Summary of Contents for Motorola Advisor Elite

  • Page 2: Table Of Contents

    Introduction Control Buttons... 2 Getting Started Turning Your Pager On ... 3 Turning Your Pager Off ... 4 Using the Function Menu ... 5 Message-Status Screen ... 6 Backlight... 7 Receiving/Reading Personal Messages ... 7 Display Zoom ... 9 Time and Date Setting the Time and Date...

  • Page 3: Sending A Test Page To Yourself

    Congratulations on purchasing an Advisor Elite pager. Your new pager provides exciting capabilities in messaging and can become a vital part of your business and personal life. The pager’s four-line display and expanded functionality incorporates many of the most advanced electronic, communications and wireless technologies available.

  • Page 4: Control Buttons

    Effective Use of Your Pager Your pager can help you keep in contact with everyone important to you. By giving your pager number to your business associates, family, and friends, you can be contacted whenever needed. If you have a cellular phone, give your pager number instead of your cellular number.

  • Page 5: Turning Your Pager On

    Directional Buttons Turning Your Pager On Press . A start-up screen is momentarily displayed and your pager activates the currently selected alert. Note: Press any button to stop the alert. Used to navigate through the Function menu and through your messages.

  • Page 6: Turning Your Pager Off

    Audible Alarm Example of the Standby Screen When the pager is on and no activity is taking place, the Standby screen is displayed. The Standby screen displays the power-on indicator N and may display other pager status indicators. Turning Your Pager Off Press to display the Function menu.

  • Page 7: Using The Function Menu

    Using the Function Menu The Function menu provides access to the many features of your pager through the use of symbols and prompts. Press to display the Function menu. When the Function menu is initially displayed a flashes to indicate the location of the cursor.

  • Page 8: Message-Status Screen

    For example, unread messages are indicated by a flashing locked messages are indicated by g. The Message-status screen also displays the time and date and any activated pager settings. The Message-status screen can be accessed by pressing H, I, G, or F from the Standby screen. mgmmomm...

  • Page 9: Backlight

    Standby screen. Receiving/Reading Personal Messages Your pager can receive up to 19 personal messages. When a message is received, your pager alerts according to the current alert setting (audible, vibrate, or no message alert). A new message is indicated by a flashing symbol.
  • Page 10 • Press H or I while reading a message to read the previous or next message. Note: When an unread message exists, your pager gives a periodic reminder alert until all unread messages are read, or for up to 30 minutes.

  • Page 11: Display Zoom

    From the Function menu, press H to move the cursor to 1. Press . Display zoom is now active. All new and stored messages including notebook messages are displayed in a 2-line format. Pager prompts are not enlarged in the zoom mode.

  • Page 12: Setting The Time And Date

    To Disable Display Zoom From the Function menu, press H to move the cursor to 4. Press . Display zoom is now disabled. Setting the Time and Date From the Function menu, press H to move the cursor to v. Press to display the Set-time-and-alarm screen.
  • Page 13 Press to activate the time and date setting. c12:00AM --/--/-- If you move the cursor past the last symbol in the row (far right), it automatically wraps around to the first symbol in the beginning of the same row (far left). Note: To exit from any screen without making changes, press 3:15PM 05/05/97z SET TIME...

  • Page 14: Setting The Incoming Message Alert

    Setting the Alert Pattern You can set your pager to alert audible with a standard alert (1), one of seven pleasing alerts (2-8), a chirp alert (j), or a chirp and vibrate alert (|). You can also select no message alert (r).
  • Page 15 From the Function menu, press H to move the cursor to l. Press to display the Choose alert menu. Press H or I to move the cursor to the desired alert. The pager gives a sample of each alert as you move through the selections. Press to activate your selection.

  • Page 16: Locking And Unlocking Messages

    Locking and Unlocking Messages Up to 10 messages can be locked to prevent them from being deleted or from being replaced when memory is full. When a message is locked, the m symbol is replaced by the g symbol indicating the message is locked. To Lock or Unlock a Message From the Message-status screen, press H or I to select the message you want to lock or unlock.

  • Page 17: Deleting Messages

    Deleting Messages This feature allows you to delete unlocked and un-alarmed messages. To Delete a Single Message From the Message-status screen, press H or I to select the message you want to delete. Press Press I to move the cursor to A. Press DELETE MESSAGE? Press...

  • Page 18: Pager Alarms

    Pager Alarm Your pager has an alarm that can be set for a specific time and date, or a specific time on a daily basis. At the selected alarm time, your pager alerts. If the alarm times passes without being acknowledged, Q flashes until any button is pressed.
  • Page 19 The alarm symbol shows the current alarm status. cis displayed if the alarm is enabled, e is displayed if the alarm is disabled. Press I to move the cursor to the alarm symbol. Press F or G until c is displayed. Press I to move the cursor to the hour digits.

  • Page 20: Set The Alarm To Alert Daily

    To Set the Alarm to Alert Daily Follow steps 1 through 8 in “To Set a One-Time Alarm” to set the alarm time. When setting the date in step 8, press G until you see double dashes for the month, day, and year (--/--/--). Example of Set-Alarm Screen for a Daily Alert Press to activate your selection.

  • Page 21: Message Alarms

    Message Alarms This feature allows you to set a one-time or daily alarm for a selected personal message. You can set an alarm for up to five personal messages. When a message alarm is set, b replaces m in the Message-status screen.
  • Page 22 Press . The Set-message-alarm screen is displayed. zv 03:15PM 05/05/7z Example of Set-Message-Alarm Screen The alarm symbol shows the current alarm status. c is displayed if the message alarm is enabled, e is displayed if the message alarm is disabled. Press F or G until c is displayed.

  • Page 23: Set A Daily Message Alarm

    Press F or G to adjust the hour digits. Repeat steps 6 and 7 to adjust the minutes, AM/PM/24 hr., and date. Press to activate your selection. You can also set a message alarm while reading the message by following steps 2 through 9 above.

  • Page 24: Private Time

    Private Time You can select a time period during which your pager is completely silent. Your pager still receives messages but is does not alert. The pager alerts only if an alarm expires or a priority message is received. To Set Private Time From the Function menu, press H to move the cursor to 3.
  • Page 25 Press and release G until 3 is displayed. Press I to move the cursor to the hour digit. Press F or G to adjust the hour digit. Repeat steps 4 and 5 to adjust the on and off time setting . Press K to activate your selection.

  • Page 26: Maildrop/Information Service Option

    3:15PM Example of Maildrop Indicators Maildrop Alerts When this option is enabled, you can set your pager to alert when maildrop messages are received. • A V in the maildrop message area indicates the alert is off for that maildrop. A j indicates the alert is on for that maildrop.
  • Page 27 • If the pager’s incoming message alert is set to silent (vibrate), all maildrops with the alert set to on (j), produce a 2-second vibration when a maildrop message is received. • If the pager’s incoming message alert is set to audible, the maildrop...
  • Page 28 Press I to move the cursor to j. Press . The choose alerts menu is displayed. Press H or I to move the cursor to the desired alert. Press to activate the alert. The pager gives a sample of the alert, unless no message alert is selected.

  • Page 29: Notebooks

    Notebooks Your pager has two notebook areas, a personal notebook for storing personal messages, and a maildrop notebook for storing information service messages. Notebook messages are indicated by messages are indicated on the first row of the display. Maildrop messages are indicated on the second row of the display.

  • Page 30: Storing Personal And Maildrop Messages In Your Notebooks

    Storing Personal and Maildrop Messages in Your Notebooks From the Message-status screen, press F , G, H, or I to move the cursor to the personal or maildrop message you want to move into the notebook. Press Press I to move the cursor to u. Press .
  • Page 31 Press F or G to scroll through the list until beginning of the notebook message you want to delete. Take children to school Look at new stock rates Congratulations on your Example of Notebook Screen in Delete Mode Press to display the Function menu. Press I to move the cursor to A.

  • Page 32: Features

    Out of Range If your pager has this feature, and if you are outside your paging coverage area, is displayed. As long as is displayed, your pager cannot...
  • Page 33 Key Click If this feature is enabled, and the pager is in the audible mode, a “click” is emitted when any of the pager’s buttons are pressed. The click is not emitted when the pager is in the silent mode.

  • Page 34: Care And Use

    Do not use alcohol or other cleaning solutions. Functionality and Use of Your Pager For questions pertaining to the functions and use of your Motorola pager, please visit our web site at www.mot.com/pagers or in the U.S., call 1-800-548-9954 or 1-800-793-7834 (TDD).

  • Page 35: Care And Maintenance

    Care and Maintenance The Advisor Elite pagers are durable, reliable, and can provide years of dependable service; however, they are precision electronic products. Water and moisture, excessive heat, and extreme shock may damage the pager. Do not expose your pager to these conditions. If repair is required, the Motorola Service Organization, staffed with specially trained technicians, offers repair and maintenance facilities throughout the world.

  • Page 36: Battery Information

    See the diagram on the following page for the battery door location. Installing/Replacing the Battery To install or replace the battery, hold the pager face down and proceed as follows: Unlock the battery door by sliding the door latch away from the battery door.
  • Page 37 Ì Advisor Elite Pager Battery Replacement (rear view) To install a new battery, reverse this procedure, taking note of the positive (+) and negative (-) markings. CAUTION : Do not insert the battery backwards or all messages will be erased.

  • Page 40: Patent Information

    Patent Information This Motorola product is manufactured under one or more Motorola U.S. patents. These patent numbers are listed inside the housing of this product. Other U.S. patents for this product are pending. t, Motorola, Advisor Elite, and are trademarks or registered trademarks of Motorola, Inc.
  • Page 41 Advisor Elite™ Quick Reference Card Turning Your Pager On Press Turning Your Pager Off From the Function Menu, press move the cursor to Press twice. Function Menu Provides access to the features described in this quick reference card and in your user’s guide.
  • Page 42 Press to move the cursor to Press Follow steps 3 through 6 in Setting the Time and Date . Note: To set a daily pager or message alarm, press displayed for the month, day, and year (--/--/--). until is displayed.
  • Page 43 To turn private time off, in step 4 above, press and release To Enable/Disable Display Zoom From the Function menu, press move the cursor to disable. Press Pager Symbols Power On Audible Alert Mode on Private Time enabled Alarm enabled to activate your selection. µ...
  • Page 44 Choose Alert Set Time and Alarm Set Private Time Display Zoom On Display Zoom Off Set Silent Alert Set Audible Alert Turn Pager Off Escape (to Message-status screen) Delete Message Delete All Messages Lock Message Unlock Message Turn Maildrop Alert On...
