Supplementary Instructions for Windows NT
This manual contains supplementary instructions regarding the use of the computer. It explains the cases
where the operation of the computer differs from that in the Operating Instructions and Reference Manual.
NT
The following functions are not supported with Windows NT
in the "Operating Instructions" about the following functions.
Illustrations in this Manual
NOTE:
CAUTION:
WARNING:
[Start]-[Shut Down]:
Enter :
Fn + F5 :
Panasonic Hand Writing
Battery Monitor
ZV and CardBus Card
USB Devices
Smart Boot
NOTE provides a useful fact or helpful information.
CAUTION indicates a condition that may result in minor or moderate injury.
WARNING indicates a hazard that may result in moderate or serious injury.
This illustration means to click [Start], then to click [Shut Down].
(For some applications, you may need to double-click.)
This illustration means to press the [Enter] key.
This illustration means to press and hold the [Fn] key, then press the [F5] key.
CF-17/CF-M34
Contents
First-time Operation ..........................................
Starting Up/Shutting Down ...............................
Dealing With Problems ......................................
Reinstalling Software ........................................
Specifications .................................................
Personal Computer
. Please ignore the description
®
®
®
4.0
Series
2
6
7
9
13

Advertisement

Table of Contents
loading

Related Manuals for Panasonic Toughbook CF-17 Series

Summary of Contents for Panasonic Toughbook CF-17 Series

  • Page 1 Specifications ..........The following functions are not supported with Windows NT . Please ignore the description ® in the "Operating Instructions" about the following functions. Panasonic Hand Writing Battery Monitor ZV and CardBus Card USB Devices Smart Boot Illustrations in this Manual NOTE: NOTE provides a useful fact or helpful information.

  • Page 2: First-Time Operation

    First-time Operation Please read the steps below to help you learn what accessories are included, and to gain an understanding of some basic computer-related operations. Confirm the inclusion of all accessories (except below Operating Instructions page 9 ) Windows 95 System Pack ..1 ®...
  • Page 3 Input your computer name and select [Next]. Input an Administrator password and select [Next]. CAUTION Remember this password! If the password is forgotten, Windows NT cannot be operated. Select [Next]. Select [Do not connect this computer to a network at this time], then select [Next]. (Settings can be made for a network even after Windows starts up.
  • Page 4 First-time Operation Select [Next] at the [Card Executive 2.0 for NT Diagnostics]. Select [Next], then select [Finish]. Enter Windows will restart. Select "Windows NT Workstation Version 4.00" and press The [Begin Logon] display will appear. Perform the operation in step In [Start] –...
  • Page 5 Select [Exit] menu and select [Get Default Values], and then press Enter . At the confirmation message, select [Yes] and press Enter . Select [Advanced] menu and set [Plug & Play] to [Disable]. Press F10 . At the confirmation message, select [Yes] and press Enter . The [Begin Logon] display will appear.

  • Page 6: Starting Up/Shutting Down

    Starting Up/Shutting Down Starting Up Open the display Operating Instructions page15) Turn your computer on Operating Instructions page 15) Select your operating system Select "Windows NT Workstation Version 4.00" and press Enter . Logon Wait for 10 seconds after confirming that the HDD access has been completed, then press Ctrl + Alt + Del .

  • Page 7: Dealing With Problems

    Check to see if a fully charged battery is properly installed. Remove the battery pack and disconnect the AC adapter, then connect them again. Please input your password. If you have forgotten it, contact Panasonic Technical Support. is displayed Operating Instructions "List of Error Codes"...
  • Page 8 Dealing With Problems (Summary) Display At the time of purchase, the display setting is preset for an external display. If you connect No display after powering an external display, the screen is displayed on the external display. When there is no display to an external display, •...

  • Page 9: Reinstalling Software

    NOTE If you have not created the Tool Disk, you can create by selecting [Create Tool disk] in [Start] - [Programs] - [Panasonic]. If you can not create this disk, please contact Panasonic Technical Support. Important Save all important data. If reinstallation is carried out, all data existing prior to the installation will be lost. The reinstallation will return the computer to close to the conditions at time of purchase.

  • Page 10: System Setup

    Reinstalling Software 18 At the [Windows NT Setup], select [Next]. System setup 19 At the [Setup Options], select [Typical] then select [Next]. 33 Set the Firstaid CD into the CD-ROM drive and select 20 Input your name and organization then select [Next]. [Start] - [Programs] - [Command Prompt].
  • Page 11 13 Select [Xircom MPCI Modem 56 WinGlobal], then press Windows NT Service Pack Setup [Next]. 14 Select [COM5], then press [Next]. NOTE 15 Press [Finish], then press [Close]. <For U.K.> Select [English [United Kingdom]] in [Regional Settings]- [Input Locales]. Installing Touchscreen 1 Set the CD for Windows NT Service Pack 5 into the CD- 1 In [Start] - [Run], input [c:\util\drivers\tscreen\setup.exe], ROM drive.
  • Page 12 Reinstalling Software 8 When the message indicating the end of the installation Installing Phoenix Card Executive operation appears, select [OK]. If the display asks you to restart Windows, select [OK]. 1 In [Start] - [Run], input [c:\util\drivers\pccard\setup.exe], After Windows restarts, remove the CD. (Perform then select [OK].

  • Page 13: Specifications

    Check the bottom of the computer or the box the computer came in at the time of purchase. CPU or Memory: Use DMI Viewer to check these specifications (Select [Start] - [Programs] - [Panasonic] - [DMI Viewer]). Hard Disk Drive (HDD): Access the HDD’s “Properties”...
  • Page 14 <MEMO>...
  • Page 15 <MEMO>...
  • Page 16 Pentium is a registered trademark of Intel Corporation. Phoenix Card Executive is a trademark of Phoenix Technologies Ltd. Acrobat is a registered trademark of Adobe Systems Incorporated. Panasonic is a registered trademark of Matsushita Electric Industrial Co., Ltd. FJ1199-0 DFQX2804ZA...
