Thank you for purchasing a Panasonic Hybrid IP-PBX.
Please read this manual carefully before using this product and save this manual for future use.
KX-TDA100/KX-TDA200: PMPR Software File Version 3.2000 or later
Hybrid IP-PBX

Installation Manual

KX-TDA100
KX-TDA200
Model
SD Logo is
a trademark.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TDA100

Summary of Contents for Panasonic KX-TDA100

  • Page 1: Installation Manual

    KX-TDA100 KX-TDA200 Model Thank you for purchasing a Panasonic Hybrid IP-PBX. Please read this manual carefully before using this product and save this manual for future use. SD Logo is KX-TDA100/KX-TDA200: PMPR Software File Version 3.2000 or later a trademark.

  • Page 2: System Components

    System Components System Components Table Category Model No. Description Shelves KX-TDA100 Basic Shelf KX-TDA200 Basic Shelf Main Processing Card Main Processing Card (MPR) MPR Option Card KX-TDA0105 Memory Expansion Card (MEC) KX-TDA0196 Remote Card (RMT) Trunk Cards KX-TDA0180 8-Port Analogue Trunk Card (LCOT8)
  • Page 3 System Components Table Category Model No. Description Extension Cards KX-TDA0143 4 Cell Station Interface Card (CSIF4) KX-TDA0144 8 Cell Station Interface Card (CSIF8) KX-TDA0170 8-Port Digital Hybrid Extension Card (DHLC8) KX-TDA0171 8-Port Digital Extension Card (DLC8) KX-TDA0172 16-Port Digital Extension Card (DLC16) KX-TDA0173 8-Port Single Line Telephone Extension Card (SLC8) KX-TDA0174...
  • Page 4 S/M-type Back-up Battery Cable KX-A229 L-type Back-up Battery Cable KX-A258 Blank Slot Cover KX-T30865 Doorphone Compatible Panasonic Proprietary Telephones The Hybrid IP-PBX supports the following telephones: • Digital proprietary telephones (e.g., KX-T7600 series) • Analogue proprietary telephones (e.g., KX-T7700 series) •...

  • Page 5: Important Notice

    Notice • Some optional service cards and features are not available for certain countries/areas. Consult your certified Panasonic dealer for detailed instructions. • In this manual, the suffix of each model number (e.g., KX-TDA100NE) is omitted unless necessary. Important Notice Prior to connection of this product, please verify that the intended operating environment is supported.

  • Page 6: Important Safety Instructions

    Important Safety Instructions SAFETY REQUIREMENTS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug the product from the wall outlet before cleaning.

  • Page 7: Save These Instructions

    SAVE THESE INSTRUCTIONS Installation Manual...
  • Page 8 Contact your telephone company. If all SLTs operate properly, there may be a problem with your Hybrid IP-PBX. Do not reconnect the Hybrid IP-PBX to the trunks until it has been serviced by an authorised Panasonic Factory Service Centre.
  • Page 9 For users in Germany only • Machine Noise Information Ordinance, 3rd GPSGV: The highest sound pressure level is 70 dB (A) or less according to EN ISO 7779. For users in Finland, Norway and Sweden only • This unit may only be installed in a room or space with restricted access, and equipotential bonding must be applied.
  • Page 10 UNPLUG THIS UNIT FROM THE AC OUTLET IF IT EMITS SMOKE, AN ABNORMAL SMELL OR MAKES UNUSUAL NOISE. THESE CONDITIONS CAN CAUSE FIRE OR ELECTRIC SHOCK. CONFIRM THAT SMOKE HAS STOPPED AND CONTACT AN AUTHORISED PANASONIC FACTORY SERVICE CENTRE. • WHEN RELOCATING THE EQUIPMENT, FIRST DISCONNECT THE TELECOM CONNECTION BEFORE DISCONNECTING THE POWER CONNECTION.
  • Page 11 For Future Reference Please print, record, and retain the following information for future reference. Note The serial number of this product can be found on the label affixed to the unit. You should record the model number and the serial number of this unit as a permanent record of your purchase to aid in identification in the event of theft.
  • Page 12 Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. Declarations of Conformity for the relevant Panasonic products described in this manual are available for download by visiting: http://www.doc.panasonic.de...
  • Page 13 Introduction This Installation Manual is designed to serve as an overall technical reference for the Panasonic Hybrid IP- PBX, KX-TDA100/KX-TDA200. It provides instructions for installing the hardware, and programming the Hybrid IP-PBX using the KX-TDA Maintenance Console. The Structure of this Manual...
  • Page 14 A replacement fuse cover can be purchased from your local Panasonic dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE AC OUTLET IN YOUR PREMISES, THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
  • Page 15 How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse and fuse cover. The equipment must be connected to direct extension lines, and a payphone should not be connected as an extension. 999 and 112 can be dialled on the apparatus after accessing the Exchange line for the purpose of making outgoing calls to the BT emergency services.

  • Page 16: Table Of Contents

    2.2.9 Attaching a Ferrite Core ....................60 2.2.10 Fastening Amphenol Connector..................63 2.2.11 Wall Mounting (KX-TDA200) ..................... 65 2.2.12 Wall Mounting (KX-TDA100) ..................... 67 2.2.13 Floor Standing (KX-TDA200 Only)..................69 2.2.14 Surge Protector Installation....................71 Information about the Main Processing Card...............74 2.3.1 MPR Card .........................74...
  • Page 17 2.4.11 IP-GW4 Card (KX-TDA0480) ..................104 2.4.12 IP-GW4E Card (KX-TDA0484) ..................106 2.4.13 IP-GW16 Card (KX-TDA0490) ..................108 Information about the Extension Cards ..............110 2.5.1 CSIF4 Card (KX-TDA0143) and CSIF8 Card (KX-TDA0144)......... 110 2.5.2 DHLC8 Card (KX-TDA0170) ..................112 2.5.3 DLC8 Card (KX-TDA0171) .....................
  • Page 18 2.13 Starting the Hybrid IP-PBX................... 212 2.13.1 Starting the Hybrid IP-PBX ..................... 212 Guide for the KX-TDA Maintenance Console ........215 Overview ........................216 3.1.1 Overview .........................216 Connection ........................217 3.2.1 Connection ........................217 Installation of the KX-TDA Maintenance Console ............219 3.3.1 Installing and Starting the KX-TDA Maintenance Console..........219 Troubleshooting..................

  • Page 19: System Outline

    Section 1 System Outline This section provides general information on the Hybrid IP- PBX, including the system capacity and specifications. Installation Manual...

  • Page 20: System Highlights

    1.1 System Highlights System Highlights 1.1.1 System Highlights Networking Features This Hybrid IP-PBX supports the following networking features: TIE Line Service A TIE line is a privately leased communication line between 2 or more PBXs, which provides cost effective communications between company members at different locations. Virtual Private Network (VPN) VPN is a service provided by the telephone company.

  • Page 21: Hospitality Features

    PS is the sub telephone. PC Phone/PC Console Features This Hybrid IP-PBX supports PC Phone and PC Console. These Panasonic CTI applications provide advanced features combining telephone and PC, such as the ability to display detailed caller information, including a photograph, on the screen of the PC when a call is received, or to dial a telephone number automatically just by selecting a name.

  • Page 22: Basic System Construction

    The basic shelf contains an MPR card for controlling the Hybrid IP-PBX. To use the system, install a power supply unit (PSU) in the PSU Slot and optional service cards in the basic shelf. KX-TDA100 KX-TDA200 Construction of the Basic Shelf...

  • Page 23: System Connection Diagram

    1.2 Basic System Construction 1.2.2 System Connection Diagram Private IP Network Trunk (Telephone Company Lines) Analogue/BRI/PRI/T1/E1 Remote PC Router Hybrid IP-PBX Batteries IP-PT IP Softphone CTI Server Fax Machine Printer Wireless Phone External Sensor/ External Relay Device DSS Console ISDN Telephone Doorphone &...
  • Page 24 1.2 Basic System Construction Hybrid IP-PBX KX-T7636/ KX-T7600 KX-T7600 KX-T7633 DLC16 LCOT4 LCOT4 (KX-TDA0172) (KX-TDA0183) (KX-TDA0183) DLC8 LCOT16 (KX-TDA0171) Voice LCOT16 (KX-TDA0181) Processing (KX-TDA0181) System PT-interface CS LCOT8 DSS Console LCOT8 (KX-TDA0180) (KX-TDA0180) CID/PAY8 (KX-TDA0189) CID8 KX-T7636/ (KX-TDA0193) Fax Machine DHLC8 DSS Console KX-T7633...

  • Page 25: Optional Equipment

    Power Supply Unit for KX-TDA200. Total power output of 279 W. Safety Class 1 compliant. KX-TDA0104 M-Type Power Supply Unit (PSU-M) Power Supply Unit for KX-TDA100 and KX-TDA200. Total power output of 140.4 W. Safety Class 1 compliant. KX-TDA0105 Memory Expansion Card (MEC)
  • Page 26 1.3 Optional Equipment Model No. Model Name Description KX-TDA0175 16-Port Single Line Telephone 16-port extension card for SLTs with Message Extension with Message Lamp Card Waiting Lamp control and 4 power failure transfer (MSLC16) (PFT) ports. Maximum power output of 160 V/90 V for Message Waiting Lamp control.
  • Page 27 Model Name Description KX-TDA0470 16-Channel VoIP Extension Card (IP- 16-channel VoIP extension card. Compliant with EXT16) Panasonic proprietary protocol, and ITU-T G.729a and G.711 CODEC methods. KX-TDA0480 4-Channel VoIP Gateway Card (IP- 4-channel VoIP gateway card. Compliant with VoIP GW4) H.323 V.2 protocol, and ITU-T G.729a and G.723.1...

  • Page 28: Specifications

    1.4 Specifications Specifications 1.4.1 General Description Control Bus Original bus (16-bit, 8 MHz, 10 megabytes per second) Communication Bus H.100 bus conformity (1024 time slots) Switching Non-blocking Power Input PSU-S 100 V AC to 130 V AC, 1.4 A/200 V AC to 240 V AC, 0.8 A, 50 Hz/60 Hz PSU-M 100 V AC to 130 V AC, 2.5 A/200 V AC to 240 V AC, 1.4 A,...
  • Page 29 1-pair wire (D1, D2) DSS Console and Add-on 1-pair wire (D1, D2) Key Module Dimension KX-TDA100 334 mm (W) × 390 mm (H) × 270 mm (D) KX-TDA200 430 mm (W) × 415 mm (H) × 270 mm (D) Weight (when fully...

  • Page 30: Characteristics

    1.4 Specifications 1.4.2 Characteristics PT: KX-T7600 series DPT: 90 Ω; all other DPTs/APTs: 40 Ω Terminal Equipment Loop Limit • SLT: 600 Ω including set • Doorphone: 20 Ω • CS: 130 Ω; PT-interface CS: 65 Ω • 15 000 Ω minimum Minimum Leakage Resistance Maximum Number of Extension 1 for PT or SLT...

  • Page 31: System Capacity

    Any card that exceeds the capacity of the Hybrid IP-PBX will be ignored. • When the Hybrid IP-PBX starts up with an invalid configuration, some cards will be ignored. Cards Installed in the Slots of the Hybrid IP-PBX KX-TDA100 KX-TDA200 Free Slots 1 to 6 (from the left) MPR Card Slot...
  • Page 32 1.4 Specifications The following number of optional service cards can be installed in the various slots of the Hybrid IP-PBX. Maximum Number Card Type Installed in KX-TDA100 KX-TDA200 MPR Card Slot Trunk Card Total 6 Total 8 LCOT4 LCOT8 LCOT16 DID8 E&M8...
  • Page 33 1.4 Specifications Maximum Number Card Type Installed in KX-TDA100 KX-TDA200 Extension Card Total 6 Total 8 DHLC8 DLC8 DLC16 SLC8 SLC16 Free Slots CSLC16 MSLC16 IP-EXT16 CSIF4 CSIF8 OPB3 CTI-LINK When installing T1, E1, PRI30, PRI23, or IP-GW4 cards, make sure that the number of these cards × 2 + the number of other cards (including IP-GW4E cards) does not exceed 8.
  • Page 34 Cards Mounted on Other Optional Service Cards The following number of optional service cards can be mounted on the specified other optional service cards. Maximum Number Card Type Mounted on KX-TDA100 KX-TDA200 MPR Card CID/PAY8 LCOT8 Card/LCOT16 Card CID8 EXT-CID...
  • Page 35 The following number of items of terminal equipment can be supported by the Hybrid IP-PBX. For how to count the total number of items of equipment to be connected, refer to "MEC Card Calculation". Terminal Equipment Type KX-TDA100 KX-TDA200 Without MEC...
  • Page 36 MEC Card Calculation Calculate the MEC figure from the type and total number of items of equipment to be connected. If the MEC figure exceeds 64 (for KX-TDA100) or 128 (for KX-TDA200), you need to install an MEC card. MEC Card Calculation...
  • Page 37 Only the extension cards that can support SLTs count for the load figures. PSU Capacity Each PSU supports a different load figure. PSU Type Maximum Load Figure PSU-S PSU-M PSU-L Available for the KX-TDA100 Available for the KX-TDA100 and KX-TDA200 Available for the KX-TDA200 Installation Manual...
  • Page 38 1.4 Specifications Calculation Example (KX-TDA200) Equipment Type Load Figure KX-T7600 series DPT 48 units Other DPT 2 units SLC16 1 card MSLC16 1 card 8 ports Total The total load figure is 96. As this is between 64 and 128, you should install the PSU-M. But if you expect expansion in the future, it may be better to install the PSU-L.

  • Page 39: Installation

    Section 2 Installation This section describes the procedures to install the Hybrid IP- PBX. Detailed instructions for planning the installation site, installing the shelves and optional service cards, and cabling of peripheral equipment are provided. Further information on system expansion and peripheral equipment installation is included.

  • Page 40: Before Installation

    Use caution when installing or modifying telephone lines. Installation Precautions This set is made for wall mounting (KX-TDA100/KX-TDA200) or floor standing (KX-TDA200 only), and should be installed in a location where it is accessible for inspections and maintenance. To prevent malfunction, noise, or discolouration, avoid installing the system in the following locations: In direct sunlight and hot, cold, or humid places.
  • Page 41 2.1 Before Installation Use 2-pair telephone cables when connecting PTs. Use 1-pair telephone cables when connecting SLTs, data terminals, answering machines, computers, Voice Processing Systems, etc. Unplug the system from its power source when wiring, and plug the system back in only after all wiring is completed.

  • Page 42: Installation Of The Hybrid Ip-Pbx

    2.2 Installation of the Hybrid IP-PBX Installation of the Hybrid IP-PBX 2.2.1 Unpacking Unpack the box and check the items below: KX-TDA100 KX-TDA200 Main Unit AC Cord with a Ferrite Core Metal Bracket Screw A Screw B (Black) Anchor Plug...

  • Page 43: Names And Locations

    2.2 Installation of the Hybrid IP-PBX 2.2.2 Names and Locations Inside View KX-TDA100 KX-TDA200 RUN Indicator ALARM Indicator USB Port RS-232C Port PSU Slot Null Slot (not available for any optional service card) Free Slots 1 to 6 (from the left)

  • Page 44: Opening/Closing The Front Cover

    2.2 Installation of the Hybrid IP-PBX 2.2.3 Opening/Closing the Front Cover Opening the Front Cover Insert a flathead screwdriver into the opening (on the left of the screw cover) and unlatch the screw cover. Screw Cover Turn the screw anticlockwise to loosen. Slide the front cover to the right until it stops, then lift the front cover.

  • Page 45: Closing The Front Cover

    2.2 Installation of the Hybrid IP-PBX Closing the Front Cover Hook the front cover onto the shelf (line up the protrusions on the cover with the receptacles on the shelf). Then slide the front cover to the left until it locks. Turn the screw clockwise to tighten.

  • Page 46: Installing/Replacing The Power Supply Unit

    Lower/Upper Input Voltage Range Current Input Frequency PSU-S Lower: 100 V AC to 130 V AC 1.4 A (for KX-TDA100) Upper: 200 V AC to 240 V AC 0.8 A PSU-M Lower: 100 V AC to 130 V AC 2.5 A...
  • Page 47 2.2 Installation of the Hybrid IP-PBX Never install or replace a PSU unless at least 20 s has elapsed after the AC supply and backup battery supply are disconnected. To protect the back board from static electricity, do not touch parts on the back board in the main unit and PSU.

  • Page 48: Replacing The Power Supply Unit

    2.2 Installation of the Hybrid IP-PBX Push the release lever in the direction of the arrow, so that the PSU engages securely with the connector on the back board. Back Board Release Lever Turn the 4 screws clockwise, in the order indicated by the numbers 1 to 4, to fix the PSU. Screws Replacing the Power Supply Unit Unplug the AC power cord and Back-up Battery Cable.
  • Page 49 2.2 Installation of the Hybrid IP-PBX Turn the 4 screws anticlockwise to loosen them. Screws Pull the release lever in the direction of the arrow to disconnect the PSU from the back board. Back Board Release Lever Replace the PSU. New PSU Current PSU Follow the steps in "Installing the Power Supply Unit".

  • Page 50: Frame Earth Connection

    2.2 Installation of the Hybrid IP-PBX 2.2.5 Frame Earth Connection IMPORTANT Connect the frame of the Hybrid IP-PBX to earth. Loosen the screw. Screw Insert an earthing wire (user- supplied)*. Tighten the screw. Connect the earthing wire to Earthing earth. wire To earth * For earthing wire, green-and-yellow insulation is required, and the cross-sectional area of the conductor...

  • Page 51: Backup Battery Connection

    2.2 Installation of the Hybrid IP-PBX 2.2.6 Backup Battery Connection The backup batteries and Back-up Battery Cable provide a backup power supply to allow full use of the Hybrid IP-PBX in the event of a power failure. In case of power failure, the backup batteries automatically maintain the power to the Hybrid IP-PBX without interruption.

  • Page 52: Connecting Backup Batteries

    2.2 Installation of the Hybrid IP-PBX Connecting Backup Batteries Turn off the battery switch on the PSU. Connect the Back-up Battery Cable to a set of 3 identical batteries. Battery Switch Battery Connector Back-up Battery Cable Fuse Black Backup Batteries (VRLA 12 V DC x 3) Installation Manual...

  • Page 53: Installing/Removing The Optional Service Cards

    2.2 Installation of the Hybrid IP-PBX 2.2.7 Installing/Removing the Optional Service Cards CAUTION To protect the back board from static electricity, do not touch parts on the back board in the main unit and on the optional service cards. To discharge static electricity, touch ground or wear an earthing strap. Note The optional service cards can be installed or removed while the DC power is supplied.
  • Page 54 2.2 Installation of the Hybrid IP-PBX Holding the card as shown below, push the release lever in the direction of the arrow so that the card engages securely with the connector on the back board. Back Board Release Lever Turn the 2 screws clockwise to fix the card in place. Screws Note Make sure the screws are tightened to earth the card securely.
  • Page 55 2.2 Installation of the Hybrid IP-PBX Covering the Blank Slots Be sure to cover each slot in which no optional service card is installed by using a Blank Slot Cover. CAUTION Failure to install the Blank Slot Cover may cause electromagnetic interference. Installation Manual...
  • Page 56 2.2 Installation of the Hybrid IP-PBX Handling of the Cables When cables are connected to the Hybrid IP-PBX, run the cables to either the right or the left and then towards the back of the shelf as shown below. Note For safety reasons, do not stretch, bend, or pinch the AC power cord.
  • Page 57 2.2 Installation of the Hybrid IP-PBX Removing the Optional Service Cards Turn the 2 screws anticlockwise to loosen them. Screws Pull the release lever in the direction of the arrow to disconnect the card from the back board. Pull the card from the shelf to remove it.

  • Page 58: Types Of Connectors

    2.2 Installation of the Hybrid IP-PBX 2.2.8 Types of Connectors Connector Type Pin Number Used for • DHLC8 (KX-TDA0170) RJ11 • SLC8 (KX-TDA0173) • SLC16 (KX-TDA0174) • MSLC16 (KX-TDA0175) • CSLC16 (KX-TDA0177) • LCOT8 (KX-TDA0180) • LCOT16 (KX-TDA0181) • LCOT4 (KX-TDA0183) (Twisted pair cable) •...
  • Page 59 2.2 Installation of the Hybrid IP-PBX Connector Type Pin Number Used for • DHLC8 (KX-TDA0170) Amphenol • DLC8 (KX-TDA0171) Type A Type B • DLC16 (KX-TDA0172) • SLC8 (KX-TDA0173) • SLC16 (KX-TDA0174) • MSLC16 (KX-TDA0175) • CSLC16 (KX-TDA0177) • LCOT8 (KX-TDA0180) (Shielded twisted pair cable) •...

  • Page 60: Attaching A Ferrite Core

    2.2 Installation of the Hybrid IP-PBX 2.2.9 Attaching a Ferrite Core A ferrite core must be attached when: • an RJ45 connector is connected to T1, E1, PRI, BRI, IP-GW16 or IP-EXT16 cards, or • an Amphenol connector is connected to an extension card. Note In Canada, the ferrite core is not necessarily required for the T1 and PRI23 cards.
  • Page 61 2.2 Installation of the Hybrid IP-PBX For a BRI Card Attach the ferrite core, then close the case of the ferrite core. Attach the ferrite core as close to the card's connector as possible. The ferrite core is included with the card. When only 1 or 2 cables are used for connection, wrap the cable(s) once around the ferrite core.
  • Page 62 2.2 Installation of the Hybrid IP-PBX Attaching to an Amphenol Connector For Extension Cards Pass the cable through the ferrite core, then close the case of the ferrite core. Attach the ferrite core 3 cm away from the connector. The ferrite core is included with the card. 3 cm If you need to open the ferrite core, use a flathead screwdriver to unlatch the case of the ferrite core.

  • Page 63: 2.2.10 Fastening Amphenol Connector

    2.2 Installation of the Hybrid IP-PBX 2.2.10 Fastening Amphenol Connector An Amphenol 57JE-type connector is used on some of the optional service cards. To connect an Amphenol connector, use the spring latch or screw to fix the upper part and use Velcro tape ®...
  • Page 64 2.2 Installation of the Hybrid IP-PBX Amphenol Connector Pin Assignment Chart Below is an Amphenol connector pin assignment chart for all optional service cards that use the Amphenol connector. For more details, refer to the appropriate section in "2.4 Information about the Trunk Cards" and "2.5 Information about the Extension Cards".

  • Page 65: Wall Mounting (Kx-Tda200)

    2.2 Installation of the Hybrid IP-PBX 2.2.11 Wall Mounting (KX-TDA200) CAUTION • Make sure that the wall the shelf will be attached to is capable of supporting at least 4 times the weight of the shelf. • Drive mounting screws into the wall. Be careful to avoid touching any metal laths, wire laths or metal plates in the wall.
  • Page 66 2.2 Installation of the Hybrid IP-PBX Hook the shelf onto the metal bracket, making sure that the shelf slides down and onto the hooked parts of the metal bracket. Use 2 screws (B) to fix both sides of the shelf. Screw (B) Installation Manual...

  • Page 67: Wall Mounting (Kx-Tda100)

    2.2 Installation of the Hybrid IP-PBX 2.2.12 Wall Mounting (KX-TDA100) CAUTION • Make sure that the wall the shelf will be attached to is capable of supporting at least 4 times the weight of the shelf. • Drive mounting screws into the wall. Be careful to avoid touching any metal laths, wire laths or metal plates in the wall.
  • Page 68 2.2 Installation of the Hybrid IP-PBX Hook the shelf onto the metal bracket, making sure that the shelf slides down and onto the hooked parts of the metal bracket. Use 2 screws (B) to fix both sides of the shelf. Screw (B) Installation Manual...

  • Page 69: Floor Standing (Kx-Tda200 Only)

    2.2 Installation of the Hybrid IP-PBX 2.2.13 Floor Standing (KX-TDA200 Only) Notes • Do not block the openings of the shelf. Allow space of at least 20 cm above and 10 cm at the sides of the shelf. • Make sure that the surface behind the shelf is flat and free of obstacles, so that the openings on the back of the shelf will not be blocked.
  • Page 70 2.2 Installation of the Hybrid IP-PBX Lift the shelf, attach it to the metal bracket, slide it backwards until it locks, and retain it with 2 screws (B). FRONT Screws (B) Metal Bracket Fix the front cover on the shelf (refer to "2.2.3 Opening/Closing the Front Cover"). Installation Manual...

  • Page 71: 2.2.14 Surge Protector Installation

    2.2 Installation of the Hybrid IP-PBX 2.2.14 Surge Protector Installation Overview A massive electrical surge can be caused if lightning strikes a telephone cable 10 m above ground, or if a telephone line comes into contact with a power line. A surge protector is a device that is connected to a trunk to prevent potentially dangerous electrical surges from entering the building via the trunk and damaging the Hybrid IP-PBX and connected equipment.
  • Page 72 2.2 Installation of the Hybrid IP-PBX Outside Installation (Main Building) Surge Protector Trunk (Another Building) Trunk Extn. PT-interface CS Hybrid Terminal IP-PBX Board Surge Extn. Protector Extn. Extn. PT-interface CS Earth Extn.: Extension Line If you install an extension outside of the building, the following precautions are recommended: Install the extension wire underground.
  • Page 73 2.2 Installation of the Hybrid IP-PBX Connect the earth rod to the surge protector using an earthing wire with a cross-sectional area of at least 1.3 mm Bury the earth rod near the protector. The earthing wire should be as short as possible. The earthing wire should run straight to the earth rod.

  • Page 74: Information About The Main Processing Card

    2.3 Information about the Main Processing Card Information about the Main Processing Card 2.3.1 MPR Card Function Contains the main processor for all processes, basic shelf main protocol, time switch (TSW) control, detection of system clock alarm, basic shelf power down alarm, and watchdog timer overflow. An MEC card and an RMT card can be mounted on the MPR card (refer to "2.3.2 MEC Card (KX-TDA0105)"...
  • Page 75 2.3 Information about the Main Processing Card CAUTION • Use only the SD Memory Card included with the Hybrid IP-PBX, or a Panasonic optional upgrade SD Memory Card. • The SD Memory Card contains software for all the processes of the Hybrid IP-PBX and all the customer data.

  • Page 76: Mec Card (Kx-Tda0105)

    2.3 Information about the Main Processing Card 2.3.2 MEC Card (KX-TDA0105) Function Memory expansion card to increase system data storage space, enable Broadcasting and Call Billing for Guest Room features, and double the number of DPTs, using Digital XDP connection. To be mounted on the MPR card.

  • Page 77: Rmt Card (Kx-Tda0196)

    2.3 Information about the Main Processing Card 2.3.3 RMT Card (KX-TDA0196) Function Analogue modem card for remote communication with the Hybrid IP-PBX. ITU-T V.90 support. To be mounted on the MPR card. inside Screw RMT Card Accessories and User-supplied Items Accessories (included): Screws ×...

  • Page 78: Information About The Trunk Cards

    2.4 Information about the Trunk Cards Information about the Trunk Cards 2.4.1 LCOT4 Card (KX-TDA0183), LCOT8 Card (KX-TDA0180), and LCOT16 Card (KX-TDA0181) Function LCOT4: 4-port analogue trunk card with 2 power failure transfer (PFT) ports. LCOT8: 8-port analogue trunk card with 2 power failure transfer (PFT) ports. One CID8 or CID/PAY8 card can be mounted on the LCOT8 card (refer to "2.4.3 CID/PAY8 Card (KX-TDA0189)"...
  • Page 79 2.4 Information about the Trunk Cards Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Ring port 1 Tip port 1 Ring port 2 Tip port 2 Ring port 3 Tip port 3 Ring port 4 Tip port 4 Ring port 5 Tip port 5 Ring port 6...

  • Page 80: Did8 Card (Kx-Tda0182)

    2.4 Information about the Trunk Cards 2.4.2 DID8 Card (KX-TDA0182) Function 8-port DID trunk card. Amphenol To DID line Accessories and User-supplied Items Accessories (included): Screws × 2 User-supplied (not included): Amphenol connector Notes • To connect the Amphenol connector, refer to "2.2.10 Fastening Amphenol Connector". •...
  • Page 81 2.4 Information about the Trunk Cards LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 82: Cid/Pay8 Card (Kx-Tda0189)

    2.4 Information about the Trunk Cards 2.4.3 CID/PAY8 Card (KX-TDA0189) Function 8-port Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF, and 8-port Pay Tone Service (12 kHz/16 kHz). To be mounted on the LCOT8/LCOT16 cards. Set all DIP switches for ports 09-16 at "OFF"...

  • Page 83: Cid8 Card (Kx-Tda0193)

    2.4 Information about the Trunk Cards 2.4.4 CID8 Card (KX-TDA0193) Function 8-port Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF. To be mounted on the LCOT8/LCOT16 cards. LCOT16 card only inside CID8 Card Screw S W 1 Accessories and User-supplied Items Accessories (included): Screws ×...

  • Page 84: E&M8 Card (Kx-Tda0184)

    2.4 Information about the Trunk Cards 2.4.5 E&M8 Card (KX-TDA0184) Function 8-port E & M (TIE) trunk card. Type 5 support. Amphenol To terminal board from the E & M (TIE) line Accessories and User-supplied Items Accessories (included): Screws × 2 User-supplied (not included): Amphenol connector Notes •...
  • Page 85 2.4 Information about the Trunk Cards Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Tip port 1 Ring port 1 Tip 1 port 1 Ring 1 port 1 E line port 1 M line port 1 SG line port 1 SG line port 2 Tip port 2 Ring port 2...
  • Page 86 2.4 Information about the Trunk Cards LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 87: T1 Card (Kx-Tda0187)

    2.4 Information about the Trunk Cards 2.4.6 T1 Card (KX-TDA0187) Function 1-port T1 trunk card. EIA/TIA standard compliant. LEDs RJ45 To NT1 / Extension Accessories and User-supplied Items Accessories (included): Ferrite core × 1 User-supplied (not included): RJ45 connector Notes •...
  • Page 88 2.4 Information about the Trunk Cards Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Receive data (+) Receive data (-) Reserved – – Transmit data (-) Transmit data (+) Reserved – – RJ45 Connector for Extension Use Signal Name Level [V] Function...
  • Page 89 2.4 Information about the Trunk Cards Indication Colour Description SYNC Green Synchronisation status indication • OFF: Not synchronised • ON: Synchronised • Flashing (60 times per minute): Synchronised (Clock Master) Maximum Cabling Distance of Extension Connection The maximum length of the extension cable that connects the T1 cards is shown below: Diameter Maximum Distance 0.5 mm:...

  • Page 90: E1 Card (Kx-Tda0188)

    2.4 Information about the Trunk Cards 2.4.7 E1 Card (KX-TDA0188) Function 1-port E1 trunk card. ITU-T standard compliant. LEDs RJ45 BNC (TX) outer conductor J 3 0 8 J 3 0 8 To NT1/Extension For Frame For Frame To NT1/Extension Ground Open Ground Short For RJ45...
  • Page 91 2.4 Information about the Trunk Cards Switch Settings Switch Type Usage and Status Definition Select 120 Ω (default) or 75 Ω to match the connector type to be Termination Slide used. Slide When using an RJ45 connector, select A (default) for trunk or B for extension use.
  • Page 92 2.4 Information about the Trunk Cards BNC (coaxial) Connector (RX) Signal Name Level [V] Function Receive data (-) Receive data (+) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) •...

  • Page 93: Bri4 Card (Kx-Tda0284) And Bri8 Card (Kx-Tda0288)

    2.4 Information about the Trunk Cards 2.4.8 BRI4 Card (KX-TDA0284) and BRI8 Card (KX-TDA0288) Function BRI4: 4-port ISDN Basic Rate Interface card with 1 power failure transfer port. EURO-ISDN/ETSI compliant. BRI8: 8-port ISDN Basic Rate Interface card with 1 power failure transfer port. EURO-ISDN/ETSI compliant.
  • Page 94 2.4 Information about the Trunk Cards Switch Settings Switch Type Usage and Status Definition Slide Select A (default) for trunk or B for extension use. Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Reserved – – Transmit data 1 Receive data 2 Receive data 1...
  • Page 95 2.4 Information about the Trunk Cards Indication Colour Description LINE 8 Green Line status indication (LINE 1 to LINE 8): LINE 7 Refer to "LINE LED Pattern" below for details. LINE 6 Note LINE 5 LINE 4 LINE 5 to LINE 8 are for BRI8 card only. LINE 3 LINE 2 LINE 1...
  • Page 96 2.4 Information about the Trunk Cards Maximum Cabling Distance of S0 Bus Connection The maximum length of the extension cable that connects the Hybrid IP-PBX and the ISDN terminal equipment (TE) is shown below: CAT 5: Under 1000 m Point-to-Point CAT 5: Under 150 m Point-to-Multipoint TE 1...

  • Page 97: Pri30 Card (Kx-Tda0290Ce/Cj)

    2.4 Information about the Trunk Cards 2.4.9 PRI30 Card (KX-TDA0290CE/CJ) Function 1-port ISDN Primary Rate Interface card (30B channels). EURO-ISDN/ETSI compliant. LEDs RJ45 To NT1 / Extension To NT1/Extension For RJ45 BNC (TX) BNC (RX) 120Ω 120Ω For BNC 75Ω 75Ω...
  • Page 98 2.4 Information about the Trunk Cards Switch Settings Switch Type Usage and Status Definition Select 120 Ω (default) or 75 Ω to match the connector type to be Termination Slide used. Slide When using an RJ45 connector, select A (default) for trunk or B for extension use.
  • Page 99 2.4 Information about the Trunk Cards BNC (coaxial) Connector (RX) Signal Name Level [V] Function Receive data (-) Receive data (+) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) •...
  • Page 100 2.4 Information about the Trunk Cards Maximum Cabling Distance of Extension Connection The maximum length of the extension cable that connects the PRI30 cards is shown below: Diameter Maximum Distance 0.5 mm: 200 m Installation Manual...

  • Page 101: Pri23 Card (Kx-Tda0290)

    2.4 Information about the Trunk Cards 2.4.10 PRI23 Card (KX-TDA0290) Function 1-port ISDN Primary Rate Interface card (23B channels). NI (North American standard ISDN protocol) compliant. LEDs RJ45 To NT1/ Extension Accessories and User-supplied Items Accessories (included): Ferrite core × 1 User-supplied (not included): RJ45 connector Notes •...
  • Page 102 2.4 Information about the Trunk Cards Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Receive data (+) Receive data (-) Reserved – – Transmit data (-) Transmit data (+) Reserved – – RJ45 Connector for Extension Use Signal Name Level [V] Function...
  • Page 103 2.4 Information about the Trunk Cards Indication Colour Description SYNC Green Synchronisation status indication • OFF: Not synchronised • ON: Synchronised • Flashing (60 times per minute): Synchronised (Clock Master) D-LINK Green Data link status indication • OFF: Not established •...

  • Page 104: Ip-Gw4 Card (Kx-Tda0480)

    2.4 Information about the Trunk Cards 2.4.11 IP-GW4 Card (KX-TDA0480) Function 4-channel VoIP gateway card. Compliant with VoIP H.323 V.2 protocol, and ITU-T G.729a and G.723.1 CODEC methods. G3 fax support. LEDs RJ45 (10BASE-T) To private IP network Accessories and User-supplied Items Accessories (included): CD-ROM (including PC programming software and documentation) ×...
  • Page 105 2.4 Information about the Trunk Cards LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 106: Ip-Gw4E Card (Kx-Tda0484)

    2.4 Information about the Trunk Cards 2.4.12 IP-GW4E Card (KX-TDA0484) Function 4-channel VoIP gateway card. Compliant with VoIP H.323 V.2 protocol, and ITU-T G.729a, G.723.1, and G.711 CODEC methods. LEDs RJ45 (10BASE-T/100BASE-TX) To private IP network Accessories and User-supplied Items Accessories (included): CD-ROM (including documentation for web programming) ×...
  • Page 107 2.4 Information about the Trunk Cards LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 108: Ip-Gw16 Card (Kx-Tda0490)

    2.4 Information about the Trunk Cards 2.4.13 IP-GW16 Card (KX-TDA0490) Function 16-channel VoIP gateway card. Compliant with VoIP H.323 V.2 protocol, and ITU-T G.729a, G.723.1, and G.711 CODEC methods. LEDs RJ45 (10BASE-T/100BASE-TX Full Duplex) To private IP network Accessories and User-supplied Items Accessories (included): Ferrite core ×...
  • Page 109 2.4 Information about the Trunk Cards LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 110: Information About The Extension Cards

    2.5 Information about the Extension Cards Information about the Extension Cards 2.5.1 CSIF4 Card (KX-TDA0143) and CSIF8 Card (KX-TDA0144) Function CSIF4: 4-port CS interface card for 4 CSs. CSIF8: 8-port CS interface card for 8 CSs. RJ45 (LINE 1 to LINE 8) To CS Accessories and User-supplied Items Accessories (included): none...
  • Page 111 2.5 Information about the Extension Cards Pin Assignments RJ45 Connector Signal Name Function Reserved – Data port (High) POWH Power (High) POWL Power (Low) Data port (Low) Reserved – LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication •...

  • Page 112: Dhlc8 Card (Kx-Tda0170)

    2.5 Information about the Extension Cards 2.5.2 DHLC8 Card (KX-TDA0170) Function 8-port digital hybrid extension card for DPTs, APTs, SLTs, DSS consoles, and PT-interface CSs, with 2 power failure transfer (PFT) ports. Amphenol To extensions Accessories and User-supplied Items Accessories (included): Screws × 2, Ferrite core × 1 User-supplied (not included): Amphenol connector Notes •...
  • Page 113 2.5 Information about the Extension Cards Pin Assignments Amphenol Connector No. Signal Name Function No. Signal Name Function SLT Ring port 1 SLT Tip port 1 PT Data port 1 (Low) PT Data port 1 (High) Reserved – Reserved – SLT Ring port 2 SLT Tip port 2 PT Data port 2 (Low)
  • Page 114 2.5 Information about the Extension Cards LED Indications Indication Colour Description CARD STATUS Green/ Card status indication Orange/Red • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 115: Dlc8 Card (Kx-Tda0171)

    2.5 Information about the Extension Cards 2.5.3 DLC8 Card (KX-TDA0171) Function 8-port digital extension card for DPTs, DSS consoles, and PT-interface CSs. Amphenol To extensions Accessories and User-supplied Items Accessories (included): Screws × 2, Ferrite core × 1 User-supplied (not included): Amphenol connector Notes •...
  • Page 116 2.5 Information about the Extension Cards Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Reserved – Reserved – Data port 1 (Low) Data port 1 (High) Reserved – 28-29 Reserved – Data port 2 (Low) Data port 2 (High) Reserved –...

  • Page 117: Dlc16 Card (Kx-Tda0172)

    2.5 Information about the Extension Cards 2.5.4 DLC16 Card (KX-TDA0172) Function 16-port digital extension card for DPTs, DSS consoles, and PT-interface CSs. Amphenol To extensions Accessories and User-supplied Items Accessories (included): Screws × 2, Ferrite core × 1 User-supplied (not included): Amphenol connector Notes •...
  • Page 118 2.5 Information about the Extension Cards Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Data port 1 (Low) Data port 1 (High) Data port 2 (Low) Data port 2 (High) Data port 3 (Low) Data port 3 (High) Data port 4 (Low) Data port 4 (High) Data port 5 (Low)

  • Page 119: Slc8 Card (Kx-Tda0173)

    2.5 Information about the Extension Cards 2.5.5 SLC8 Card (KX-TDA0173) Function 8-port extension card for SLTs with 2 power failure transfer (PFT) ports. Amphenol To extensions Accessories and User-supplied Items Accessories (included): Screws × 2, Ferrite core × 1 User-supplied (not included): Amphenol connector Notes •...
  • Page 120 2.5 Information about the Extension Cards Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Ring port 1 Tip port 1 Reserved – 27-28 Reserved – Ring port 2 Tip port 2 Reserved – 30-31 Reserved – Ring port 3 Tip port 3 Reserved –...

  • Page 121: Ext-Cid Card (Kx-Tda0168)

    2.5 Information about the Extension Cards 2.5.6 EXT-CID Card (KX-TDA0168) Function Sends Caller ID signals to extension ports. To be mounted on the SLC8 card only. inside SLC8 Card Screw EXT-CID Card Accessories and User-supplied Items Accessories (included): Screws × 2 User-supplied (not included): none Installation Manual...

  • Page 122: Slc16 Card (Kx-Tda0174), Mslc16 Card (Kx-Tda0175), And Cslc16 Card (Kx-Tda0177)

    Accessories (included): Screws × 2, Ferrite core × 1 User-supplied (not included): Amphenol connector Notes • Panasonic SLT with Message Waiting Lamp (e.g., KX-T7310) is recommended for connection to the MSLC16 card. • Attach the included ferrite core to the cable. Refer to "2.2.9 Attaching a Ferrite Core".
  • Page 123 2.5 Information about the Extension Cards Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Ring port 1 Tip port 1 Ring port 2 Tip port 2 Ring port 3 Tip port 3 Ring port 4 Tip port 4 Ring port 5 Tip port 5 Ring port 6...

  • Page 124: Ip-Ext16 Card (Kx-Tda0470)

    2.5 Information about the Extension Cards 2.5.8 IP-EXT16 Card (KX-TDA0470) Function 16-channel VoIP extension card. Compliant with Panasonic proprietary protocol, and ITU-T G.729a and G.711 CODEC methods. LEDs RJ45 (10BASE-T/100BASE-TX Full Duplex) To private IP network Accessories and User-supplied Items Accessories (included): Ferrite core ×...
  • Page 125 If the LINK indicator is OFF, the ONLINE indicator will also be OFF. ALARM Alarm indication • OFF: Normal • ON: Alarm VoIP BUSY Green Panasonic proprietary VoIP protocol process indication • OFF: VoIP process inactive • ON: VoIP process active LINK Green Link status indication • OFF: Connection error •...

  • Page 126: Information About The Other Cards

    2.6 Information about the Other Cards Information about the Other Cards 2.6.1 OPB3 Card (KX-TDA0190) Function Optional 3-slot base card for mounting a maximum of 3 option cards from the following: • DPH4 card • DPH2 card • EIO4 card •...

  • Page 127: Dph4 Card (Kx-Tda0161)

    2.6 Information about the Other Cards 2.6.2 DPH4 Card (KX-TDA0161) Function 4-port doorphone card for 4 doorphones and 4 door openers. To be mounted on the OPB3 card. Fully insert the connectors through the panel openings. DPH4 Card OPB3 Card 8-pin Screw To doorphones...
  • Page 128 2.6 Information about the Other Cards Pin Assignments 8-pin Terminal Block Signal Name Function Doorphone 4 transmit com4 Doorphone 4 receive Doorphone 3 transmit com3 Doorphone 3 receive Doorphone 2 transmit com2 Doorphone 2 receive Doorphone 1 transmit com1 Doorphone 1 receive 10-pin Terminal Block Signal Name Function...

  • Page 129: Dph2 Card (Kx-Tda0162)

    2.6 Information about the Other Cards 2.6.3 DPH2 Card (KX-TDA0162) Function 2-port doorphone card for 2 German-type doorphones and 2 door openers. To be mounted on the OPB3 card. Fully insert the connectors through the panel openings. DPH2 Card OPB3 Card 8-pin Screw To doorphones/...
  • Page 130 2.6 Information about the Other Cards Pin Assignments 8-pin Terminal Block Proprietary Standard Function Signal Name Signal Name Path_2b b (2) Doorphone 2 transmit Path_2a a (2) Doorphone 2 receive Call_2b RT b (2) Doorphone 2 call button Call_2a RT a (2) Doorphone 2 call button com Path_1b b (1)
  • Page 131 2.6 Information about the Other Cards Connection Diagram for German-type Doorphones and Door Openers German-type Doorphone 2 BL: Light RT: Call Button OP: Door Opener Connection Terminal Door Opener 2 DC: Doorphone Current Supply Control Terminal Path: Doorphone Call Path Call_2b L O U B Call_2a...

  • Page 132: Eio4 Card (Kx-Tda0164)

    2.6 Information about the Other Cards 2.6.4 EIO4 Card (KX-TDA0164) Function 4-port external input/output card. To be mounted on the OPB3 card. Fully insert the connectors through the panel openings. EIO4 Card OPB3 Card 8-pin Screw To external sensors To external relays 10-pin Accessories and User-supplied Items Accessories (included): Screws ×...
  • Page 133 2.6 Information about the Other Cards Pin Assignments 8-pin Terminal Block Signal Name Function Control 4 Control 4 com Control 3 Control 3 com Control 2 Control 2 com Control 1 Control 1 com 10-pin Terminal Block Signal Name Function Reserved –...
  • Page 134 2.6 Information about the Other Cards External Sensor Power to the external sensor is provided from the EIO4 card and must be grounded through the EIO4 card as indicated in the diagram below. A pair of "sensor" and "common" lines are connected to the EIO4 card for each external sensor.

  • Page 135: Echo16 Card (Kx-Tda0166)

    2.6 Information about the Other Cards 2.6.5 ECHO16 Card (KX-TDA0166) Function 16-channel card for echo cancellation during conferences. To be mounted on the OPB3 card. OPB3 Card inside ECHO16 Card Screw Accessories and User-supplied Items Accessories (included): Screws × 3 User-supplied (not included): none Note To establish a conference call involving 6 to 8 parties, install an ECHO16 card and enable echo...

  • Page 136: Msg4 Card (Kx-Tda0191)

    2.6 Information about the Other Cards 2.6.6 MSG4 Card (KX-TDA0191) Function 4-channel message card. To be mounted on the OPB3 card. OPB3 Card inside MSG4 Card Screw Accessories and User-supplied Items Accessories (included): Screws × 3 User-supplied (not included): none Installation Manual...

  • Page 137: Cti-Link Card (Kx-Tda0410)

    2.6 Information about the Other Cards 2.6.7 CTI-LINK Card (KX-TDA0410) Function Ethernet card for CTI communication via 10BASE-T port. CSTA Phase 3 protocol compatible. LEDs RJ45 (10BASE-T) To LAN/ CTI Server Accessories and User-supplied Items Accessories (included): none User-supplied (not included): RJ45 connector Notes •...
  • Page 138 2.6 Information about the Other Cards LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal • Red ON: Fault (includes reset) • Red Flashing (60 times per minute): Out of Service LINK STATUS Green Link status indication...

  • Page 139: Connection Of Extensions

    2.7 Connection of Extensions Connection of Extensions 2.7.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) Cable Maximum Distance ø 0.4 mm: 222 m PT-interface CS ø 0.5 mm: 347 m ø 0.6 mm: 500 m CAT 5: 347 m KX-T7600 Series DPT Cable Maximum Distance...

  • Page 140: Parallel Connection Of The Extensions

    2.7 Connection of Extensions 2.7.2 Parallel Connection of the Extensions Any SLT can be connected in parallel with an APT or a DPT as follows. Note In addition to an SLT, an answering machine, a fax machine or a modem (PC) can be connected in parallel with an APT or a DPT.
  • Page 141 2.7 Connection of Extensions Using an EXtra Device Port With KX-T7600 Series DPT (except KX-T7665) To DHLC8 card 2-conductor wiring cord 4-conductor wiring cord Connect pins "T" and "R". Connect pins "T", "R", "D1" and "D2". TO MAIN UNIT TO TEL / PABX To DHLC8 card To SLT...

  • Page 142: Digital Extra Device Port (Digital Xdp) Connection

    2.7 Connection of Extensions 2.7.3 Digital EXtra Device Port (Digital XDP) Connection A DPT can be connected to another DPT on the Digital XDP connection. In addition, if the DPT is connected to a DHLC8 card, it can also have an SLT connected in Parallel mode or XDP mode. Notes •...
  • Page 143 2.7 Connection of Extensions Using an EXtra Device Port To DLC8/DLC16 card 4-conductor wiring cord To DHLC8 card Connect pins "T", "R", 2-conductor wiring cord (for connection of SLT) "D1" and "D2". Connect pins "T" and "R". 4-conductor wiring cord Connect pins "T", "R", "D1"...
  • Page 144 2.7 Connection of Extensions With KX-T7600E Series DPT Using a Modular T-Adaptor To DLC8/DLC16 card Modular To DHLC8 card T-Adaptor (for connection of SLT) 2-conductor wiring cord Connect pins "T" and "R". 4-conductor wiring cord Connect pins "D1" and "D2". 4-conductor wiring cord Connect pins "D1"...
  • Page 145 2.7 Connection of Extensions Using an EXtra Device Port Connecting to a Slave DPT To DLC8/DLC16 card To DHLC8 card 4-conductor wiring cord (for connection of SLT) Connect pins "T", "R", 2-conductor wiring cord "D1" and "D2". Connect pins "T" and "R". 4-conductor wiring cord Connect pins "T", "R", "D1"...
  • Page 146 2.7 Connection of Extensions Connecting to a Master DPT To DLC8/DLC16 card To DHLC8 card 4-conductor wiring cord (for connection of SLT) Connect pins "D1" and "D2". 4-conductor wiring cord Connect pins "T", "R", "D1" and "D2". Master DPT Slave DPT 2-conductor wiring cord Connect pins "T"...

  • Page 147: First Party Call Control Cti Connection

    2.7 Connection of Extensions 2.7.4 First Party Call Control CTI Connection CTI connection between a PC and a KX-T7633/T7636 DPT provides first party call control. The CTI connection is made via a USB interface (version 2.0), and uses the TAPI 2.1 protocol. A USB Module (KX-T7601) must be connected to the KX-T7633/T7636 DPT.

  • Page 148: Connection Of Dect Portable Stations

    This Cell Station Unit for DECT is for connection to Panasonic PBXs in use in European countries. PS: DECT Portable Station (KX-TCA155/KX-TCA255/KX-TD7590/KX-TD7580) The KX-TDA100 and KX-TDA200 can support up to 128 PSs. For more details about the PS, refer to the PS Operating Instructions.
  • Page 149 2.8 Connection of DECT Portable Stations KX-TDA100BX/KX-TDA200BX: 8 CAUTION • The CS should be kept free of dust, moisture, high temperature (more than 40 ), low temperature ˚C (less than 0 ), and vibration, and should not be exposed to direct sunlight. ˚C •...

  • Page 150: Procedure Overview

    2.8 Connection of DECT Portable Stations 2.8.2 Procedure Overview When connecting the wireless system, use extreme care in conducting the site survey. Site surveys can be conducted using the KX-TCA255 or KX-TD7590 PS. An incorrectly performed site survey can result in poor service area, frequent noise, and disconnection of calls.
  • Page 151 2.8 Connection of DECT Portable Stations Make sure that the radio signal strength level is greater than "3" at any location within the service area required by the user. 4. Finish the site survey Refer to "2.8.6 After Site Survey". Return all DIP switches of each CS to the OFF position, and stop supplying power.

  • Page 152: Site Planning

    2.8 Connection of DECT Portable Stations 2.8.3 Site Planning Choosing the best site for the CS requires careful planning and testing of essential areas. The best location may not always be convenient for installation. Read the following information before installing the unit. Understanding Radio Waves Characteristics of Radio Waves The transmission of radio waves and the CS coverage area depend on the structure and materials of the...
  • Page 153 2.8 Connection of DECT Portable Stations Object Material Transmission Tendency Wall Concrete The thicker they are, the less radio waves penetrate them. Ferroconcrete Radio waves can penetrate them, but the more iron there is, the more radio waves are reflected. Window Glass Radio waves usually penetrate them.
  • Page 154 2.8 Connection of DECT Portable Stations CS Coverage Area The example below shows the size of the coverage area of 1 CS if it is installed in an area with no obstacles. Note Radio signal strength levels are measured during the site survey (refer to "2.8.5 Site Survey Using the KX-TCA255/KX-TD7590").
  • Page 155 2.8 Connection of DECT Portable Stations Where CS coverage areas overlap, the PS will start call handover to the next CS if the signal from one CS becomes weak. However, if a PS moves away from a CS and there are no CSs available for handover, the PS may go out of range and the call could be lost.

  • Page 156: Before Site Survey

    2.8 Connection of DECT Portable Stations 2.8.4 Before Site Survey Use the KX-TCA255 or KX-TD7590 PS to conduct the site survey. Note Display prompts for the site survey are only available in English. Checking the CS ID Number Check the CS ID number label attached to the CS. If the CS ID number label is not attached to the CS, check the CS ID number using the KX-TDA Maintenance Console.
  • Page 157 2.8 Connection of DECT Portable Stations Using the KX-TD7590 To enter letters INT' CS No. CS ID No. Press 1, 9, and POWER 0 to 7 0 to 9 and A to F for more than 5 seconds. To the Desired CS No. To the initial display Note To clear the CS ID number assigned to the PS, follow the procedure below:...
  • Page 158 2.8 Connection of DECT Portable Stations Setting and Installing the CS Temporarily for Site Survey Switch the Radio Signal Test switch from OFF to ON. Set the channel number switches as desired. DIP Switch Channel Number Switch Keep this switch at the default "OFF"...
  • Page 159 2.8 Connection of DECT Portable Stations After setting the DIP switch, connect an AC adaptor or battery box to the CS using a power supply adaptor. Notes • The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet. Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected.

  • Page 160: Site Survey Using The Kx-Tca255/Kx-Td7590

    2.8 Connection of DECT Portable Stations 2.8.5 Site Survey Using the KX-TCA255/KX-TD7590 The PS has a Radio Signal Test mode that monitors the state of the radio link to the CS for site survey. In Radio Signal Test mode, the frame loss and signal strength of a synchronous slot, and the signal strength of the other slots can be measured when the PS is monitoring the CS.
  • Page 161 2.8 Connection of DECT Portable Stations Move to the CS until the radio signal strength level becomes "12". Move away from the CS and identify the CS coverage area within which the radio signal strength level is greater than "8". Draw the area on the map. Move away from the CS and identify the CS coverage area within which the radio signal strength level is greater than "3".
  • Page 162 2.8 Connection of DECT Portable Stations Repeat steps 1 and 2 for other CSs, and relocate the CSs when necessary. Overlap adjacent CS coverage areas where the radio signal strength level is "8" by 5 m to 10 m. Channel no. 0 Channel no.
  • Page 163 2.8 Connection of DECT Portable Stations Referring to the Stored Scan Data Using the KX-TCA255 Log No. Press 1, 9, and POWER 0 to 9 for more than 2 seconds. To go to other slots To go to specific channel Channel No.

  • Page 164: After Site Survey

    2.8 Connection of DECT Portable Stations 2.8.6 After Site Survey After obtaining the proper measurement results, exit Radio Signal Test mode before connecting the CS to the Hybrid IP-PBX. Keep pressing the POWER button on the PS until the PS is turned OFF. Disconnect the AC adaptor or battery box from the CS and stop supplying electricity.

  • Page 165: Connecting A Cell Station To The Hybrid Ip-Pbx

    2.8 Connection of DECT Portable Stations 2.8.7 Connecting a Cell Station to the Hybrid IP-PBX Using a CSIF Card Refer to the following example to connect a CS to the Hybrid IP-PBX. CSIF8 Card Port 1 Cable Maximum Distance ø 0.4 mm: 444 m ø...
  • Page 166 2.8 Connection of DECT Portable Stations Using a DHLC/DLC Card Refer to the following example to connect a CS to the Hybrid IP-PBX. DHLC8 Card Cable Maximum Distance ø 0.4 mm: 222 m ø 0.5 mm: 347 m ø 0.6 mm: 500 m CAT 5: 347 m...
  • Page 167 2.8 Connection of DECT Portable Stations Connecting the CS Connect the cable from the CSIF/DHLC/DLC card to the CS. Modular To CSIF/DHLC/DLC card Pass the cable through the groove of the CS (in any direction depending on your preference). TO MAIN UNIT / PABX To CSIF/DHLC/DLC card Installation Manual...
  • Page 168 2.8 Connection of DECT Portable Stations For the KX-TDA0142CE User only: Wrap the cable once around the ferrite core. Then close the case of the ferrite core. To CSIF card Note If you need to open the ferrite core, use a flathead screwdriver to unlatch the case of the ferrite core. Installation Manual...
  • Page 169 2.8 Connection of DECT Portable Stations Registering the PS The PS must be registered to the Hybrid IP-PBX before it can be used. Programming of both the PS and Hybrid IP-PBX is required. A PT with multiline display (e.g., KX-T7636 6-line display) is required to perform the Hybrid IP-PBX system programming.
  • Page 170 2.8 Connection of DECT Portable Stations Using the KX-TD7590 System lock can be set after PS registration. When system lock is enabled, the system lock password will be required for system setting. Press POWER for 5 seconds. To register for the first time SELECT Select "INITIAL SETTING".
  • Page 171 2.8 Connection of DECT Portable Stations Setting the Personal Identification Number (PIN) for PS Registration To prevent registering the PS to a wrong Hybrid IP-PBX, a PIN for PS registration can be set to the Hybrid IP-PBX. Before registering the PS to the Hybrid IP-PBX, enter the PIN set to the Hybrid IP-PBX into the PS. By doing so, the PS will only be registered to the Hybrid IP-PBX with the matching PIN.
  • Page 172 2.8 Connection of DECT Portable Stations PS Termination Confirm the following before cancelling the PS registration: • The PS is turned on. • The PS is within range. [691] PS No. 001 to 128 ENTER ENTER If "Rejected" or "Time out" is displayed CLEAR To the PS operation...
  • Page 173 2.8 Connection of DECT Portable Stations Testing the Operation Walk around the service area while having a conversation using a registered PS. If noise is frequent or conversations disconnect, relocate the CSs or install an additional CS. Installation Manual...

  • Page 174: Wall Mounting

    2.8 Connection of DECT Portable Stations 2.8.8 Wall Mounting Place the reference for wall mounting (on the following page) on the wall to mark the 2 screw positions. Install the 2 screws and washers (included) into the wall. Notes • Make sure that the screw heads are at the same distance from the wall.
  • Page 175 2.8 Connection of DECT Portable Stations Reference for Wall Mounting Please copy this page and use as a reference for wall mounting. Install a screw here. 71 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.

  • Page 176: Connection Of 2.4 Ghz Portable Stations

    This unit determines the area covered by the wireless system. Up to 2 calls can be made at the same time through each CS. PS: 2.4 GHz Portable Station (KX-TD7680/KX-TD7690) The KX-TDA100 and KX-TDA200 can support up to 128 PSs. For more details about the PS, refer to the PS Operating Instructions. CAUTION •...
  • Page 177 2.9 Connection of 2.4 GHz Portable Stations Please take into consideration the distance between the CSs when site planning. Please consult a certified dealer for details. However, the required distance between CSs may vary depending on the environment of the installation site and conditions in which the wireless system is used.

  • Page 178: Procedure Overview

    2.9 Connection of 2.4 GHz Portable Stations 2.9.2 Procedure Overview When connecting the wireless system, use extreme care in conducting the site survey. An incorrectly performed site survey can result in poor service area, frequent noise, and disconnection of calls. 1.
  • Page 179 2.9 Connection of 2.4 GHz Portable Stations 4. Finish the site survey Refer to "2.9.6 After Site Survey". Return all DIP switches of each CS to the OFF position, and stop supplying power. Turn off the PS. 5. Connect the CS and PS to the Hybrid IP-PBX and test the operation Refer to "2.9.7 Connecting a Cell Station to the Hybrid IP-PBX".

  • Page 180: Site Planning

    2.9 Connection of 2.4 GHz Portable Stations 2.9.3 Site Planning Choosing the best site for the CS requires careful planning and testing of essential areas. The best location may not always be convenient for installation. Read the following information before installing the unit. Understanding Radio Waves Characteristics of Radio Waves The transmission of radio waves and the CS coverage area depend on the structure and materials of the...
  • Page 181 2.9 Connection of 2.4 GHz Portable Stations Object Material Transmission Tendency Wall Concrete The thicker they are, the less radio waves penetrate them. Ferroconcrete Radio waves can penetrate them, but the more iron there is, the more radio waves are reflected. Window Glass Radio waves usually penetrate them.
  • Page 182 2.9 Connection of 2.4 GHz Portable Stations CS Coverage Area The example below shows the size of the coverage area of 1 CS if it is installed in an area with no obstacles. Note Radio signal strength levels are measured during the site survey (refer to "2.9.5 Site Survey"). Coverage Area Radio signal strength level is greater than "3".
  • Page 183 2.9 Connection of 2.4 GHz Portable Stations one CS becomes weak. However, if a PS moves away from a CS and there are no CSs available for handover, the PS may go out of range and the call could be lost. If the signal from the CS fades, due to the structure of the building, there may be some handover delay.

  • Page 184: Before Site Survey

    2.9 Connection of 2.4 GHz Portable Stations 2.9.4 Before Site Survey Setting and Installing the CS Temporarily for Site Survey Switch the Radio Signal Test switch from OFF to ON. Set the CS number switches as desired. DIP Switch CS Number Switch Keep this switch at the default "OFF"...
  • Page 185 2.9 Connection of 2.4 GHz Portable Stations After setting the DIP switch, connect an AC adaptor or battery box to the CS using a power supply adaptor. Note The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet. Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected.

  • Page 186: Site Survey

    2.9 Connection of 2.4 GHz Portable Stations 2.9.5 Site Survey The PS has a Radio Signal Test mode that monitors the state of the radio link to the CS. After installing the CSs temporarily, set the PS to Radio Signal Test mode and measure each CS coverage area. Then, record the results on the map of the installation site.
  • Page 187 2.9 Connection of 2.4 GHz Portable Stations Measure the radio signal strength by moving towards and away from the CS. Move to the CS until the radio signal strength level becomes "12". Move away from the CS and identify the CS coverage area within which the radio signal strength level is greater than "8".
  • Page 188 2.9 Connection of 2.4 GHz Portable Stations Overlap the CS coverage areas of at least 2 CSs at any location in the installation site. CS no. 1 CS no. 2 CS no. 3 CS no. 4 Make sure that the radio signal strength level is greater than "3" at any location in the service area required by the user.
  • Page 189 2.9 Connection of 2.4 GHz Portable Stations Deleting the Stored Scan Data Using the KX-TD7680 Scan Data No. Press 1, 9, and POWER 0 to 9, or # for all data for more than 2 seconds. To the Desired Scan Data No. Using the KX-TD7690 Scan Data No.

  • Page 190: After Site Survey

    2.9 Connection of 2.4 GHz Portable Stations 2.9.6 After Site Survey After obtaining the proper measurement results, exit Radio Signal Test mode before connecting the CS to the Hybrid IP-PBX. Keep pressing the POWER button on the PS until the PS is turned OFF. Disconnect the AC adaptor or battery box from the CS and stop supplying electricity.

  • Page 191: Connecting A Cell Station To The Hybrid Ip-Pbx

    2.9 Connection of 2.4 GHz Portable Stations 2.9.7 Connecting a Cell Station to the Hybrid IP-PBX Using a CSIF Card Refer to the following example to connect a CS to the Hybrid IP-PBX. CSIF8 Card Port 1 Cable Maximum Distance ø...
  • Page 192 2.9 Connection of 2.4 GHz Portable Stations Using a DHLC/DLC Card Refer to the following example to connect a CS to the Hybrid IP-PBX. DHLC8 Card Cable Maximum Distance ø 0.4 mm: 222 m ø 0.5 mm: 347 m ø 0.6 mm: 500 m CAT 5: 347 m...
  • Page 193 2.9 Connection of 2.4 GHz Portable Stations Connecting the CS Connect the cable from the CSIF/DHLC/DLC card to the CS. Modular To CSIF/DHLC/DLC card Pass the cable through the groove of the CS (in any direction depending on your preference). TO MAIN UNIT / PABX To CSIF/DHLC/DLC card...
  • Page 194 2.9 Connection of 2.4 GHz Portable Stations Registering the PS The PS must be registered to the Hybrid IP-PBX before it can be used. Programming of both the PS and Hybrid IP-PBX is required. A PT with multiline display (e.g., KX-T7636 6-line display) is required to perform the Hybrid IP-PBX system programming.
  • Page 195 2.9 Connection of 2.4 GHz Portable Stations PS Registration [690] PS No. Extn. No. To the PS operation 001 to 128 1 to 4 digits below ENTER ENTER When the PS has not been registered yet When registering the PS for the first time, it is possible to select the desired language for the display. (You do not need to enter the PS system programming mode when registering for the first time.) Using the KX-TD7680 [ F2 ]...
  • Page 196 2.9 Connection of 2.4 GHz Portable Stations Setting the System Lock When a system lock has been set, the system lock password will be required for PS system setting. Using the KX-TD7680 Choose Select "Enable/Disable". "SYSTEM LOCK". System Lock Password System Lock Password ENABLE 4 digits...
  • Page 197 2.9 Connection of 2.4 GHz Portable Stations Setting the Personal Identification Number (PIN) for PS Registration To prevent registering the PS to a wrong Hybrid IP-PBX, a PIN for PS registration can be set to the Hybrid IP-PBX. Before registering the PS to the Hybrid IP-PBX, enter the PIN set to the Hybrid IP-PBX into the PS. By doing so, the PS will only be registered to the Hybrid IP-PBX with the matching PIN.
  • Page 198 2.9 Connection of 2.4 GHz Portable Stations PS Termination Confirm the following before cancelling the PS registration: • The PS is turned on. • The PS is within range. [691] PS No. 001 to 128 ENTER ENTER If "Rejected" or "Time out" is displayed CLEAR To the PS operation...

  • Page 199: Wall Mounting

    2.9 Connection of 2.4 GHz Portable Stations 2.9.8 Wall Mounting Place the reference for wall mounting (on the following page) on the wall to mark the 2 screw positions. Install the 2 screws and washers (included) into the wall. Notes •...
  • Page 200 2.9 Connection of 2.4 GHz Portable Stations Reference for Wall Mounting Please copy this page and use as a reference for wall mounting. Install a screw here. 71 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.

  • Page 201: Connection Of Doorphones, Door Openers, External Sensors, And External Relays

    The Hybrid IP-PBX supports a maximum of 16 doorphones (KX-T30865 with a DPH4 card, or German-type doorphone with a DPH2 card), 16 door openers, 16 external sensors, and 16 external relays. Notes • KX-T30865 is a Panasonic doorphone. • German-type doorphones, door openers, external sensors, and external relays are user-supplied. Maximum Cabling Distance...
  • Page 202 2.10 Connection of Doorphones, Door Openers, External Sensors, and External Relays Pass the wires through the hole in the base cover, and attach the base cover to a wall using 2 screws. Screw To 8-pin terminal block Note Two kinds of screws are included with a KX-T30865. Please choose the appropriate kind for your wall type.
  • Page 203 2.10 Connection of Doorphones, Door Openers, External Sensors, and External Relays Attach the terminal blocks to the connectors of the DPH4/DPH2/EIO4 card on the Hybrid IP-PBX. To doorphones/ door openers/ external sensors/ external relays Installation Manual...

  • Page 204: 2.11 Connection Of Peripherals

    2.11 Connection of Peripherals 2.11 Connection of Peripherals 2.11.1 Connection of Peripherals Maximum Distance Cable Maximum Distance CTI Server ø 0.4 mm: 10 m ø 0.5 mm: 10 m ø 0.6 mm: 10 m CAT 5: 10 m BGM/ Cable Maximum Distance Music on Hold ø...
  • Page 205 2.11 Connection of Peripherals Pager Up to 2 paging devices (user-supplied) can be connected to the Hybrid IP-PBX. CAUTION External Paging Jacks are SELV ports and should only be connected to approved SELV devices, or in Australia, via the Line Isolation Unit with the Telecommunications Compliance Label. PC/Printer (via RS-232C) The Hybrid IP-PBX is equipped with an RS-232C interface.
  • Page 206 2.11 Connection of Peripherals For connecting a printer/PC with a 25-pin RS-232C connector Hybrid IP-PBX (9-pin) Printer/PC (25-pin) Circuit Type Signal Signal Circuit Type Pin No. Pin No. (EIA) Name Name (EIA) RD (RXD) SD (TXD) RD (RXD) ER (DTR) SD (TXD) ER (DTR) DR (DSR)
  • Page 207 2.11 Connection of Peripherals PC/CTI Server (via USB version 2.0) The Hybrid IP-PBX is equipped with a USB interface. This interface provides communication between the Hybrid IP-PBX and a PC or a CTI server. The PC is used for system programming, diagnostics and external system database storage (save/load) functions.

  • Page 208: 2.12 Power Failure Connections

    2.12 Power Failure Connections 2.12 Power Failure Connections 2.12.1 Power Failure Connections When the power supply to the Hybrid IP-PBX fails, power failure transfer (PFT) will switch from the current connection to the Power Failure Connection. Refer to "2.4.1 Power Failure Transfer" in the Feature Guide for further information.
  • Page 209 2.12 Power Failure Connections RJ11 Connector Pin Assignments for Analogue Trunk Card PFT Ports 1 and 2 Signal Name Function Ring port 2 Ring port 1 Tip port 1 Tip port 2 PFT Ports 3 and 4 (for LCOT16 card only) Signal Name Function Ring port 4...
  • Page 210 2.12 Power Failure Connections Using BRI Card LINE 1 and LINE 2 of the BRI4 and BRI8 cards can be used for Power Failure Connections. Note When the power returns, the connection will switch back to normal configuration from the Power Failure Connection, and a trunk conversation established during power failure will be dropped.
  • Page 211 2.12 Power Failure Connections RJ45 Connector LINE 2 Pin Assignments Signal Name Level [V] Function Reserved – – Receive data 2 Transmit data 1 Transmit data 2 Receive data 1 Reserved – – Installation Manual...

  • Page 212: 2.13 Starting The Hybrid Ip-Pbx

    2.13 Starting the Hybrid IP-PBX 2.13 Starting the Hybrid IP-PBX 2.13.1 Starting the Hybrid IP-PBX CAUTION • SD Memory Card must be inserted in the SD Memory Card slot of the MPR card before startup. • Before touching the System Initialise Switch, discharge static electricity by touching ground or wearing an earthing strap.
  • Page 213 2.13 Starting the Hybrid IP-PBX Plug the AC power cord into the Hybrid IP-PBX and an AC outlet, and turn on the Hybrid IP-PBX. The RUN indicator will flash. Note For safety reasons, do not stretch, bend, or pinch the AC power cord. To AC Outlet While the RUN indicator is flashing, slide the System Initialise Switch back to the "NORMAL"...
  • Page 214 2.13 Starting the Hybrid IP-PBX Installation Manual...

  • Page 215: Guide For The Kx-Tda Maintenance Console

    Section 3 Guide for the KX-TDA Maintenance Console Explains the installation procedure, structure, and basic information of the KX-TDA Maintenance Console. Installation Manual...

  • Page 216: Overview

    3.1 Overview Overview 3.1.1 Overview KX-TDA Maintenance Console is designed to serve as an overall system programming reference for the Hybrid IP-PBX. To programme and administer the Hybrid IP-PBX by PC, you need to install the KX-TDA Maintenance Console onto the PC. This section describes overview and installation of the KX-TDA Maintenance Console only.

  • Page 217: Connection

    3.2 Connection Connection 3.2.1 Connection Serial Interface Connection USB Port To USB Port To COM Port RS-232C Port Note For pin assignments and maximum cabling distance, refer to "2.11.1 Connection of Peripherals". LAN Connection via CTI-LINK Card RJ45 Switching Hub To network port Note For pin assignments and maximum cabling distance, refer to "2.6.7 CTI-LINK Card (KX-TDA0410)".
  • Page 218 3.2 Connection External Modem Connection Modem To RS-232C port (25-pin) To trunk/Hybrid IP-PBX extension RS-232C Port port assigned as the trunk destination (9-pin) External Modem (25-pin) Hybrid IP-PBX (9-pin) Signal Name Pin No. Pin No. Signal Name RD (RXD) RD (RXD) SD (TXD) SD (TXD) ER (DTR)

  • Page 219: Installation Of The Kx-Tda Maintenance Console

    3.3 Installation of the KX-TDA Maintenance Console Installation of the KX-TDA Maintenance Console 3.3.1 Installing and Starting the KX-TDA Maintenance Console System Requirements Required Operating System • Microsoft Windows 98 SE, Windows Me, Windows 2000, or Windows XP ® ® Minimum Hardware Requirements •...
  • Page 220 3.3 Installation of the KX-TDA Maintenance Console Installing the KX-TDA Maintenance Console Notes • Make sure to install and use the latest version of the KX-TDA Maintenance Console. • To install or uninstall the software on a PC running Windows 2000 Professional or Windows XP Professional, you must be logged in as a user in either the "Administrators"...
  • Page 221 3.3 Installation of the KX-TDA Maintenance Console Click the check box to connect to the Hybrid IP-PBX. Options will appear as shown here, on the left. Enter the system password for installer (default: 1234). Select "USB", then click OK. Note To connect to the Hybrid IP-PBX via USB, the KX-TDA USB driver must be installed on the PC, as explained above in "Installing the KX-TDA Maintenance...
  • Page 222 3.3 Installation of the KX-TDA Maintenance Console The PC will not perform any shutdown operation, or enter the power-saving system standby mode while the KX-TDA Maintenance Console is connected to the Hybrid IP-PBX. To perform either of the operations above, first close the connection to the Hybrid IP-PBX. CAUTION Do not remove the SD Memory Card while power is supplied to the Hybrid IP-PBX.

  • Page 223: Troubleshooting

    Section 4 Troubleshooting This section provides information on the Hybrid IP-PBX and telephone troubleshooting. Installation Manual...

  • Page 224: Troubleshooting

    4.1 Troubleshooting Troubleshooting 4.1.1 Installation PROBLEM PROBABLE CAUSE SOLUTION Extension does not operate. Bad extension card. • Exchange the card for a known working one. Bad connection between the • Take the telephone and plug it into the Hybrid IP-PBX and telephone. same extension port using a short telephone cord.
  • Page 225 4.1 Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION The ALARM indicator on the A major system error occurs in • See the error log using the KX-TDA front of the shelf turns on red. the Hybrid IP-PBX. Maintenance Console (refer to "4.1.5 Troubleshooting by Error Log").

  • Page 226: Connection

    4.1 Troubleshooting 4.1.2 Connection Connection between the Hybrid IP-PBX and a PT: CAUSE SOLUTION Can you dial The T/R is connected to the D1/D2. Use the correct cord (the an extension? inner 2 wires are for T/R and the outer 2 wires are for D1/D2).
  • Page 227 4.1 Troubleshooting Connection between the trunk and the Hybrid IP-PBX: CAUSE SOLUTION (Continued from the Trunk is connected to the T2/T1. Reconnect the trunk to previous page.) the T1/R1 or T2/R2 of the telephone jack using 2-conductor wiring. Can you dial out on a Trunk Hybrid IP-PBX...

  • Page 228: Operation

    4.1 Troubleshooting 4.1.3 Operation PROBLEM PROBABLE CAUSE SOLUTION • When using the • The HANDSET/HEADSET • When the headset is not used, set the speakerphone on an APT, selector is set to the HANDSET/HEADSET selector to the nothing is audible. "HEADSET"...
  • Page 229 4.1 Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION • PS stays out of service • It may take about 20 s for • Wait until the CS starts up. when the CS status is CS to start up after the changed from Out of status has been changed to Service to In Service.

  • Page 230: Using The Reset Button

    4.1 Troubleshooting 4.1.4 Using the Reset Button If the Hybrid IP-PBX does not operate properly, use the Reset Button. Before using the Reset Button, try the system feature again to confirm whether there definitely is a problem or not. CAUTION In order to avoid possible corruption of data on the SD Memory Card, please ensure that the "SD ACCESS"...

  • Page 231: Troubleshooting By Error Log

    4.1 Troubleshooting 4.1.5 Troubleshooting by Error Log When a major system error occurs in the Hybrid IP-PBX, the ALARM indicator on the front of the shelf turns on red, and the system logs the error information. Error Log Display Format Below is the display format of the error log.
  • Page 232 The 5-digit sub code of the relevant hardware (1XXYY). • 1: Shelf number • XX: Slot number – KX-TDA100: 00 to 06 (00: MPR Card Slot; 01 to 06: Free Slots) – KX-TDA200: 00 to 11 (00: MPR Card Slot; 01 to 11: Free Slots) •...

  • Page 233: Appendix

    Section 5 Appendix Installation Manual...

  • Page 234: Revision History

    5.1 Revision History Revision History 5.1.1 PMPR Software File Version 1.1xxx New Options • System Components Table • KX-TDA0105 Memory Expansion Card (MEC) • KX-TDA0182 8-Port DID Card (DID8) • KX-TDA0183 4-Port Analogue Trunk Card (LCOT4) • KX-TDA0484 4-Channel VoIP Gateway Card (IP-GW4E) •...

  • Page 235: Pmpr Software File Version 2.0Xxx

    5.1 Revision History 5.1.2 PMPR Software File Version 2.0xxx New Options • System Components Table • KX-TDA0490 16-Channel VoIP Gateway Card (IP-GW16) • KX-TDA0470 16-Channel VoIP Extension Card (IP-EXT16) • KX-TDA0164 4-Port External Input/Output Card (EIO4) • KX-TDA0168 Extension Caller ID Card (EXT-CID) •...

  • Page 236: Pmpr Software File Version 3.0Xxx

    5.1 Revision History 5.1.3 PMPR Software File Version 3.0xxx Changed Contents • 1.4.3 System Capacity • 3.3.1 Installing and Starting the KX-TDA Maintenance Console Installation Manual...

  • Page 237: Pmpr Software File Version 3.2Xxx

    5.1 Revision History 5.1.4 PMPR Software File Version 3.2xxx New Options • System Components Table • KX-TDA0177 16-Port Single Line Telephone Extension Card with Caller ID (CSLC16) Changed Contents • 3.3.1 Installing and Starting the KX-TDA Maintenance Console Installation Manual...
  • Page 238 5.1 Revision History Installation Manual...

  • Page 239: Index

    Index Installation Manual...
  • Page 240 Index Numerics CID8 Card (KX-TDA0193) Components, System 16-Channel Echo Canceller Card (KX-TDA0166) 25, 135 Connecting Backup Batteries 16-Channel VoIP Extension Card (KX-TDA0470) 27, 124 Connection Diagram, System 16-Channel VoIP Gateway Card (KX-TDA0490) 27, 108 Connector Types 16-Port Analogue Trunk Card (KX-TDA0181) 26, 78 Cover for Blank Slot 16-Port Digital Extension Card (KX-TDA0172)
  • Page 241 26, 78 KX-TDA0184 (8-Port E & M Trunk Card) 26, 84 Pager KX-TDA0187 (T-1 Trunk Card) 26, 87 Panasonic Proprietary Telephones, Compatible KX-TDA0188 (E-1 Trunk Card) 26, 90 Panasonic Proprietary Telephones, Incompatible KX-TDA0189 (8-Port Caller ID/Pay Tone Card) 26, 82...
  • Page 242 PSU Capacity PSU-L 37, 46 PSU-M 37, 46 Wall Mounting (CS) 174, 199 PSU-S 37, 46 Wall Mounting (KX-TDA100) Wall Mounting (KX-TDA200) Wiring Precautions Quick Setup Remote Card (KX-TDA0196) 26, 77 Reset Button Revision History RF Specification, DECT Portable Station...
  • Page 243 Index Installation Manual...
  • Page 244 Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. 2003 Panasonic Communications Co., Ltd. All Rights Reserved.
