SHR-2160/2162/2080/2082 USER'S MANUAL
3

Live Channel Selection and Audio On/Off Setup

In other split modes than Full Screen Mode and Auto Sequence Mode, you can choose a channel
to be displayed in each split area on your own. In addition, the channel being set to Audio On can
be turned to Audio On/Off in all Live Modes.
Audio On/Off Setup in the Full Screen
In full screen mode, the selected channel's audio automatically turns on, and you can turn the
audio on and off as you toggle the audio button. Depending on the Audio On/Off setup
condition, the Audio icon of the channel changes to the Yellow/white color.
Audio On/Off Setup in the 16 Split Mode
If you press [ENTER] Button in the 16 Split Mode, the selection cursor in the following figure
will appear and the channel concerned will be selected. When you select a temporary channel
and press the audio button, you can turn the audio of the selected channel to on or off. Depending
on the Audio On/Off setup condition, the Audio icon of the channel changes to the Yellow/white
color. You can set audio from 1 to 4 channels in 16-split mode.
CAM_01 CAM_02 CAM_03
CAM_05 CAM_06 CAM_07
CAM_09
CAM_13
Selecting channels in 4,6,7,8,and 9 split mode and PIP mode, and
setting up Audio on/off.
As in 16 split mode, when pressing the [enter] button in 4,6,7,8, and 9 split mode and PIP mode it
brings up the selecting cursor and selects the applied channel.
When you select a temporary channel, you can select the watched channel with the channel 1-16
buttons, and just as when in 16-split mode you can set audio to on or off with the audio button's
LED.
According to the audio on/off setting environment, the audio icon of the applied channel changes
to yellow/white.
4-5
English
CAM_04
CAM_08
CAM_11 CAM_12
CAM_10
CAM_14 CAM_15 CAM_16
4

Freeze and Zoom

Freeze Function
Freeze function pauses the video image in the Live Screen, it is only available in the Live Mode.
You can set freeze to on or off with the [FREEZE] button.
Zoom Function
Zoom function enlarges the selected area to double size, and it is only available in the
single mode.
If the [ZOOM] button is pressed in the single mode, the Zoom area appears. Use the
UP/DOWN/LEFT/RIGHT key to adjust the position of Zoom area. After selecting the Zoom area,
press the [Enter] button to display the selection area in double size. You can adjust the video
image position with the UP/DOWN/LEFT/RIGHT key at the Zoom in state. For Zoom off at the
Zoom in state, use the [ZOOM] button.
4-6
English
