- Page 1 VS-50803 VS-50803 VS-50803 VS-50803 VS-50803 VS-60803 VS-60803 VS-60803 VS-60803 VS-60803 WS-65903 WS-65903 WS-65903 WS-65903 WS-65903 VS-70803 VS-70803 VS-70803 VS-70803 VS-70803 WS-73903 WS-73903 WS-73903 WS-73903 WS-73903 VS-80803 VS-80803 VS-80803 VS-80803 VS-80803 AV Systems Connections Guide AV Systems Connections Guide AV Systems Connections Guide...
- Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
-
Page 3: Table Of Contents
TV + stereo audio system ............24 TV + Mitsubishi products that have A/V network terminals 26 TV + DVD player with Component Video Outputs ....28 TV + AV receiver ..............30 TV + HDTV receiver (Mitsubishi brand only) and cable ..34... - Page 4 blank page AV Systems Connection Guide...
-
Page 5: Chapter 1: Basic Connections
This section will show you the basic connections to hookup your TV. If you have difficulty making any of the connections to your TV, you may want to contact your Mitsubishi dealer or your local cable company. • TV + separate UHF and VHF antennas •... -
Page 6: Tv + Separate Uhf And Vhf Antennas
TV + separate UHF and VHF antennas UHF Antenna VHF Antenna (Channels 14-69) (Channels 2-13) Flat Twin Lead TV Rear Terminal Flat Twin Lead External VIDEO AUDIO HIGH-DEFINITION INTERFACE Antenna S-VIDEO (MONO) HDTV VIDEO or Cable INPUT-1 INPUT-2 HDTV AUDIO HDTV CONTROL (MONO) INPUT-3... - Page 7 TV + separate UHF and VHF antennas If UHF and VHF signals are brought into your home with two separate antennas, you’ll need to combine them in order to connect them to the TV. To do this you will need a UHF/VHF combiner. Use this hook-up to: •...
-
Page 8: Tv + Antenna Or Cable Without A Cable Box
TV + antenna or cable without a cable box TV rear terminals VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 75 Ohm Coaxial Cable INPUT-2 HDTV CONTROL HDTV AUDIO 300 Ohm Flat (MONO) Twin Lead INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) HOME G LINK... - Page 9 TV + antenna or cable without a cable box Use this hook-up to: • connect the incoming cable or antenna to the ANT-A input terminal on the TV. equipment you will need: If you have a standard 75-ohm coaxial cable, you will not need additional equipment.
-
Page 10: Tv + Cable With A Cable Box When Tv Guide Plus + Will Not Be Used
TV + cable with a cable box when TV GUIDE Plus + will not be used TV rear terminals VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV AUDIO HDTV CONTROL (MONO) INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) HOME G LINK NETWORK... - Page 11 TV + cable with a cable box when TV GUIDE Plus + will not be used This hook-up will allow you to use the advanced features of your TV, such as 2-tuner PIP and SuperQuickView ™ and watch basic cable channels on Antenna-A. You will be able to view the pre- mium cable channels that are descrambled by your cable box on Antenna-B.
-
Page 12: Tv + Vcr + Cable With A Cable Box When Tv Guide Plus + Will Not Be Used
TV + VCR + cable with a cable box when TV GUIDE Plus + will not be used VCR Rear Terminals Yellow AUDIO OUT AUDIO IN VIDEO OUT White £ (Y/C) © CH-1 CH-1 Antenna § § § § § MONITOR CH-2 CH-2... - Page 13 TV + VCR + cable with a cable box when TV GUIDE Plus + will not be used Use this hook-up to: • connect a VCR along with your cable and cable box, when you will not be using TV GUIDE Plus+ equipment you will need: Three lengths of One set of RCA pin-...
-
Page 14: Tv + Vcr + Antenna Or Cable Without A Cable Box
TV + VCR + antenna or cable without a cable box VCR Rear Terminals Yellow ¢ AUDIO IN VIDEO OUT AUDIO OUT © White (Y/C) ® CH-1 CH-1 Antenna MONITOR CH-2 CH-2 £ Attach only cable type ® © Yellow TV Rear Terminals VIDEO AUDIO... - Page 15 TV + VCR + antenna or cable without a cable box Use this hook-up to: • connect a VCR along with your cable or antenna equipment you will need: Two lengths of One set of RCA One IR emitter One RCA pin- OR One S-Video cable 75 ohm coaxial pin-type audio assembly (if...
-
Page 16: Connecting The Infrared (Ir) Emitter
Connecting the Infrared (IR) Emitter for TV GUIDE Plus+ TV Back Panel VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV CONTROL HDTV AUDIO (MONO) INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) NETWORK HOME G LINK DVD VIDEO THEATER AUDIO OUTPUT (MONO) - Page 17 Infrared receivers are usually located on the front face of the VCR or cable box. Consult the owner manual(s) of your equip- ment to ensure accurate positioning of the Mitsubishi IR transmitter lenses. ⁄Important: When you have both a cable box and a VCR, place one IR transmit- ter in front of each component.
-
Page 18: Tv + Cable With A Cable Box When Tv Guide Plus + Will Be Used
TV + cable with a cable box when TV GUIDE Plus + will be used Incoming † Cable TV Rear Terminal VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV CONTROL HDTV AUDIO (MONO) £ ¢ INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) - Page 19 TV + cable with a cable box when TV GUIDE Plus + will be used Use this hook-up to: • connect a cable box to view premium cable channels and use TV GUIDE Plus+ equipment you will need: Transmitter Lenses IR Emitter one two-way splitter four lengths of 75 ohm...
-
Page 20: Tv + Vcr + Cable With A Cable Box When Tv Guide Plus + Will Be Used
TV + VCR + cable with a cable box when TV GUIDE Plus + will be used VCR Rear Terminals Yellow VIDEO OUT AUDIO OUT AUDIO IN White © § (Y/C) ¶ CH-1 CH-1 Antenna MONITOR CH-2 CH-2 Attach only cable type Yellow... - Page 21 TV + VCR + cable with a cable box when TV GUIDE Plus + will be used Use this hook-up to: • connect a VCR along with a cable box and use TV GUIDE Plus+ equipment you will need: IR Transmitters Transmitter Lenses IR Emitter Connection one two-way splitter...
- Page 22 TV + cable with a cable box with TV GUIDE Plus + (cont.) § Connect an RCA pin-type video cable from the VIDEO OUT terminal on the back of the VCR to the VIDEO INPUT 1 or INPUT 2 terminal on the back of the TV. ⁄Important: If you are connecting a Super VHS (S-VHS) VCR, use an S-Video cable instead of an RCA pin-type video cable.
-
Page 23: Chapter 2: Additional Component Connections
This book will show you the basic connections to hookup your TV with components. If you have difficulty making any of the connections to your TV, you may want to contact your Mitsubishi dealer or your local cable company. • TV + stereo audio system •... -
Page 24: Tv + Stereo Audio System
TV + stereo audio system Audio system rear terminals TAPE TAPE White Lead SUBWOOFER (MONO) † Red Lead TV Rear Terminals VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV AUDIO HDTV CONTROL (MONO) INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) HOME G LINK... - Page 25 TV + stereo audio system After you have completed your basic connections (TV to antenna, cable, VCR and TV GUIDE Plus+ emitter assembly) as shown in the previous pages, Use this hook-up to: • listen to the sound from your TV and/or VCR through your home audio system.
-
Page 26: Tv + Mitsubishi Products That Have A/V Network Terminals
TV + Mitsubishi products that have A/V network terminals Mitsubishi Component rear terminals INPUT A/V NETWORK PREOUT REAR CENTER WOOFER ¢ TV rear terminals VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV AUDIO HDTV CONTROL (MONO) INPUT-3... - Page 27 Only one of the products needs to be in “line of sight” of the remote control. Mitsubishi VCRs that have Active A/V Network also have the benefits of additional automated tasks. See Chapter 2 of the Owner's Guide, " Creating the AV Connection ," for more informa- tion about the Active A/V Network features.
-
Page 28: Tv + Dvd Player With Component Video Outputs
TV + DVD player with component video outputs ® VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV AUDIO HDTV CONTROL (MONO) INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) HOME G LINK NETWORK THEATER DVD VIDEO AUDIO OUTPUT (MONO) VIDEO AUDIO LOOP... - Page 29 TV + DVD player with component video outputs After you have completed the basic connections (TV to antenna, cable, VCR and TV GUIDE Plus+ emitter assembly) outlined in the previous pages, you can use the folllowing hookup to: Use this hook-up to: •...
-
Page 30: Tv + Av Receiver
TV + AV receiver † VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV AUDIO HDTV CONTROL (MONO) INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) HOME G LINK NETWORK THEATER DVD VIDEO AUDIO OUTPUT (MONO) VIDEO AUDIO LOOP ANT-A ANT-B ¢... - Page 31 TV + AV receiver After you have completed your basic connections (TV to antenna, cable, VCR and TV GUIDE Plus+ transmitter) as shown in the previous pages, use this hook-up to: • Select the inputs and control the sound through the AV receiver's remote control.
-
Page 32: Tv Back Panel
Connecting the Infrared (IR) Emitter for the Home Theater connection TV Back Panel VIDEO AUDIO HIGH-DEFINITION INTERFACE S-VIDEO (MONO) HDTV VIDEO INPUT-1 INPUT-2 HDTV AUDIO HDTV CONTROL (MONO) INPUT-3 MONITOR OUTPUT ACTIVE A/V (MONO) HOME G LINK NETWORK THEATER DVD VIDEO AUDIO OUTPUT (MONO) - Page 33 Connecting the Infrared (IR) Emitter for the Home Theater connection Use this hook-up to: • connect a Mitsubishi AV receiver to your TV for the Home Theater function. equipment you will need (included with TV): Transmitter Lenses IR Emitter IR emitter assembly two strips of double-sided adhesive foam tape (not pictured).
-
Page 34: Tv + Hdtv Receiver (Mitsubishi Brand Only) And Cable
MODEL NO. HD-1080 AC 120V 60 Hz 60 W AC LINE DISTRIBUTED BY MITSUBISHI CONSUMER ELECTRONICS AMERICA, INC. 6100 ATLANTIC BOULEVARD NORCROSS, GA 30071-1386 MADE IN JAPAN † A T S C C E R T I F I E D THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. - Page 35 TV + HDTV Receiver (cont.) use this hook-up to: • connect your Mitsubishi HDTV receiver and a cable television system. equipment you will need: one length of HDTV one 5-in-1 BNC pin- one set of RCA pin- one length of coaxial...
- Page 36 MITSUBISHI CONSUMER ELECTRONICS AMERICA, INC. 9351 Jeronimo Road Irvine, CA 92618-1904 800-332-2119 © 1998 Mitsubishi Consumer Electronics America, Inc. 871C570A10 Printed in U.S.A AV Systems Connection Guide...
