GAS COOKTOP INSTALLATION INSTRUCTIONS
INSTALLATION AND SERVICE MUST BE PERFORMED BY
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
For Standard
Installation:
Gas Cooktop Dimensions
Gas Cooktop Cutout
Dimensions
3"(7.6 cm)
2"(5.1 cm) Dia.
Opening to route
power cable
F
Do not slide unit into cabinet cutout.
Protruding screws on the bottom of unit
may damage the bottom front finish.
MODEL
A. LENGTH
36 (91.4 )
35
7
/
(91.1)
8
All dimensions are in inches (cm).
All dimensions are in inches (cm).
NOTE: Wiring diagrams for this cooktop are enclosed in this booklet
(For 36" Models with 6 Sealed Burners)
A QUALIFIED INSTALLER.
A
2
1
/
"
2
(6.4 cm)
2"(5.1 cm)
1" (2.5 cm)
G
Figure 1
B. WIDTH
C. DEPTH
25¾ (65.4)
7¾ (19.7)
35
30"(76.2 cm)
Min.*
B
C
4"X 4" (10.2 cm x 10.2 cm)
opening to route gas
supply.
H***
E
D
"
35
/
1
8
(89.2 cm)
**Note: D & E are critical to the proper
installation of the cooktop. Please make
sure to respect those dimensions. D reflects
a finished dimension it is recommended to
undercut this dimension and adjust upon
installation of the appliance due to the
variation in countertop materials.
CUTOUT DIMENSIONS
LENGTH
D**
E**
15
/
(91.3)
35
3
/
(89.4)
22 (55.9) 1
16
16
1
* 30" (76.2 cm) min. for
unprotected cabinet
24" (61 cm) min. for protected
surface
"
7
/
1
4
(18.4 cm)
H. DEPTH BELOW
WIDTH
COOKTOP***
F
G
1
/
(2.9) Max.
7
1
/
8
2
318201455 (0403) Rev. D
English - pages 1-8
Español - páginas 9-16
Français - pages 17-23
Wiring Diagram page - 24
(19.1)

Advertisement

Table of Contents
loading

Summary of Contents for Electrolux 36"

  • Page 1 GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER. IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE. READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death.
  • Page 2 GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) * 30" (76.2 cm) min. for unprotected cabinet For Installation with the optional Stainless Steel Backsplash. 24" (61 cm) min. for protected surface 30"(76.2 cm) Min.* 2"(5.1 cm) 9"(22.9cm) Optional Stainless Steel Backsplash...
  • Page 3: Important Notes To The Installer

    GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) Important Notes to the Installer This cooktop has been design certified by International Approval Services (I.A.S). As with any appliance using 1. Read all instructions contained in these installation gas and generating heat, there are certain safety instructions before installing the cooktop.
  • Page 4 GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) 13" (33 cm) max. depth for cabinet installed above cooktop 30" (76.2 cm) Min. Clearance Between the Top of the Cooking 30" (76.2 cm) min. Platform and the Bottom 1"...
  • Page 5: Lp/Propane Gas Conversion

    GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) The conversion must be performed by a qualified service Wall Outlet Location technician in accordance with the kit instructions and all local codes and requirements. Failure to follow instructions could result in serious injury or property 4"...
  • Page 6: Grounding Instructions

    GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) The supply line should be equipped with an approved Grounding Instructions shutoff valve. This valve should be located in the same IMPORTANT Please read carefully. room as the cooktop and should be in a location that allows ease of opening and closing.
  • Page 7: Checking Operation

    GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) 2. Turn on Electrical Power and Open Main Shutoff Checking Operation Gas Valve Refer to the Use and Care Guide packaged with the cooktop for operating instructions and for care and 3.
  • Page 8: Model And Serial Number Location

    GAS COOKTOP INSTALLATION INSTRUCTIONS (For 36" Models with 6 Sealed Burners) Model and Serial Number Location The serial plate is located on the underside of the cooktop. When ordering parts for or making inquires about your range, always be sure to include the model and serial numbers and a lot number or letter from the serial plate of your cooktop.
