Epson BrightLink 475Wi / 480i / 485Wi
Replacing the Lamp
Before you replace the lamp, let the projector cool down for at least one hour so the lamp will not be hot.
Warning: Let the lamp fully cool before replacing it to avoid injury.
You can replace the lamp while the projector is mounted on the wall or ceiling.
1. Turn off the projector and unplug the power cord.
2. Allow the projector lamp to cool down for at least one hour.
Warning: If the lamp is broken, glass fragments may be loose inside the lamp chamber. Be careful
removing any broken glass to avoid injury. If the projector is mounted on the wall or ceiling, stand to
the side in case the lamp is broken.
3. Use the screwdriver included with the replacement lamp to loosen the screw securing the lamp
cover.
4. Slide off the lamp cover.
INSTALLATION HANDBOOK
Lamp and Status Information
1
Advertisement
Related Manuals for Epson BrightLink 475Wi
Summary of Contents for Epson BrightLink 475Wi
- Page 1 INSTALLATION HANDBOOK Epson BrightLink 475Wi / 480i / 485Wi Lamp and Status Information Replacing the Lamp Before you replace the lamp, let the projector cool down for at least one hour so the lamp will not be hot. Warning: Let the lamp fully cool before replacing it to avoid injury.
- Page 2 INSTALLATION HANDBOOK Epson BrightLink 475Wi / 480i / 485Wi Lamp and Status Information 5. Loosen the screws securing the lamp to the projector. The screws do not come all the way out. 6. Lift up the lamp handle and gently pull the lamp out of the projector.
- Page 3 INSTALLATION HANDBOOK Epson BrightLink 475Wi / 480i / 485Wi Lamp and Status Information 7. Gently insert the new lamp into the projector along the guide rail. If it does not fit easily, make sure it is facing the right way. Press the handle down.
- Page 4 INSTALLATION HANDBOOK Epson BrightLink 475Wi / 480i / 485Wi Lamp and Status Information 9. Replace the lamp cover and tighten the screw to secure it. Note: Be sure the lamp cover is securely installed or the lamp will not come on.
- Page 5 INSTALLATION HANDBOOK Epson BrightLink 475Wi / 480i / 485Wi Lamp and Status Information Resetting the Lamp Timer You must reset the lamp timer after replacing the projector's lamp to clear the lamp replacement message and to keep track of lamp usage correctly.
