O O W W N N E E R R ' ' S S M M A A N N U U A A L L
Thanks for buying a TEAC. Read this manual carefully
to get the best performance from this Digital Receiver.
CAUTION:
Use of controls, adjustments or procedures other than
those specified herein, may void your warranty.
CAUTION : To reduce the risk of electrical shock, do not
remove the cover. No user serviceable parts inside.
Refer any servicing to qualified Service personnel.
The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user
to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock to a person
The exclamation point with an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance (Digital Receiver)
This product has a serial number, Please record
the serial number and retain it for your records.
WARNING : TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
DV-B800
Advertisement
Table of Contents
Related Manuals for Teac DV-B800
Summary of Contents for Teac DV-B800
-
Page 1: Digital Terrestrial Receiver
O O W W N N E E R R ’ ’ S S M M A A N N U U A A L L Thanks for buying a TEAC. Read this manual carefully to get the best performance from this Digital Receiver. -
Page 2: Please Read This First
PLEASE READ THIS FIRST! How do I connect this box to my TV? Using the RCA lead supplied (Yellow, White, Red); connect from the rear of the box (see Video and Audio R, Audio L) directly to the AV input on your television. If you television does not have stereo sound, then there is no need to connect the red lead. -
Page 3: Safety Instructions
Keep the STB indoors and away from potential hazards, such as houseplants, rain and direct sunlight. To provide you with the convenience of usage, TEAC has the right to make changes and improvements to the products including the user manual without any notice in advance. -
Page 4: Table Of Contents
Understanding the Remote Control Unit Setup ........................22 ..........8 ~ 9 Menu Language....................22 Connecting Your Equipment ..............10 Screen Type ....................23 Banner Time ....................23 Front Panel ......................10 Screen Save Time ..................23 Rear Panel .......................11 Other Setting ....................24 ~ 26 Connection ......................12 ~ 13 Installation .......................27 Setting Up Your System ................14... -
Page 5: Understanding The Remote Control Unit
Note : Your DVB receiver is capable of displaying teletext on screen since it has an embedded teletext decoder. **AUSTEXT only available from 7 digital - 8 - - 9 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 6: Connecting Your Equipment
ANT IN To connect the antenna here. IR SENSOR Point remote controller toward front on the DV-B800 LOOP THROUGH Used to connect a RF signal from the STB to either the RF input jack (antenna) on your VCR or to the antenna input of your TV. -
Page 7: Connection
Component YPbPr input. Be sure to select on your TV remote controller to switch to component input mode. It may also be called AV or EXT key. - 12 - - 13 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 8: Setting Up Your System
• Press GREEN (Manual) button and the STB will begin to search all channels you have chosen and save them into the channel list. - 14 - - 15 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 9: Basic Function
Channel List. 3. Press the CH+/CH- buttons on the Remote Control Unit to select the channel you want. YPbPr D-SUB No out activated - 16 - - 17 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 10: Menu Operation
UP / DOWN / LEFT / RIGHT buttons, and then press OK button on the Remote Control Unit. Also use the PAGEUP/PAGEDN ( ) buttons. - 18 - - 19 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 11: Channel Information
OK button on the appropriate event. The EPG Service may not be available depending on the broadcaster’s Repress Yellow button to undo selection. situation. - 20 - - 21 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 12: Setup
This menu Language provided only in English. Note : Due to the complexity of this product only English is provided. Check TEAC's website for future updates. http://stb.teac.com.au 4. Screen Save Time This is to save your screen from possible damage caused by long-term still picture. -
Page 13: Other Setting
French, German, Hungarian, Italian,Portuguese, Spanish, Turkish, Arabic and Farsi. Note : Subtitle languages are only available if the broadcast network is Transmitting extra languages. - 24 - - 25 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 14: Installation
Displays the system information: Model Name, S/W Version, H/W Version, B/L Version and Company Name. Note : If you contact TEAC Total Care Hotline, please have your serial number and details (as per above) ready before speaking with our telephone operator. - Page 15 Press the MENU button to return to the previous menu. Note : The Manual Channel Search may take a few minutes, depending upon how many CH(Networks) were ticked(tag),before press GREEN key. - 28 - - 29 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver...
-
Page 16: Change Pin Code
Note : The parental rating values used in Australia refer to a set of Australian Classification codes, which may be different to those used in other parts of the world. - 30 - - 31 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 17: Teletext Navigation
Yellow button : Change Display size -This command switches between three possible display sizes. More Information available at http://stb.teac.com.au -normal size (all Teletext rows are displayed). -double size of the upper half, only the upper half of the Teletext page is displayed. -
Page 18: Technical Specifications
: AC 100 ~ 230V ~ 50/60Hz Type : SMPS Power Consumption : Max. 30W Standby Power : Max. 4W Protection : Separate internal fuse. - 34 - - 35 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver... -
Page 19: Frequently Asked Questions
Unlike other electronic appliances in your house, the clock is called ASPECT on the remoite and it will switch formats. set by the broadcaster and not TEAC's box. Therefore if the clock is still wrong, change to another television network to see the correct time. - Page 20 Some displays also require a signal with HDCP. This type of displau may be incompatible with this receiver. - 38 - - 39 - DV-B800 High Definition Digital Terrestrial Receiver DV-B800 High Definition Digital Terrestrial Receiver...
- Page 21 Freecall telephone 1800-656700 between Monday to Friday - EST 9am to 5pm TEAC CORPORATION 3-7-3, Nakacho, Musashino-shi, Tokyo 180-8550, Japan. Phone : (0422)52-5081 TEAC AUSTRALIA PTY.,LTD. A.B.N. 80 005 408 462 TEAC Melbourne Office (Head office)
