Philips HR7755/01 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
- The Foodprocessor is equipped with mechanical and
thermal safety switches.
Materials used:
- Bowl, bowl lid,
blender jar & safety cover
- Housing, screw cap, pushers,
inlay bowl handle, switch
- Emulsifying disc
- Feeding tray, sausage horn
- Kneading accessory
- Toolholder bowl, sausage seperator
- Insert holder
- Foodprocessor knife, insert discs
- Cutter, grinding discs
- Meat mincer processing tube,
worm shaft
Safety:
- Automatically resettable : protects motor against
thermal cut out
- Built – in safety lock
- Motor brake system
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Published by Philips Domestic Appliances and Personal Care
03/07
Essence
: SAN
: PP
: PP
: ABS
: PP / 30% chalk
: POM
: ABS
: Stainless steel
: Metal
: Alu - alloy
overheating
: detects wheter lid & bowl or
meat mincer are assembled
: stops the appliance wthin
1.5 seconds
Printed in the Netherlands
TECHNICAL INFORMATION
- Motor : universal, radio / TV interference
suppressed
- Power consumption : 800 Watt max.
- Voltage & frequency : 230 V, 50 Hz
- Cordset : 100 cm, double insulated with
moulded on plug
- Speed setting : 2 speeds + pulse
- Bowl capacity : 2.5 L dry ingredients, 1.7 L liquids
- Blender capacity : total jar capacity 2.0 L,
- Meat mincer capacity : 1.3 kg meat per minute (pork)
- Speeds unloaded : blender drive shaft 19500 rpm (max)
accessories drive shaft 2150 rpm
(max at speed 2 + pulse)
accessories drive shaft 1700 rpm
(min at speed 1)
- Weight in fancy box : 6.900 g
- Dimensions
fancy box (l x w x h) : 395 mm x 380 mm x 395 mm
- Colours : White with Vapor Dusk accents,
clear transparant bowl & jar
© Copyright reserved
Food processor
HR7755/01
1,5 L effective
Subject to modification
