Quick Start

To attach the MultiSync FP Series monitor to your system,
follow these instructions:
1. Turn off the power to your computer and MultiSync monitor.
If you are using the signal cable, continue to Step 2.
If you are using a BNC cable, please skip to Step 3.
NOTE: BNC cables may be purchased at your local electronics store.
2. For the PC: Connect one end of the 15-pin mini D-SUB signal cable to
the connector of the display card in your system (Figure A.1) and the
other end to the back of the monitor (Figure A.2). Tighten all screws.
Proceed to Step 4.
For the Mac: Connect the Macintosh cable adapter (not included) to the
computer (Figure B.1). Attach one end of the 15-pin mini D-SUB signal
cable to the Macintosh cable adapter (not included) (Figure B.1) and the
other end to the back of the monitor (Figure B.2). Tighten all screws.
Proceed to Step 4.
3. Connect the BNC cable to the appropriate connectors on the back of the
monitor. Connect the red BNC cable to the BNC connector on the
monitor labeled R, the green BNC cable to the BNC connector on the
monitor labeled G(/Sync), the blue BNC cable to the BNC connector on
the monitor labeled B. If you have a fourth BNC connector (Composite
Sync), connect it to the BNC connector on the monitor labeled HS/CS. If
you have a fifth BNC connector (Vertical Sync), connect it to the BNC
connector on the monitor labeled VS (Figure C.1).
Note: Incorrect cable connections may result in irregular operation or
damage display components.
E - 2
