DVP-S325/S525D / S725D
SERVICE MANUAL
CD/DVD player
Laser
Semiconductor laser
Signal format system
PAL/(NTSC)
Audio characteristics
Frequency response
DVD (PCM 96 kHz): 2 Hz to 44 kHz
(±1 dB)* (S325/S525D)
DVD (PCM 96 kHz): 2 Hz to 44 kHz
(±0.5 dB)* (S725D)
DVD (PCM 48 kHz): 2 Hz to 22 kHz
(±0.5 dB)
CD: 2 Hz to 20 kHz (±0.5 dB)
Signal-to-noise ratio
More than 110 dB (LINE OUT (AUDIO)
connectors only) (S325/S525D)
More than 110 dB (AUDIO OUT
connector only) (S725D)
Harmonic distortion
Less than 0.0025%
Dynamic range
More than 100 dB (DVD)
More than 98 dB (CD)
Wow and flutter
Less than detected value
(±0.001% W PEAK)
Outputs and inputs
Jack
Output
type
level
LINE OUT
Phono
2 Vrms
(AUDIO)
jacks
(at 50 kilohms)
(S325/S525D)
AUIO OUT
Phono
2 Vrms
(S725D)
jacks
(at 50 kilohms)
DIGITAL OUT
Optical
–18 dBm
(OPTICAL)
output
connector
DIGITAL OUT
Phono
0.5 Vp-p
(COAXIAL)
jack
LINE OUT
Phono
1.0 Vp-p
(VIDEO)
jacks
(S325/S525D)
MICROFILM
RMT-D108O/D108P/D109P/D111O/D111P
Photo: DVP-S725D
SPECIFICATIONS
VIDEO OUT
(1, 2) (S725D)
S VIDEO OUT
(S325/S525D)
S VIDEO OUT
(1, 2) (S725D)
COMPONENT
VIDEO OUT
(Y, C
/B-Y,
B
C
/R-Y)
R
(S725D)
PHONES
(EXCEPT S325)
5.1CH
OUTPUT
(EXCEPT S325)
General
Power requirements
Power consumption
Load impedance
Over 10 kilohms
Dimensions (approx.)
Mass (approx.)
Over 10 kilohms
Operating temperature
Wave length: 660 nm
75 ohms terminated
75 ohms,
sync negative
AEP Model
DVP-S325/S525D/S725D
East European Model
North European Model
DVP-S325/S525D/S725D
Russian Model
DVP-S325/S525D/S725D
Australian Model
DVP-S525D/S725D
Phono
1.0 Vp-p
75 ohms,
jacks
sync negative
4-pin
Y: 1.0 Vp-p
75 ohms,
mini DIN
sync negative
C: 0.3 Vp-p
75 ohms terminated
(PAL)
C: 0.286 Vp-p
(NTSC)
phono
Y: 1.0 Vp-p
75 ohms,
jacks
sync negative
C
/B-Y,
B
C
/R-Y:
R
0.7 Vp-p
75 ohms
Phone
12 mW
32 ohms
jack
Phono
2 Vrms
Over 10 kilohms
jacks
(at 50 kilohms)
220 – 240 V AC, 50/60 Hz
16 W (S325)
17 W (S525D)
22 W (S725D)
430 × 95 × 305 mm (w/h/d)
incl. projecting parts
3.3 kg (S325)
3.4 kg (S525D)
4.0 kg (S725D)
5°C to 35°C
– Continued on next page –
CD/DVD PLAYER
E Model
DVP-S725D
