Front view

LCD panel

Rear view

LAN
terminal
(See page 19.)
RS-232C
terminal
(See page 19.)
DVI IN
terminals
(See pages
15, 16 and 17.)
HDMI
terminal
(See page 16.)
COMPUTER IN 1 terminals
(See pages 15, 16 and 17.)
Note
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
• The illustrations used throughout this manual are based on TL-M5200.

Part Names

HOT
Handles (Fixed type)
COMPUTER IN 2 terminals
(See pages 15, 16 and 17.)
POWER indicator (See page 22.)
TIMER indicator (See page 42.)
OPC indicator (See page 32.)
OPC sensor (See page 32.)
Remote control sensor (See page 21.)
CAUTION
The area surrounding these terminals
gets hot. Exercise due caution when
handling. (TL-M4600 only)
MONITOR OUT terminals
(See page 17.)
AC input terminal
(See page 20.)
SPEAKER OUT terminals
(See page 18.)
9
