JVC VN-T216U Quick Manual

Fixed hd ip dome camera
Hide thumbs Also See for VN-T216U:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
FIXED HD IP DOME CAMERA
VN-T216U
Thank you for purchasing this product.
Before operating this unit, please read the "INSTRUCTIONS", "QUICK GUIDE" and "SAFETY
PRECAUTIONS" carefully to ensure the best possible performance.
For Customer Use:
Enter below the Serial No. which is located on the
body. Retain this information for future reference.
Model No.
Serial No.
VN-T216U
QUICK GUIDE
LST1369-001B

Advertisement

Table of Contents
loading

Related Manuals for JVC VN-T216U

Summary of Contents for JVC VN-T216U

  • Page 1 FIXED HD IP DOME CAMERA VN-T216U QUICK GUIDE Thank you for purchasing this product. Before operating this unit, please read the "INSTRUCTIONS", "QUICK GUIDE" and "SAFETY PRECAUTIONS" carefully to ensure the best possible performance. For Customer Use: Enter below the Serial No. which is located on the body.

  • Page 2: Table Of Contents

    Contents Introduction ............................ 2 Unpack Everything ........................... 2 Operating Precautions ........................2 Preparation ............................3 Camera Installation .......................... 3 Disassembling the Camera ....................... 3 Connecting the Power Wiring ....................4 Adjusting the Camera Position ....................4 Adjusting Zoom and Focus ....................... 5 Mounting the Camera ........................

  • Page 3: Introduction

    ･ Near a source of radiation, X-rays, strong radio waves use the camera and make sure to send it to the nearest or magnetism. JVC dealer for inspection. ･ In a place subject to vibration. ■ Real Time Clock ...

  • Page 4: Preparation

    ･ Electrical or Mechanical Shock to SD card. sure to check the license agreement of the copyrighted ･ Power off or ejecting of SD card during recording. material thoroughly.  ･ Rewriting times exceeds upper limit of the SD card (The When rights or rights holders are involved with regard to upper limit depends on grade of the SD card.) the targeted duplicating subject, permission may be...

  • Page 5: Connecting The Power Wiring

    Connecting the Power Wiring Connect the power supply cable to the power connectors. Select one of the following options.  For DC12V Connect 12 V (-) to terminal =DC12V- Connect 12 V (+) to terminal =DC12V+  For AC24V Connect 24 V (~) cables to terminals ~AC24V. ...

  • Page 6: Adjusting Zoom And Focus

     Tilt Adjustment (C) After loosening the thumbnuts, position the camera as desired, then finger –tighten the thumbnuts to set the position. Do not turn the lens more than 360° as this may cause internal cables to disconnect Caution or break. Adjusting Zoom and Focus ...
  • Page 7 To prevent the camera from falling off, ensure that it is connected to a firm place (ceiling slab or channel) using a Safety Wire (Fall Prevention Wire is not supplied). Warning Pay also careful attention to the length, strength, wiring, and material (insulating properties) of the fall prevention wire to be used.

  • Page 8: Locking The Camera

    Safety Wire (Fall Prevention Wire, not supplied) Locking the Camera  Use soft, lint-free cloth to wipe the dome cover clean and remove fingerprints.  Attach the inner liner and camera housing.  Turn the power on after you have installed the camera.

  • Page 9: Network Configuration

    “Reply from…” appears, it means the connection is done. Start Internet Explorer and enter IP address: 192.168.0.2. A login window will appear. Enter the default user name: admin and password: jvc to log in. Images of the camera can be viewed through Internet Explorer. Before viewing, follow these steps to enable the display.
  • Page 10  In Windows 7 only, Click【Tools】【Internet Options】【Security】 Enable Protected Mode (require restarting Internet Explorer)  Unchecked  Click Custom Level. This will open the Security Settings – Internet Zone screen.  Scroll down to the ActiveX controls and plug-ins radio buttons and set as follows: 【Download signed ActiveX controls】...
  • Page 11 【Automatic prompting for ActiveX controls】 Enable 【Run ActiveX controls and plug-ins】 Enable 【Script ActiveX controls marked safe for scripting*】 Enable  Press OK to save the settings. Close all Internet Explorer windows and start a new window. This will allow the new settings to take effect.

  • Page 12: Using "Ip Finder" To Search Camera's Ip Address

    6. Type your setting IP address into the browser. Then you should be able to see the camera image screen. Using “IP Finder” to Search Camera’s IP Address The IP Finder is a tool which helps users to find VN-T16/216 series network cameras in the LAN which your computer is connected.

  • Page 13: Warnings

    2 Warnings Installation and maintenance should be performed only by qualified and experienced technicians to conform to all local codes and to maintain your warranty. DANGER! AC24V models require the use of CSA Certified/UL Listed Class 2 power adapters to ensure compliance with electrical safety standards.

  • Page 14: Specifications

    4 Specifications Operational Specifications Image device 1/2.7-type Mega-pixel CMOS sensor Sensitivity Color: 0.6 lx, B/W: 0.6 lx (50％) Day/Night Easy D/N Auto Gain Control Off/On, selectable Auto Iris Control AES (Automatic Electric Shutter) ATW (2800K～8500K) and Manual White Balance NTSC: 1/30~1/10000 sec Electric Shutter PAL: 1/25~1/10000 sec Noise Reduction...
  • Page 15 Multiple user access levels with password Security protection Users 1 Administrator, 5 Users Video Access from Full control of all camera settings available to Web Browser administrator Windows XP or Windows 7 as OS, Minimum Web Internet Explorer Version 6.0-9.0, Browsing CPU: Intel Pentium 4 2.4 GHz or equivalent AMD, Requirements...
  • Page 16 © 2012 JVC KENWOOD Corporation...
