CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR
PROPERTY DAMAGE MAY OCCUR!
200 x 200 to
700 x 400
Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
13-09-030-9332E8-EN.indd 1
Owner's Manual
Tilt Flat Screen
Wall Mount
Model: DWT3285L
32"- 85"
Tripp Lite по адресу: www.tripplite.com
Copyright © 2014 Tripp Lite. All rights reserved.
MAX
1
56.6kg
(125lbs)
MAX
4/3/2014 2:57:58 PM
Advertisement
Summary of Contents for Tripp Lite DWT3285L
- Page 1 (125lbs) Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: www.tripplite.com Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com...
- Page 2 WARRANTY REGISTRATION Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary.
- Page 3 Component Checklist IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit www.tripplite.com/support for service. Wall Bracket (1) Mount Arms (2) M8x20 (4) M6x14 (4) M5x10 (2) Lag Bolts (4) Concrete Anchor (4) Rubber Washer (4)
- Page 4 1a. Mount on Wood Stud Wall 65 mm (2.5”) ø 4 mm (ø 5/32”) Find and mark the exact location of mounting holes Wall Bracket Drill pilot holes Lag Bolt Screw the wall Metal plate onto the Washer wall WARNING •...
- Page 5 1b. Mount on Solid Brick, Cinder Block or Concrete Wall 64 mm (2.5”) ø 8 mm (ø 5/16”) Mark the exact location of mounting holes Drill pilot holes Lag bolt Concrete Anchor Metal Washer Screw the wall plate onto the wall WARNING •...
- Page 6 2. Attach Mount Arms to Display Rubber Washer M8X20 M6X14 Note: Choose appropriate screws, washers and spacers (if necessary) according to the type of screen. • Position the adapter brackets as close as possible to the center of the display. •...
- Page 7 3. Attach Mount Arms to Wall Bracket Wall Wall Security Screw • Attach display to wall bracket and slide into position. Loosely fasten mount arms into place using security screws. • Adjust display until it’s in the desired position. Tighten security screws using supplied Hex key to lock into place.
- Page 8 4. Height and Level Adjustment DOWN ROTATE LEFT ROTATE RIGHT Adjust display as desired. • Turn knob CLOCKWISE to raise side. • Turn knob COUNTER-CLOCKWISE to lower side. 13-09-030-9332E8-EN.indd 8 4/3/2014 2:58:03 PM...
- Page 9 5. Tilt and Depth Adjustment TILT FORWARD TILT BACKWARD TILT RIGHT TILT LEFT Adjust display as desired. • Turn knob CLOCKWISE to move corner towards the wall. • Turn knob COUNTER-CLOCKWISE to move corner away from the wall. Note: Adjustments are made with the wall bracket open (see step 8 for instructions on opening the unit) and you facing the back of your display.
- Page 10 6. Cable Management Cable Mesh Sleeve Display cables can be routed along top or bottom of wall bracket. • Use mesh sleeve and cable ties for cable management. 7. Opening and Closing Wall Bracket Locking PULL UP PUSH UP Locking To open wall bracket, push or pull up on locking tabs.
- Page 11 8. Opening and Closing Mount Arms To Open PULL DOWN Open mount arms by pulling down on the orange cords while an assistant pulls the bottom of the display up and away from the wall. Note: The kickstand will automatically engage. Make sure it is in the down position before letting go of the display. Important: Open position is for service access only.
- Page 12 9. Securing Wall Bracket (Optional) M5X10 To prevent locking tabs from releasing, secure them with the two M5x10 Security Screws provided. 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 13-09-030 • 93-32E8_RevA 13-09-030-9332E8-EN.indd 12 4/3/2014 2:58:07 PM...
