Specifications

Monitor
Specifications
Picture Tube
Viewable Image Size:
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area
(Factory Setting)
Active Display Area
(Full Scan)
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
78134171
MultiSync
Monitor
Diagonal: 49.5 cm/19 inch
45.8 cm/18 inch
Radius: 57800 mm
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Sync on Green video (Positive) 0.7 Vp-p and sync.
(Negative) 0.3 Vp-p
Analog input: Unlimited number of Colors
Horizontal: 31 kHz to 110 kHz
Vertical: 55 Hz to 160 Hz
640 x 480 @ 60 to 160 Hz
800 x 600 @ 55 to 160 Hz
832 x 624 @ 55 to 160 Hz
1024 x 768 @ 55 to 136 Hz
1152 x 870 @ 55 to 120 Hz
1280 x 1024 @ 55 to 102 Hz ................... NEC cites recommended resolution at
1600 x 1200 @ 55 to 88 Hz
1792 x 1344 @ 55 to 78 Hz
1800 x 1440 @ 55 to 73 Hz
1856 x 1392 @ 55 to 75 Hz
1920 x 1440 @ 55 to 73 Hz
Horizontal: 356 mm/14.0 inches
Vertical: 267 mm/10.5 inches
366 mm/14.4 inches
275 mm/10.8 inches
AC 100 – 120 V/220 - 240 V, 50/60 Hz
1.8A @ 100 – 120 V/0.8A@ 220-240 V
442 mm (W) x 456 mm (H) x 447 mm (D)
17.4 inches (W) x 18.0 inches (H) x 17.6 inches (D)
27.5 kg
60.6 lbs
+10 C to +35 C/+50 F to +90 F
Humidity: 30% to 80%
Altitude: 3,000 m/10,000 Feet
-20 C to +60 C/-4 F to +140 F
Humidity: 10% to 90%
Altitude: 13,700 m/45,000 Feet
NOTE: Technical specifications are subject to change without notice.
14
® FP ™
950
90 deflection, 0.25 - 0.27 mm (variable)
grille pitch, medium short persistence
phosphor, aperture grille CRT, multi-layered,
anti-static screen coating, semi-dark-tint
screen, and OptiClear
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
85 Hz for optimal display performance
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
12
12/3/98, 4:10 PM
Notes
® screen surface.
