 42: Compu Link Remote Control System

    COMPU LINK Remote Control System The COMPU LINK remote control system allows you to operate JVC’s audio components through the remote sensor on the receiver. Automatic Source Selection To use this remote control system, you need to connect JVC’s audio...
  • Page 43: Operating Jvc's Audio/Video Components

    Operating JVC’s Audio/Video Components You can operate JVC’s audio and video components with this receiver’s remote control, since control signals for JVC’s components are preset in the remote control. Sound control section (Amplifier) Operating Audio Components You can always perform the following operations:...
  • Page 44 CD player CD recorder After pressing CD, you can perform the following operations on a After pressing TAPE/CDR (or TAPE/CDR CONTROL), you can CD player: perform the following operations on a CD recorder: Start playing. Start playing. Return to the beginning of the current (or previous) Return to the beginning of the current (or previous) track.
  • Page 45: Operating Video Components

    Start playing. control: Return to the beginning of the current (or previous) chapter. • Some JVC’s VCRs can accept two types of the control signals— ¢: Skip to the beginning of the next chapter. remote code “A” and “B.” Before using this remote control, make Stop playing.
  • Page 46: Operating Other Manufacturers' Video Equipment

    Operating Other Manufacturers’ Video Equipment This remote control supplied with the receiver can transmit control signals for other manufacturers’ TVs, CATV converters, DBS tuners, VCRs and DVD players. When operating the other manufacturers’ components, refer also to For TV the manuals supplied with them. Manufacturer Codes Manufacturer...
  • Page 47 To change the transmittable signals for For DBS tuner operating a CATV converter or DBS tuner Manufacturer Codes 1. Press and hold CATV/DBS , 57, 67 Amstrad 43, 44, 45, 46, 47, 48, 49 2. Press CATV/DBS CONTROL. Blaupunkt 3. Enter a manufacturer’s code using buttons 1 – 9, Echostar 50, 51, 67 Goldstar...
  • Page 48 To change the transmittable signals for For VCR operating another manufacturer’s VCR Manufacturer Codes 1. Press and hold VCR , 26, 27, 28, 29, 58 2. Press VCR. Aiwa 01, 02 Bell & Howell 3. Enter manufacturer’s code using buttons 1–9, Blaupunkt 04, 05 and 0.
  • Page 49 To change the transmittable signals for For DVD player operating another manufacturer’s DVD player Manufacturer Codes 1. Press and hold AUDIO 00*, 02 2. Press DVD. Denon Panasonic 3. Enter a manufacturer’s code using buttons 1–9, Philips and 0. Pioneer 04, 05, 06 See the list on the right column to find the code.
  • Page 50: Troubleshooting

    Troubleshooting Use this chart to help you solve daily operational problems. If there is any problem you cannot solve, contact your JVC’s service center. PROBLEM POSSIBLE CAUSE SOLUTION The display does not light up. The power cord is not plugged in.
  • Page 51: Specifications

    Specifications Designs & specifications are subject to change without notice Frequency Response (8 Ω) Amplifier DVD IN, VCR IN, TV SOUND/DBS IN: Output Power 20 Hz to 100 kHz (+1 dB, –3 dB) At Stereo operation CD IN, TAPE/CDR IN: 20 Hz to 100 kHz (+1 dB, –3 dB) 100 W per channel, min.
  • Page 52 VICTOR COMPANY OF JAPAN, LIMITED © 2003 VICTOR COMPANY OF JAPAN, LIMITED 0303NHMMDWJEIN...
