Emerson EDC210 User Manual

Digital Camera
EDC210
Camera modes
When you turn on the camera, the default mode is Photo Mode. To scroll through
and select one of the camera modes below, press the [MODE] button until the
desired mode is displayed.
[MODE] button
Press the [MODE] button to switch between:
Picture Mode - Take Pictures
or
Video Mode - Record videos
or
Playback Mode - Playback videos or view pictures
System Settings
Press the [MENU] button within any mode and follow the steps below to access
the System Settings Screen.
1. Use the [ ] button to select [ ] System Settings.
2. Use the [ ] and [ ] buttons to scroll to a setting, then use the [
enter.
3. Use the [ ], [ ], [ ], or [ ] buttons to make changes, then con rm by
pressing the [OK] button.
4. Press the [MENU] button to exit the System Settings Screen.
Default Screen System Settings Screen
System Settings Options
SOUNDS
shutter (on/off), start-up (on/off), Beep (on/off), Volume (0/1/2/3).
AUTO REVIEW
set time of review after picture is taken (off, 1 sec, 3 sec).
POWER FREQUENCY
50Hz / 60Hz
(The Camera's default setting is 60hz for the USA and North America)
POWER SAVE
Select 1,3, or 5 minutes. To conserve battery power, the camera
will shut off if no buttons are pressed within the selected time.
LANGUAGE
Set the camera's language
DATE & TIME
Set the camera's date and time.
MSDC or PCCAM (Only select PCCAM when you would like to
USB
use the camera as a webcam then be sure to change back to MSDC
when using as camera).
START-UP IMAGE
Choose a picture for the camera's startup screen.
FORMAT
Format the SD/SDHC card (Deletes everything on the card).
RESET ALL
Reset the camera's settings to factory default.
In the box
Digital Camera
CD (ArcSoft® Media
Impression software)
Requires 3 AAA batteries (not included)
Location of controls
[T] - Zoom in
button
Mini
USB
Port
[MODE]
button
Picture Mode
1. Make sure that an SD card is inserted into the camera.
2. Turn on the camera, the Standby Picture Mode Screen is displayed and the
camera is in Picture Mode.
3. Press the [SHUTTER] button to take a picture.
1 2 3 4 5 6 7 8
1. Picture Mode Icon
2. Self timer
AUTO
3. White balance
4. Spot Metering
9
5. Exposure mode
6. Image Size
10
7. Image Quality
8. Pictures remaining
9. SD card indicator
10. LED light indicator
12
1.26 11
11. Zoom level
12. Battery level
Self timer and continuous shooting
1. While in picture mode, press the [ ] button on
the control wheel to select 2 second self-timer,
10 second self-timer or Burst.
2. When you select 2 or 10 seconds self timer,
the timer starts counting down from 2 or 10
seconds, and the camera takes a picture; when
you select burst, the camera takes 3 pictures
continuously.
3. Press the [SHUTTER] button to start self
timer or burst snapshot.
4. Press the [ ] button to turn o the self timer or
Burst feature (o is when the icon disappears
from the screen).
Deleting les
To delete the last picture or video taken, press the [
wheel then select "Yes" or "No". You can also browse and delete les on the
camera (refer to Playback Settings > Delete).
LED light indicator
In Picture Mode press the [ ] button repeatedly to select
from: AUTO / OFF / ON
Picture Mode Settings
1. Press the [MODE] button until the Picture Mode is selected.
2. Press the [MENU] button to access the Picture Mode Settings Screen.
3. Use the [ ] and [ ] buttons to scroll to a setting, then use the [
enter.
4. Use the [ ], [ ], [ ], or [ ] buttons to make changes, then con rm by
] button to
pressing the [OK] button.
5. Press the [MENU] button to exit the Picture Mode Settings Screen.
Picture Mode Settings Screen
Select and con rm options
Picture Mode Settings Options
RESOLUTION · 3M (2048x1536) / 5M (2592x1944) / 8M (3264x2448) / 12M (4000x3000)
(Higher picture resolution takes up more space on the card).
QUALITY
Super fine / Fine / Normal
METERING
Center / Multi / Spot
WHITE BALANCE
Auto / Daylight / Cloudy / Fluorescent / Tungsten
EXPOSURE
Adjust the exposure
DRIVER MODE
"Off" (disables the self timer), "2" or "10" second options
(self timer), "Burst" (3 frame shot)
Setting up your camera
Battery Installation
1. Open the battery cover by pressing and sliding the battery lock.
2. Insert 3 alkaline "AAA" size batteries (not included) into the compartment.
3. Close the battery cover.
USB Cable
(connects to your
computer)
Digital Camera
AAA Batteries
User Guide
EDC210
User Guide
[W] - Zoom out
button
[OK] button
Control wheel
Battery
compartment
[MENU]
button
Video Mode
1. Make sure that an SD card is inserted into the camera.
2. Turn on the camera, and press the [MODE] button once to enter Video Mode
(the Video Mode Screen is displayed).
3. Press the [SHUTTER] button, the Recording Screen is displayed and the
camera is recording video.
4. To pause the recording, press the [ ] button. Press again to resume
recording.
5. To stop recording and save, press the [SHUTTER] button again. The display
returns to the Standby Recording Screen.
1 2 3
AUTO
9
Zoom
Use the [T] and [W] button to zoom
in and out when recording video,
taking photos or viewing still images.
LED light
In Video Mode press the [
turn the LED light On. This is useful
] button on the control
for low light situations.
1. Press the [ ] button to turn the LED on
2. Press the [ ] button again to turn the LED o
Note: If the LED is turned on, and you are currently recording a video,
pressing [ ] will stop the recording. Press up again to turn the LED o .
Video Mode Settings
1. Press the [MODE] button until the Video Mode is selected.
2. Press the [MENU] button to access the Video Mode Settings Screen.
] button to 3. Use the [ ] and [ ] buttons to scroll to a setting, then use the [
enter.
4. Use the [ ] , [ ], [ ], or [
pressing the [OK] button.
5. Press the [MENU] button to exit the Picture Mode Settings Screen.
Video Mode Settings Screen
SCROLL
CONFIRM
ENTER
SCROLL
Video Mode Settings Options
640X480 (Higher quality video/shortest recording time)
MOVIE SIZE
320X240 (lower quality video/shortest recording time)
FRAME RATE 30 Frames Per Second (Higher quality video/shorter recording time)
15 Frames Per Second (Lower quality video/shorter recording time)
METERING
Center / Multi / Spot
WHITE BALANCE
Auto / Daylight / Cloudy / Fluorescent / Tungsten
SD card installation
This camera has no internal memory and requires an SD card (not included) to
take and save pictures or record videos. The camera can support SD cards up to
16GB. To install the SD card into the camera, follow the steps below:
1. Turn o the camera.
2. Insert the SD card into the card slot (as shown below) until it clicks and locks
into place. Make sure the metal contacts are facing the front of the camera.
3. To remove the card, gently push it in until it pops out.
• Make sure the Lock switch on the SD card is in the UNLOCKED position.
• A card can only be inserted one way: do not use force when inserting the card.
• Inserting or removing a card while the camera is on may damage the card, files
stored on the card, or the camera.
Using your camera
Turning the camera on/o
1. To turn the camera on, press and HOLD the [POWER] button until
[POWER] button
the display turns on.
Microphone 2. To turn the camera o , press and HOLD the [POWER] button until
the display turns o .
[SHUTTER] Button
Tripod mount SD card slot
This camera has an auto-shutoff feature which can be set for specific times (refer to
System Settings > Power Save).
Playback Mode
1. Turn on the camera, and press the [MODE] button twice to enter Playback
mode.
2. Use the [
3. If you select a video, press the [SHUTTER] button to start or stop the video
playback.
4. When in Playback mode, you can use the [W] button to view thumbnails. Use
the arrows on the control wheel to scroll and the [OK] button to select.
4. Press the [MODE] button again to return to the Video Mode or Picture
Mode.
4 5
1. Video Mode Icon
2. White balance
6 3. Spot Metering
4. Movie size
5. Recording time (video)
7
6. SD card indicator
7. LED indicator
8. Digital zoom indicator
1.26
9. Battery Indicator
8
4
] button to
4 JPG
Playback Settings
1. Press the [MODE] button to enter Playback Mode.
2. Press the [MENU] button to access the Playback Mode Settings Screen.
] button to 3. Use the [
enter, then con rm by pressing the [OK] button.
] buttons to make changes, then con rm by 4. Press the [MENU] button to exit the Playback Mode Settings Screen.
Note: When a video is selected, "Lock" and "Delete" are the only options.
Playback Mode Settings Screen
SCROLL
CONFIRM
ENTER
SCROLL
Select and con rm options
Playback Mode Settings Options
LOCK
DELETE
SLIDE SHOW
EFFECT
ROTATE
RESIZE
STARTUP IMAGE
or
[POWER] button
] or [ ] button to select a video or picture.
1 2
3
1. Playback Mode Icon
2. Number of saved videos
3. SD Card indicator
4. File type (video le)
1 2
3
1. Playback Mode Icon
2. Number of saved pictures
3. SD Card indicator
4. File type (photo le)
] and [ ] buttons to select an option, then use the [ ] button to
SCROLL
CONFIRM
ENTER
SCROLL
Select and con rm options
Lock one or all of your picture and video files. When locked the files
will not be to be deleted.
"One" (Delete the currently displayed video or picture) or "All"
Start a slide show, and adjust the slide show settings.
Select from various special effects.
Rotate the picture.
Resize the picture.
Choose a picture for the camera's startup screen.
