INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D'INSTRUCTIONS
COLOUR CCD Camera
CCD-Farbkamera
Caméra CCD COULEUR
About this manual
Before installing and using the camera, please read this
manual carefully. Be sure to keep it handy for later reference.
À propos de ce manuel
Avant d'installer et d'utiliser la caméra, veuillez lire ce
manuel attentivement. Gardez-le à portée de main
pour toute référence ultérieure.
Über diese Bedienungsanleitung
Lesen Sie bitte vor der Montage und dem
Inbetriebnehmen der Kamera zuerst diese
Bedienungsanleitung sorgfältig durch und bewahren Sie
sie zum späteren Nachschlagen auf.
VCC-9612P
Advertisement
Table of Contents
Related Manuals for Sanyo VCC-9612P
Summary of Contents for Sanyo VCC-9612P
- Page 1 VCC-9612P INSTRUCTION MANUAL BEDIENUNGSANLEITUNG MANUEL D’INSTRUCTIONS COLOUR CCD Camera CCD-Farbkamera Caméra CCD COULEUR About this manual Über diese Bedienungsanleitung Before installing and using the camera, please read this Lesen Sie bitte vor der Montage und dem manual carefully. Be sure to keep it handy for later reference.
-
Page 2: Table Of Contents
CONTENTS FEATURES • Built-in interline transfer method 1/3" CCD, approx. 470,000 PRECAUTIONS..................2 picture elements PARTS NAMES AND FUNCTIONS............3 • Low smear, anti-blooming, low lag, no burning and no geometric PREPARATIONS AND CONNECTIONS..........6 distortion using the CCD solid state image device •... -
Page 3: Precautions
Disconnect the power greasy smoke or steam, where the dampness may get too high, or cord immediately, and consult your dealer (or a Sanyo Authorized where there is a lot of dust. -
Page 4: Parts Names And Functions
PARTS NAMES AND FUNCTIONS Manual pan, tilt and rotation The angle of the lens can be adjusted manually in ranges indicated below. A: Horizontally ±45˚ B: Vertically ±60˚ C: Rotation of the camera unit ±35˚ English... - Page 5 PARTS NAMES AND FUNCTIONS 1 Camera unit fixing screws (4) 6 12 V DC input terminal (12 V DC IN) These screws are used to attach the camera unit to the base. Tighten the four screws evenly when attaching the camera unit. Connect DC connecting cord from the AC adaptor to the 12V DC IN terminal on the base.
- Page 6 PARTS NAMES AND FUNCTIONS G Zoom ring M LEVEL volume control To adjust the viewing range (zoom), loosen the zoom ring knob, Used when the BLC switch is set to 1. Under normal conditions, it then turn the ring towards T (the range will be smaller and the should be turned all the way to the left.
-
Page 7: Preparations And Connections
PREPARATIONS AND CONNECTIONS Concerning the coaxial cable To connect the camera to peripheral devices, use a coaxial cable with BNC plug. • Cable type RG-6U (5C-2V), 500 m maximum. • Cable type RG-11U (7C-2V), 600 m maximum. If the type of peripheral devices connected, the type of cable used and/or the cable length are not as specified, the image and synchronization signals may not be transmitted correctly. -
Page 8: Connections And Installation
CONNECTIONS AND INSTALLATION Basic connections for monitoring or recording The peripheral devices (VCR, monitor, etc.) and cables are sold separately. (Example of connection to a monitor) Make the video signal connection between the camera and the monitor or time lapse VCR. -
Page 9: Camera Installation
CONNECTIONS AND INSTALLATION Coaxial cable connection 27mm 10mm Cut and prepare the extremity of the coaxial cable (sold separately), as illustrated. Attach the coaxial cable to the base. (Cut the shielding mesh here) Loosen the CAMERA (VIDEO) OUT terminal screw (A) and the GND terminal screw (B), then insert the center wire of the coaxial cable in the CAMERA (VIDEO) OUT terminal and make sure the shielding mesh part of the cable is located under the GND terminal plate, then tighten both screws (A and B) to attach the cable. - Page 10 CONNECTIONS AND INSTALLATION Install the camera unit onto the base. Connect the video signal cable plug (B) and the power supply cable plug (C) from the base to their respective connectors on the camera unit. Then install the camera unit onto the base.
-
Page 11: Settings And Adjustments
SETTINGS AND ADJUSTMENTS The digital process may disturb the image for about 5 seconds after the camera is turned on. Factory settings The camera is shipped from the factory with the following settings. These settings should give adequate results under normal conditions. If the settings need to be modified, please consult the reseller or installer. - Page 12 SETTINGS AND ADJUSTMENTS In this case, the backlight compensation default setting may not give good results. To obtain a better image, set the BLC switch to 1 (ON), then turn the LEVEL volume control to the right until the desired correction level is obtained. Manual white balance adjustment To set the colors, first set the WB switch to M, then adjust as desired, using the (B and R) color adjustment volume controls.
- Page 13 SETTINGS AND ADJUSTMENTS Zoom and focus adjustments After the camera has been installed, the zoom and focus must be adjusted while viewing on a monitor the transmitted image. Remove the lens cover, then press on both sides of the secondary lens cover to remove it.
-
Page 14: Troubleshooting
This camera is a precision instruments and, if treated with care, it will provide years of satisfactory performance. However, in the event of a problem, the owner is advised not to attempt to make repairs or open the cabinet. Servicing should always be referred to your dealer or Sanyo Authorized Service Center. -
Page 15: Specifications
