WF1704W5(A/C/D/F/G/H/R/S/T/V/W/Z)
WF1702W5(A/C/D/F/G/H/R/S/T/V/W/Z)
WF1700W5(A/C/D/F/G/H/R/S/T/V/W/Z)
WF1604W5(A/C/D/F/G/H/R/S/T/V/W/Z)
WF1602W5(A/C/D/F/G/H/R/S/T/V/W/Z)
WF1600W5(A/C/D/F/G/H/R/S/T/V/W/Z)
Washing Machine
user manual
This manual is made with 100% recycled paper.
imagine
the possibilities
Thank you for purchasing this Samsung product.
WF1602W5-03013B-04_EN.indd 1
2014/8/6 11:19:14

Advertisement

Table of Contents
loading

Related Manuals for Samsung WF1704W5(A/C/D/F/G/H/R/S/T/V/W/Z)

Summary of Contents for Samsung WF1704W5(A/C/D/F/G/H/R/S/T/V/W/Z)

  • Page 1 WF1704W5(A/C/D/F/G/H/R/S/T/V/W/Z) WF1702W5(A/C/D/F/G/H/R/S/T/V/W/Z) WF1700W5(A/C/D/F/G/H/R/S/T/V/W/Z) WF1604W5(A/C/D/F/G/H/R/S/T/V/W/Z) WF1602W5(A/C/D/F/G/H/R/S/T/V/W/Z) WF1600W5(A/C/D/F/G/H/R/S/T/V/W/Z) Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing this Samsung product. WF1602W5-03013B-04_EN.indd 1 2014/8/6 11:19:14...
  • Page 2 Bubble allows detergent to distribute evenly and penetrate fabrics faster and deeper. • Outdoor Care Using a Samsung washing machine with Eco Bubble allows you to wash waterproof clothing with greater comfort, in the knowledge that your washer provides excellent care for your outdoor clothes.
  • Page 3 This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
  • Page 4 Congratulations on your new Samsung ActivFresh™ washer. This manual contains important information on the installation, use and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many benefits and features.
  • Page 5 WARNING: To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: WarninG Do not let children (or pets) play in or on your washing machine. The washing machine door does not open easily from the inside and children may be seriously injured if trapped inside.
  • Page 6 safety information SEVErE WarninG SiGnS fOr inStaLLatiOn WarninG The installation of this appliance must be performed by a qualified technician or service company. - Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. The appliance is heavy, take care upon lifting it Plug the power cord into an AC 230V/50Hz/15A wall socket or higher and use the socket for this appliance only.
  • Page 7 Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance. - This may result in electric shock or fire. Do not pull the power cord, when unplugging the power plug.
  • Page 8 safety information Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or other flammable or explosive substances. - This may result in electric shock, fire or an explosion. Do not open the washer door by force while it is operating (high-temperature washing/ drying/spinning).
  • Page 9 CautiOn SiGnS fOr uSinG CautiOn When the washer is contaminated by a foreign substance such as detergent, dirt, food waste, etc., unplug the power plug and clean the washer using a damp and soft cloth. - Failure to do so may result in discoloration, deformation, damage or rust. The front glass may be broken by a strong impact.
  • Page 10 safety information Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in electric shock, fire, problems with the product, or injury. Do not spray volatile material such as insecticide onto the surface of the appliance.
  • Page 11 Do not use natural hand-washing soap for the washer. - If it hardens and accumulates inside the washer, it may result in problems with the product, discoloration, rust or bad odors. Do not wash large laundry items such as bedding in the washing net. - Place socks and brassieres into the washing net and wash them with the other laundry.

  • Page 12: Table Of Contents

    contents sETTING Up yOUR WAshING Checking the parts mAChINE Meeting installation requirements Electrical supply and grounding Water Supply Drain Flooring Surrounding temperature Alcove or closet installation Installing your washing machine WAshING A lOAd OF lAUNdRy Washing for the first time Basic instructions Using the control panel Child lock...

  • Page 13: Setting Up Your Washing

    Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. release lever...

  • Page 14: Electrical Supply And Grounding

    setting up your washing machine mEEtinG inStaLLatiOn rEQuirEmEntS Electrical supply and grounding To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and local codes and ordinances. It is the personal responsibility of the appliance owner to provide adequate electrical service for this appliance.

  • Page 15: Drain

    Drain Samsung recommends a standpipe height of 65 cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory.

  • Page 16: Removing The Shipping Bolts

    setting up your washing machine sTEp 2 removing the shipping bolts Before installing the washing machine, you must remove the five shipping bolts from the back of the unit. 1. Loosen all the bolts with the supplied wrench. 2. Hold the bolt with the spanner and pull it through the wide section of the hole.

  • Page 17: Adjusting The Levelling Feet

    sTEp 3 adjusting the levelling feet When installing your washing machine, ensure that the power plug, the water supply and the drain are easily accessible. 1. Slide the washing machine into position. 2. Level your washing machine by turning the leveling feet in and out as necessary by hand.
  • Page 18 setting up your washing machine Connecting the water supply hose (selected models) 1. Remove the adaptor from the water supply hose. adaptor Water supply hose 2. First, using a ‘+’ type screwdriver, loosen the four screws on the adaptor. Next, take the adaptor and turn part (2) 5 mm following the arrow until there is a 5 mm gap.
  • Page 19 6. Turn on the water supply and ensure that no water leaks from the water valve, tap or adaptor. If there is a water leaks, repeat the previous steps. Do not use your washing machine if there is a water leak. This may cause electric shock or injury.
  • Page 20 setting up your washing machine Connecting the drain hose The end of the drain hose can be positioned in three ways: 1. Over the edge of a wash basin: The drain hose must be placed at a height of between 60 and 90 cm.

  • Page 21: Washing A Load Of Laundry 21 Washing For The First Time

    With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. WaSHinG fOr tHE firSt timE Before washing laundry for the first time, you must run a complete empty cycle (i.e. no laundry).

  • Page 22: Using The Control Panel

    washing a load of laundry uSinG tHE COntrOL panEL WF1702W5*,WF1600W5* WF1602W5* dIGITAl GRAphIC Displays the remaining wash cycle time, all cycle information, and error messages. dIsplAy Select the tumble pattern and spin speed for the cycle. For detailed information, refer to “Washing clothes using the cycle selector”...

  • Page 23: Delay End

    Wool - Only for machine-washable wool. A load should be less than 2.0 kg. • The wool course washes the laundry using gentle cradling actions. During the wash, the gentle cradling and soaking actions are continued to protect the wool fibers from shrinkage / distortion and for a super gentle clean.

  • Page 24: Child Lock

    washing a load of laundry Eco Bubble selection is turned on as a default. Press the Eco Bubble option button once to deselect and the Bubble Generator OFF (shown on the panel), press it again to turn the function back ON. • Some wash cycles must have Eco Bubble option ON (will show on ECO bUbblE the panel, and the Generator will turn on automatically).
  • Page 25 Delay end You can set the washing machine to finish your wash automatically at a later time, choosing a delay of between 3 to 19 hours (in 1 hour increments). The hour displayed indicates the time at which the wash will be finished. 1.

  • Page 26: Washing Clothes Using The Cycle Selector

    • Although bubbles are generated once the wash begins, it may take several minutes for users to see them. Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed.

  • Page 27: Washing Clothes Manually

    Washing clothes manually You can wash clothes manually without using the Cycle Selector. 1. Turn the water supply on. 2. Press the power button on the washing machine. 3. Open the door. 4. Load the articles loosely into the drum one at a time, without overfilling it. 5.
  • Page 28 washing a load of laundry Determining the load capacity Do not overload the washing machine or your laundry may not wash properly. Use the chart below to determine the load capacity for the type of laundry you are washing. Fabric Type load Capacity WF1704 WF1604 model...

  • Page 29: Detergent And Additives Information

    DEtErGEnt anD aDDitiVES infOrmatiOn Which detergent to use The type of detergent you should use is based on the type of fabric (cotton, synthetics, items, wool), colour, wash temperature, and degree of soiling. Always use “low suds” laundry detergent, which is designed for automatic washing machines. Follow the detergent manufacturer’s recommendations based on the weight of the laundry, the degree of soiling, and the hardness of the water in your area.

  • Page 30: Cleaning And Maintaining Your

    cleaning and maintaining your washing machine Keeping your washing machine clean improves its performance, wards off unnecessary repairs, and lengthens its life. DraininG tHE WaSHinG maCHinE in an EmErGEnCy 1. Unplug the washing machine from the power supply. 2. Open the filter cover using a coin or a key. filter cover 3.

  • Page 31: Cleaning The Detergent Drawer And Drawer Recess

    CLEaninG tHE DEtErGEnt DraWEr anD DraWEr rECESS 1. Press the release lever on the inside of the release lever detergent drawer and pull the drawer out. Liquid detergent divider 2. Remove the liquid detergent divider from the detergent drawer 3. Wash all parts under running water. 4. Clean the drawer recess with an old toothbrush. 5.

  • Page 32: Cleaning The Debris Filter

    cleaning and maintaining your washing machine CLEaninG tHE DEBriS fiLtEr We recommend cleaning the debris filter 5 or 6 times a year, or when the error message of “5E” is displayed. (Refer to “Draining the washing machine in an emergency” in the previous page.) Before cleaning the debris filter, make sure to unplug the power cord.

  • Page 33: Cleaning The Water Hose Mesh Filter

    CLEaninG tHE WatEr HOSE mESH fiLtEr You should clean the water hose mesh filter at least once a year, or when the error message of “4E” is displayed: 1. Turn off the water supply to the washing machine. 2. Unscrew the hose from the back of the washing machine. To prevent water from gushing out due to the air pressure in the hose, cover the hose with a cloth.

  • Page 34: Troubleshooting And 33 Check These Points If Your Washing Machine

    • Check if the drain pump is blocked by flocks or dirt . Clean the debris filter to abate noise. a strange noise. If the problem persists, contact your local Samsung Customer Service. 34_ troubleshooting and information codes WF1602W5-03013B-04_EN.indd 34 2014/8/6 11:19:26...

  • Page 35: Information Codes

    • If the correct voltage is supplied, the cycle will resume automatically. For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer.
  • Page 36 cycle chart CyCLE CHart user option)  max load(kg) dETERGENT spin speed(mAx) rpm max Temp WF1704 WF1604 pROGRAm WF1704 WF1702 WF1700 (˚C) WF1702 WF1602 pre-wash wash softener WF1604 WF1602 WF1600 WF1700 WF1600 1400 1200 1000 Cotton   Synthetics 1400 1200 1000 ...

  • Page 37: Appendix 36 Fabric Care Chart

    appendix faBriC CarE CHart The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing, and dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundering problems.

  • Page 38: Specifications

    appendix SpECifiCatiOnS TypE FRONT lOAdING WAshER WF1704/WF1702/WF1700 WF1604/WF1602/WF1600 DimEnSiOnS W600mm X D550mm X H850mm W600mm X D450mm X H850mm WatEr prESSurE 50 kPa ~ 800 kPa WatEr VOLumE ℓ ℓ WF1704 WF1702/WF1700 WF1604 WF1602 WF1600 GrOSS WEiGHt 64 kg 60 kg 62 kg 57 kg 56 kg MODEL...
  • Page 39 memo WF1602W5-03013B-04_EN.indd 39 2014/8/6 11:19:28...
  • Page 40 QUESTIONS OR COMMENTS? Country CAll OR VIsIT Us ONlINE AT SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/support Code No. DC68-03013B-04_EN WF1602W5-03013B-04_EN.indd 40 2014/8/6 11:19:28...
