Page 1 AVALON 2 0 1 1 QUICK REFERENCE GUIDE I n f o r ma t i o n P r o v i d e d b y :...
Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Avalon.
Page 3: Table Of Contents
Seat belts-Shoulder belt anchor Spare tire & tools Tire Pressure Monitoring (warning) System 24 Trunk-Internal release Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. ®...
Page 4: Overview
OVERVIEW Instrument panel Steering wheel controls Steering wheel audio controls Telephone controls Steering wheel climate controls Ignition switch (standard key) I n f o r ma t i o n P r o v i d e d b y : Voice command button Multi-information display button Driving position memory switches...
Page 5 Cruise control Tire Pressure Monitoring (warning) System reset Tilt lock release lever Telescopic lock release I n f o r ma t i o n P r o v i d e d b y : Power rearview mirror control VSC OFF switch Glass breakage sensor Rear sunshade switch...
Page 6: Instrument Cluster
Front passenger occupant classification indicator/ Front passenger airbag ON/OFF indicator Low engine oil pressure warning If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer.
Page 7 Malfunction/Check Engine indicator Engine oil replacement reminder Low fuel level warning Open door warning Airbag SRS warning Tire Pressure Warning Low windshield washer fluid level warning Security indicator Headlight low/high beam indicator Turn signal indicator Automatic headlight leveling system warning Slip indicator Vehicle Stability Control OFF indicator Traction Control OFF indicator...
Page 8: Keyless Entry 1
OVERVIEW Keyless entry Locking operation Without Smart Key system With Smart Key system Push Unlocking operation Without Smart Key system With Smart Key system Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety.
Page 9: Smart Key System 2
Smart Key system (if equipped) Start function Green indicator ON Depress Push Carrying brake pedal NOTE: Gear shift lever must be in Park and brake pedal depressed. Power (without starting engine) Without depressing the brake pedal, pressing the “ENGINE START STOP” switch will change the operation mode in succession from: Accessories such as the radio will operate.
Page 10: Fuel Tank Door Release And Cap
OVERVIEW Fuel tank door release and cap Turn Push Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Light control-Instrument panel Brightness control Trunk release I n f o r ma t i o n P r o v i d e d b y : Trunk opener Push...
Page 11: Engine Maintenance
Hood release Pull Pull up latch and raise hood Engine maintenance Engine coolant reservoir Power steering fluid reservoir I n f o r ma t i o n P r o v i d e d b y : Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank NOTE: Regularly scheduled maintenance, including oil changes, will...
Page 12: Auto Lock Functions 2
FEATURES/OPERATIONS Auto lock functions Automatic door locks can be programmed to operate in two different modes, or turned OFF. 1. Doors lock: when shifting from Park. Doors unlock: when shifting into Park. 2. Doors lock: when the vehicle speed goes above 12 mph. Doors unlock: when the driver’s door is opened within 10 seconds after turning the “ENGINE START STOP”...
Page 13: Parking Brake
Steering lock release If steering lock does not disengage: With Smart Key system Without Smart Key system Turn Turn Turn Push Gently turn wheel while pressing the “ENGINE START STOP” switch. If the lock does not release, the switch will flash green.
Page 14: Seat Adjustments-Front
FEATURES/OPERATIONS Seats-Head restraints Lock release button Seat adjustments-Front Leg support (if equipped) Seat position, cushion angle (if equipped) and height (if equipped) Seatback angle Lumbar support (if equipped) Seat adjustments-Rear I n f o r ma t i o n P r o v i d e d b y : Seatback angle lever Refer to the Owner’s Manual for more details.
Page 15 Lights & turn signals Headlights Headlights Parking lights Auto DRL OFF Low beam High beam High beam flasher -Daytime Running Light system (DRL)(if equipped) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Automatically turns lights off after a delay of 30 seconds, or the lock switch on remote may be pushed after locking.
Page 16: Windows-Power
FEATURES/OPERATIONS Windshield wipers & washers With AUTO rain-sensing wiper With interval wiper (if equipped) (if equipped) Adjust frequency* Adjust sensor Single wipe Single wipe sensitivity Interval wipe Auto wipe Slow Slow Fast Pull to wash and wipe Fast Pull to wash and wipe * Intermittent windshield wiper frequency adjustment Rotate to increase/decrease wipe frequency.
Page 17: Cruise Control
Cruise control Turning system ON/OFF System ON/OFF Functions Resume Increase speed Cancel Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Garage door opener (HomeLink ®...
Page 18: Sunshade-Rear 1
Refer to “Hands-free system (for cellular phone),” Section 3-4 in the Owner’s Manual for more details, or go to Toyota.com and enter “Bluetooth” in the keyword search. Sunshade-Rear (if equipped)
Page 19: Moonroof
Moonroof (if equipped) Sliding operation Push once to open partway; again to open completely. Open Close Recommended driving position to minimize wind noise. Tilting operation Close Tilt NOTE: If battery is disconnected, the moonroof needs to be reinitialized. Refer to the Owner’s Manual for more details. Multi-information display I n f o r ma t i o n P r o v i d e d b y : Push...
Page 20 FEATURES/OPERATIONS Audio Type 1 Push to skip up/down folder and radio category type Load CD(s) Eject CD Seek station/ CD track select Push to turn Push to ON/OFF adjust tone & balance Mute/pause Mode Station/CD View CD text track scan Preset button - functions in other modes indicated above number Type 2...
Page 21: Steering Wheel Switches
RADIO To preset stations Tune in the desired station and hold down a preset button until you hear a beep. Push desired preset button to select. To scan stations Push and hold “SCAN” to scan preset stations. Push again to hold selection. AUX or USB/AUX audio jack By inserting a mini plug into the AUX or USB/AUX audio jack, you can listen to music from a portable audio device through the vehicle’s speaker...
Page 22: Air Conditioning/Heating
FEATURES/OPERATIONS Air Conditioning/Heating Automatic climate control ON “DUAL” button Indicator ON: Separate temperature settings for driver and passenger. Indicator OFF: Synchronize temperature settings for driver and passenger. Temperature selector (passenger side) Air Conditioning ON/OFF Fresh or recirculated cabin air Airflow vent In “...
Page 23: Clock
Seat ventilators/Heaters (if equipped) With ventilator Heater only Turn Push Heater Turn Ventilator Push Push knob to pop the controller out. Turn clockwise for heater, counter-clockwise for ventilator. Clock H-Hour set M-Minute set :00-Round off minutes I n f o r ma t i o n P r o v i d e d b y :...
Page 24: Cup Holders
FEATURES/OPERATIONS Power outlets Auxiliary box Console box The “ENGINE START STOP” switch/engine switch must be in the “ACC” or “ON” position to be used. Cup holders Front Rear (type B) Rear (type A) I n f o r ma t i o n P r o v i d e d b y :...
Page 25: Safety And Emergency Features
SAFETY AND EMERGENCY FEATURES Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again.
Page 26: Seat Belt Comfort Guide
If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. NOTE: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light.
Page 27: Spare Tire & Tools
Trunk-Internal release Pull Spare tire & tools Tool location Luggage floor cover Spare tire cover Jack handle Wheel nut wrench Jack Spare tire Removing the spare tire I n f o r ma t i o n P r o v i d e d b y : (1) Remove the luggage cover.
Page 28 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 I n f o r ma t i o n P r o v i d e d b y : Printed in U.S.A. 2/10 Cert no. SGS-COC-005612 09-TCS-03785 00505-QRG11-AVA...
Page 29 TABLE OF CONTENTS Index 1-4. Opening and closing the Before driving windows and moon roof Power windows..... 80 Moon roof ......83 1-1. Key information Keys ........24 1-5. Refueling Opening the fuel tank 1-2. Opening, closing and locking cap........87 the doors and trunk Smart key system....
Page 30 2-4. Using other driving systems When driving Cruise control ..... 182 Rear view monitor system......186 2-1. Driving procedures Driving assist systems..195 Driving the vehicle....138 Engine (ignition) switch 2-5. Driving information (with smart key Cargo and luggage..... 200 system) ......
Page 31 TABLE OF CONTENTS Index ® 3-3. Using the Bluetooth audio Interior features system ® Bluetooth audio system ......277 3-1. Using the air conditioning ® Using the Bluetooth system and defogger audio system ....280 Automatic air conditioning ® Operating a Bluetooth system......
Page 32 3-6. Using the storage features Maintenance and care List of storage features ..337 3-7. Other interior features 4-1. Maintenance and care Sun visors ......345 Cleaning and protecting Vanity mirrors...... 346 the vehicle exterior ... 374 Clock ........347 Cleaning and protecting Ashtrays ......
Page 33 TABLE OF CONTENTS Index When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers ... 458 Maintenance data (fuel, oil level, etc.) ... 508 If your vehicle needs to be towed ...... 459 Fuel information....516 If you think something is Tire information....
Page 34 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 35: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 36 SRS airbag system and seat belt pretensioner system, be sure to check with your Toyota dealer for pre- cautionary measures or special instructions regarding installation.
Page 37 CAUTION General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others.
Page 38 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 39 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 40: Before Driving
TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other features interior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 41 Pictorial index Exterior Windshield wiper P. 177 ∗ Moon roof P. 83 Outside rear view mirror P. 77 Hood P. 391 Side marker light P. 173 I n f o r ma t i o n P r o v i d e d b y : Turn signal light P.
Page 42 Tail/stop light P. 173 Rear window defogger P. 225 Tail lights P. 173 Fuel filler door P. 87 Trunk P. 50 Door P. 43 Tire I n f o r ma t i o n P r o v i d e d b y : Back-up light Rotation P.
Page 43 Pictorial index Interior Door pocket Head restraint P. 62 P. 344 Console box P. 339 Seat belt P. 65 SRS driver airbag P. 101 Power window SRS knee airbag switch P. 80 P. 101 Front passenger airbag P. 101 I n f o r ma t i o n P r o v i d e d b y : ∗...
Page 44 Inside rear view mirror P. 75 Interior light P. 336 Personal light P. 336 Personal light P. 336 SRS curtain shield airbag P. 101 ∗ I n f o r ma t i o n P r o v i d e d b y : Moon roof switch P.
Page 45 Pictorial index Interior Door lock switch P. 44 Window lock switch P. 80 I n f o r ma t i o n P r o v i d e d b y : Power window switches P. 80 AVALON_U (OM41428U)
Page 46 Storage compartment P. 342 Cup holders P. 343 ∗ Ashtray P. 348 Shift lever P. 156 Shift lock override button P. 491 I n f o r ma t i o n P r o v i d e d b y : ∗...
Page 47: Instrument Panel
Pictorial index Instrument panel Gauges and meters P. 164 Headlight switch P. 173 Turn signal lever P. 161 Windshield wipers and Fog light switch P. 176 washer switch P. 177 Driving position ∗ memory switches Glove box P. 338 P. 58 I n f o r ma t i o n P r o v i d e d b y : Horn P.
Page 48 Audio remote control switches P. 274 ∗ Telephone switch P. 281 Engine (ignition) switch (vehicles with smart key system) P. 149 Engine (ignition) switch (vehicles without smart key system) P. 153 Climate remote control I n f o r ma t i o n P r o v i d e d b y : switches P.
Page 49 Pictorial index Instrument panel Emergency flashers P. 458 Clock P. 347 Air conditioning system P. 216 Audio system P. 227 Navigation system I n f o r ma t i o n P r o v i d e d b y : Rear window and outside rear view mirror defoggers P.
Page 50 Outside rear view mirror switches P. 77 VSC off switch P. 196 Fuel filler door opener P. 87 Trunk opener P. 50 ∗ I n f o r ma t i o n P r o v i d e d b y : Rear sunshade switch P.
Page 51: 1-1. Key Information
1-1. Key information Keys The following keys are provided with the vehicle. Vehicles with smart key system Electronic keys • Operating the smart key system (→P. 26) • Operating wireless remote control function (→P. 38) Mechanical keys Key number plate Vehicles without smart key system Master keys Operating the wireless remote...
Page 52 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 492)
Page 53: 1-2. Opening, Closing And Locking The Doors And Trunk
1-2. Opening, closing and locking the doors and trunk ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Electronic key Electronic key Electronic key...
Page 54 1-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors Grip the handle to unlock the door. Make sure to touch the sensor on the back of the handle. The door cannot be unlocked for 3 seconds after the door is locked.
Page 55 1-2. Opening, closing and locking the doors and trunk Antenna location and effective range Antenna location Antennas outside cabin Antenna outside trunk Antenna inside trunk Antennas inside cabin I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 56 1-2. Opening, closing and locking the doors and trunk Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 3 ft. (1 m) of an outside door handles.
Page 57 1-2. Opening, closing and locking the doors and trunk Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from →...
Page 58 1-2. Opening, closing and locking the doors and trunk Switching the door unlock function It is possible to set which doors the entry function unlocks. Turn the “ENGINE START STOP” switch off. When the indicator on the key surface is turned off, push and hold , or for approximately 5 seconds while pushing the button on the key.
Page 59 1-2. Opening, closing and locking the doors and trunk Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. When the entry function has not been used for 2 weeks or more When the electronic key has been left within approximately 3 ft.
Page 60 1-2. Opening, closing and locking the doors and trunk Note for the smart key system Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases. • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 61 1-2. Opening, closing and locking the doors and trunk Security feature If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the theft deterrent system automatically locks the vehicle again. Alarms and warning indicators A combination of exterior and interior alarms are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation.
Page 62 1-2. Opening, closing and locking the doors and trunk Alarm Situation Correction procedure Interior alarm The electronic key battery Replace the battery. sounds once is low. (→P. 428) Tried to open the door and Interior alarm exit the vehicle without Shift the shift lever to sounds continu- shifting the shift lever to...
Page 63 1-2. Opening, closing and locking the doors and trunk Customization that can be configured at Toyota dealer Settings (e.g. smart key system) can be changed. (Customizable features →P. 532) Certification for the smart key system For vehicles sold in the U.S.A.
Page 64 (→P. 28) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
Page 65: Wireless Remote Control
1-2. Opening, closing and locking the doors and trunk Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle and the trunk from outside the vehicle. Vehicles with smart key system Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door.
Page 66 1-2. Opening, closing and locking the doors and trunk Vehicles without smart key system Locks all doors Sounds alarm (push and hold) (→P. 97) Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
Page 67 (that emits radio waves) is being used nearby lWhen the wireless key has been left near an electrical appliance such as a personal computer Customization that can be configured at Toyota dealer Settings (e.g. 2-step unlocking function, trunk unlocking function) can be changed. (Customizable features →P. 532)
Page 68 1-2. Opening, closing and locking the doors and trunk Certification for wireless remote control For vehicles sold in the U.S.A. FCC ID: HYQ14AAB FCC ID: HYQ13BZH FCC ID: HYQ14ABK FCC ID: HYQ13BZW FCC ID: NI4TMLF-1 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 69 1-2. Opening, closing and locking the doors and trunk For vehicles sold in the U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 70: Doors
1-2. Opening, closing and locking the doors and trunk Doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. Entry system (vehicles with smart key system) →P. 27 Wireless remote control →P.
Page 71 1-2. Opening, closing and locking the doors and trunk Door lock switch Locks all doors Unlocks all doors Inside lock button Locks the door Unlocks the door The front doors can be opened by pulling the inside handles even if the lock buttons are in the lock position.
Page 72 1-2. Opening, closing and locking the doors and trunk Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door. Vehicles with smart key system The door cannot be locked if the “ENGINE START STOP” switch is in the ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 73 1-2. Opening, closing and locking the doors and trunk Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift lever out of “P” locks all door locking function doors.
Page 74 1-2. Opening, closing and locking the doors and trunk Setting and canceling the functions To switch between setting and canceling, follow the procedure below: Vehicles with smart key system: Close all the doors and turn the “ENGINE START STOP” switch to IGNITION ON mode. (Perform within 10 seconds.) Vehicles without smart key system: Close all the doors and...
Page 75 1-2. Opening, closing and locking the doors and trunk Shift lever Function Switch position position Shift position linked door lock- ing function “P” Shift position linked door unlocking function Speed linked door locking func- tion “N” Driver’s door linked door unlock- ing function When the setting or canceling operation is complete, all doors are locked and then unlocked.
Page 76 1-2. Opening, closing and locking the doors and trunk Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 532) CAUTION To prevent an accident Observe the following precautions while driving the vehicle.
Page 77: Trunk
1-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the trunk opener, smart key system or wireless remote control. Opening the trunk from inside the vehicle Push the opener switch. Opening the trunk from outside the vehicle Entry system (vehicles with smart key system) →P.
Page 78 1-2. Opening, closing and locking the doors and trunk Internal trunk release lever The trunk lid can be opened by pulling down on the glow-in-the-dark lever located on the inside of trunk lid. The lever will continue to glow for some time after the trunk lid is closed.
Page 79 1-2. Opening, closing and locking the doors and trunk CAUTION When children are in the vehicle Observe the following precautions. Failure to do so may result in death or serious injury. Do not allow children to enter the trunk. If a child is accidentally locked in the trunk, they could overheat or suffo- cate.
Page 80 Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to fall closed again after it is opened.
Page 81: Adjustable Components (Seats, Steering Wheel, Mirrors)
1-3. Adjustable components (seats, steering wheel, mirrors) Front seats Seat leg support switch Seat position fore/aft switch Seat cushion (front) angle switch Vertical height switch Seatback angle switch Lumbar support switch : if equipped Active head restraint When a front seatback receives a strong impact during a rear- end collision, the head restraint moves...
Page 82 1-3. Adjustable components (seats, steering wheel, mirrors) Active head restraint Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may cause the head restraint inner structure to appear. This does not indicate a problem. During Inner rear-end...
Page 83: Rear Seats
1-3. Adjustable components (seats, steering wheel, mirrors) Rear seats To adjust the seat back angle, pull the lock release lever. Keep the flap area clear Do not place objects on the flap area. If Flap area objects are left in the gap, the reclining seatback will not lock properly, and may move unexpectedly.
Page 84 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION Reclining adjustment Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
Page 85: Driving Position Memory System
1-3. Adjustable components (seats, steering wheel, mirrors) ∗ Driving position memory system Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be entered into the computer’s mem- ory and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
Page 86 1-3. Adjustable components (seats, steering wheel, mirrors) Recalling the memorized position Vehicles with smart key system: Turn the “ENGINE START STOP” switch to IGNITION ON mode. Vehicles without smart key system: Turn the engine switch to the “ON” position. Push button “1” or “2” to recall the memorized position.
Page 87 1-3. Adjustable components (seats, steering wheel, mirrors) Linking driving position memory with door unlock operation (vehicles with smart key system) Memorized driving positions can be recalled when you unlock the driver’s door using the entry function or wireless remote control and open the driver’s door.
Page 88 1-3. Adjustable components (seats, steering wheel, mirrors) Canceling the linked door unlock operation Close the driver’s door with the “ENGINE START STOP” switch OFF. Push the “SET” button and the button on the wireless remote control at the same time for about 1 second until you hear 2 beeps.
Page 89: Head Restraints
1-3. Adjustable components (seats, steering wheel, mirrors) Head restraints Head restraints are provided for all seats. Front seats Down Push and hold the lock release button when lowering the head restraint. Lock release button Rear seats Down Push and hold the lock release button when lowering the head restraint.
Page 90 1-3. Adjustable components (seats, steering wheel, mirrors) Removing the head restraints Pull the head restraint up while pushing the lock release button. Installing the head restraints Align the head restraint with the installa- tion holes and push it down to the lock position.
Page 91 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. Adjust the head restraints to the correct position at all times. After adjusting the head restraints, push down on them and make sure they are locked in position.
Page 92: Seat Belts
1-3. Adjustable components (seats, steering wheel, mirrors) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 93 1-3. Adjustable components (seats, steering wheel, mirrors) Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Seat belt comfort guide (outside rear seats) If the shoulder belt sits close to a person’s neck, use the seat belt comfort guide.
Page 94 1-3. Adjustable components (seats, steering wheel, mirrors) Buckle, position and release the seat belt. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
Page 95 1-3. Adjustable components (seats, steering wheel, mirrors) Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend, and you can move around fully.
Page 96 Toyota dealer free of charge. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 97 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at the same time, including children. Toyota recommends that children should be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
Page 98 Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. Have any necessary repairs carried out by your Toyota dealer. Inap- I n f o r ma t i o n P r o v i d e d b y : propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
Page 99 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION Using a seat belt comfort guide Make sure the belt is not twisted and that it lies flat. The elastic cord must be behind the belt and the guide must be on the front. To reduce the chance of injury in case of a sudden stop, sudden swerve or accident while driving, remove and store the comfort guide in its pocket when it is not in use.
Page 100: Steering Wheel
1-3. Adjustable components (seats, steering wheel, mirrors) Steering wheel The steering wheel can be adjusted to a comfortable position. To change the angle Hold the steering wheel, press the tilt lock release lever, and adjust to the ideal position by moving the steering wheel vertically.
Page 101 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION After adjusting the steering wheel Make sure that the steering wheel is locked. Otherwise, the steering wheel may move suddenly, possibly causing an accident and resulting in death or serious injury. While driving Do not adjust the steering wheel.
Page 102: Inside Rear View Mirror
1-3. Adjustable components (seats, steering wheel, mirrors) Inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. In auto mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Press the button for longer than 3 seconds to turn auto mode on/off.
Page 103 1-3. Adjustable components (seats, steering wheel, mirrors) Adjusting the height of the rear view mirror Adjust the height of the rear view mirror by moving it up and down. To prevent sensor error To ensure correct functioning of the sen- sors, do not touch or cover the sensors.
Page 104: Outside Rear View Mirrors
1-3. Adjustable components (seats, steering wheel, mirrors) Outside rear view mirrors Mirror angle can be adjusted using the switch. Select a mirror to adjust. Left Right Adjust the mirror. Right Down Left Folding the mirrors Push backward to fold the mir- rors.
Page 105 1-3. Adjustable components (seats, steering wheel, mirrors) The outside rear view mirrors can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in the ACCESSORY or IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. When the mirrors are fogged up Turn on the mirror heaters to defog the mirrors.
Page 106 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION While driving Observe the following precautions. Failing to do so may result in losing control of the vehicle and cause an acci- dent, resulting in death or serious injury. Do not adjust the mirrors. Before driving, be sure to make an adjustment of the driver and passenger side mirrors properly.
Page 107: Opening And Closing The Windows And Moon Roof Power Windows
1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. One-touch closing Closing One-touch opening Opening : Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 108 1-4. Opening and closing the windows and moon roof The power windows can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. Operating the power windows after turning the engine off Vehicles with smart key system The power windows can be operated for approximately 45 seconds even...
Page 109 1-4. Opening and closing the windows and moon roof CAUTION When closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 110: Moon Roof
1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. Opening and closing Open Stops just before it is opened fully. Press the switch again to fully open.
Page 111 1-4. Opening and closing the windows and moon roof The moon roof can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. Operating the moon roof after turning the engine off Vehicles with smart key system The moon roof can be operated for approximately 45 seconds even after the...
Page 112 1-4. Opening and closing the windows and moon roof To reduce moon roof wind noise Drive with the moon roof opened automatically (just before fully opened position). Sunshade The sunshade can be opened and closed manually. However, the sunshade will open automatically when the moon roof is opened. When the battery is disconnected The moon roof must be initialized in order to ensure proper operation.
Page 113 1-4. Opening and closing the windows and moon roof CAUTION When opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 114: 1-5. Refueling
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle Turn the “ENGINE START STOP” switch or the engine switch OFF and ensure that all the doors and windows are closed. Opening the fuel tank cap Press the fuel filler door opener switch.
Page 115 1-5. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap clockwise until you hear a click. The cap will revolve slightly in the opposite direction once released. Fuel types Use unleaded gasoline. (Octane Rating 87 [Research Octane Number 91] or higher) Fuel tank capacity Approximately 18.5 gal.
Page 116 When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result I n f o r ma t i o n P r o v i d e d b y : in death or serious injury.
Page 117 1-5. Refueling NOTICE Refueling Do not spill fuel during refueling. Failing to do so may damage the vehicle, such as causing the exhaust sys- tems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 118: Theft Deterrent System Engine Immobilizer System
1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles with a smart key system The indicator light flashes after...
Page 119 1-6. Theft deterrent system Vehicles without a smart key system The indicator light flashes after the key has been removed from the engine switch to indi- cate that the system is operat- ing. The indicator light stops flash- ing after the registered key has been inserted into the engine switch to indicate that the system has been can-...
Page 120 1-6. Theft deterrent system Certifications for the engine immobilizer system For vehicles sold in the U.S.A. FCC ID: MOZRI-21BTY FCC ID: NI4TMIMB-1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 121: Alarm
1-6. Theft deterrent system Alarm The system sounds the alarm and flashes lights when forcible entry is detected. Triggering the alarm The alarm is triggered in the following situations when the alarm is set: l A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote door lock func- tion or using the mechanical key.
Page 122 1-6. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm. Vehicles with a smart key system l Unlock the doors or trunk. l Turn the “ENGINE START STOP” switch to ACCESSORY or IGNITION ON mode, or start the engine.
Page 123 1-6. Theft deterrent system Triggering of the alarm The alarm may be triggered in the following situations. (Stopping the alarm deactivates the alarm system.) A person inside the vehicle opens a door, the trunk or hood. The battery is recharged or replaced when the vehicle is locked.
Page 124 1-6. Theft deterrent system Panic mode Vehicles with smart key system When is pushed for longer than about one second, an alarm will sound for about 60 seconds and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle.
Page 125: Theft Prevention Labels (U.s.a.)
1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 126: Safety Information Correct Driving Posture
1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 127 1-7. Safety information CAUTION While driving Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 128: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 129 1-7. Safety information Airbag system components Front airbag sensor Driver’s seat position sensor Front passenger airbag Knee airbag “AIR BAG ON” and “AIR BAG Airbag sensor assembly OFF” indicator lights Occupant detection system Side airbag (ECU and sensors) Curtain shield airbag Front passenger’s seat belt buckle switch Side and curtain shield airbag...
Page 130 1-7. Safety information Your vehicle is equipped with “ADVANCED AIRBAGS” designed based on US motor vehicle safety standards (FMVSS208). The air- bag system controls airbag deployment power for the driver and front passenger. The driver airbag system consists of the driver seat’s position sensor etc.
Page 131 1-7. Safety information Operating conditions (front airbags) The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 132 1-7. Safety information Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or hard surface Falling into or jumping over a deep hole...
Page 133 1-7. Safety information Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 134 1-7. Safety information When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. The front of the vehicle is damaged or deformed, or was involved in an acci- dent that was not severe enough to cause the SRS airbags to inflate.
Page 135 1-7. Safety information CAUTION SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts. The SRS driver airbag deploys with considerable force, and can cause death or serious injury especially if the driver is very close to the airbag.
Page 136 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 137 1-7. Safety information CAUTION SRS airbag precautions Do not sit on the edge of the seat or lean against the dashboard. Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. Do not drive the vehicle while the driver or passenger have items resting on their knees.
Page 138 1-7. Safety information CAUTION SRS airbag precautions Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad or lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
Page 139 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnish, are damaged or cracked, have them replaced by your Toyota dealer. Do not place anything, such as a cushion, on the front passenger’s seat.
Page 140 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 141: Front Passenger Occupant Classification System
1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light “AIR BAG OFF”...
Page 142 1-7. Safety information Condition and operation in the front passenger occupant classi- fication system Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Devices...
Page 143 1-7. Safety information Unoccupied “AIR BAG ON” and “AIR BAG OFF” indicator lights illuminated Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front Activated passenger side Front passenger’s seat belt pretensioner...
Page 144 1-7. Safety information : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may recognize him/her as a child depending on his/her physique and posture. : In the event the front passenger does not wear a seat belt. : When a large child who has outgrown a child restraint system sits in the front passenger seat, the system may recognize him/ her as an adult depending on his/her physique or posture.
Page 145 1-7. Safety information CAUTION Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 146 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction on the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 147: Child Restraint Systems
1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 148 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear-facing ⎯ Infant seat/convertible seat Forward-facing ⎯ Convertible seat Booster seat I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 149 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 150 1-7. Safety information CAUTION Child restraint precautions A forward-facing child restraint system may be installed on the front pas- senger seat only when it is unavoidable. A child restraint system that requires a top tether strap should not be used in the front passenger seat since there is no top tether strap anchor for the front passenger seat.
Page 151 1-7. Safety information CAUTION Child restraint lock function belt precaution Do not allow children to play with the child restraint lock function belt. If the belt becomes twisted around a child’s neck, it will not be possible to pull the belt out leading to choking or other serious injuries that result in death.
Page 152: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the outboard rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 153 1-7. Safety information Installation with LATCH system Adjust the seatback as leaned as As leaned possible. as possible Widen the gap between the seat cushion and seatback slightly. Type A Latch the hooks of the lower straps onto the LATCH anchors. I n f o r ma t i o n P r o v i d e d b y : Canada only AVALON_U (OM41428U)
Page 154 1-7. Safety information If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether anchors. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 155 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat Place the child restraint system on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 156 1-7. Safety information While pushing the child restraint system down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 157 1-7. Safety information Fully extend the shoulder strap and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 158 1-7. Safety information Booster seat Place the booster seat on the seat facing the front of the vehi- cle. Sit the child in the booster seat. Fit the seat belt to the booster seat according to the manufac- turer’s instructions and insert the plate into the buckle.
Page 159 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Secure the child restraint using a seat belt or LATCH anchors, and lock the head restraint in place at the lowest position.
Page 160 1-7. Safety information Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. CAUTION When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR...
Page 161 1-7. Safety information CAUTION When installing a child restraint system Only put a forward-facing child seat on the front seat when unavoidable. When installing a forward-facing child restraint on the front passenger seat, move the seat as far back as possible even if “AIR BAG OFF”...
Page 162 1-7. Safety information CAUTION Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of sud- den braking, sudden swerving or an accident.
Page 163 1-7. Safety information I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 164: 2-1. Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. Starting the engine →P. 149, 153 Driving With the brake pedal depressed, shift the shift lever to “D”. (→P. 156) Release the parking brake. (→P.
Page 165 Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended...
Page 166 2-1. Driving procedures CAUTION When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine run- ning. This prevents the vehicle from creeping. When driving the vehicle Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
Page 167 2-1. Driving procedures CAUTION When driving the vehicle If the smell of exhaust is noticed inside the vehicle, open the windows and check that the trunk is closed. Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard.
Page 168 2-1. Driving procedures CAUTION When driving the vehicle Do not adjust the position of the steering wheel, the seat, or the inside or outside rear view mirrors while driving. Doing so may result in a loss of vehicle control that can cause accidents that may result in death or serious injury.
Page 169 2-1. Driving procedures CAUTION When shifting the shift lever Be careful not to shift the shift lever with the accelerator pedal depressed. This may lead to unexpected rapid acceleration of the vehicle that may cause an accident and result in death or serious injury. When the vehicle is stopped Do not race the engine.
Page 170 2-1. Driving procedures CAUTION When the vehicle is parked Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Failure to do so may result in the following: • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
Page 171 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 172 2-1. Driving procedures CAUTION When braking the vehicle When the brakes are wet, drive more cautiously. Braking distance increases when the brakes are wet, and may cause one side of the vehicle to brake differently than the other side. Also the parking brake may not securely hold the vehicle.
Page 173 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. The rotor damage can result if the pads are not replaced when needed.
Page 174 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function Changes in quantity and quality of oil and fluid used for the engine, trans- mission, differentials, etc.
Page 175: Engine (Ignition) Switch (With Smart Key System)
2-1. Driving procedures Engine (ignition) switch (with smart key system) Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in “P”.
Page 176 2-1. Driving procedures Changing engine (ignition) switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) Emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 177 When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. Auto power OFF function The “ENGINE START STOP” switch will automatically turn OFF when left in ACCESSORY mode for 1 hour or more.
Page 178 2-1. Driving procedures CAUTION When starting the engine Always start the engine while sitting in the driver’s seat. Do not press the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. Stopping the engine in an emergency If you want to stop the engine in an emergency while driving the vehicle, push and hold the “ENGINE START STOP”...
Page 179: Engine (Ignition) Switch (Without Smart Key System)
2-1. Driving procedures Engine (ignition) switch (without smart key system) Starting the engine Check that the parking brake is set. Check that the shift lever is set in “P”. Sit in the driver’s seat and firmly depress the brake pedal. Turn the engine switch to the “START”...
Page 180 2-1. Driving procedures Turning the key from “ACC” to “LOCK” Shift the shift lever to “P”. Push in the key and turn to the “LOCK” position. When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK” position.
Page 181 2-1. Driving procedures CAUTION When starting the engine Always start the engine while sitting in the driver’s seat. Do not press the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. While driving Do not turn the engine switch to the “LOCK”...
Page 182: Automatic Transmission
2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever S mode driving position Vehicles with smart key system: While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever.
Page 183 2-1. Driving procedures Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving S mode driving : Shifting to the D position allows the system to select a gear suitable for the driving conditions. Setting the shift lever to the D position is recommended for normal driv- ing.
Page 184 2-1. Driving procedures Changing shift ranges in S mode Shift the shift lever to the S mode driving position and operate the shift lever. Upshifting Downshifting The initial shift range in S mode is set automatically to 5 or 4 accord- ing to vehicle speed.
Page 185 2-1. Driving procedures Shift ranges and their functions l Automatically selecting gears between 1 and 6 according to vehicle speed and driving condition. (However the gear is limited according to selected shift range.) l You can choose from 6 levels of engine braking force. l A lower shift range will provide greater engine braking force than a higher shift range, and the engine speed will also increase.
Page 186 S mode driving position This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 187: Turn Signal Lever
2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever.
Page 188: Parking Brake
2-1. Driving procedures Parking brake Sets the parking brake (Depressing the pedal again releases the parking brake.) U.S.A. Canada : Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. Usage in winter time See “Winter driving tips”...
Page 189: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 190: 2-2. Instrument Cluster
2-2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on the target region. Engine coolant temperature gauge Displays the engine coolant temperature. Tachometer Displays the engine speed in revolutions per minute. Shift position indicator Displays the shift position Speedometer Displays the vehicle speed.
Page 191 2-2. Instrument cluster Odometer/Trip meter display Odometer Displays the total distance the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and dis- play different distances independently.
Page 192 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter NOTICE To prevent damage to the engine and its components Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed.
Page 193: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster The units used on the speedometer and some indicators may differ depending on the target region.
Page 194 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by your Toyota dealer.
Page 195 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by your Toyota dealer.
Page 196: Multi-Information Display
2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data including the current outside air temperature. l Outside temperature dis- play l Trip information Displays driving range, fuel consumption and other cruis- ing related information Switching the display Items displayed can be switched by pressing the “DISP”...
Page 197 2-2. Instrument cluster Display items Outside temperature Displays the outside air temperature The temperature range that can be displayed is from -40 °F (-40 °C) up to 122 °F (50 °C). Driving range Displays the estimated maximum distance that can be driven with the quantity of fuel remaining •...
Page 198 2-2. Instrument cluster Average vehicle speed Displays the average vehicle speed since the engine was started or the function was reset The function can be reset by pressing the “DISP” but- ton for longer than 1 second when the average vehi- cle speed is displayed.
Page 199: 2-3. Operating The Lights And Windshield Wipers
2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. U.S.A. The headlights, park- ing lights, daytime run- ning lights and so on turn on and off auto- matically. (When the “ENGINE START STOP”...
Page 200 2-3. Operating the lights and windshield wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off.
Page 201 Customization that can be configured at Toyota dealer Settings (e.g. light sensor sensitivity) can be changed. (Customizable features →P. 532)
Page 202: Fog Light Switch
2-3. Operating the lights and windshield wipers Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 203: Windshield Wipers And Washer
2-3. Operating the lights and windshield wipers Windshield wipers and washer Intermittent wiper with interval adjuster (if equipped) Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper operation Temporary operation Increases the intermittent windshield wiper frequency...
Page 204 2-3. Operating the lights and windshield wipers Wash/wipe operation Wipers will automatically oper- ate a couple of times after the washer squirts. Raindrop detection windshield wipers (if equipped) With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed.
Page 205 2-3. Operating the lights and windshield wipers Sensor sensitivity (high) Sensor sensitivity (low) Wash/wipe operation Wipers will automatically oper- ate a couple of times after the washer squirts. The windshield wiper and washer can be operated when Vehicles with smart key system The “ENGINE START STOP”...
Page 206 I n f o r ma t i o n P r o v i d e d b y : Customization that can be configured at Toyota dealer Settings (e.g. switching operation when the vehicle is stationary) can be changed.
Page 207 When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. I n f o r ma t i o n P r o v i d e d b y :...
Page 208: Using Other Driving Systems Cruise Control
2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without using the accelerator. Indicator Cruise control switch Set the vehicle speed Press the “ON-OFF” button to activate the cruise control. Press the button once more to deactivate the cruise control.
Page 209 2-4. Using other driving systems Adjusting the speed setting To change the set speed, operate the lever until the desired set speed is obtained. Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment. Momentarily move the lever in the desired direction.
Page 210 2-4. Using other driving systems Canceling and resuming regular acceleration Pulling the lever toward you cancels the constant speed control. The speed setting is also can- celed when the brakes are applied. Pushing lever resumes constant speed control. Resuming is available when the vehicle speed is more than approximately 25 mph (40 km/h).
Page 211 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF”...
Page 212: Rear View Monitor System
2-4. Using other driving systems ∗ Rear view monitor system The rear view monitor system assists the driver by displaying an image of the view behind the vehicle while reversing. The image is displayed in reverse on the screen. This allows the image to appear in the same manner as that of the rear view mirror.
Page 213 2-4. Using other driving systems Switching the screen Green indicator comes on. Orange indicator comes on. When using the rear view monitor system The anti-glare function of the inside rear view mirror will be canceled. Automatic shut off The display will be turned off automatically after 5 minutes. Display mode The rear view monitor display mode can be adjusted when the engine switch is in the ON and the shift lever is in R.
Page 214 2-4. Using other driving systems To temporarily turn off the monitor when it is on. Push the button. The indicator should turn orange. The monitor will automatically turn on again after the engine switch is turned OFF and ON. To manually turn on the monitor when it is turned off. Push the button.
Page 215 2-4. Using other driving systems Displayed area The area covered by the camera is lim- ited. Objects which are close to either corner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary according to vehicle orientation or road conditions.
Page 216 2-4. Using other driving systems Rear view monitor guide lines ITN24A032 Guide lines are displayed on the screen. Guide lines shown differ from those shown on the actual screen. Vehicle width extension guide lines (blue) These lines indicate the estimated vehicle width extension. Distance guide line (blue) This line indicates a position on the ground about 3 ft.
Page 217 2-4. Using other driving systems Rear view monitor system camera In the following cases, it may be difficult to see the images on the screen, even when the system is functioning correctly. • In the dark (e.g. at night). • If the temperature near the lens is extremely high or low.
Page 218 2-4. Using other driving systems Smear effect If a bright light (e.g. sunlight reflected off the vehicle body) is picked up by the camera, a smear effect peculiar to the camera may occur. : Smear effect — A phenomenon that occurs when a bright light (for exam- ple, sunlight reflected off the vehicle ITN24A034...
Page 219 2-4. Using other driving systems CAUTION When using the rear view monitor system Observe the following precautions to avoid an accident that could result in death or serious injuries. Never depend solely on the monitor system when reversing. Always check visually and with the mirrors to confirm your intended path is clear.
Page 220 Conditions which may affect the rear view monitor system If the back of the vehicle is hit, the camera’s position and mounting angle may change. Contact your Toyota dealer. Rapid temperature changes, such as when hot water is poured on the vehicle in cold weather, may cause the system to function abnormally.
Page 221: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) Helps to prevent wheel lock when the brakes are applied suddenly, or if the brakes are applied while driving on a slippery road surface.
Page 222 2-4. Using other driving systems To disable TRAC/TRC and/or VSC If the vehicle gets stuck in fresh snow or mud, TRAC/TRC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. Turning off TRAC/TRC Quickly push and release the button to turn off TRAC/TRC.
Page 223 2-4. Using other driving systems Automatic reactivation of TRAC/TRC and VSC Vehicles with smart key system Turning the “ENGINE START STOP” switch off after turning off the TRAC/TRC and VSC will automatically re-enable them. Vehicles without smart key system Turning the engine switch to the “LOCK” position after turning off the TRAC/TRC and VSC will automatically re-enable them.
Page 224 2-4. Using other driving systems CAUTION The ABS does not operate effectively when The limits of tire gripping performance have been exceeded. The vehicle hydroplanes while driving at high speed on the wet or slick road. Stopping distance when the ABS is operating on the wet or slick roads The ABS is not designed to shorten the vehicle’s stopping distance.
Page 225 The ABS and VSC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 226: 2-5. Driving Information
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. l Stow cargo and luggage in the trunk whenever possible. Be sure all items are secured in place. l Be careful to keep the vehicle level. Placing the weight as far forward as possible helps maintain vehicle balance.
Page 227 (→P. 205) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. I n f o r ma t i o n P r o v i d e d b y :...
Page 228 2-5. Driving information Example on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb. (166 kg) are riding in your vehicle, which has a total load capacity of 870 lb. (395 kg), the available amount of cargo and luggage load capacity will be as follows: 870 lb.
Page 229 2-5. Driving information CAUTION Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk. Receptacles containing gasoline Aerosol cans Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury. Do not place cargo or luggage in or on the following locations as the item may get under the brake or accelerator pedal and prevent the pedals from being depressed properly, block the driver’s vision, or hit...
Page 230 2-5. Driving information CAUTION Weight of the load Do not exceed the maximum axle weight rating or the total vehicle weight rating. Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 231: Vehicle Load Limits
Even if the number of occupants are within the seating capacity, do not exceed the total load capacity. Towing capacity Toyota does not recommend towing a trailer with your vehicle. Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 232 2-5. Driving information Total load capacity and seating capacity These details are also described on the tire and loading information label. (→P. 418) CAUTION Overloading the vehicle Do not overload the vehicle. It may not only cause damage to the tires, but also degrade steering and braking ability, resulting in an accident.
Page 233: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations l Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 234 2-5. Driving information Before driving the vehicle Perform the following according to the driving conditions. l Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 235 2-5. Driving information Selecting snow chains Use the correct snow chain size when mounting the snow chains. Chain size is regulated for each tire size. Side chain: 0.12 in. (3.0 mm) 1.18 in. (30.0 mm) 0.39 in. (10.0 mm) Cross chain: 0.16 in.
Page 236 2-5. Driving information Snow chain installation Observe the following precautions when installing and removing chains. Install and remove tire chains in a safe location. Install tire chains on the front tires only. Install tire chains following the instructions provided in the accompanying instructions.
Page 237 2-5. Driving information NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 238: Trailer Towing
Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 239: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 240: Using The Air Conditioning System And Defogger Automatic Air Conditioning System
3-1. Using the air conditioning system and defogger Automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Automatic mode Dual operation Outside air or recirculated mode Air conditioning ON/OFF switch Windshield defogger Fan speed Passenger’s side temperature control Driver’s side temperature control...
Page 241 3-1. Using the air conditioning system and defogger Turning to the right increase the temperature and turn- to the left decrease the temperature. The temperature for the driver and passenger seats can be set sep- arately. Adjusting the settings Adjusting the temperature setting Turning to the right increase the temperature and turning to the left decrease the temperature.
Page 242 3-1. Using the air conditioning system and defogger Changing the air outlets Press The air outlets switch each time the button is pressed. The air flow shown on the display indicate the following. Air flows to the upper body. Air flows to the upper body and feet.
Page 243 3-1. Using the air conditioning system and defogger Air flows to the feet. Air flows to the feet and the windshield defogger operates. Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) modes each time the button is pressed.
Page 244 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system con- trol operates automatically. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 245 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Center outlets Turn the knob to open or close the vent Direct air flow to the left or right, up or down Side outlets Direct air flow to the up or down...
Page 246 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. Air conditioning odors During use, various odors from inside and outside the vehicle may enter I n f o r ma t i o n P r o v i d e d b y : into and accumulate in the air conditioning system.
Page 247 3-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 248: Using The Steering Wheel Climate Control Switches
3-1. Using the air conditioning system and defogger Using the steering wheel climate control switches Some air conditioning feature can be controlled using the switches on the steering wheel. Temperature control Automatic mode Using the automatic mode Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the tempera- ture setting.
Page 249: Rear Window And Outside Rear View Mirror Defoggers
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. Press the button to turn on the rear window and outside rear view mirror defoggers.
Page 250 3-1. Using the air conditioning system and defogger Operating conditions Vehicles with smart key system The “ENGINE START STOP” switch must be in IGNITION ON mode. Vehicles without smart key system The engine switch must be in the “ON” position. CAUTION When the outside rear view mirror defoggers are on Do not touch the rear view mirror surfaces, as they can become very hot and...
Page 251: 3-2. Using The Audio System
3-2. Using the audio system Audio system type With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system Type A: CD player with changer and AM/FM radio I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 252 3-2. Using the audio system Type B: CD player and AM/FM radio (with CD changer control- ler) Title Page Using the radio P. 231 Using the CD player P. 239 Playing back MP3 and WMA discs P. 247 Operating an iPod P.
Page 253 3-2. Using the audio system Language settings The language used for all voice guidance, voice recognition and mes- sages may be changed. Press Press that corresponds to “MORE”. Press that corresponds to “LANG”. Press that corresponds to the desired language. For vehicles sold in the U.S.A.
Page 254 3-2. Using the audio system CAUTION For vehicles sold in the U.S.A. Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. Laser products • Do not take this unit apart or attempt to make any changes yourself. This is an intricate unit that uses a laser pickup to retrieve information from the surface of compact discs.
Page 255: Using The Radio
3-2. Using the audio system Using the radio Adjusting the frequency (AM, FM mode) or channel (SAT mode) Seeking the frequency Station selector Changing the category (SAT mode) Muting the sound Power Volume AM/FM/SAT mode button Displaying text Selecting the preset station pages messages Scanning for receivable stations I n f o r ma t i o n P r o v i d e d b y :...
Page 256 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) Search for desired stations by turning or pressing “∧” or “∨” on Press and hold the button (one of ) the station is to be set to, and you hear a beep. Each preset page may contain AM, FM, or XM radio station presets.
Page 257 3-2. Using the audio system ® Scanning radio stations (excluding XM Satellite Radio) Scanning the preset radio stations Press and hold until you hear a beep. Preset stations will be played for a few seconds each. When the desired station is reached, press once again.
Page 258 3-2. Using the audio system ® Satellite Radio (if equipped) ® Receiving XM Satellite Radio Press The display changes as follows each time the button is pressed. “AM” → “FM” → “SAT” Turn to select a desired channel from all the catego- ries or press “∧”...
Page 259 3-2. Using the audio system ® Scanning XM Satellite Radio channels l Scanning channels in the current category Press When the desired channel is reached, press the button again. l Scanning preset channels Press and hold until you hear a beep. When the desired channel is reached, press the button again.
Page 260 3-2. Using the audio system Reception sensitivity Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc. The radio antenna is mounted inside the rear window. To maintain clear radio reception, do not attach metallic window tinting or other metallic objects to the antenna wire mounted inside the rear window.
Page 261 CHECK ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
Page 262 3-2. Using the audio system There is no song/program title or artist name/fea- ----- ture associated with the channel at that time. No action needed. The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”.
Page 263: Using The Cd Player
3-2. Using the audio system Using the CD player Fast-forwarding and reversing/Selecting a track Selector buttons Playback/pause CD load (type A only) CD eject Power Volume Displaying Playback text messages Searching playback I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 264 3-2. Using the audio system Loading a CDs Loading a single CD Type A Press When the indicator on the slot turns from amber to green, insert a CD. Type B Insert a CD. Loading multiple CDs (type A only) Press and hold until you hear a beep.
Page 265 3-2. Using the audio system Ejecting CDs Ejecting a CD Type A To select the CD to be ejected, press that corresponds to “ ” or “ ”. The selected CD number is shown on the display. Press and remove the CD. Type B Press and remove the CD.
Page 266 3-2. Using the audio system Selecting a track Press “∧” to move up or “∨” to move down using until the desired track number appears on the display. Fast-forwarding and rewinding tracks Press and hold “∧” or “∨” on Scanning a CD Press The first 10 seconds of each track will be played.
Page 267 3-2. Using the audio system Random playback Current CD Press that corresponds to “RDM”. Songs are played in random order. To cancel, press the button again. All CDs (type A only) Press that corresponds to “RDM” twice. Tracks on all loaded CDs are played in random order. To cancel, press the button again.
Page 268 “PLEASE WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Con- tact your Toyota dealer if the CD still cannot be played back. Discs that can be used Discs with the marks shown below can be used.
Page 269 3-2. Using the audio system NOTICE CDs and adapters that cannot be used Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the player and/or the CD insert/eject function. CDs that have a diameter that is not 4.7 in.
Page 270 3-2. Using the audio system NOTICE Player precautions Failure to follow the precautions below may result in damage to the CDs or the player itself. Do not insert anything other than CDs into the CD slot. Do not apply oil to the player. Store CDs away from direct sunlight.
Page 271: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Fast-forwarding and reversing/Selecting a file Selecting a folder Playback/pause Selector buttons CD load (type A only) CD eject Selecting a file Power Volume Playback Displaying text messages Searching playback Loading and ejecting MP3 and WMA discs →P.
Page 272 3-2. Using the audio system Selecting and scanning a folder Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. To return to the first folder, press and hold “∨” on until you hear a beep.
Page 273 3-2. Using the audio system Fast-forwarding and rewinding files Press and hold “∧” or “∨” on Playing and pausing files Press Random playback To play files from a particular folder in random order Press that corresponds to “RDM”. To cancel, press the button again. To play all of the files on a disc in random order (type A only) Press that corresponds to “RDM”...
Page 274 “PLEASE WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Con- tact your Toyota dealer if the CD still cannot be played. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the Discs that can be used →P.
Page 275 3-2. Using the audio system Lens cleaners →P. 244 MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 276 3-2. Using the audio system WMA file compatibility • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver.
Page 277 3-2. Using the audio system File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. Multi-sessions As the audio system is compatible with multi-sessions, it is possible to play discs that contain MP3 and WMA files.
Page 278 3-2. Using the audio system Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 279: Operating An Ipod
3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Connecting an iPod Open the cover and connect an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 280 3-2. Using the audio system Selecting a play mode Press that corresponds to “BROWSE” to select iPod menu mode. Press that corresponds to the desired play mode. Play mode list First Second Third Fourth Play mode selection selection selection selection Playlists Songs PLIST...
Page 281 3-2. Using the audio system Selecting songs from a song list Press that corresponds to “LIST”. The current playlist is displayed. Turning to select the desired song. Press returns the screen from list display to the previous screen. Selecting songs Turn or press “∧”...
Page 282 3-2. Using the audio system Shuffle playback Playing songs from one playlist or album in random order Press that corresponds to “RDM”. To cancel, press the button twice. Playing songs from all the playlists or albums in random order Press that corresponds to “RDM”...
Page 283 3-2. Using the audio system About iPod Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. iPod is a trademark of Apple Inc., registered in the U.S. and other coun- tries. iPod functions When an iPod is connected and the audio source is changed to iPod mode, the iPod will resume play from the same point in which it was last...
Page 284 3-2. Using the audio system Error messages “iPod ERROR”: This indicates a problem in the iPod, inside the USB box or the connection between them. “NO SONGS”: This indicates that there is no music data in the iPod. “UPDATE YOUR iPod”: This indicates that the version of the iPod is not compatible.
Page 285 3-2. Using the audio system CAUTION While driving Do not connect iPod or operate the controls. NOTICE To prevent damage to iPod Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. Do not push down on or apply unnecessary pressure to the iPod while it is connected as this may damage the iPod or its terminal.
Page 286: Operating A Usb Memory
3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. Connecting a USB memory Open the cover and connect a USB memory. Turn on the power of the USB memory if it is not turned on.
Page 287 3-2. Using the audio system Selecting and scanning a folder Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. Returning to the first folder Press and hold “∨” on until you hear a beep. Scanning the first file of all the folders Press and hold until you hear a beep.
Page 288 3-2. Using the audio system Playing and pausing files Press Fast-forwarding and rewinding files ∧ Press and hold “ ” or “∨” on Random playback Playing files from a folder in random order Press that corresponds to “RDM”. To cancel, press the button twice. Playing all the files from a USB memory in random order Press that corresponds to “RDM”...
Page 289 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed time. When using the USB port You may be unable to use the instrument panel power outlet if a device is connected to the USB port at the same time.
Page 290 3-2. Using the audio system USB memory Compatible devices USB memory that can be used for MP3 and WMA playback. Depending on the type of USB device, playback may not be possible. Compatible device formats The following device formats can be used: •...
Page 291 3-2. Using the audio system MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
Page 292 3-2. Using the audio system MP3 and WMA playback • When a device containing MP3 or WMA files is connected, all files in the USB memory device are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3 or WMA files or create any unnecessary folders.
Page 293 3-2. Using the audio system CAUTION While driving Do not connect USB memory or operate the controls. NOTICE To prevent damage to USB memory Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the player. Do not push down on or apply unnecessary pressure to the USB memory while it is connected as this may damage the USB memory or its terminal.
Page 294: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Adjusting the sound quality Selector buttons Power Volume Menu button Using the audio control function Changing modes Press Press that corresponds to the desired mode. “BASS”, “MID” (type A only), “TREB”, “FADE” or “BAL” I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 295 3-2. Using the audio system Adjusting sound quality Turning adjusts the level. Mode Sound quality Turn to the Turn to the Level displayed mode left right BASS Bass -5 to 5 Mid-range -5 to 5 High (type A only) TREB Treble -5 to 5 Front/rear...
Page 296 3-2. Using the audio system Adjusting the Automatic Sound Levelizer (ASL) Press Press that corresponds to “MORE”. Press that corresponds to “ASL”. Press that corresponds to the desired mode. Type A: “ON” or “OFF” ASL automatically adjusts the volume and tone quality according to vehi- cle speed.
Page 297: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it using the vehicle’s speakers. Open the cover and connect the portable audio device. Press Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls.
Page 298: Using The Steering Switches
3-2. Using the audio system Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Increases/decreases vol- Radio mode: Selects radio stations CD mode: Selects tracks files (MP3 and WMA) and discs iPod mode: Selects a song USB memory mode: Selects a file and folder ®...
Page 299 3-2. Using the audio system Turning on the power Press when the audio system is turned off. The audio system can be turned off by holding the switch down until you hear a beep. Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time the button is pressed.
Page 300 3-2. Using the audio system Selecting a track/file or song Press to select the CD, iPod, USB memory or ® Bluetooth audio mode. Press “∧” or “∨” on to select the desired track/file or folder. Selecting a folder or album ®...
Page 301: Using The Bluetooth ® Audio
® 3-3. Using the Bluetooth audio system ® Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 302 ® 3-3. Using the Bluetooth audio system Conditions under which the system will not operate ® If using a portable player that does not support Bluetooth If the portable player is switched off If the portable player is not connected If the portable player’s battery is low If the portable player is behind the seat or in the glove box or console box If metal is covering or touching the portable player...
Page 303 ® 3-3. Using the Bluetooth audio system ® Certification for the Bluetooth audio system Type A FCC ID: BABFT0001A IC ID: 2024B-FT0001A MADE IN CHINA Type B FCC ID: L2C0045TR IC ID: 3432A-0045TR MADE IN MEXICO This device complies with Part 15 of the FCC Rules and RSS-210 Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interfer- ence received, including interference that may cause undesired operation.
Page 304: Using The Bluetooth
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system Audio unit Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item ®...
Page 305 ® 3-3. Using the Bluetooth audio system Steering wheel Volume The voice guidance volume cannot be adjusted by using this button. Talk switch Turns the voice command sys- tem on (press)/turns the voice command system off (press and hold) Microphone I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 306 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable to the operation of the Bluetooth audio sys- tem without the need to check the display or operate Operation procedure when using voice commands Press the talk switch and follow voice guidance instructions.
Page 307 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: Press until “BT AUDIO”...
Page 308 ® 3-3. Using the Bluetooth audio system Select “Confirm” using a voice command or A passkey is displayed and heard, and a voice guidance instruction for inputting the passkey into the portable player is heard. Input the passkey into the portable player. Refer to the manual that comes with the portable player for the oper- ation of the portable player.
Page 309 ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system Normal operation Second First menu Third menu Operation detail menu “Pair Audio Registering a portable player Player” “Select Audio Selecting a portable player to Player” be used Changing the registered “Change Name”...
Page 310 ® 3-3. Using the Bluetooth audio system When using a voice command For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. Situations that the system may not recognize your voice When driving on rough roads When driving at high speeds When air is blowing out of the vents onto the microphone When the air conditioning fan emits a loud noise...
Page 311: Operating A Bluetooth ® Enabled Portable Player
® 3-3. Using the Bluetooth audio system ® ∗ Operating a Bluetooth enabled portable player Fast-forwarding and reversing/Selecting a track Selecting a track Selector buttons Selecting an album Power Volume Playback Playback/pause Displaying text messages Selecting an album Press “∨” or “∧” on Selecting tracks I n f o r ma t i o n P r o v i d e d b y : Turn...
Page 312 ® 3-3. Using the Bluetooth audio system Playing and pausing tracks Press Fast-forwarding and rewinding tracks ∧ Press and hold “ ” or “∨” on Switching the display Press Each time the button is pressed, the display changes in the following order: Track title →...
Page 313: Setting Up A Bluetooth ® Enabled Portable Player
® 3-3. Using the Bluetooth audio system ® ∗ Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: Functions and operation procedures Press until “BT AUDIO”...
Page 314 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio Player” using a voice command or , and perform the procedure for registering a portable player. (→P. 283) Selecting a portable player to be used Select “Select Audio Player” using a voice command or Select the portable player to be used by either of the following methods, and select “Confirm”...
Page 315 ® 3-3. Using the Bluetooth audio system Press the talk switch and say “From Car” or “From Audio”, and select “Confirm” by using a voice command or Vehicles with smart key system: If “From Car” is selected, the porta- ble player will be automatically connected whenever the “ENGINE START STOP”...
Page 316 ® 3-3. Using the Bluetooth audio system Press the talk switch or select “Record Name” using and say the new name. Select “Confirm” using a voice command or Listing the registered portable players Select “List Audio Players” using a voice command or .
Page 317 ® 3-3. Using the Bluetooth audio system Changing the passkey Select “Set Passkey” using a voice command or Press the talk switch, say a 4 to 8-digit number, and select “Confirm” using a voice command or When the entire number to be registered as a passkey has been input, press again.
Page 318 ® 3-3. Using the Bluetooth audio system Deleting a registered portable player Select “Delete Audio Player (Delete Audio)” using a voice command or Select the portable player to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a.
Page 319: Bluetooth ® Audio System Setup
® 3-3. Using the Bluetooth audio system ® Bluetooth audio system setup System setup items and operation procedures →P. 320 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 320: Using The Hands-Free System (For Cellular Phone)
3-4. Using the hands-free system (for cellular phone) Hands-free system (for cellular phone) ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone. With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”.
Page 321 For additional information pairing and connecting cellular phone or for phone ® compatibility with vehicle’s Bluetooth system, please visit the following website: http://www.toyota.letstalk.com Conditions affecting operation The hands-free phone system may not operate normally in the following situ- ations: The cellular phone is turned off, or located outside the service area.
Page 322 3-4. Using the hands-free system (for cellular phone) Certification for the hands-free system Type A FCC ID: BABFT0001A IC ID: 2024B-FT0001A MADE IN CHINA Type B FCC ID: L2C0045TR IC ID: 3432A-0045TR MADE IN MEXICO This device complies with Part 15 of the FCC Rules and RSS-210 Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 323: Using The Hands-Free System
3-4. Using the hands-free system (for cellular phone) Using the hands-free system Audio unit Display message, name, phone number, etc. is displayed. Lower-case characters and special characters, such as an umlaut, cannot be dis- played. Selects speed dials Selects items such as menu or number Turn: Selects an item Press: Inputs the selected...
Page 324 3-4. Using the hands-free system (for cellular phone) Steering wheel Volume The voice guidance volume cannot be adjusted by using this button. On-hook switch Turns the hands-free system off/ends a call/refuses a call Off-hook switch Turns the hands-free system on/starts a call Talk switch Turns the voice command sys- tem on (press)/turns the voice...
Page 325 3-4. Using the hands-free system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free system without checking the display or operating Operation procedure when using a voice command Press the talk switch and follow voice guidance instructions.
Page 326 3-4. Using the hands-free system (for cellular phone) Using the hands-free system for the first time Before using the hands-free system, it is necessary to register a cel- lular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
Page 327 3-4. Using the hands-free system (for cellular phone) Registration to the hands-free phone system only Select “Phone Only” using a voice command or ® Registration to the hands-free phone system and Bluetooth audio system at the same time Select “Internal Audio (Int. Audio)” using a voice command or Select “Confirm”...
Page 328 3-4. Using the hands-free system (for cellular phone) Menu list of the hands-free system Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in ⎯ ⎯ Callback the incoming call history memory Dialing a number stored in ⎯...
Page 329 3-4. Using the hands-free system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Lock Locking the phone book Security Phonebook Unlocking the phone book Unlock Registering a cellular phone Pair Phone to be used Changing a registered name Change Name...
Page 330 3-4. Using the hands-free system (for cellular phone) Using a short cut key First menu Second menu Operation detail Dialing a number registered ⎯ Dial “XXX (name)” in the phone book ⎯ Dial “XXX (number)” Dialing the input numbers Phone book add ⎯...
Page 331 3-4. Using the hands-free system (for cellular phone) Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command For numbers, say a combination of single digits from zero to nine, # (pound), ∗...
Page 332: Making A Phone Call
3-4. Using the hands-free system (for cellular phone) Making a phone call Making a phone call l Dialing by inputting a number “Dial by number” l Dialing by inputting a name “Dial by name” l Speed dialing l Dialing a number stored in the outgoing history memory “Redial”...
Page 333 3-4. Using the hands-free system (for cellular phone) Dialing by inputting a number Press the talk switch and say “Dial by number”. Press the talk switch and say the phone number. Dial by one of the following methods: a. Press the off-hook switch. b.
Page 334 3-4. Using the hands-free system (for cellular phone) Speed dialing Press the off-hook switch. Press the preset button in which the desired number is regis- tered. Press the off-hook switch. When receiving a phone call Answering the phone Press the off-hook switch. Refusing the call Press the on-hook switch.
Page 335 3-4. Using the hands-free system (for cellular phone) Using the call history memory Follow the procedure below to use a number stored in the call history memory: Press the talk switch and say “Redial” (when using a number stored in the outgoing call history memory) or “Call back” (when using a number stored in the incoming call history memory).
Page 336 3-4. Using the hands-free system (for cellular phone) Call history Up to 5 numbers can be stored in each of the outgoing and incoming history memories. When talking on the phone Do not talk simultaneously with the other party. Keep the volume of the receiving voice down. Otherwise, voice echo will increase.
Page 337: Setting A Cellular Phone
3-4. Using the hands-free system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free system allows the system to function. The following functions can be used for regis- tered cellular phones: Functions and operation procedures To enter the menu for each function, follow the steps below by using a voice command or l Registering a cellular phone...
Page 338 3-4. Using the hands-free system (for cellular phone) Registering a cellular phone Select “Pair Phone” by using a voice command or , and do the procedure for registering a cellular phone. (→P. 302) Selecting a cellular phone to be used Select “Select Phone”...
Page 339 3-4. Using the hands-free system (for cellular phone) Changing a registered name Select “Change Name” by using a voice command or Select a name of cellular phone to be changed by either of the following methods: a. Press the talk switch and say the desired phone name, and select “Confirm”...
Page 340 3-4. Using the hands-free system (for cellular phone) Listing the registered cellular phones Selecting “List Phones” by using a voice command or causes the list of registered cellular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”. Pressing the talk switch while a name of cellular phone is being read selects the cellular phone, and the following functions will be avail- able:...
Page 341 3-4. Using the hands-free system (for cellular phone) Deleting a cellular phone Select “Delete Phone” by using a voice command or Pattern A Select the cellular phone to be deleted by either of the follow- ing methods and select “Confirm” by using a voice command a.
Page 342 3-4. Using the hands-free system (for cellular phone) Changing the passkey Select “Set Passkey” by using a voice command or Pattern A Press the talk switch, say a 4 to 8-digit number, and select “Confirm” by using a voice command or Pattern B Select a 4 to 8-digit number by using The number should be input 1 digit at a time.
Page 343 3-4. Using the hands-free system (for cellular phone) Turning the hands-free phone automatic connection on/off Turning off the automatic connection Select “Hands-free Power” by using a voice command or Select “Turn off” by using a voice command or Turning on the automatic connection Select “Hands-free Power”...
Page 344: Security And System Setup
3-4. Using the hands-free system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: Security setting items and operation procedure l Setting or changing the PIN (Personal Identification Number) 1. “Setup” → 2. “Security” → 3. “Set PIN” l Locking the phone book 1.
Page 345 3-4. Using the hands-free system (for cellular phone) Setting or changing the PIN Setting a PIN Select “Set PIN” by using a voice command or Enter a PIN by using a voice command or When using , input the code 1 digit at a time. Changing the PIN Select “Set PIN”...
Page 346 3-4. Using the hands-free system (for cellular phone) Locking or unlocking the phone book Select “Phonebook Lock” or “Phonebook Unlock” by using a voice command or Input the PIN by either of the following methods and select “Confirm” by using a voice command or a.
Page 347 3-4. Using the hands-free system (for cellular phone) ® Displaying the Bluetooth device address and name Select “Device Name” using ® Turn to display the Bluetooth device address and name. Select “Go Back” using to return to “System Setup”. Initialization Select “Initialize”...
Page 348 3-4. Using the hands-free system (for cellular phone) Initialization The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code Once the initialization has been completed, the data cannot be restored to its original state.
Page 349: Using The Phone Book
3-4. Using the hands-free system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: l Adding a new phone number 1. “Phonebook” → 2. “Add Entry” l Setting speed dial 1. “Phonebook” → 2. “Set Speed Dial (Speed Dial)” l Changing a registered name 1.
Page 350 3-4. Using the hands-free system (for cellular phone) Adding a new phone number The following methods can be used to add a new phone number: l Inputting a phone number by using a voice command l Transferring data from the cellular phone l Inputting a phone number by using l Selecting a phone number from outgoing or incoming call history Adding procedure...
Page 351 3-4. Using the hands-free system (for cellular phone) Transferring data from the cellular phone STEP2-1 Select “By Phone” and then “Confirm” by using a voice command or STEP2-2 Transfer the data from the cellular phone. Refer to the manual that comes with the cellular phone for the details of transferring data.
Page 352 3-4. Using the hands-free system (for cellular phone) Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History” by using a voice command or STEP2-2 Select “Outgoing” or “Incoming” by using a voice command or STEP2-3 Select the data to be registered by either of the fol- lowing methods: a.
Page 353 3-4. Using the hands-free system (for cellular phone) Select the name to be registered by either of the following methods, and select “Confirm” by using a voice command or a. Press the talk switch and say the desired name. b. Select “Record Name” by using , and say the desired name.
Page 354 3-4. Using the hands-free system (for cellular phone) Select the data to be registered as a speed dial by either of the following methods: a. Press the talk switch, say desired number, and select “Confirm” by using a voice command or b.
Page 355 3-4. Using the hands-free system (for cellular phone) Changing a registered name Select “Change Name” by using a voice command or Select the name to be changed by either of the following methods. a. Press the talk switch, say desired name, and select “Con- firm”...
Page 356 3-4. Using the hands-free system (for cellular phone) Deleting registered data Select “Delete Entry” by using a voice command or Select the data to be deleted by either of the following meth- ods, and select “Confirm” by using a voice command or a.
Page 357 3-4. Using the hands-free system (for cellular phone) Listing the registered data Selecting “List names” by using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following function will be available.
Page 358: 3-5. Using The Interior Lights
3-5. Using the interior lights Interior lights list Illuminated entry system: The various lights automatically turn on/ off according to the presence of the key, whether the doors are locked/unlocked, whether the doors are open/closed, and the “ENGINE START STOP” switch mode (vehicles with smart key sys- tem) or the engine switch position (vehicles without smart key sys- tem).
Page 359 “DOOR” position, the lights will go off automatically after 20 minutes. Customization that can be configured at Toyota dealer Setting (e.g. The time elapsed before lights turn off) can be changed.
Page 360 3-5. Using the interior lights Interior lights “ON” “OFF” “DOOR” The interior lights are turned on/ off by the illuminated entry sys- tem. Personal lights Front ON/OFF Rear ON/OFF I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 361: 3-6. Using The Storage Features
3-6. Using the storage features List of storage features Overhead console Glove box Door pocket Cup holders Console boxes Coin tray Storage compartment I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 362 3-6. Using the storage features CAUTION Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: Glasses may be deformed by heat or cracked if they come into contact with other stored items.
Page 363 3-6. Using the storage features CAUTION While driving Keep the glove box closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. Console boxes Front Lift the lid while pulling the lever. Rear Lift the lid while pulling the lever. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 364 3-6. Using the storage features When using the front console box lid as an armrest If necessary, the console box lid can slide forward. Pull the lid forward by grasping the front of the lid. Tray in the front console box The tray slides forward/backward and can be removed.
Page 365 3-6. Using the storage features Overhead console The overhead console is useful temporarily storing sun- glasses and similar small items. CAUTION While driving Do not leave the overhead console open. Items may fall out and cause injury. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 366 3-6. Using the storage features Storage compartment Front console Center console CAUTION While driving I n f o r ma t i o n P r o v i d e d b y : Do not leave the storage compartment open. The opened compartment may hit your body or items may be thrown out of the compartment in the event of an accident or sudden braking and cause injury.
Page 367 3-6. Using the storage features Cup holders Front open, press down release the cup holder lid. Rear (type A) Pull down the armrest. Rear (type B) Pull down the armrest and open the lid. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 368 3-6. Using the storage features CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 369: 3-7. Other Interior Features
3-7. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide back- wards. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 370: Vanity Mirrors
3-7. Other interior features Vanity mirrors The light turns on when the cover is opened. To adjust the brightness of the lights, slide the switch. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 371: Clock
3-7. Other interior features Clock Adjust the hour Adjust the minutes Rounds to the nearest hour The clock is displayed when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ACC”...
Page 372: Ashtrays
3-7. Other interior features ∗ Ashtrays CAUTION When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. To prevent fire Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed.
Page 373: Power Outlets
3-7. Other interior features Power outlets The power outlets can be used for 12V accessories that run on less than 10A. Front console box Center console box I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 374 3-7. Other interior features The power outlets can be used when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. NOTICE To avoid damaging the power outlets Close the power outlets lid when not in use.
Page 375: Seat Heaters/Ventilators
3-7. Other interior features ∗ Seat heaters/ventilators The seat heaters and ventilators heat the seats and maintain good airflow by blowing air from the seats. Vehicles with ventilator Press the knob to release it, and turn the knob to the desired temperature setting.
Page 376 3-7. Other interior features The seat heaters and ventilators can be used when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. CAUTION Burns Use caution when seating the following persons in a seat with the seat...
Page 377: Armrest
3-7. Other interior features Armrest Pull the armrest down for use. NOTICE To prevent damage to the armrest Do not place too much strain on the armrest. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 378: Rear Sunshade
3-7. Other interior features ∗ Rear sunshade The rear sunshade can be raised and lowered by pressing the switch shown below. Raise/lower The rear sunshade can be used when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON”...
Page 379 Operating the rear sunshade after turning the “ENGINE START STOP” switch or the engine switch off The rear sunshade can be raised and lowered for approximately 1 minute. Customization that can be configured at Toyota dealer Contact your Toyota dealer for further details. CAUTION...
Page 380: Floor Mats
Do not use floor mats designed for other models or different model year I n f o r ma t i o n P r o v i d e d b y : vehicles, even if they are Toyota Genuine floor mats. Only use floor mats designed for the driver’s seat.
Page 381 3-7. Other interior features CAUTION Before driving Check that the floor mat is securely fixed in the right place with all the pro- vided retaining hooks (clips). Be espe- cially careful to perform this check after cleaning the floor. With the engine stopped and the shift lever in P, fully depress each pedal to the floor to make sure it does not inter- fere with the floor mat.
Page 382: Trunk Features
3-7. Other interior features Trunk features Cargo net The cargo net is provided for securing loose items. Shopping bag hooks Storage box I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 383 3-7. Other interior features Trunk storage extension Pull down the rear seat center armrest. Open (push down the handle) CAUTION While driving To avoid injury, always return the cargo hooks to their positions when they are not in use. Always keep the trunk storage extension doors closed to reduce the chance of injury in case of accident or sudden stop.
Page 384: Garage Door Opener
3-7. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 385 3-7. Other interior features ® Programming the HomeLink Point the remote control for the device 1 to 3 in. (25 to 75 mm) ® from the HomeLink control but- tons. Keep the indicator light on the ® HomeLink in view while pro- gramming.
Page 386 3-7. Other interior features Test operation ® HomeLink pressing newly programmed button. If programming a garage door opener, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the Rolling Code type.
Page 387 3-7. Other interior features Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door opener motor.
Page 388 ® the remaining HomeLink buttons. Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 389 3-7. Other interior features ® Operating the HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator ® light on the HomeLink transceiver should turn on. ® The HomeLink continues to send a signal for up to 20 seconds as long as the button is pressed.
Page 390 3-7. Other interior features Before programming Install a new battery in the transmitter. The battery side of the transmitter must be pointed away from the ® HomeLink Certification for the garage door opener For vehicles sold in U.S.A. FCC ID: NZLZTVHL4 NOTE: This device complies with Part 15 of the FCC Rules.
Page 391 3-7. Other interior features CAUTION When programming a garage door or other remote control device The garage door may operate, so ensure people and objects are out of dan- ger to prevent potential harm. Conforming to federal safety standards ® Do not use the HomeLink Compatible Transceiver with any garage door opener or device that lacks safety stop and reverse features as required by...
Page 392: Compass
3-7. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. Operation Type A To turn the compass on or off, press the switch. Type B To turn the compass on or off, press the switch.
Page 393 3-7. Other interior features Displays and directions Display Direction North Northeast East Southeast South Southwest West Northwest Calibrating the compass I n f o r ma t i o n P r o v i d e d b y : Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field.
Page 394 3-7. Other interior features Deviation calibration Stop the vehicle where it is safe to drive in a circle. Press the switch until a number (1 to 15) appears on the com- pass display. Press the switch, and referring to the map above, select the number of the zone where you are.
Page 395 3-7. Other interior features Conditions unfavorable to correct operation The compass may not show the correct direction in the following conditions: The vehicle is stopped immediately after turning. The vehicle is on an inclined surface. The vehicle is in a place where the earth’s magnetic field is subject to interference by artificial magnetic fields (underground car park/parking lot, under a steel tower, between buildings, roof car park/parking lot, near an intersection, near a large vehicle, etc.).
Page 396 3-7. Other interior features NOTICE To avoid the compass malfunctions Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause a malfunction of the compass sensor. To ensure normal operation of the compass Do not perform circling calibration of the compass in a place where the earth’s magnetic field is subject to interference by artificial magnetic fields.
Page 397: 4-1. Maintenance And Care
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. l Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 398 4-1. Maintenance and care Automatic car washes Fold the mirrors back before washing the vehicle. Brushes used in automatic car washes may scratch the vehicle surface and harm your vehicle’s paint. High pressure car washes Do not allow the nozzles of the car wash to come within close proximity of the windows.
Page 399 4-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 400: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 401 4-1. Maintenance and care Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 402 4-1. Maintenance and care NOTICE Cleaning detergents Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces. • Non-seat portions: Organic substances such as benzine or gasoline, alkaline or acidic solutions, dye, or bleach.
Page 403: Maintenance Maintenance Requirements
You can perform some maintenance procedures yourself. Please be aware that do-it-yourself maintenance may affect war- ranty coverage. The use of Toyota Repair Manuals are recommended. For details about warranty coverage, see the separate “Owner’s War- ranty Information Booklet” or “Owner’s Manual Supplement”.
Page 404 It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 405 4-2. Maintenance CAUTION If your vehicle is not properly maintained It could result in serious damage to the vehicle and possible serious injury or death. Hazardous materials Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 406: General Maintenance
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 407 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven pedal Accelerator pedal effort or catching)? • Can the vehicle be hold securely on an Automatic transmission “Park” mechanism incline with the shift lever in “P”? • Moves smoothly? Brake pedal •...
Page 408 4-2. Maintenance Vehicle exterior Items Check points Doors/trunk • Operate smoothly? Engine hood • The lock system works properly? Fluid leaks • Is there any leakage after parking? • Inflation pressure is correct? • Tire surfaces not worn or damaged? Tire •...
Page 409: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...
Page 410: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
Brake fluid level (→P. 402) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 411 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent Engine oil level (→P. 396) • Rag or paper towel, funnel (used only for adding engine oil) • Fuse with same amperage rating Fuses (→P. 432)
Page 412 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. When working on the engine compartment Keep hands, clothing, and tools away from the moving fan and engine drive belt.
Page 413 4-3. Do-it-yourself maintenance CAUTION When working near the electric cooling fan or radiator grille Vehicles with smart key system Be sure the “ENGINE START STOP” switch is turned OFF. With the “ENGINE START STOP” switch in IGNITION ON mode, the electric cooling fan may automatically start to run if the air conditioning is on and/or the cool- ant temperature is high.
Page 414: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Lift the hood catch and lift the hood. CAUTION Pre-driving check Check that the hood is fully closed and locked.
Page 415: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front Rear I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 416 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 417: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Brake fluid reservoir (→P. 400) (→P. 402) Power steering fluid Fuse box (→P. 432) reservoir (→P. 403) Battery (→P. 405) Engine oil filler cap Radiator (→P. 401) (→P. 397) Electric cooling fans Engine oil level dipstick Condenser (→P.
Page 418 4-3. Do-it-yourself maintenance Engine compartment cover Removing the cover Installing the clips Open Insert Press NOTICE After installing an engine compartment cover I n f o r ma t i o n P r o v i d e d b y : Make sure that the cover is securely installed in its original position.
Page 419 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil Park the vehicle on level ground. After turning off the engine, wait more than five minutes for the oil to drain back into the bottom of the engine.
Page 420 4-3. Do-it-yourself maintenance Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 421 Oil consumption: Max. 1.1 qt./600 miles, 0.9 lmp.qt./600 miles (1.0 L per 1000 km). If the vehicle consumes more than this amount, contact your Toyota dealer. After changing the engine oil (U.S.A.only) The oil change system should be reset. Perform the following procedures: Switch the display to the odometer.
Page 422 Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 423 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, coolant reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection Only use “Toyota Super Long Life Coolant”...
Page 424 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot...
Page 425 4-3. Do-it-yourself maintenance Brake fluid Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Make sure to check the fluid type and prepare the necessary items. Adding fluid Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel Brake fluid can absorb moisture from the air...
Page 426 4-3. Do-it-yourself maintenance NOTICE If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high. If the reservoir needs frequent refilling, it may indicate a serious problem. Power steering fluid Fluid level The fluid level should be within the appropriate range.
Page 427 4-3. Do-it-yourself maintenance Checking the fluid level Make sure to check the fluid type and prepare the necessary items. ® Fluid type Automatic transmission fluid DEXRON II or III Items Rag or paper, clean funnel (only for adding fluid) Clean all dirt off the reservoir. Remove the cap by turning it counterclockwise.
Page 428 4-3. Do-it-yourself maintenance Battery Check the battery as follows. Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 429 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: Do not cause sparks by touching the battery terminals with tools.
Page 430 4-3. Do-it-yourself maintenance CAUTION Emergency measures regarding electrolyte If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 431 4-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the low washer fluid warning light comes on, the washer tank may be empty. Add washer fluid. CAUTION When refilling the washer fluid Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 432: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recom- mends that tire rotation is Front carried out at the same inter- val as tire inspection. Do not fail to initialize the tire...
Page 433 4-3. Do-it-yourself maintenance The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 470) Installing tire pressure warning valves and transmitters When replacing tires or wheels, tire pressure warning valves and transmitters must also be installed.
Page 434 4-3. Do-it-yourself maintenance How to initialize the tire pressure warning system Park the vehicle in safe place and turn the “ENGINE START STOP” switch or the engine switch OFF. While the vehicle is moving, initialization is not performed. Adjust the tire inflation pressure to the specified cold tire infla- tion pressure level.
Page 435 When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Toyota dealer. When to replace your vehicle’s tires Tires should be replaced if:...
Page 436 4-3. Do-it-yourself maintenance Tire life Any tire over 6 years old must be checked by a qualified technician even if they have seldom or never been used or damage is not obvious. If the tread wears down below 0.16 in. (4 mm) on snow tires The effectiveness of snow tires is lost.
Page 437 4-3. Do-it-yourself maintenance Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 438 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pres- sure warning light does not flash 3 times.
Page 439 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Toyota. Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 440 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 441: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 514) I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 442 4-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. Read the pressure using the graduations of the gauge. If the tire inflation pressure is not within the recommended levels, adjust tire pressure.
Page 443 Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 444 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear Uneven wear Poor handling Possibility of blowouts resulting from overheated tires Poor sealing of the tire bead Wheel deformation and/or tire separation A greater possibility of tire damage from road hazards...
Page 445: Wheels
Used wheels l Bent wheels that have been straightened Aluminum wheel precautions l Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. l When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 446 4-3. Do-it-yourself maintenance When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
Page 447 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 448: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method Set the air conditioning system to recirculated mode. The air conditioning filter case cannot be removed with the sys- tem in the outside air mode.
Page 449 I n f o r ma t i o n P r o v i d e d b y : from the filter and blow for approximately 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm bar). If it is not available, have the filter cleaned by your Toyota dealer. AVALON_U (OM41428U)
Page 450 4-3. Do-it-yourself maintenance Replacement method Remove the air conditioning filter from the filter case and replace it with a new one. ↑UP” marks shown on “ the filter and the filter case should be pointing up. Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule.
Page 451: Key Battery
4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. You will need the following items: l Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with rag.) l Small Phillips-head screwdriver l Lithium battery CR1632 (vehicles with smart key system), CR2016 (vehicles without smart key system) Replacing the battery (vehicles with smart key system)
Page 452 4-3. Do-it-yourself maintenance Remove the depleted battery. Insert a new battery with the “+” terminal facing up. Replacing the battery (vehicles without smart key system) Remove the cover. Remove the module. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 453 Use a CR1632 (vehicles with smart key system), or CR2016 (vehicles without smart key system) lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by a Toyota dealer.
Page 454 4-3. Do-it-yourself maintenance NOTICE For normal operation after replacing the battery Observe the following precautions to prevent accidents. Always work with dry hands. Moisture may cause the battery to rust. Do not touch or move any other components inside the remote control. Do not bend the battery terminals.
Page 455: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “ENGINE START STOP” switch or the engine switch OFF.
Page 456 4-3. Do-it-yourself maintenance Remove the fuse with the pull- out tool. Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse...
Page 457 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment Fuse Ampere Circuit Rear window defogger, outside RR DEF 50 A rear view mirror defogger Anti-lock brake system, vehicle ABS/VSC No.2 30 A stability control system RDI FAN 50 A Electric cooling fan Anti-lock brake system, vehicle ABS/VSC No.1...
Page 458 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Electronic controlled transmission system, multiport fuel injection STOP No.3 7.5 A system/sequential multiport fuel injection system Multiport fuel injection system/ 15 A sequential multiport fuel injection system 7.5 A Starter system DOOR No.1 25 A Multiplex communication system ALT-S 7.5 A...
Page 459 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ EFI No.1 25 A sequential multiport fuel injection system, fuel pump HORN 10 A Horn HEAD LH UPR 15 A Left-hand headlight (high beam) HEAD RH UPR 15 A Right-hand headlight (high beam) 25 A Air fuel ratio sensor WASHER...
Page 460 4-3. Do-it-yourself maintenance Driver’s side instrument panel Fuse Ampere Circuit RR DOOR 20 A Power window RL DOOR 20 A Power window Power window, driving position FR DOOR 20 A memory system 15 A Front fog lights 7.5 A On-board diagnosis system MPX-B 7.5 A Multiplex communication system...
Page 461 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Parking lights, license plate lights, TAIL 10 A tail lights, front and rear side marker lights Seat heaters, navigation system, emergency flashers, electronically controlled PANEL 7.5 A automatic transmission system, glove box light, instrument panel lights, power outlets Center display, shift lock control system, moon roof, multiplex...
Page 462 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, SRS airbag system, front 10 A passenger occupant classification system, smart key system, starting system, electronic controlled transmission system Gauges and meters, center GAUGE No.2 7.5 A display Power rear view mirrors, center...
Page 463 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.
Page 464: Headlight Aim (With Discharge Headlights)
4-3. Do-it-yourself maintenance Headlight aim (with discharge headlights) Vertical movement bolts Adjustment bolt A Adjustment bolt B Before checking the headlight aim Make sure the vehicle has a full tank of gas and the area around the headlight is not deformed. Park the vehicle on level ground.
Page 465 If you feel that there is a large deviation, have the headlight aim adjusted at a Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 466: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 467 4-3. Do-it-yourself maintenance Rear bulb locations Stop light License plate light Rear side marker light Back-up light Rear turn signal light Replacing light bulbs Headlight low beams (halogen bulb) Turn the bulb base counterclock- wise. I n f o r ma t i o n P r o v i d e d b y : Unplug the connector while pull- ing the lock release.
Page 468 4-3. Do-it-yourself maintenance Headlight high beams and daytime running lights Turn the cover counterclockwise and remove it. Turn the bulb base counterclock- wise. Unplug the connector while pull- ing the lock release. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 469 4-3. Do-it-yourself maintenance Front fog lights Remove the fender liner clip. Partly remove the fender liner and unplug the connector while depressing the lock release. I n f o r ma t i o n P r o v i d e d b y : Turn the bulb base counterclock- wise.
Page 470 4-3. Do-it-yourself maintenance Front turn signal/parking lights Remove the fender liner clip. Partly remove the fender liner and turn the bulb base counter- clockwise. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 471 4-3. Do-it-yourself maintenance Front side marker lights Remove the fender liner clip. Partly remove the fender liner and turn the bulb base counter- clockwise. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 472 4-3. Do-it-yourself maintenance Auxiliary lights Turn the bulb base counterclock- wise. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 473 4-3. Do-it-yourself maintenance Rear turn signal lights, stop lights and rear side marker lights Open the trunk and remove the cover as follows. Turn the bulb bases counter- clockwise and remove (upper and lower), or squeeze bulb base and remove (center). Remove the light bulb.
Page 474 4-3. Do-it-yourself maintenance Back-up lights Open the trunk and remove the trunk panel cover. Turn the bulb base counterclock- wise. ITN43A078 Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y : ITN43A079 AVALON_U (OM41428U)
Page 475 4-3. Do-it-yourself maintenance License plate light Remove the cover. To prevent damaging the vehicle, wrap the flathead screwdriver with a tape. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 476 4-3. Do-it-yourself maintenance Bulbs other than the above If any of the bulbs listed below has burnt out, have your Toyota dealer replace it. l Headlights (discharge bulb) l Side turn signal lights l Tail lights l High mounted stoplight Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations.
Page 477 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
Page 478 4-3. Do-it-yourself maintenance CAUTION High-intensity discharge (HID) headlights (if equipped) Contact your Toyota dealer before replacing high-intensity discharge headlights (including light bulbs). Do not touch the high-intensity discharge headlight’s high voltage socket when the headlights are turned on. An extremely high voltage of 20000V will be discharged and could result in serious injury or death by electric shock.
Page 479 4-3. Do-it-yourself maintenance I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 480: Essential Information Emergency Flashers
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 481: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 482 5-1. Essential information Towing with a sling-type truck NOTICE To prevent body damage Do not tow with a sling-type truck, either from the front or rear. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 483 5-1. Essential information Towing with a wheel lift-type truck From front Release the parking brake. From rear Use a towing dolly under the front wheel. NOTICE To prevent causing damage to the transmission I n f o r ma t i o n P r o v i d e d b y : Never tow this vehicle from the rear with the front wheel on the ground.
Page 484 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 485: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 486: Fuel Pump Shut Off System
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 487: Event Data Recorder
5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is a system to record data in a crash or a near car crash event.
Page 488 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: l An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained...
Page 489: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer) •...
Page 490 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Malfunction in: (U.S.A.)
Page 491 5-2. Steps to take in an emergency Warning light Warning light/Details SRS warning light Malfunction in: • The SRS airbag system; • Front passenger occupant classification system; or • The seat belt pretensioner system. ABS warning light (U.S.A.) Malfunction in: •...
Page 492 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. I n f o r ma t i o n P r o v i d e d b y :...
Page 493 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Low washer fluid warning light Fill the tank. Low level of washer fluid Engine oil replacement reminder light Illuminates for about 3 sec- onds and then flashes for Check the engine oil, and about 15 seconds: change if necessary.
Page 494 5-2. Steps to take in an emergency Have the malfunction repaired immediately. (vehicles with smart key system) After taking the specified steps to correct the suspected problem, check that the warning light turn off. Interior Exterior Correction Warning light Details buzzer buzzer procedure...
Page 495 5-2. Steps to take in an emergency Interior Exterior Correction Warning light Details buzzer buzzer procedure An open door other than the driver’s door is closed while the Turn the electronic key is “ENGINE outside the detec- START STOP” Once 3 times tion range and the switch OFF or...
Page 496 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. SRS warning light...
Page 497 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.)
Page 498 If the tire pressure warning light comes on after blinking for 1 minute when the “ENGINE START STOP” switch is turned to IGNITION ON mode, have it checked by your Toyota dealer. Vehicles without smart key system If the tire pressure warning light comes on after blinking for 1 minute when the engine switch is turned to the “ON”...
Page 499 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 500 5-2. Steps to take in an emergency CAUTION Please note that the TPMS (tire pressure warning system) is not a sub- stitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale (tire pressure warning light).
Page 501: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface. l Set the parking brake. l Shift the shift lever to “P”.
Page 502 5-2. Steps to take in an emergency Take out the jack Remove the cover. To remove the jack, turn the jack joint by hand until the jack becomes free. Taking out the spare tire Remove the luggage floor cover. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 503 5-2. Steps to take in an emergency Loosen the center fastener that secures the spare tire. Remove the spare tire cover. Replacing a flat tire Chock the tires. I n f o r ma t i o n P r o v i d e d b y : Flat tire Wheel chock positions Left-hand side...
Page 504 5-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Turn the tire jack portion “A” by hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is slightly raised off the ground.
Page 505 5-2. Steps to take in an emergency Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface. Remove the wheel ornament by pushing from the reverse side.
Page 506 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 507 5-2. Steps to take in an emergency Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Reinstall the wheel ornament. Stow the flat tire, tire jack and all tools. To store the jack To store the jack, align the hole of the jack head with the vehicle hook.
Page 508 5-2. Steps to take in an emergency CAUTION Using the tire jack Improper use of the tire jack may lead to death or injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 509 5-2. Steps to take in an emergency CAUTION Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury. Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 N•m, 10.5 kgf•m) as soon as possible after changing wheels. Failure to follow these precautions could cause the nuts to loosen and the wheels may fall off, which could lead to an accident causing death or serious injury.
Page 510 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 511: If The Engine Will Not Start
5-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting procedures → are being followed ( P. 149, P. 153), consider each of the following points. The engine will not start even when the starter motor oper- ates normally One of the following may be the cause of the problem.
Page 512 There may be a malfunction in the steering lock system (vehi- cles with smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with smart key system) When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
Page 513: If The Shift Lever Cannot Be Shifted From P
(a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 514: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. Bring the other key and the key number stamped on the key number plate. I n f o r ma t i o n P r o v i d e d b y :...
Page 515: If The Electronic Key Does Not Operate Properly (With Smart Key System)
5-2. Steps to take in an emergency If the electronic key does not operate properly (with smart key system) If communication between the electronic key and vehicle is inter- rupted (→P. 30) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote con- trol cannot be used.
Page 516 5-2. Steps to take in an emergency Changing “ENGINE START STOP” switch modes and starting the engine Put the shift lever in “P” and apply the brakes. Touch the Toyota emblem side of electronic “ENGINE START STOP” switch. An alarm will sound to indicate...
Page 517 5-2. Steps to take in an emergency Stopping the engine Shift the shift lever to “P” and press the “ENGINE START STOP” switch as you normally do when stopping the engine. Replacing the key battery As the above procedure is the temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery depletes.
Page 518: If The Vehicle Battery Is Discharged
You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12 volt battery, you can jump start your Toyota following the steps below.
Page 519 Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. I n f o r ma t i o n P r o v i d e d b y :...
Page 520 5-2. Steps to take in an emergency Starting the engine when the battery is discharged The engine cannot be started by push-starting. To prevent battery discharge Turn off the headlights and the audio system while the “ENGINE START STOP” switch or the engine is turned off. Turn off any unnecessary electrical components when the vehicle is run- ning at a low speed for an extended period, such as in heavy traffic, etc.
Page 521 5-2. Steps to take in an emergency CAUTION Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
Page 522: If Your Vehicle Overheats
Wait until the engine coolant temperature gauge begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Toyota dealer. After the engine has cooled down sufficiently, check the...
Page 523 Add coolant if required. Water can be used in an emer- gency measure if coolant is unavailable. (→P. 512) Have the vehicle checked at your nearest Toyota dealer as soon as possible. Overheating In the following situations, your vehicle may be overheating.
Page 524 5-2. Steps to take in an emergency CAUTION To prevent an accident or injury when inspecting under the hood of your vehicle If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injury such as burns.
Page 525: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and shift the shift lever in “P”.
Page 526: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly depress it.
Page 527 5-2. Steps to take in an emergency Vehicles with a smart key sys- tem: To stop the engine, press and hold the “ENGINE START STOP” switch for 3 consecu- tive seconds or more, or press it briefly for 3 times or more in Press and hold for 3 seconds or more succession.
Page 528 5-2. Steps to take in an emergency I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 529: 6-1. Specifications
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 197.6 in. (5020 mm) Overall width 72.8 in. (1850 mm) Overall height 58.5 in. (1485 mm) Wheelbase 111.0 in. (2820 mm) Front 62.2 in. (1580 mm) Tread Rear 61.6 in.
Page 530 6-1. Specifications Vehicle identification The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 531 I n f o r ma t i o n P r o v i d e d b y : Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity.
Page 532 6-1. Specifications Oil grade: ILSAC multigrade engine oil Recommended viscosity: SAE 5W-30 SAE 5W-30 is the best choice for good fuel economy and good starting in cold weather. If SAE 5W-30 is not available, SAE 10W-30 oil may be used. However, it should be replaced with SAE 5W-30 at the next oil Outside temperature...
Page 533 Cooling system Capacity 8.8 qt. (8.3 L, 7.3 lmp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 534 Toyota dealer. NOTICE Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmis- sion of your vehicle.
Page 535 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Type A Tire size P215/55R17 93V Vehicle speed (kPa, kgf/cm or bar) Front and rear tire inflation pressure More than 99 mph 38 (260, 2.6) (Recommended cold tire (160 km/h) inflation pressure) 99 mph...
Page 536 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights Low beam (discharge bulbs) Low beam (halogen bulbs) High beam Fog lights Auxiliary light Front turn signal/parking 3457A 28/8 lights Exterior Front side marker lights Rear turn signal lights 7440A Stop lights 7440 Rear side marker lights...
Page 537: Fuel Information
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks Consult your Toyota dealer.
Page 538 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10 % ethanol or 15 % MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87.
Page 539 Toyota does not recommend gasoline containing MMT Some gasoline contains octane enhancing additive called MMT (Methylcy clopentadienyl Manganese Tricarbonyl). Toyota DOES NOT recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 540: Tire Information
6-1. Specifications Tire information Typical tire symbols Tire size (→P. 521) DOT and Tire Identification Number (TIN) (→P. 520) Location of treadwear indicators (→P. 409) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Tire ply composition and materials Plies are layers of rubber-coated parallel cords.
Page 541 6-1. Specifications Maximum cold tire inflation pressure (→P. 525) This means the pressure to which a tire may be inflated. Load limit at maximum cold tire inflation pressure (→P. 525) Summer tire or all season tire (→P. 414) An all season tire has “M+S” on the sidewall. A tire not marked “M+S”...
Page 542 6-1. Specifications Tire size Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
Page 543 It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. I n f o r ma t i o n P r o v i d e d b y :...
Page 544 6-1. Specifications DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades. Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci-...
Page 545 6-1. Specifications Temperature A, B, C The temperature grades are A (the highest), B, and C, represent- ing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a speci- fied indoor laboratory test wheel.
Page 546 6-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation parked for three hours or more, or has not pressure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which a Maximum inflation...
Page 547 6-1. Specifications Tire related term Meaning Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb...
Page 548 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 549 6-1. Specifications Tire related term Meaning Groove The space between two adjacent tread ribs The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears...
Page 550 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire have a gross vehicle weight rating (GVWR) of...
Page 551 6-1. Specifications Tire related term Meaning That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the Sidewall separation cord material in the sidewall A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in...
Page 552 6-1. Specifications Designated seating Occupant distribution in Vehicle normal load, capacity, Number of a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 553: Customization Customizable Features
Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function Default setting...
Page 554 6-2. Customization Customized Item Function Default setting setting Operation indicator (Emergency flashers) Operation indicator (Buzzer) Trunk unlocking func- Wireless tion remote control Push twice Trunk unlocking opera- Push and hold (→P. 38) tion One short push Panic function Buzzer sounds when pushing with any door not closed...
Page 555 6-2. Customization Customized Item Function Default setting setting Driver’s door unlocked in 1- All doors Unlocking using a key step, all doors unlocked unlocked in 1-step in 2-step Speed-detecting auto- matic door lock function Door lock → P. 43) Opening driver’s door unlocks all doors Shift the shift lever to “P”...
Page 556 6-2. Customization Customized Item Function Default setting setting Switching operation when the vehicle is sta- Windshield tionary wipers and Variable washer Time elapsed before depending on (→P. 177) the drip prevention 3 seconds the vehicle function operates speed 7.5 seconds Time elapsed before 15 seconds lights turn off...
Page 557: Initialization Items To Initialize
6-3. Initialization Items to initialize After reconnecting or performing maintenance on the battery, the fol- lowing items must be initialized for normal system operation. Item When to initialize Reference • After reconnecting or changing the Power window P. 81 battery Moon roof P.
Page 558: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 559: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 560 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 561 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 562: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 563 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 564 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 565 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 566 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 567 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 568 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 569 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 570 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 571 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 572 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41428U)
Page 573: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor GAWR Gross Axle Weight Ratings Emission inspection and maintenance LATCH Lower Anchors and Tethers for Children Light Emitting Diode Methylcy clopentadienyl Manganese Tricarbonyl M + S...
Page 574: Alphabetical Index
Alphabetical index Alphabetical index A/C ..........216 Automatic headlight leveling ABS........... 195 system ........175 Air conditioning system Automatic light control Air conditioning filter ..... 425 system ........173 Automatic air conditioning Automatic transmission system........ 216 Automatic transmission ..156 Steering switches ....224 If the shift lever cannot be Airbags shifted from P......491...
Page 575 Alphabetical index Child restraint system Daytime running light Definition .......121 system ........174 Installation ......125 Defogger Installing CRS with lower Rear window ......225 anchorages ......126 Side mirror ......225 Installing CRS with seat Dimension ........508 belts ........128 Dinghy towing ......213 Installing CRS with top Display straps ........132...
Page 576 Alphabetical index Emergency, in case of Engine oil If a warning light turns on ..467 Capacity ........510 If the electronic key does not Checking .......396 operate properly....493 Preparing and checking If the engine will not start..489 before winter .......207 If the shift lever cannot be Event data recorder ....465 shifted from P.....
Page 577 Alphabetical index Hands-free system Jack (for cellular phone) ....296 Positioning a floor jack ..392 Hazard lights Vehicle-equipped jack...479 Switch........458 Jack handle ......479 Head restraints......62 Headlight aim ......441 Keyless entry ......38 Headlights Keys Discharge headlights Electronic key......24 precautions ......455 Engine switch....149, 153 Switch........173 If the electronic key does not...
Page 578 Alphabetical index Maintenance Personal light Do-it-yourself maintenance .. 387 Switch........336 General maintenance ... 383 Wattage.........515 Maintenance data....508 Power outlets ......349 Maintenance requirements... 380 Power windows ......80 Meter Instrument panel light Radiator ........401 control ........ 166 Radio .........231 Meters ........164 Rear seat Mirrors Adjustment ......56...
Page 579 Alphabetical index Seat heaters......351 Steering wheel Seating capacity.......205 Adjustment ......73 Seats Audio switches ......274 Adjustment ......54, 56 Climate switches ....224 Adjustment precaution ..55, 57 Steering wheel memory ..58 Child seats/child restraint Storage compartment....342 system installation ....125 Storage feature ......337 Cleaning ........377 Stuck Climate control ......351...
Page 580 Alphabetical index Tires Warning buzzers Chains ........209 Brake system ......467 Checking ......409 Downshifting......159 If you have a flat tire ..... 479 Open door ......469 Inflation pressure....514 Seat belt reminder....470 Information ......519 Warning lights Replacing ......479 Anti-lock brake system ..469 Rotating tires ......
Page 581: What To Do If
What to do if... What to do if... A tire punctures If you have a flat tire P. 479 P. 91 Engine immobilizer system The engine does not start P. 489 If the engine will not start P. 496 If the battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
Page 582 What to do if... The warning light or indicator If the warning light turns on P. 467 light comes on nWarning lights Brake system warning Malfunction indicator light lamp P. 467 P. 468 Driver’s seat belt reminder ABS warning light light P.
Page 583: Gas Station Information
Without filter 6.0 (5.7, 5.0) “Toyota Genuine Motor Oil” or equivalent I n f o r ma t i o n P r o v i d e d b y : Engine oil type Oil grade: ILSAC multigrade engine oil P.

Toyota 2011 Avalon Quick Reference Manual

Quick Links

Related Manuals for Toyota 2011 Avalon

Summary of Contents for Toyota 2011 Avalon
