3 - Now go to the Philips Hue Bridge and press the
link button in the middle of the device. This will link
the Hue Bridge with the TV. Do this within 30
seconds. The TV will confirm if a Hue Bridge is now
linked to the TV.
4 - Select OK and press OK.
With the Philips Hue bridge linked to the TV, go to
page Hue bulbs.
Step 3 - Hue Bulbs
In the next step, you will select the Philips Hue bulbs
that have to follow the Ambilight.
You can select a maximum of 9 Philips Hue bulbs for
Ambilight+hue.
To select the bulbs for Ambilight+hue...
1 - In the list, mark the bulbs that have to follow the
Ambilight. To mark a bulb, select the bulb name and
press OK. When you mark a bulb, the bulb will blink
once.
2 - When you're done, select OK and press OK.
With the bulbs marked for Ambilight+hue, go to page
Configure bulb.
Step 4 - Configure Bulb
In the following step, you will configure each Philips
Hue bulb.
To configure each Hue bulb...
1 - Select a bulb to configure and press OK. The
bulb you selected is flashing.
2 - Select Start and press OK.
3 - First indicate where you placed the bulb relative
to the TV. A correct setting of the Angle will send the
correct Ambilight colour to the bulb. Select the slider
bar to adjust the position.
4 - Secondly, indicate the Distance between the
bulb and the TV. The further away from the TV, the
weaker the Ambilight colour. Select the slider bar to
adjust the distance.
5 - Finally, set the Brightness of the bulb. Select the
slider bar to adjust the brightness.
6 - To stop configuring this bulb, select OK and
press OK.
7 - In the Configure Ambilight+hue menu, you can do
the same for each bulb.
8 - When all Ambilight+hue bulbs are configured,
select Finish and press OK.
Ambilight+hue is ready for use.
Switch On or Off
You can switch off the Ambilight+hue effect on the
bulbs. The bulbs will light up white.
To switch off Ambilight+hue...
1 - Press  SETTINGS, select Ambilight+hue and
press OK.
2 - Select Off or On and press OK.
3 - Press  (left) to go back one step or press 
BACK to close the menu.
Immersion
You can adjust the level of the Ambilight effect for the
Ambilight+hue bulbs.
To adjust the Ambilight+hue Immersion...
1 - Press  SETTINGS, select All Settings and
press OK.
2 - Select Ambilight > Ambilight+hue and press OK.
3 - Select Immersion and press  (right).
4 - Press  (up) or  (down) to adjust the value.
5 - Press  (left) to go back one step or press 
BACK to close the menu.
View Configuration
In View configuration, you can consult the current
Ambilight+hue configuration. Which network you use,
how many bulbs are connected, etc.
To view the current Ambilight+hue setup...
1 - Press  SETTINGS, select All Settings and
press OK.
2 - Select Ambilight > Ambilight+hue and press OK.
3 - Select View Configuration and press OK.
4 - Press  (left) to go back one step or press 
BACK to close the menu.
Reset Configuration
You can reset (uninstall) the complete Ambilight+hue
configuration in one go.
To reset the Ambilight+hue configuration...
1 - Press  SETTINGS, select All Settings and
press OK.
2 - Select Ambilight > Ambilight+hue and press OK.
3 - Select Reset Configuration and press OK. The
configuration is reset.
4 - Press  (left) to go back one step or press 
BACK to close the menu.
