Operating Instructions
Digital Cordless Phone
KX-TG1891NZ
Model No.
This unit is Caller ID compatible. To display the caller's
phone number, you must subscribe to Caller ID service.
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and save
them for future reference.
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TG1891NZ
Summary of Contents for Panasonic KX-TG1891NZ
-
Page 1: Operating Instructions
Operating Instructions Digital Cordless Phone KX-TG1891NZ Model No. This unit is Caller ID compatible. To display the caller’s phone number, you must subscribe to Caller ID service. Charge the batteries for about 7 hours before initial use. Please read these operating instructions before using the unit and save... -
Page 2: Table Of Contents
Table of Contents Preparation Troubleshooting ....36 Specifications ....39 Introduction . -
Page 3: Introduction
Preparation Introduction Thank you for purchasing a new Panasonic digital cordless phone. For your future reference Attach or keep original receipt to assist with any repair under warranty. Serial No. (found on the bottom of the base unit) Date of purchase... -
Page 4: Accessory Information
Telephone line cord Rechargeable batteries AAA (R03) size (Part No. HHR-55AAAB) Handset cover *1 The handset cover comes attached to the handset. Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information. Model No. Description KX-TGA189AZ Additional Digital Cordless Handset KX-TCA828EX... -
Page 5: Important Information
Preparation placed in rooms where the temperature is less than 5 C or Important information greater than 40 C. Warning: General L To prevent the risk of electrical shock, L Use only the AC adaptor supplied with do not expose this product to rain or this product, noted on page 4. - Page 6 Preparation L Disconnect the telecom connection Battery caution before disconnecting the power L We recommend using the battery(ies) connection prior to relocating the noted on page 4. Use only equipment, and reconnect the power rechargeable battery(ies). first. L Do not mix old and new batteries. L No “111”...
- Page 7 Preparation all, it provides no assurance that any item will work correctly in all respects with another item of Telepermitted equipment of a different make or model, nor does it imply that any product is compatible with all of Telecom’s network services. Important notice: L Under power failure conditions, this telephone may not operate.
-
Page 8: Controls
Preparation G Dial keypad H {R} (Recall) Controls I Receiver J Display Base unit K {ih} (Off/Power) L {C/T} (Clear/Mute) M {INT} (Intercom) N Microphone O Charge contacts Using the joystick Push the joystick up, down, left, or right to navigate through menus and to select. A Charge contacts B {x} (Page) Note:... -
Page 9: Displays
Preparation Icon Meaning Soft keys The handset features 2 soft keys and a Night mode is on. joystick. By pressing a soft key, or by (page 22) pressing the centre of the joystick, you Handset number can select the feature shown directly (standby display setting, above it on the display. -
Page 10: Connections
Preparation Soft key icons Connections Icon Action Connect the telephone line cord until it Returns to the previous clicks into the base unit and telephone screen. line jack (A). Connect the AC adaptor " Displays the menu. cord (B) by pressing the plug firmly (C). Accepts the current selection. -
Page 11: Battery Installation And Replacement
– Caller ID features (page 26) do not function properly. touching the battery ends (S, T) or the unit contacts. L When replacing batteries, we recommend using the Panasonic rechargeable batteries noted on page 4, 6. Telephone line cord Press the notch on the handset cover firmly and slide it in the direction of the arrow. -
Page 12: Battery Charge
Battery icon Battery level & High Medium L When flashing: Needs to be charged. Panasonic Ni-MH battery performance (supplied batteries) Battery charge Operation Operating time Place the handset on the base unit for about 7 hours before initial use. In continuous use 12 hours max. -
Page 13: Screen Saver Mode
Preparation times. i # i {^}/{V}: Select the desired language. Screen saver mode i # i {ih} The backlight will turn off completely Date and time after 1 minute of inactivity if the handset is not on the base unit. Press "... -
Page 14: C Making/Answering Calls
Making/Answering Calls Editing/erasing/storing Making calls j (right soft key) {^}/{V}: Select the desired number. Lift the handset and dial the phone i " number. L To correct a digit, press {C/T}. Proceed with the desired operation. ■ Editing a number before calling When finished talking, press {ih} {^}/{V}: “Edit and Call”... -
Page 15: Answering Calls
Making/Answering Calls will probably need to pause after dialling {0} until you hear a dial tone. Useful features during {0} i l a call Dial the phone number. i {C} Note: Mute L A 3 second pause is inserted each While mute is turned on, you will be able time l is pressed. -
Page 16: Key Lock
Making/Answering Calls {^}/{V}: “High Tone” or “Low Tone” i # L d is displayed. Key lock The handset can be locked so that no calls or settings can be made. Incoming calls can be answered, but all other functions are disabled while key lock is To turn key lock on, press "... -
Page 17: Phonebook
Phonebook {^}/{V}: “Category Name” i Handset phonebook Edit the name (10 characters max.; page 33). i # i {ih} The handset phonebook allows you to make calls without having to dial manually. You can add 200 names and Finding and calling a handset phone numbers, assign each handset phonebook entry phonebook entry to the desired... -
Page 18: Editing Entries
Phonebook {^}/{V}: Select the category you One touch dial want to search. i # L If you select “All”, the unit will Assigning an entry in the handset end the category search. phonebook to a one touch dial key {^}/{V}: Scroll through the Dial keys {1} to {9} can each be used as phonebook if necessary. -
Page 19: Chain Dial
Phonebook Chain dial This feature allows you to dial phone numbers in the handset phonebook while you are on a call. This feature can be used, for example, to dial a calling card access number or bank account PIN that you have stored in the handset phonebook, without having to dial manually. -
Page 20: N Handset Settings
Handset Settings Handset settings To customise the handset: " (centre of joystick) Select N by pushing the joystick in any direction. i # Push the joystick up or down to select the desired item in the handset settings menu. i # Push the joystick up or down to select the desired item in the sub-menu. - Page 21 Handset Settings *1 When the ringer volume is turned off, ~ is displayed and the handset does not ring for outside calls. However even when the ringer volume is turned off, the handset rings: – at the minimum level for alarm and intercom calls –...
-
Page 22: Special Instructions For Time Settings
Handset Settings Special instructions Special instructions for time settings for ringer setup Alarm Night mode An alarm will sound for 3 minutes at the Night mode allows you to select a block set time once or daily. Set the date and of time during which the handset will not time beforehand (page 13). - Page 23 Handset Settings L When the night mode is set, f is displayed. Setting the ring delay This setting allows the handset to ring during night mode if the caller waits long enough. After the selected amount of time passes, the handset will ring. If you select “No Ringing”, the handset will not ring during night mode.
-
Page 24: Base Unit Settings
*1 Change the recall time, if necessary, depending on the requirements of your service provider/telephone company or PBX. *2 If you change the PIN, please make note of your new PIN. The unit will not reveal the PIN to you. *3 If you forget your PIN, consult your nearest Panasonic service centre. -
Page 25: Special Instructions For Call Options
Enter the base unit PIN (default: “0000”). L If you forget your PIN, consult Selecting area codes to be your nearest Panasonic service deleted automatically centre. In some situations, phone numbers Set which handsets will be restricted... -
Page 26: Caller Id Service
Caller ID Service L Phone numbers of the last 50 callers will be logged in the caller list. Using Caller ID service L When caller information is received and it matches a phone number Important: stored in the unit’s phonebook: L This unit is Caller ID compatible. -
Page 27: Caller List
Caller ID Service L To erase the item, press W. i on page 20 when calls from this category {^}/{V}: “Yes” i # are received. The default setting is “Ext. Ringtone”. n (left soft key) i " Note: {^}/{V}: “Category” i # L If you do not want to dial the area {^}/{V}: Select a category. -
Page 28: For Telecom Call Minder Or Telstraclear Message Mailbox Service Subscribers
Caller ID Service Note: Storing caller information into L If 9 still remains on the display even the handset phonebook after you have listened to new messages, turn it off by pressing and " (centre of joystick) i j i holding {C/T} for 2 seconds. -
Page 29: Multi-Unit Operation
PIN (default: “0000”). i # handset moves from one radio cell to L If you forget your PIN, consult another. your nearest Panasonic service centre. L When the handset has been registered successfully, w will stop flashing. If the key tone is turned on (page 20), a confirmation tone will be heard. -
Page 30: Selecting A Base Unit
Select the handset(s) you want to base unit by using a DECT repeater. cancel, by pressing the desired Please use only the Panasonic DECT handset number. i # repeater noted on page 4. Consult your L The selected handset number(s) Panasonic dealer for details. -
Page 31: Intercom Between Handsets
Multi-unit Operation 2 people in the same radio cell can have Setting the repeater mode a conference call with an outside party. " (centre of joystick) i | i Example: When handset 1 transfers a call to handset 2 {^}/{V}: “Other Options” i Handset 1: During an outside call, press {INT}. -
Page 32: Copying Phonebook Entries
Multi-unit Operation Copying phonebook entries You can copy handset phonebook entries to the handset phonebook of another compatible Panasonic handset. Note: L Category settings for phonebook entries are not copied. Copying one entry Find the desired handset phonebook entry (page 17). i "... -
Page 33: Useful Information
Useful Information Character entry The dial keys are used to enter characters and numbers. Each dial key has multiple characters assigned to it. The available character entry modes are Alphabet (ABC), Numeric (0-9), Greek (F), Extended 1 (G), Extended 2 (H), and Cyrillic (I). - Page 34 Useful Information Extended 1 character table (N) L The following are used for both uppercase and lowercase: Extended 2 character table (O) L The following are used for both uppercase and lowercase: Cyrillic character table (P)
-
Page 35: Error Messages
Useful Information Error messages Error message Cause & solution L Phonebook copy failed. Confirm the other handset Failed (the receiver) is in standby mode and try again. L The receiver’s phonebook memory is full. Erase the Incomplete unnecessary phonebook entries from the other handset (the receiver) and try again. - Page 36 Useful Information Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the base unit AC adaptor and turn off the handset, then reconnect the base unit AC adaptor and turn on the handset. Telephone Problem Cause &...
- Page 37 Useful Information Problem Cause & solution L The base unit AC adaptor or telephone line cord is not I cannot make or receive calls. connected. Check the connections. L If you are using a BT double adaptor to connect the unit, remove the adaptor and connect the unit to the phone wall socket directly.
- Page 38 Cancel unused handset registrations from the base unit (page 30). L You entered the wrong PIN. If you forget your PIN, consult your nearest Panasonic service centre. L Place the handset and the base unit away from other electrical appliances.
- Page 39 Useful Information L The illustrations used in these operating instructions may differ Specifications slightly from the actual product. ■ Standard: GAP (Generic Access Profile) ■ Number of channels: 120 Duplex Channels ■ Frequency range: 1.88 GHz to 1.90 GHz ■ Duplex procedure: TDMA (Time Division Multiple Access) ■...
- Page 40 Index Night mode Handset: 22 Index O One touch dial: 18 Additional base units: 29 Pause: 14 Additional handsets: 29 Phonebook Alarm: 22 Handset phonebook: 17 Answering calls: 15 Phonebook copy: 32 Auto talk: 15, 20 PIN: 24 Power on/off: 13 Base unit Cancelling: 30 Recall: 15, 24...
- Page 41 Notes...
- Page 42 Notes...
- Page 43 Notes...
- Page 44 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
