Dolphin
99EX/99GX Mobile Computers
®
with Windows
Embedded Handheld 6.5
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Honeywell Dolphin 99EX

Summary of Contents for Honeywell Dolphin 99EX

  • Page 1 ™ Dolphin 99EX/99GX Mobile Computers ® with Windows Embedded Handheld 6.5 User’s Guide...
  • Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.

  • Page 3: Table Of Contents

    How to Extend Your Warranty ....................xi Send Feedback ........................xii Chapter 1 - Getting Started Out of the Box ........................1-1 Dolphin 99EX/99GX Terminals ....................1-1 Initial Setup ..........................1-1 Before Initial Use......................1-2 Using the Charging/Communication Cables ..............1-3 Replacing the Main Battery Pack ..................1-4 Home Screen ........................1-5...
  • Page 4 Using the Touch Panel ...................... 2-12 Installing a Screen Protector..................2-12 Healthcare Housing ......................2-12 Batteries ..........................2-13 Main Battery Pack......................2-13 Internal Backup Battery ....................2-15 Managing Battery Power ..................... 2-15 Checking Battery Power ....................2-16 Installing a Memory Card....................2-17 Installing a SIM Card ......................
  • Page 5 55-Key Full Alpha/Numeric Keyboard ................5-14 55-Key Keyboard Combinations .................. 5-15 Chapter 6 - System Settings Overview..........................6-1 Clock & Alarms ........................6-2 Personal Menu ........................6-3 Buttons........................... 6-3 System Menu........................6-7 About ..........................6-8 Backlight ........................6-9 Battery ......................... 6-10 Certificates........................
  • Page 6 Installing Additional Software .................... 7-10 Adding Programs Using ActiveSync or Windows Mobile Device Center..... 7-11 Connecting the Terminal to a Wireless Network............7-12 Adding Programs Using the Internet................7-12 Software Upgrades......................7-12 99EX and 99GX COM Port Assignment Table..............7-13 Chapter 8 - Working with Wireless Wide Area Networking Overview..........................
  • Page 7 Selecting the Port ......................10-1 COM7 .......................... 10-1 GPS Intermediate Driver....................10-2 GPS Demo ........................10-2 Chapter 11 - Dolphin 99EX HomeBase Device (Model 99EX-HB) Overview..........................11-1 Unpacking the HomeBase ................... 11-1 Parts and Functions......................11-2 Bottom Panel ....................... 11-5 Power ..........................
  • Page 8 Chapter 13 - Dolphin 99EX Mobile Base Device (Model 99EX-MB) Overview..........................13-1 Front Panel ........................13-2 Bottom Panel ........................13-3 Back Panel and Mounting Brackets................... 13-4 Mounting..........................13-5 Safety Precautions....................... 13-5 Installation........................13-5 Powering the Dolphin Terminal ..................13-6 Charging the Dolphin Terminal..................13-6 Establishing Communication .....................
  • Page 9 Chapter 16 - Dolphin 99EX QuadCharger Device (Model 99EX-QC) Overview..........................16-1 Parts and Functions......................16-2 Supplying Power........................ 16-3 Inserting and Charging Batteries ..................16-3 Mounting the QuadCharger ....................16-4 Troubleshooting......................... 16-5 Appendix A - Dolphin 99EX/99GX Terminal Agency Information Label Locations ........................A-1 Model Number, Serial Number, IMEI and MEID Labels ..........A-1...

  • Page 11: Customer Support

    If your device has a touch screen display, please note that a touch screen responds best to a light touch from the pad of your finger or a Honeywell approved stylus. Using excessive force or a metallic object when pressing on the touch-screen may cause damage to the tempered glass surface and may not be covered by the product's warranty.

  • Page 12: Send Feedback

    Send Feedback Your feedback is crucial to the continual improvement of our documentation. To provide feedback about this manual, please contact the Technical Communications department directly at ACSHSMTechnicalCommunications@honeywell.com.

  • Page 13: Chapter 1 - Getting Started

    Dolphin 99EX/99GX Terminals Dolphin 99EX and 99GX model terminals are designed for use with standard battery pack model 99EX- BTSC (Li-poly 3.7V, 11.3 watt hour) and extended battery pack model 99EX-BTEC (Li-ion 3.7V, 18.5 watt hour) manufactured for Honeywell International Inc.

  • Page 14: Before Initial Use

    Battery Error Notification If your terminal displays the following indicators, replace the main battery pack with a Honeywell new Honeywell battery pack. For information on how to remove the main battery pack from the terminal, see Replacing the Main Battery Pack on page 1-4.

  • Page 15: Using The Charging/Communication Cables

    Using the Charging/Communication Cables Use only UL Listed power supply, which has been qualified by Honeywell with output rated at 5VDC and 3 amps with the device. Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty.

  • Page 16: Replacing The Main Battery Pack

    6. Replace the battery door. Apply pressure to engage the door latch. The battery door must be installed prior to powering the unit. 7. Reattach the hand strap. We recommend use of Honeywell Li-poly or Li-Ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty. 1 - 4...

  • Page 17: Home Screen

    Home Screen After the Dolphin terminal initializes the first time, you see the Home screen. to reach the Start screen from the home screen. to access the Dolphin Wireless Manager (see page 7-6) from the home screen. Title Bar The Title bar, located at the top of the screen, displays the active program, the status of various system functions, and the current time.
  • Page 18 Calls are forwarded Call on hold Missed call Data call in progress A battery error has occurred. Replace the main battery pack with a Honeywell Li-poly or Li-ion battery pack. Battery is has a full charge Battery has a high charge...
  • Page 19 Icons in the Title Bar Indicator Meaning No active network connection GPRS available GPRS connecting GPRS in use HSDPA available HSDPA connecting HSDPA in use EDGE available EDGE connecting EDGE in use UMTS available UMTS connecting UMTS in use Radio is off The radio is not connected to a network.

  • Page 20: Horizontal Scroll

    Horizontal Scroll The Horizontal Scroll, located at the top of most application windows, provides access to additional application screens. You can flick left or right on the scroll or tap each label on the scroll, until you get to the desired screen. Tapping a label to the left or right of the center item brings new labels into view. Note: Tap the Title bar to access the horizontal scroll if it is not visible on the screen.

  • Page 21: File Explorer

    File Explorer You can also use the File Explorer to find files and organize these files into folders. 1. Tap > File Explorer 2. Tap the Up button at the bottom of the screen to move up one level in the directory. 3.

  • Page 22: File Provisioning On The 99Ex And 99Gx

    \Honeywell The Honeywell partition or root file system partition is persistent over a Hard Reset, Soft Reset, and the removal of the battery pack or the removal of AC power. However, during a kernel upgrade the root file system is reformatted so all data in the folder is deleted and replaced by any files in the \IPSM\Honey- well\AutoInstall folder as part of the upgrade process.

  • Page 23: Resetting The Terminal

    5 seconds. You may hear a clicking sound when you hold the keys down. 2. When the white Honeywell splash screen appears, enter code 1277 on the keyboard. For terminals with a 34-Key Numeric (Calculator) Keyboard (see page 5-8), enter code 7811 instead of 1277.

  • Page 24: Suspend Mode

    3. Select Perform Factory Reset from the menu, and then press ENT The following message appears on the terminal screen: “All installed applications & customized settings will be deleted. Do you want to proceed?” 4. Press Y for yes, proceed with the Factory Reset. If you change your mind and do not want to proceed, press N for no and the terminal will launch the current image instead of a factory reset.

  • Page 25: Chapter 2 - Hardware Overview

    Hardware Overview Standard Configurations 99EX Models WLAN & WPAN WLAN, WPAN & Camera • Microsoft Windows Embedded Handheld • Microsoft Windows Embedded Handheld 6.5 Classic 6.5 Classic • OMAP3715 (1Ghz) • OMAP3715 (1Ghz) • 512MB* RAM X 1GB Flash • 512MB* RAM X 1GB Flash •...
  • Page 26 WLAN, WPAN, WWAN with GPS & Camera WLAN, WPAN, & WWAN • Microsoft Windows Embedded Handheld • Microsoft Windows Embedded Handheld 6.5 Classic 6.5 Classic • OMAP3715 (1Ghz) • OMAP3715 (1Ghz) • 512MB* RAM X 1GB Flash • 512MB* RAM X 1GB Flash •...

  • Page 27: Peripherals For The 99Ex And 99Gx

    Ethernet network. In addition, the ebase is equipped with a USB host port that is Hi- Speed 2.0v compliant, which enables the terminal to interface with the majority of PC-based enterprise systems. This device also contains an auxiliary battery well that charges a spare Honeywell Li-poly or extended Li-ion battery.

  • Page 28: Accessories For The 99Ex And 99Gx

    Intelligent bat- tery technology on-board the terminal ensures proper charging. The Dolphin 99EX Mobile Charger is an ideal low-cost charging solution for in-transit mobile applications.

  • Page 29: Front Panel: 99Ex And 99Gx

    Front Panel: 99EX and 99GX Note: Your Dolphin model may differ from the model illustrated; however, the features noted are standard for all 99EX and 99GX models unless otherwise indicated. General Notification LED Charge Indicator LED Front Speaker Touch Panel Display SCAN Key Navigation Keys Recessed Keyboard...

  • Page 30: Front Panel Features For The 99Ex And 99Gx

    Front Panel Features for the 99EX and 99GX Blue Modifier Key Using the Modifier Keys on page 5-3. Front Speaker The front speaker is the receiver for handset phone (voice) calls and/or VoIP calls depending on the Dolphin model. General Notification LED The light emitting diode (LED) located above the top right corner of the LCD display flashes and illuminates during resets, scanning/imaging, and taking a picture.

  • Page 31: Back Panel: 99Ex And 99Gx

    Touch Panel Display The color 3.7 inch liquid crystal display (LCD) touch panel is covered with an industrial, protective lens for greater durability. The video graphic array (VGA) display resolution is 480 X 640. The color LCD (16 bit RGB) uses thin film transistor (TFT) technology. The touch panel backlight illuminates when the screen is touched, but not when the Backlight key is pressed.

  • Page 32: Back Panel Features For The 99Ex And 99Gx

    Note: Honeywell recommends the use of Single Level Cell (SLC) industrial grade microSD or microSDHC memory cards with Dolphin terminals for maximum performance and durability. Contact a Honeywell sales representative for additional information on qualified memory card options.

  • Page 33: Side Panels: 99Ex And 99Gx

    Rear Speaker The integrated rear speaker sounds audio signals as you scan bar code labels and enter data. The integrated speaker also supports playback of wave and MP3 files, software mixer, and speakerphone for WWAN/GSM audio. The operating frequency range is 600-3000Hz at >90dB.

  • Page 34: Right Side

    Right Side Volume Control Button Lower Volume | Raise Volume Right Button Standard Li-poly Battery Door Extended Li-ion Battery Door • Rear Speaker Handle (99GX Only) Scan Trigger (99GX Only) Lanyard Strap (99GX Only) Handle (99GX Only) The handle is integrated into the back panel of the terminal and is ergonomically designed to be comfortable through repetitive scans.

  • Page 35: Bottom Panel: 99Ex And 99Gx

    Lanyard Strap (99GX Only) The 99GX comes with a removable lanyard strap that attaches to the bottom of the handle. Bottom Panel: 99EX and 99GX Description 8 10 12 14 16 18 USBC_DET 11 13 15 17 USBC_D- USBC_D+ Audio_GND USBH_D- 5V_OUT USBH_D+...

  • Page 36: Using The Touch Panel

    Honeywell. Please contact a Honeywell sales associate for details. Honeywell also mandates use of a proper stylus, which is one that has a stylus tip radius of no less than 0.8 mm. Use of the Honeywell stylus included with the terminal is recommended at all times.

  • Page 37: Batteries

    Note: The RTC battery will preserve the Real Time Clock 60 days after the main battery and internal backup battery are fully depleted. Main Battery Pack We recommend use of Honeywell Li-ion or Li-poly battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty. •...
  • Page 38 Customer Support on page • If you are not sure the battery or charger is working properly, send it to Honeywell International Inc. or an authorized service center for inspection. • Excessive discharge can degrade battery performance. Recharge the battery when your terminal indicates low battery power.

  • Page 39: Internal Backup Battery

    The internal backup battery must be fully charged before using the terminal for the first time. Honeywell recommends charging the Dolphin terminal for at least 24 hours prior to initial use to ensure the internal backup battery is fully charged.

  • Page 40: Checking Battery Power

    MedState=25% This sets the Low Battery point to 25%. When the battery hits the percentage charge specified here, the user is notified. LowState=10% This sets the Critical Battery point to 10%. When the battery hits the percentage charge specified here, the user is notified. Note: Warnings do not appear when the terminal is on external power.

  • Page 41: Installing A Memory Card

    Installing a Memory Card Honeywell recommends the use of Single Level Cell (SLC) industrial grade microSD or microSDHC memory cards with Dolphin terminals for Step 5 maximum performance and durability. Contact a Honeywell sales repre- sentative for additional information on qualified memory card options.
  • Page 42 2 - 18...

  • Page 43: Chapter 3 - Using The Scan Image Engine

    Using the Scan Image Engine Overview The Dolphin terminal houses a compact image engine that instantly reads popular 1D and 2D bar codes and supports omni-directional aiming and decoding for greater flexibility in real-world settings. The image engine can also capture black and white digital images, such as signatures and pictures of dam- aged inventory.

  • Page 44: Depth Of Field

    Depth of Field The depth of field measurements used the following parameters: • Distances are measured from the front of the engine. • +23°C (+73°F), 0 lux • Photographic quality codes Focus N5603/N5600 N5603/N5600 N5603/N5600 High Density (HD) Standard Range (SR) Extended Range (ER) Symbology Distance (in/cm)

  • Page 45: Supported Bar Code Symbologies

    10 mil QR 10.6 (8.4) (12.7) (4.3) (5.6) (18.0) (12.4) (10.9) (26.9) (16.5) 20 mil QR 15.5 13.3 19.6 17.6 (5.6) (20.1) (14.5) (5.6) (39.4) (33.8) (6.1) (49.8) (44.7) 32 mil 17.0 14.5 23.2 19.5 Maxicode (6.1) (21.8) (15.7) (6.4) (43.2) (36.8) (9.9)

  • Page 46: Decoding

    Decoding The terminal supports two types of image decoding for use in various bar code reading and imaging applications: full-area imaging and Advanced Linear Decoding (ALD). Full-Area Imaging Full-area imaging provides omni-directional reading of linear and non-linear 1D and 2D bar codes, OCR, signature capture, and picture taking.

  • Page 47: Aiming Options

    Aiming Options The aiming beams are smaller when the terminal is held closer to the code and larger when it is farther from the code. Symbologies with smaller bars or elements (mil size) should be read closer to the unit whereas symbologies with larger bars or elements (mil size) should be read farther from the unit.

  • Page 48: Capturing Images

    Capturing Images The image-capture process is an intuitive, split-second operation for experienced users. By following the basic guidelines, new users can easily develop their own technique and, with practice, quickly learn to adapt it to different application environments. Image Preview When the imaging process is initiated, the touch screen displays a preview of the object.

  • Page 49: Uploading Images

    Note: Visit the Microsoft Windows Vista Web site for information on how to sync your music, pictures, contacts and calendars using Windows Mobile Device Center. We recommend use of Honeywell peripherals, power cables, and power adapters. Use of any non-Honeywell peripherals, cables, or power adapters may cause damage not covered by the warranty.
  • Page 50 3 - 8...

  • Page 51: Chapter 4 - Using The Color Camera

    Using the Color Camera Overview Dolphin 99EX terminals equipped with a 3.1-Megapixels Resolution color camera with Automated Cam- era Control (ACC), and an Application Programming Interface (API) provide easy integration of color pic- ture and video capture into business applications. The camera lens and camera flash are located on the back panel of the terminal.

  • Page 52: Taking A Picture Using The Windows Embedded Handheld 6.5 Camera Tool

    Options Tap Options > Camera. The Camera Options menu appears. There are five tabs of configurable options accessible from the Camera Options menu. Profile Tab Display Tab The profile tab allows you to customize your camera settings, or chose from several predefined profiles designed to provide the best picture quality for common tasks.

  • Page 53: Recording Video

    Menu Tap Menu on the Command Bar to adjust the camera settings, switch to video mode, and access addi- tional camera options. Item Descriptions Video Activate Video Mode Mode Set Mode (i.e., Normal, Burst, or Timer) Resolution Set Picture Resolution (i.e., QVGA, VGA, SVGA, XGA, UXGA, or QXGA) Zoom Set Zoom (i.e., x1, x2, or x3) Flash...
  • Page 54 4 - 4...

  • Page 55: Chapter 5 - Using The Keyboards

    Using the Keyboards Available Keyboards There are four keyboard options in the 99EX/99GX series: 34-Key Alpha/Numeric 34-Key Numeric 43-Key Alpha/Numeric 55-Key Full Alpha/ Keyboard (Calculator) Keyboard Keyboard Numeric Keyboard SEND SEND SEND SCAN ☼ SCAN SCAN ☼ SCAN ☼ ☼ A B C D E F A B C...

  • Page 56: Using The Function Keys

    Using the Function Keys Name Function Backlight Turns the keyboard backlight on and off. ☼ Flashlight Turns the flashlight on and off. The flashlight is located on the back panel & of the terminal. ☼ Blue Note: The flashlight function is disabled on all 99GX models. Backspace Moves the cursor back one space each time the key is pressed.

  • Page 57: Using The Modifier Keys

    Using the Modifier Keys Name Function ALPHA The ALPHA key enables you to toggle between the alpha and numeric ALPHA 34-Key modes. See ALPHA Key on page 5-5. Blue The blue and red keys are used in combination with other keys to type special characters and perform system functions.
  • Page 58 Function & Moves the cursor down one page. Moves the cursor one character to the right. Moves the cursor one character to the left. Note: Additional functionality varies according to the application in use. 5 - 4...

  • Page 59: 34-Key Alpha/Numeric Keyboard

    34-Key Alpha/Numeric Keyboard SCAN key Left Navigation\SEND key Right Navigation\END key SEND Escape key SCAN Backlight\Flashlight key ☼ Tab key Enter key Up Navigation key Down Navigation key A B C D E F G H I J K L ALPHA Mode keys PQRS T U V...

  • Page 60: 34-Key Alpha/Numeric Keyboard Combinations

    34-Key Alpha/Numeric Keyboard Combinations Shift-NUM ALPHA Shift- Blue (Default) ALPHA Escape Left Left Left Left Left Send Left (Phone) Scan Scan Right Right Right Right Right End (Phone) Right Backlight Toggles Keyboard Backlight On/Off Toggles Toggles Flashlight Keyboard On/Off (99EX Backlight On/ models only) Volume Up...
  • Page 61 Shift-NUM ALPHA Shift- Blue (Default) ALPHA Shift Shift Shift Shift Space Space Space Space Space BKSP Backspace Backspace Backspace Backspace Backspace Delete Delete Delete Delete Underscore Delete Power Off/On CTRL Control Control Menu Blue Blue Blue Blue ALPHA Toggles between ALPHA mode and NUM Lock mode 5 - 7...

  • Page 62: 34-Key Numeric (Calculator) Keyboard

    34-Key Numeric (Calculator) Keyboard SCAN key Left Navigation\SEND key Right Navigation\END key SEND Escape key SCAN Backlight\Flashlight key ☼ Tab key Enter key Up Navigation key Down Navigation key A B C D E F G H I J K L PQRS T U V WXYZ...

  • Page 63: 34-Key Numeric (Calculator) Keyboard Combinations

    34-Key Numeric (Calculator) Keyboard Combinations Shift-NUM ALPHA Shift- Blue (Default) ALPHA Escape Left Left Left Left Left Send Left (Phone) Scan Scan Right Right Right Right Right End (Phone) Right Backlight Toggles Keyboard Backlight On/Off Toggles Toggles Flashlight Keyboard On/Off (99EX Backlight On/ models only) Volume Up...
  • Page 64 Shift-NUM ALPHA Shift- Blue (Default) ALPHA Shift Shift Shift Shift Space Space Space Space Space BKSP Backspace Backspace Backspace Backspace Backspace Delete Delete Delete Delete Underscore Delete Power Off/On CTRL Control Control Menu Blue Blue Blue Blue ALPHA Toggles between ALPHA mode and NUM Lock mode 5 - 10...

  • Page 65: 43-Key Alpha/Numeric Keyboard

    43-Key Alpha/Numeric Keyboard SCAN key Left Navigation\SEND key Right Navigation\END key SEND Escape key SCAN Backlight\Flashlight key ☼ Tab key Enter key Up Navigation key Down Navigation key Number (NUM) Mode keys Space key Backspace key Shift key BKSP A LT Power key Number (NUM) Lock key C T R L...

  • Page 66: 43-Key Keyboard Combinations

    -Key Keyboard Combinations ALPHA Shift-ALPHA Shift-NUM Blue (Default) Escape Left Left Left Left Left Send Left (Phone) Scan Scan Right Right Right Right Right Right (Phone) Backlight Toggles Keyboard Backlight On/Off Toggles Toggles Flashlight Keyboard On/Off (99EX Backlight On/ models only) Volume Up Prior (Phone)
  • Page 67 ALPHA Shift-ALPHA Shift-NUM Blue (Default) & * (multiply) . (period) > * (multiply) , (comma) < (underscore) Shift Shift Space BKSP Backspace Power Off/On CTRL Control Control Menu Blue Blue Blue Blue Toggles between NUM lock mode and ALPHA mode 5 - 13...

  • Page 68: 55-Key Full Alpha/Numeric Keyboard

    55-Key Full Alpha/Numeric Keyboard Right Navigation\END key Left Navigation\SEND key SCAN key Escape key Backlight\Flashlight key SCAN ☼ Tab key Enter key Up Navigation key Down Navigation key BKSP Space key Backspace key Delete key Shift key & — ‘ A LT Power key C T R L...

  • Page 69: 55-Key Keyboard Combinations

    -Key Keyboard Combinations Normal Shift Blue Escape Left Left Left Send Left (Phone) Scan Scan Right Right Right Right (Phone) Backlight Toggle Keyboard Backlight On/Off Toggle Toggle Flashlight On/ Keyboard Off (99EX Backlight On/ models only) Volume Up Prior Down Down Down Volume Down...
  • Page 70 Normal Shift Blue SHIFT Shift Period . (period) > * (multiply) . (period) Comma , (comma) < _ (underscore) , (comma) + (add) - (subtract) & _ (underscore) ‘ (back quote) “ (quotes) " (back quotes) u or U 5 - 16...
  • Page 71 Normal Shift Blue v or V w or W x or X y or Y Power Off/On CTRL Control Menu Blue Blue z or Z z or Z 5 - 17...
  • Page 72 5 - 18...

  • Page 73: Chapter 6 - System Settings

    System Settings Overview Customized settings are available on the System Settings menu. Tap > Settings and the settings screen opens. Icon Description Bluetooth Configures the Bluetooth radio. See Working with the Bluetooth Radio on page 9-1. Clock & Set the system clock, date, time and schedule alarms. See Clock &...

  • Page 74: Clock & Alarms

    Icon Description System Adjusts system settings. See System Menu on page 6-7. Microsoft My Synchronizes your phone’s contacts, calendar, tasks, text messages, music, photos, videos, and other documents with your My Phone account at Phone http:\\myphone.microsoft.com. Clock & Alarms The Clock & Alarms settings can be accessed from the Home screen or the Settings Menu. 1.

  • Page 75: Personal Menu

    Personal Menu To access the Personal Menu, tap > Settings > Personal. The screen opens displaying the Per- sonal Menu. Icon Description Buttons Program the side buttons to perform specific tasks. See Buttons on page 6-3. Owner Enter your contact information (e.g., name, company, address, telephone number and E-mail address).
  • Page 76 Changing Button Assignments 1. After HotKeys is enabled, tap > Settings > Personal > Buttons Note: The buttons that appear on this window are the only buttons that can be programmed via the Buttons setting. You cannot add buttons to this window. 2.

  • Page 77: Using File Explorer

    Command Description <Right Softkey> Opens the menu or performs the action displayed on the right side of the Command bar. <Scan2> Activates the scanner/imager. <Rotate Screen> Changes the screen orientation from portrait to landscape. <Scroll Down> Scrolls down in the open application. <Scroll Left>...
  • Page 78 3. Navigate to the Windows folder and open the Start Menu (My Device > Windows > Start Menu > Programs), tap and hold a blank area of the window, and tap Paste Shortcut on the pop-up menu. Note: If there is no blank space available in the window, tap on Menu > Edit > Paste Shortcut. 4.

  • Page 79: System Menu

    System Menu The System menu enables you to verify and sometimes alter system parameters. To access the System menu, go to Start > Settings > System. Tap the appropriate icon to open that system setting. Icon See Page About About on page 6-8.

  • Page 80: About

    Icon See Page External External GPS on page 6-11. Five Volt Five Volt Control on page 6-12. Control Smart Smart Sensor on page 6-12. Sensors Managed Managed Programs on page 6-14. Programs Memory Memory on page 6-15. Power Power on page 6-16.

  • Page 81: Backlight

    Backlight The Backlight system setting enables you to customize backlight functionality for the display. The back- light for the color display is user-defined. The Backlight system setting screen contains three tabs: Bat- tery Power, External Power, and Brightness. > Settings > System > Backlight. Battery Power Tab External Power Tab Brightness Tab...

  • Page 82: Battery

    Battery The Battery system settings menu contains two tabs: Battery Status and Log Config. The Battery Sta- tus tab provides the status of the main battery pack (e.g., Battery Time to Full or Battery Time to Empty, Voltage, Current, Temperature, Chemistry, and Serial Number). The Log Config Tab allows you to con- figure the BatteryLogFile.

  • Page 83: Encryption

    Encryption Encryption gives you the option of encrypting files placed on storage cards so that those files cannot be read by any other device. Error Reporting Error Reporting gives you the option of enabling or disabling the error reporting function of Windows Embedded Handheld 6.5.

  • Page 84: Five Volt Control

    Five Volt Control Five Volt Control gives you the option to manually enable 5V output to supply power to an external device. By default, 5-Volt Output automatically turns on when AC power is applied to the terminal. If you want to use a USB memory stick without AC power, then you must manually turn on the 5-Volt Output. Do not leave 5-Volt output enabled when you are not using it to supply power to an external device.
  • Page 85 Event Track displays an event log summary of detected free fall events exceeding 2 ft. over 250 ms. The summary includes the time, date, and duration of the most recent 50 events. Several options are provided for audible notification of free fall events.

  • Page 86: Managed Programs

    Accelerometer Calibration Tap Start to calibrate the integrated accelerometer sensor used for motion detection. When calibration is complete, the "Accelerometer Calibration Finished!" message window appears. Managed Programs Managed Programs are a list of programs that are managed if enrolled to enterprise domain. Managed Programs is the client-side that works with the server product System Center Mobile Device Manager (MDM).

  • Page 87: Memory

    IPSM—Short for Internal Persistent Storage Manager. Data or programs stored in the IPSM are not affected when the operating system is upgraded. Autoinstall programs, for example, are stored in \\IPSM\Honeywell\Autoinstall so that they are always installed after an operating system upgrade or factory reset.

  • Page 88: Ril

    The RIL Information screen displays useful statistics for the GSM WAN Voice module (PH8). To verify whether or not the GSM radio is enabled, check the Dolphin Wireless Manager (see page 7-6). Power Power system settings contains two tabs: Battery and Advanced >...

  • Page 89: Remove Programs

    If a program is manually removed using the Remove Programs application, the program does not re-install on a hard or soft reset. Note: A program (file) does not automatically install if it is added to the \\IPSM\Honeywell\Autoinstall folder and a hard or soft reset is performed. For information on program installation, see...
  • Page 90 Screen The Screen system setting contains three screens: General, Clear Type, and Text Size. General Screen Orientation The General screen enables you to set the dynamic screen rotation. Three choices of screen orientation are supported: Portrait, Landscape (right-handed), and Landscape (left- handed).

  • Page 91: Task Manager

    Text Size Screen The Text Size screen enables you to perform font scaling within certain views of the: • Home screen, • Contacts, • Calendar, • Messaging, and • Tasks. Font scaling means that you can increase or decrease the point size of the font on application windows.
  • Page 92 Using the Task Manager Applications To view the status of the programs running on your mobile computer, tap the Menu button at the bottom of the screen, then tap View > Applications. From the application list, you can: • Tap and hold on an application, then tap Switch To on the pop-up menu.

  • Page 93: Chapter 7 - Communication

    Communication Connections Menu The Connections system setting provides access to the terminal’s various wireless communication options. Icon Tapping this icon… Beam Enables infrared communication. on page 7-3. Receiving Data Connections Opens Microsoft’s connections manager. on page 7-4. Connections Manager Manages the wireless radios installed in the terminal. See Dolphin Dolphin Wireless Manager...

  • Page 94: Using The Irda Port

    Using the IrDA Port Using the IrDA port, you can send and receive data between the terminal and other devices equipped with infrared. This can include, but is not limited to, Windows Embedded Handheld information such as Contacts and Tasks, as well as software upgrades. IrDA Port Location IrDA Port Note: Your Dolphin model may differ from the models illustrated;...

  • Page 95: Receiving Data

    4. The IrDA port searches for a receiving IrDA port in the vicinity. The selected device reads “Pending.” 5. When the IrDA port finds the aligned IrDA port, it immediately starts sending the selected file. The selected device reads “Sending.” 6.

  • Page 96: Connections Manager

    Connections Manager Microsoft’s Connections Manager sets up multiple network connections to Internet Service Providers (ISPs) via external modem. Do NOT enter connection parameters in the Connections Manager if: • you are using one of the on-board wireless radios to connect to a network. The Dolphin terminal uses the settings from each radio’s configuration utility to connect.

  • Page 97: Advanced

    • Proxy server connection Note: If you are connected to your ISP or private network during synchronization, the terminal should download the proper proxy settings during synchronization with the workstation. If these settings are not on your workstation or need to be changed, ask your ISP or network administrator for the proxy sever name, server type, port, type of Socks protocol used, and your user name and password.

  • Page 98: Dolphin Wireless Manager

    Dolphin Wireless Manager The Dolphin Wireless Manager provides a centralized interface that enables and disables all the on- board radios. Each radio has its own configuration program. The Dolphin Wireless Manager also pro- vides shortcuts to the configuration utilities for each radio. on the Home screen to access the Dolphin Wireless Manager.

  • Page 99: Accessing Radio Configuration Utilities

    Tap WLAN Settings and the Honeywell WLAN Security Supplicant opens. The Honeywell WLAN Security Supplicant User’s Guide is available for download from the Dolphin 99EX or 99GX product page at www.honeywellaidc.com. Bluetooth Tap Bluetooth Settings and the Bluetooth Settings open.

  • Page 100: Network Cards

    When communicating via ActiveSync or Windows Mobile Device Center, your terminal is designed to be connected to the host workstation with a communication peripheral sold/manufactured by Honeywell, such as the charge/communication cable. Use of any peripheral not sold/manufactured by Honeywell may cause damage not covered by the warranty.
  • Page 101 • Select which information types are synchronized, controlling how much data is synchronized. For example, you can choose how many weeks of past appointments you want synchronized. Communication Types The Dolphin terminal supports the following types of communication via ActiveSync through its Connector (see page 2-11) on the bottom panel: The USB cable and hardware peripherals allow the terminal to communicate with a workstation or...

  • Page 102: Installing Additional Software

    Installing Additional Software Dolphin terminals ship with the operating system, radio drivers, and custom Honeywell software already installed. These are the default programs that install when your terminal first boots up. You can install additional software programs to the terminal provided that the following parameters are met: •...

  • Page 103: Adding Programs Using Activesync Or Windows Mobile Device Center

    4. Tap on the program file to start the installation. • If you copied the file to the \Honeywell\Autoinstall folder, you can perform a Soft Reset (CTRL + ENTER) to install the program. For more information, see Hardware Maintenance page 2-16.

  • Page 104: Connecting The Terminal To A Wireless Network

    WLAN Radio The WLAN radio is configured in the Honeywell WLAN Security Supplicant, which you access by tapping the program icon in the task tray near the bottom of the touch screen. For complete configuration instruc- tions, download the Honeywell Secure Wireless (SWC) Client User’s Guide from...

  • Page 105: 99Ex And 99Gx Com Port Assignment Table

    To prevent data loss, back up all user data to an SD card or external memory device before performing an upgrade. Note: An active Microsoft ActiveSync or Windows Mobile Device Center connection between a host workstation and the Dolphin terminal may be required for some types of software upgrades. For additional information, see Connecting and Synchronizing the Terminal and Workstation on page 7-8.
  • Page 106 7 - 14...

  • Page 107: Chapter 8 - Working With Wireless Wide Area Networking

    Working with Wireless Wide Area Networking Overview The 99EX has two radio options available to support wireless WAN connectivity: • Voice and data GSM/HSPA+/UMTS/GPRS/EDGE (99EXLW models) • Data only GSM/HSPA+/UMTS/GPRS/EDGE and CDMA/1xRTT/EVDO (99EXLG, 99EXBF and 99EXLF models) Note: Current offerings for the 99GX only include WLAN/WPAN radio configurations. The 99EXLW voice and data GSM/HSPA+ radio is optimized for the following two-way wireless commu- nications: •...

  • Page 108: Signal Strength Indicator

    On the Dolphin 99EX, the SIM card socket is located in the battery well under a protective door that is secured with a T6 TORX screw. The socket is compatible with a standard size SIM card.
  • Page 109 4. Wait at least 3 seconds, then remove the battery. 5. Remove the T6 TORX screw securing the protective door closed. Step 5 6. Lift up the lower left corner of the door to access the SIM card socket. 7. Unlock the access door to the memory socket by sliding the door toward the IrDA port side of the terminal.

  • Page 110: Enabling The Wwan Radio

    Radio Models Voice Communication (99EXLW Models) You can use the Dolphin 99EX terminal as a phone over the GSM radio. Audio Modes for Phone Calls By default, handset mode is used for phone calls. The front microphone and speaker (see page 2-5) provide the voice input and audio output.

  • Page 111: Making A Phone Calls From The Dialer Window

    Making a Phone Calls from the Dialer Window Note: The WWAN radio must be active for voice communication, see Enabling the WWAN Radio on page 8-4. 1. Tap on the Home screen or tap > Phone Displays the network carrier from the SIM card.

  • Page 112: Changing The Phone Sounds, Security, Services, And Network Options

    2. Select either Calls and Contacts, All Calls or Speed Dial numbers. Changing the Phone Sounds, Security, Services, and Network Options 1. From the Dialer Window, tap Menu > Options. 2. Swipe left or right at the top of the screen to scroll through the four setting windows (i.e., Sounds, Security, Services, and Network) and modify any options you want changed.

  • Page 113: Data Communication (Gsm/Hspa+ Global Model 99Exlw)

    Services For each service, the phone reads settings from the network stored on the SIM card and then displays the available options from the carrier on the screen. To customize the settings, select it from the list and tap “Get Settings”. Network You can find, select, and set your preferred network order from the Network screen.

  • Page 114: Information Requirements

    Information Requirements You must have from the SIM card carrier: • The APN (access point name). • The user name and password of the account. Establishing Data Communication (GSM/HSPA+ Global Model 99EXLW) 1. Tap > Settings > Connection > Connections 2.
  • Page 115 5. Enter the user name and password from the account. Tap Finish. 6. The connection you just created should appear in the list on the modem tab. 7. Tap and hold on the connection. Select Connect on the popup menu. 8.

  • Page 116: Automatic Or Manual Network Selection

    9. When the connection is complete, the network icon changes to: 10. You can now send data over GSM. Ending the Data Connection By default, the data connection disconnects after a certain amount of time passes without use. This period of time is determined by ISP. To end the data connection manually, tap the network icon in the Title bar and select Disconnect on the popup bubble.

  • Page 117: Data Communication (Gsm/Cdma Models 99Exlg, 99Exbf And 99Exlf)

    b. Select a new network and tap OK. The Phone registers on the new network and the Network tab appears. c. To switch to another network, tap the now active Select button and the process repeats. 4. To switch back to automatic roaming, select Automatic under Select networks and tap OK. Data Communication (GSM/CDMA Models 99EXLG, 99EXBF and 99EXLF) Wireless carriers that use CDMA networks (i.e., Verizon and Sprint) require a one time device activation step before the terminal is acknowledged and allowed to work on the carrier’s network.

  • Page 118: Accessing The Gobi Manager To Set Up Or Change Network Settings

    Accessing the Gobi Manager to Set Up or Change Network Settings On GSM/CDMA (data only) 99EX models, the Gobi Manager enables you to see real time status of the radio, setup your Network selection, view your profile and scan for networks. To access the Gobi Manager: 1.

  • Page 119: Establishing Data Communication (Gsm/Cdma Models 99Exlg, 99Exbf, & 99Exlf)

    Profile Tab The Profile tab allows you to see Radio capability information and network statistics including: • Radio Hardware and Software versions • Radio and SIM identification numbers • Serving network connection type and state • Available radio interfaces for the current serving network About Tab Displays copyright and version information for the Connection Manager.
  • Page 120 8 - 14...

  • Page 121: Chapter 9 - Working With The Bluetooth Radio

    Working with the Bluetooth Radio Enabling the Bluetooth Radio You enable the Bluetooth radio in the Dolphin Wireless Manager (see page 7-6). 1. Tap on the Home screen to access the Dolphin Wireless Manager. 2. Tap anywhere inside the Bluetooth rectangle and Bluetooth begins activating. 3.

  • Page 122: Pairing And Trusted Devices

    Pairing and Trusted Devices The terminal does support pairing. Pairing happens during general connection setup. Paired devices are "trusted" devices. This means that there is unrestricted access to all services (including services that require authorization and authentication). A connection can exclude pairing. A device that is connected to the terminal but not paired with it is con- sidered an untrusted device.
  • Page 123 4. Select a device from the list and tap Next. The types of devices in the vicinity of the radio appear in the list of discovered devices. 5. You are prompted to enter a passcode. • If the device has a specific passcode, enter it in the Passcode field and tap Next. When attempting to connect to a printer or headset with Bluetooth capabilities, the passcode may default to either 1111 or 0000.
  • Page 124 8. When the connection is complete, a list of matching and supported services on the device appears. Only the services that are mutually supported on both devices appear in the Partnership Settings window. 9. Select the services you want to use and tap Save. The services on the new devices have to be selected or the pairing won’t include those services, even though the devices are paired.

  • Page 125: Transferring Files

    Transferring Files 1. Tap > File Explorer. 2. Navigate to the file you want to transfer. 3. Tap and hold on the file and select Beam File on the popup menu. 4. The Bluetooth radio begins searching for devices. When a Bluetooth device is first found, it appears as an Unknown device;...

  • Page 126: Making The Terminal Discoverable

    Making the Terminal Discoverable By default, the Dolphin terminal is not discoverable, which means that the terminal will not be found by other Bluetooth devices. To make the terminal discoverable, tap Mode on the Horizontal scroll. Select Make this device visible to other devices and tap OK. Selecting COM Ports You can select COM ports 0-9.

  • Page 127: Chapter 10 - Working With Gps

    Working with GPS Overview The Dolphin 99EX terminal contains an integrated GPS module that allows location tracking of workers and vehicles, providing better utilization of field assets. Optional mapping and navigation software pro- vides turn-by-turn driving directions and location information.

  • Page 128: Gps Intermediate Driver

    Other baud rates are not possible. The baud rate selected on COM7 is the actual baud rate with which the GPS communicates. GPS Intermediate Driver When the first user of GPD1 opens the port, the GPS Intermediate Driver opens the COM7 port. The GPS Intermediate Driver allows multiple applications to open GPD1, and the GPS data is broadcast to all open ports.

  • Page 129: Chapter 11 - Dolphin 99Ex Homebase Device (Model 99Ex-Hb)

    Dolphin 99EX HomeBase Device (Model 99EX-HB) Overview As the hub of your Dolphin system, the Dolphin 99EX HomeBase (99EX-HB) charging and communica- tion cradle supports both RS232 and USB communications, which make it able to interface with the majority of PC-based enterprise systems.

  • Page 130: Parts And Functions

    This means that one base can charge two bat- tery packs: the one installed in the terminal and a spare. We recommend use of Honeywell Li-ion or Li-poly battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.
  • Page 131 Red, Flashing The internal temperature of the auxiliary battery is too hot or there is a battery error. Charge the auxiliary battery in a cooler environment or replace the battery with a new Honeywell Li-ion or Li-poly battery. For information about charging a battery in the auxiliary battery well, see page 11-6.
  • Page 132 RS232 data communication. For more information, see Serial Connector on page 11-9. DC Power Jack Use the power cable from Honeywell that comes with the base to supply power to this power jack. For more information, see Power on page 11-5.

  • Page 133: Bottom Panel

    12VDC and 3 amps with the device. The operating temperature range is -10° to 50°C (14° to 122°F). Honeywell recommends that you leave the base connected to its power source at all times, so that it is always ready to use.

  • Page 134: Charging The Main Battery

    Note: If the AUX Battery LED flashes red, the internal temperature of the battery is too hot or there is a battery error. Charge the auxiliary battery in a cooler environment or replace the battery with a new Honeywell Li-ion or Li- poly battery.

  • Page 135: Communication

    • The Dolphin terminal activates; if the power is off, the terminal automatically powers on. If the terminal does not power on, verify that the Honeywell power supply is properly connected to the cradle and plugged into a functioning outlet.

  • Page 136: Verifying Data Transfer

    • If the base is connected to the workstation, the Dolphin terminal automatically opens ActiveSync or the Windows Mobile Device Center to establish a connection. 2. The base can now transfer data between the terminal and the host device. If communication does not occur, check the port connections to ensure that the cradle is correctly configured.

  • Page 137: Serial Connector

    Serial Connector The following diagram displays the pin diagram of the serial connector of the base. Description Internal Jumper to Pin 6 No Connect Note: The signal names are referenced to the terminal. The terminal is a DCE RS232 device. Refer to section, RS232 Communications Cables and RS232 Pin Configuration for more details.
  • Page 138 11 - 10...

  • Page 139: Chapter 12 - Dolphin 99Ex Ebase Device (Model 99Ex-Ehb)

    Dolphin 99EX eBase Device (Model 99EX-EHB) Overview The Ethernet Base (eBase) enables a single Dolphin 99EX or 99GX computer to communicate with a host device over an Ethernet network. The 99EX-EHB charger is designed for use with battery pack models 99EX-BTSC (standard Li-poly 3.7 V, 11.3 watt hour) and 99EX-BTEC (extended Li-ion 3.7 V, 18.5 watt hour) manufactured for Honeywell...

  • Page 140: Parts And Functions

    Parts and Functions Front Panel Terminal Well Auxiliary Battery Well Power/Dock LED COMM LED AUX Battery LED Terminal Well Place the terminal in this well to communicate with a host device, power the terminal, and charge the installed battery pack. The eBase completely charges the main battery in a Dolphin terminal in 4 hours for the standard 3.7V battery or 6 hours for the extended 3.7 battery.
  • Page 141 Red Flashing The internal temperature of the auxiliary battery is too hot or there is a battery error. Charge the auxiliary battery in a cooler environment or replace the battery with a Honeywell Li-ion or Li-poly battery. COMM LED The COMM LED indicates the status of data transfer between the Dolphin terminal and the eBase.

  • Page 142: Back Panel

    Back Panel Auxiliary Battery Well Green LED USB Port Yellow LED DC Power Jack RJ45 Ethernet Port Auxiliary Battery Well The eBase enables you to charge an additional battery pack independently of the terminal well in 4 hours for the standard 3.7V battery or 6 hours for the extended 3.7V battery. This feature ensures that you can always have a fully charged battery for your terminal.

  • Page 143: Bottom Panel

    Honeywell with output rated 12VDC and 3 amps with the device. The operating temperature range is -10° to 50°C (14° to 122°F). Honeywell recommends that you leave the eBase connected to its power source at all times, so that it is always ready to use.

  • Page 144: Charging The Main Battery

    Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty. We recommend use of Honeywell Li-Ion or Li-poly battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.

  • Page 145: Establishing Ethernet Communication

    • The Kernel version must be 26.01 or later in terminals running Windows Embedded Handheld 6.5 Classic. • In terminals running Windows Embedded Handheld 6.5 Professional, the kernel version must be 25.01 or later. Applications on the Dolphin Terminal Applications running on the Dolphin terminal when it is connected to the eBase should be designed spe- cifically for a partially connected network.

  • Page 146: Mounting The Ebase

    Setting Up and Connecting the Dolphin Terminal to the eBase 1. Verify the base has power. If the Power/Dock LED is not illuminated, see Connecting Power to the eBase on page 12-5. 2. Plug the USB communication cable into the USB port on the back of the eBase. Note: The Dolphin terminal should always be removed from the eBase when connecting or disconnecting the USB cable.

  • Page 147: Chapter 13 - Dolphin 99Ex Mobile Base Device (Model 99Ex-Mb)

    It features a flexible mounting bracket and a cigarette lighter adapter to adapt it to your environment. The 99EX-MB is designed for use with Dolphin 99EX and 99GX model ter- minals using battery pack model 99EX-BTSC (standard Li-poly 3.7 V, 11.3 watt hour) or 99EX-BTEC (extended Li-ion 3.7 V, 18.5 watt hour) manufactured for Honeywell International Inc.

  • Page 148: Front Panel

    Front Panel Terminal Lock (not in view) Terminal Lock Terminal Well Ball Joint Volume Control Dial for Mounting (not in view) Bracket Status LED Communications Speaker Port Mounting Bracket Used to mount the base to a fixed location. Speaker Amplifies the Dolphin’s audio signals. Status LED Illuminates solid green when the Dolphin terminal is properly seated in the terminal well.

  • Page 149: Bottom Panel

    Bottom Panel The power supply and RS232 connectors are located on the bottom of the unit. Power Supply Connector RS232 Communications Port Power Supply Connector To run on vehicle power, you can use the 12 VDC cable. The appropriate cable comes with the kit you ordered.

  • Page 150: Back Panel And Mounting Brackets

    Back Panel and Mounting Brackets Bracket Base Mounting Bracket Turnscrew USB Port Ball Joint Power supply and Ball Joint RS232 connectors (not in view) Ball Joints There are two ball joints: one on the back of the base and one on the mounting bracket. Both ball joints are inserted into the bracket and secured to mount the base.

  • Page 151: Mounting

    Safety Precautions Honeywell is not responsible for any damages caused to you, your vehicle, or other individuals due to the installation of the Dolphin Mobile mount. Follow these safety precautions when mounting the mobile base:...

  • Page 152: Powering The Dolphin Terminal

    Dolphin terminal battery pack stays fully charged. Note: Honeywell recommends that you leave the base connected to its power source at all times. The base is powered via the power connector on the bottom panel; see...

  • Page 153: Establishing Activesync Or Windows Mobile Device Center Communication

    Establishing ActiveSync or Windows Mobile Device Center Communication The Dolphin terminal is usually auto-detected and configured by ActiveSync or Windows Mobile Device Center based on the communication cable. The synchronization software automatically sets up an RS232 connection when you are using an RS232 cable. For more details, see Connecting and Synchronizing the Terminal and Workstation on page...

  • Page 154: Serial Connector

    Serial Connector The following diagram displays the pin diagram of the serial connector of the base. Description Internal Jumper to Pin 6 No Connect Note: The signal names are referenced to the terminal. The terminal is a DCE RS232 device. Refer to section, RS232 Communications Cables and RS232 Pin Configuration for more details.The ninth pin has a ring indicator (RI).

  • Page 155: Chapter 14 - Dolphin 99Ex Chargebase Device (Model 99Ex-Cb)

    The base can hold up to 4 Dolphin terminals. Each charging well charges each terminal independently of the other wells. We recommend use of Honeywell Li-Ion or Li-poly battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.

  • Page 156: Parts And Functions

    Parts and Functions Front Panel Terminal Wells Power/Dock LED Charge LED Terminal Wells The base contains four terminal wells. Each well has its own dedicated Power/Docking LED and Charging LED indicator. Power/Dock LEDs The Power/Dock LED indicates if the ChargeBase has power and if the terminal is properly seated in the terminal well.

  • Page 157: Back Panel

    12 volts DC. Use only UL Listed power supply, which has been qualified by Honeywell with output rated 12VDC and 8.5 amps with the device. The operating tem- perature range is -10° to 50°C (14° to 122°F).

  • Page 158: Charging The Main Battery

    Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty. We recommend use of Honeywell Li-Ion or Li-poly battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.
  • Page 159 Hardware Required • 3/16 in. dia x 5/8 in. long pan head screw • 1/2 in. OD x 7/32 in. ID x 3/64 in. thick washer • 3/16 in. dia nut Installing the DIN Rail 1. Slide the DIN Rail into the DIN Rail slot on the bottom panel of the base. 2.
  • Page 160 Hollow Wall Installation 1. Drill four pilot holes in the wall using a 7/8 in. drill bit. 13.78 in. [35 cm] Wall Mount Bracket 6.5 in. Wall Mount Holes [16.5 cm] 2. Slide the bolt through the wall bracket, and thread the toggle nut onto Toggle Nut the bolt.
  • Page 161 To secure the base using the optional DIN Rail: Hardware Required • DIN Rail, Qty. 1 • 3/16 in. dia x 5/8 in. long pan head screw, Qty. 2 • 1/2 in. OD x 7/32 in. ID x 3/64 in. thick washer, Qty. 2 •...

  • Page 162: Channel Bracket Installation (Pre-Existing Hardware Installations)

    Channel Bracket Installation (Pre-existing Hardware Installations) When choosing a location and installing the optional channel bracket: • Do not exceed 150 lbs. maximum load on the channel bracket. • Leave a minimum of 16 in. (40.64 cm) of horizontal space between the hardware used to attach the channel bracket to the wall.
  • Page 163 2. Attach the channel bracket to a dry, stable surface using the hardware listed on page 14-8 for the appropriate mounting surface. Mounting into Wood Stud Washer, Qty. 4 Lag Bolt, Qty. 4 Channel Bracket Minimum 16 in. (40.64 cm) Mounting into Hollow Surface Washer, Qty.

  • Page 164: Removing Power To The Chargebase

    Removing Power to the ChargeBase Attempting to remove the cable without disengaging the lock may result in damage to the base and power cable not covered by the warranty. 1. Gently slide back the outer shell of the connector to disengage cable lock. Cable Lock Do not pull on the power connector...

  • Page 165: Chapter 15 - Dolphin 99Ex Net Base Device (Model 99Ex-Nb)

    Dolphin 99EX Net Base Device (Model 99EX-NB) Overview The Net Base enables up to four Dolphin 99EX or 99GX mobile computers to communicate with a host device over an Ethernet network. In addition, the Net Base provides a second RJ45 Ethernet port for connection to an additional device such as a printer, workstation, eBase, or another Net Base.

  • Page 166: Parts And Functions

    Parts and Functions Front Panel Terminal Wells Power/Dock LED COMM LED Terminal Wells The Net Base contains four terminal wells. Each well has its own dedicated Power/Dock LED and COMM LED indicator. Place the Dolphin terminal in any one of the four wells to communicate with a host device, power the terminal, and charge the installed battery pack.

  • Page 167: Back Panel

    Port 1: 10/100Mbps RJ45 Ethernet Port Port 2: 100Mbps Only RJ45 Ethernet Port DC Power Jack Use the power cable from Honeywell that comes with the Net Base to supply power to this power jack. For more information, see Power on page 15-4.

  • Page 168: Bottom Panel

    Honeywell with output rated at 12VDC and 8.5 amps with the device. The operating temperature range is -10° to 50°C (14° to 122°F). Honeywell recommends that you leave the Net Base connected to its power source at all times, so that it is always ready to use.

  • Page 169: Charging The Main Battery

    Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty. We recommend use of Honeywell Li-Ion or Li-poly battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.

  • Page 170: Mounting The Net Base

    3. Plug the Ethernet cable into the network. 4. Insert the Dolphin into one of the terminal wells. The DOCK LED for the well changes from red to green and the connection icon on the Dolphin’s title bar changes from 5.
  • Page 171 Desk Mounting The DIN Rail (7.5 X 35 mm) slot on the bottom panel enables secure mounting on a horizontal surface. Hardware Required • 3/16 in. dia x 5/8 in. long pan head screw • 1/2 in. OD x 7/32 in. ID x 3/64 in. thick washer •...
  • Page 172 Hollow Wall Installation 1. Drill four pilot holes in the wall using a 7/8 in. drill bit. 13.78 in. [35 cm] Wall Mount Bracket 6.5 in. Wall Mount Holes [16.5 cm] 2. Slide the bolt through the wall bracket, and thread the toggle nut onto Toggle Nut the bolt.
  • Page 173 To secure the base using the optional DIN Rail: Hardware Required • DIN Rail, Qty. 1 • 3/16 in. dia x 5/8 in. long pan head screw, Qty. 2 • 1/2 in. OD x 7/32 in. ID x 3/64 in. thick washer, Qty. 2 •...

  • Page 174: Channel Bracket Installation (Pre-Existing Hardware Installations)

    Channel Bracket Installation (Pre-existing Hardware Installations) When choosing a location and installing the optional channel bracket: • Do not exceed 150 lbs. maximum load on the channel bracket. • Leave a minimum of 16 in. (40.64 cm) of horizontal space between the hardware used to attach the channel bracket to the wall.
  • Page 175 2. Attach the channel bracket to a dry, stable surface using the hardware listed on page 15-10 for the appropriate mounting surface. Mounting into Wood Stud Washer, Qty. 4 Lag Bolt, Qty. 4 Channel Bracket Minimum 16 in. (40.64 cm) Mounting into Hollow Surface Washer, Qty.

  • Page 176: Removing Power To The Net Base

    Removing Power to the Net Base Attempting to remove the cable without disengaging the lock may result in damage to the base and power cable not covered by the warranty. 1. Gently slide back the outer shell of the connector to disengage cable lock. Cable Lock Do not pull on the power connector...

  • Page 177: Chapter 16 - Dolphin 99Ex Quadcharger Device (Model 99Ex-Qc)

    (CC-CV) that is recommended for Li-ion and Li-poly batter- ies. The process monitors changes in temperature, current, and voltage and resets the battery pack. We recommend use of Honeywell Li-Ion or Li-poly battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.

  • Page 178: Parts And Functions

    Red (Flashing) The internal temperature of the auxiliary battery is too hot or there is a battery error. Charge the auxiliary battery in a cooler environment or replace the battery with a new Honeywell Li-ion or Li-poly battery. Troubleshooting For more information, on page 16-5.

  • Page 179: Supplying Power

    Supplying Power The charger must be connected to a power source via the Honeywell power adapter cable so that volt- age is adjusted appropriately. Use only UL Listed power supply, which has been qualified by Honeywell with output rated at 12VDC and 3 amps with the device.

  • Page 180: Mounting The Quadcharger

    Mounting the QuadCharger The charger should be on a dry, stable surface and can be mounted on a flat, horizontal surface such as a desktop or workbench. When choosing a location, always bear in mind that: • the mounting location must allow users easy access to the power connector. •...

  • Page 181: Troubleshooting

    Troubleshooting If you encounter problems with your QuadCharger device, refer to chart below for possible solutions. If problems persist, please contact Honeywell Technical Support. Problem Issue The Status LED does not come on when I Check the power connections; make sure the Power cable is insert a battery pack.
  • Page 182 16 - 6...

  • Page 183: Appendix A - Dolphin 99Ex/99Gx Terminal Agency Information

    Dolphin 99EX/99GX Terminal Agency Information Dolphin 99EX and 99GX mobile computers meet or exceed the requirements of all applicable standards organizations for safe operation. The best way to ensure safe operation is to use the mobile computer according to the agency guidelines in this user guide and on the regulatory sheet shipped with the terminal.
  • Page 184 A - 2...
  • Page 186 Honeywell 9680 Old Bailes Road Fort Mill, SC 29707 99EX-UG Rev H 2/16...

This manual is also suitable for:

Dolphin 99gx

Table of Contents
