Summary of Contents for A2B Electronics ECO-12
- Page 1 INSTALLATION GUIDE ECO-12 12 way passive combiner English design for TV...
- Page 2 Contents Introduction Unpacking the unit Installation Technical specification English...
- Page 3 This gives you a nice installation, easy to overlook. The ECO-12 is made for 19 inch mounting so that you can install it together with our 19 inch rack base units (EBU-100 and EBU-200).
- Page 4 2. Unpacking the unit ECO-12 is delivered with two connection cables. The following items are included in the package: Amount Description ECO-12, 12 way passive combiner Connection cables This Installation guide in printed version Every unit is quality inspected by us before delivery. Should any items be missing when unpacking, please contact our support service (see page 3 for address).
- Page 5 3. Installation The ECO-12 has 12 inputs which allows you to combine up to 12 signals within 5 to 1000MHz. The two cables that’s included has to be connected to get the signals from the inputs to the output. Connect one of the cables from “A”...
- Page 6 4. Technical specification ECO-12 12 way passive combiner Return loss Connectors 5-40 MHz > 20,0 dB Input connectors F connector female Output connectors F connector female 40-860 MHz > 18,0 dB Impedance 75 ohm 860-1000 MHz > 18,0 dB Number of inputs...
- Page 7 Notes _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ English...
- Page 8 A2B Electronics AB Södra Allén 23-25, 591 37 Motala P.O. Box 14, 591 21 Motala SWEDEN Phone +46 141 229100 Fax +46 141 229101 E-mail market@a2b.se 654400.01 rev_A To view our full line of Professional E-series Products, visit our Web site...
