Summary of Contents for C-COM Satellite iNetVu 7000 Series
- Page 1 ® iNetVu Mobile System iNetVu 7000 Series Software Installation and Configuration Guide The iNetVu® brand and logo are registered trademarks of C-COM Satellite Systems, Inc. © Copyright 2006 C-COM Satellite Systems, Inc. 1-877-iNetVu6 www.c-comsat.com Revision 3.1 January 22, 2016...
- Page 2 INETVU® MOBILE SYSTEM QUICK START – SOFTWARE INSTALLATION This page is intentionally left blank. C-COM Satellite Systems Inc. Page 2...
-
Page 3: Safety And Warning Information
Ensure Sensor and Motor cables are connected prior to powering on 7000 Series Controller. Do not connect or disconnect cables once controller has been powered on. It is recommended that controller is properly grounded at all times. C-COM Satellite Systems Inc. Page 3... -
Page 4: System Overview
Finds the satellite, peaks the signal strength and selects the optimal path to perform the selected satellite, allowing the customer’s computer to be online as soon as possible • Simple to install, configure and operate. C-COM Satellite Systems Inc. Page 4... -
Page 5: Pre-Configuration Check List
USB Connection between the PC and iNetVu® Controller • iNetVu® Software Application • First time user should use the iNetVu Wizard which is imbedded into the iNetVu software for guidance in configuring your system. C-COM Satellite Systems Inc. Page 5... -
Page 6: Tips And Recommendations
Override Compass can be selected without selecting Full Search but this does not hold true for the vice-versa. Refer to Controller User Manual for more information on using the iNetVu Controller and options associated with your system. C-COM Satellite Systems Inc. Page 6... - Page 7 Antenna Sensor Cable RG6 Coaxial Cable Network Cable Power Cable USB Cable MOTOR SENSOR CONTROL *Ground protection Transmit Source RX IN USB CABLE 24 VDC Input 90 - 264VAC (option) USB Interface System Wiring C-COM Satellite Systems Inc. Page 7...
-
Page 8: Software Installation And Configuration
Please Note: Do not connect the Controller via USB until the drivers and software have been installed 1. If you are installing from the USB flash drive or have downloaded from the C-COM FTP/KB, run the iNetVu7000Setup.exe file. 2. Install the iNetVu 7000 Software and close when complete. C-COM Satellite Systems Inc. Page 8... - Page 9 INETVU® MOBILE SYSTEM QUICK START – SOFTWARE INSTALLATION 3. Install the FTDI USB Drivers and iNetVu USB Drivers. Both are required. Click “Extract” Click “Next” Click “Finish” 4. Continue through the USB Driver Installation Wizard. Click “Next” Click “Finish” C-COM Satellite Systems Inc. Page 9...
- Page 10 Select “Install the software automatically” Click “Continue Anyway” Click “Finish” 7. Windows Vista and 7 users, the drivers should install automatically without any further user action. 8. You have successfully installed the 7000 iNetVu Drivers and Software. C-COM Satellite Systems Inc. Page 10...
- Page 11 Please select “Do not show this message again” so this pop-up will not appear after you have completed the initial Controller setup. 2. If the controller firmware does not match you will be prompted to update. C-COM Satellite Systems Inc. Page 11...
- Page 12 4. You may wish to continue through the wizard to complete the controller configuration or verify the settings. You can switch to the iNetVu software at any time by right clicking and selecting Controls. C-COM Satellite Systems Inc. Page 12...
- Page 13 5. Configure the Platform Type, Version and Serial No. If no changes are needed press “Next” to continue. Platform Type: Antenna Model Version: Antenna Version Serial No: Antenna Serial Number It is important that this information be correct or will result in undesired antenna behavior. C-COM Satellite Systems Inc. Page 13...
- Page 14 INETVU® MOBILE SYSTEM QUICK START – SOFTWARE INSTALLATION 6. Complete the Service Information section. If no modem is to be used set to NA. After changes have been made please click “Next” to continue. C-COM Satellite Systems Inc. Page 14...
- Page 15 Please ask your service provider or NOC for a valid DVB Carrier. RF Search: RF Search cannot be used in a standalone setup Duplicate the settings for all satellites: Selecting this will duplicate parameters across all Satellite No. 0 ~ 4 C-COM Satellite Systems Inc. Page 15...
- Page 16 9. Congratulations you have configured your iNetVu Controller. You can now find satellite by pressing the FIND SAT button from the front panel or by launching the iNetvu Software. *For more detailed information on the iNetVu® 7000 Controller Software, refer to the iNetVu® 7000 Controller Manual. C-COM Satellite Systems Inc. Page 16...
