- Page 1 OWNER’S MANUAL MONITOR SIGNAGE Please read this manual carefully before operating the your set and retain it for future reference. MONITOR SIGNAGE MODELS 42VS20 42VX30MS 47VS20 47VX30AS 55VS20 47VX30AF www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CONTENTS - Viewing movies LICENSES - Viewing photos - Listening to music ASSEMBLING AND - Viewing the Contents List PREPARING - DivX® VOD Guide - Using PIP/PBP Accessories Optional Accessories CUSTOMIZING SETTINGS Parts and buttons Connecting the stand Accessing main menus Connecting the Speakers - PICTURE settings Portrait Layout - AUDIO settings Mounting on a wall - TIME settings - OPTION settings REMOTE CONTROL - Picture ID - NETWORK settings USING THE MONITOR SET... -
Page 3: Controlling The Multiple
LICENSES IR CODES CONTROLLING THE MULTIPLE PRODUCT Connecting the cable RS-232C Configurations Communication Parameter Command reference list Transmission / Receiving protocol... -
Page 4: Licenses
LICENSES LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified device that plays DivX video. Visit divx.com for more information and software tools to convert your files into DivX videos. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified device must be registered in order to play purchased DivX Video- on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration. DivX Certified to play DivX video up to HD 1080p, including premium content. DivX , DivX Certified and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license. Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274 Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. VESA, VESA logo, DisplayPort Compliance Logo and DisplayPort Compliance Logo for Dual-mode Sources are registered trademarks of the Video Electronics Standards Association. -
Page 5: Assembling And Preparing
ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Accessories Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. POWER MONITOR ENERGY INPUT SAVING . , ! PQRS WXYZ 1/a/A CLEAR - * # MARK BRIGHT NESS MUTE MENU AUTO S.MENU BACK EXIT TILE Remote control and Batteries Power Cord DVD (Owner's Manual)/ Card D-sub 15 pin signal cable CAUTION... -
Page 6: Optional Accessories
ASSEMBLING AND PREPARING Optional Accessories Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories. Stand kit 42VS20 47VS20 55VS20 42VX30MS 47VX30AS 47VX30AF Stand Stand Stand Screws Screws Screws Speaker kit Cable holder/ Speaker Screws/ Cable Cable Tie NOTE Cable holder/Cable tie may not be available in some areas or for some models. Optional accessories are not included for all models. -
Page 7: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons 42VS20 42VX30MS Power Indicator LED On : Power is on LED Off: Power is off Screen Buttons Screen Marks RGB/AV DVI IN DVI OUT AUDIO SPEAKER /COMPONENT OUT RGB/AV /COMPONENT IN Connection panel Screen Marks Description INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. Adjust the up and down. Adjusts the volume level. AUTO/SET Displays the current signal and mode. -
Page 8: Power Indicator
ASSEMBLING AND PREPARING 47VS20 47VX30AS 55VS20 Power Indicator LED On : Power is on LED Off: Power is off Screen Buttons Screen Marks RGB/AV DVI IN DVI OUT AUDIO SPEAKER /COMPONENT OUT RGB/AV /COMPONENT IN Connection panel Screen Marks Description INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. Adjust the up and down. Adjusts the volume level. AUTO/SET Displays the current signal and mode. Press this button to adjust the screen automatically (available only in RGB mode) Turns the power on or off. - Page 9 ASSEMBLING AND PREPARING 47VX30AF Power Indicator LED On : Power is on LED Off: Power is off Receiver Screen Buttons Screen Marks RGB/AV DVI IN DVI OUT AUDIO SPEAKER /COMPONENT OUT RGB/AV /COMPONENT IN Connection panel Screen Marks Description INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. Adjust the up and down. Adjusts the volume level. AUTO/SET Displays the current signal and mode. Press this button to adjust the screen automatically (available only in RGB mode) Turns the power on or off. / I IR Receiver This is where the unit receives signals from the remote control.
-
Page 10: Connecting The Stand
ASSEMBLING AND PREPARING Connecting the stand 47VS20 47VX30AS 47VX30AF - Only on some models. 42VS20 42VX30MS Place a soft cloth on the table and put the - Only on some models. product with the screen facing downward. Place a soft cloth on the table and put the product with the screen facing downward. Use the screws to secure the stand on the rear side of the product as shown in the diagram. Use the screws to secure the stand on the rear side of the product as shown in the diagram. - Page 11 ASSEMBLING AND PREPARING 55VS20 - Only on some models. Place a soft cloth on the table and put the product with the screen facing downward. Use the screws to secure the stand on the rear side of the product as shown in the diagram.
-
Page 12: Connecting The Speakers
ASSEMBLING AND PREPARING Connecting the Speakers 55VS20 - Only on some models. 42VS20 47VS20 42VX30MS Connect the input signal cable to the Monitor 47VX30AS 47VX30AF before installing the speakers. Use a cable tie to organize the cables. - Only on some models. Connect the input signal cable to the Monitor before installing the speakers. Use a cable tie to organize the cables. Mount the speaker by using a screw as shown in the following. Then connect the speaker cable. Mount the speaker by using a screw as shown in the following. Then connect the speaker cable. After installing your speakers, use holders and cable ties to organize the speaker cables. After installing your speakers, use holders and cable ties to organize the speaker cables. NOTE Connect the speaker terminals noting the correct polarity. To ensure the best sound quality and minimize noise, keep the cable as short as possible as shown in the figure. -
Page 13: Portrait Layout
ASSEMBLING AND PREPARING Portrait Layout Using the FFC/IR PCB (Only for 47VX30AF model) - Only on some models. 47VX30AF When installing in a Portrait Layout, rotate the monitor clockwise 90 degrees (when facing the screen). Remove the securing tape first. Do not pull out the FFC, as this may cause Using the Kensington security system damage. The Kensington security system connector is Be careful not to damage the product during located at the back of the Monitor set. For more installation. information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com . Connect the Kensington security system cable between the Monitor set and a table. NOTE The Kensington security system is optional. You can obtain additional accessories from most electronics stores. -
Page 14: Mounting On A Wall
ASSEMBLING AND PREPARING Mounting on a wall CAUTION Disconnect the power cord first, and then For proper ventilation, allow a clearance of 10 move or install the Monitor set. Otherwise cm on each side and from the wall. Detailed electric shock may occur. installation instructions are available from your If you install the Monitor set on a ceiling or dealer, see the optional Tilt Wall Mounting Bracket slanted wall, it may fall and result in severe Installation and Setup Guide. injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. D o not over tighten the screws as this may 10 cm cause damage to the Monitor set and void your warranty. U se the screws and wall mounts that meet the VESA standard. Any damages or injuries 10 cm by misuse or using an improper accessory are not covered by the warranty. 10 cm 10 cm 10 cm NOTE If you intend to mount the Monitor to a wall, attach Use the screws that are listed on the VESA Wall mounting interface (optional parts) to the back of the set. -
Page 15: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the Monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. CAUTION Do not mix old and new batteries, as this may damage the remote control. Make sure to point the remote control to the remote control sensor on the Monitor set. POWER POWER MONITOR MONITOR MONITOR ENERGY ENERGY INPUT INPUT SAVING SAVING . , ! . , ! PQRS PQRS WXYZ WXYZ 1/a/A 1/a/A CLEAR CLEAR - * # - * #... - Page 16 USING THE MONITOR SET POWER MONITOR ENERGY INPUT SAVING . , ! PQRS WXYZ 1/a/A CLEAR - * # MARK BRIGHT NESS POWER MUTE MENU MENU AUTO AUTO S.MENU S.MENU BACK BACK TILE TILE EXIT EXIT ENERGY INPUT MONITOR SAVING .
-
Page 17: Using The Monitor Set
USING THE MONITOR SET USING THE MONITOR SET Connecting to a PC RGB connection Transmits the analog video signal from your PC to Your Monitor set supports the Plug & Play* feature. the Monitor set. Connect the PC and the Monitor set with the 15 pin signal cable as shown the * Plug & Play: A PC will have a built-in driver for following illustrations. the monitor, no extra software is needed. Select RGB input. Back of the product. RGB/AV /COMPONENT OUT AUDIO RGB/AV /COMPONENT IN NOTE Macintosh Adapter It is recommended to use the Monitor set (not included) with the HDMI connection for the best image quality. Use a shielded signal interface cable, such as D-sub 15 pin signal cable and DVI/HDMI (not included) cable, with a ferrite core to maintain standard compliance for the product. -
Page 18: Dvi Connection
USING THE MONITOR SET DVI connection HDMI connection Transmits the digital video signal from your PC to Transmits the digital video and audio signals from the Monitor set. Connect the PC and the Monitor your PC to the Monitor set. Connect the PC and set with the DVI cable as shown the following the Monitor set with the HDMI cable as shown in illustrations. the following illustrations. Select DVI input. Select HDMI input. Back of the product. Back of the product. AUDIO DVI IN AUDIO DVI IN AUDIO (not included) (not included) (not included) NOTE Use a High Speed HDMI™ Cable. Please check the PC environment if you cannot hear the sound in HDMI mode. Some PCs require you to manually change the default audio output to HDMI. If you want to use HDMI-PC mode, you must set the input label to PC mode. When HDMI PC is used, a compatiblity problem might occur. -
Page 19: Dp Connection
USING THE MONITOR SET DP connection Transmits the digital video and audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the DP cable as shown in the following illustrations. Select DP input. Back of the product. (not included) NOTE Sound may not be available depending on the DP version of your PC. -
Page 20: Adjusting The Screen
USING THE MONITOR SET Adjusting the screen Customizing image options Customize basic and advanced options of each Selecting an image mode image mode for the best screen performance. Display images in its optimized settings by Press MENU to access the main menus. selecting one of the preset image modes. Press the Navigation buttons to scroll to Press MENU to access the main menus. PICTURE and press OK. Press the Navigation buttons to scroll to Press the Navigation buttons to scroll to PICTURE and press OK. Picture Mode and press OK. Press the Navigation buttons to scroll to Press the Navigation buttons to scroll to an Picture Mode and press OK. image mode you want and press OK. Press the Navigation buttons to scroll to an Select and adjust following options, and then image mode you want and press OK. press OK. Mode Description Option Description Vivid Adjusts the video image for the retail Backlight... -
Page 21: Customizing Pc Display Options
USING THE MONITOR SET Adjusting the sound Customizing PC display options Customize options of each image mode for the Selecting an sound mode best image quality. Play the sound in its optimized settings by This function works in the following mode: selecting one of the preset sound modes. RGB[PC] mode. Press MENU to access the main menus. Press MENU to access the main menus. Press the Navigation buttons to scroll to Press the Navigation buttons to scroll to AUDIO and press OK. PICTURE and press OK. Press the Navigation buttons to scroll to Sound Press the Navigation buttons to scroll to Mode and press OK. Screen and press OK. Press the Navigation buttons to scroll to a Select and adjust following options, and then sound mode you want and press OK. press OK. Option Description Mode Description Resolution Selects a proper resolution. See Standard Select when you want standard-quality “Customizing PC display options”. -
Page 22: Customizing Sound Options
AUDIO and press OK. Press the Navigation buttons to scroll to Sound Mode and press OK. CAUTION Press the Navigation buttons to scroll to a If a fixed image displays on the screen for a sound mode you want and press OK. long period of time, it will be imprinted and become a permanent disfigurement on the Select and adjust following options, and then screen. This is “image burn” or “burn-in” and press OK. not covered by the warranty. If the aspect ratio is set to 4:3 for a long period of time, image burn may occur on the letterboxed area of the screen. Option Description Infinite LG's Infinity Sound option provides Sound 5.1 channel stereo sound from two speakers. Treble Controls the dominant sounds in the NOTE output. When you turn up the treble, it will increase the output to the lower You can also change the image size by frequency range. accessing the main menus. Bass Makes the output sound softer. If the bass is increased, the frequency of the output also increases. Reset Resets the sound mode to the default MODE AV Component RGB... - Page 23 USING THE MONITOR SET - 16:9 : This selection will allow you to adjust the - 4:3 : This selection will allow you to view a picture horizontally, in linear proportion, to fill the picture with an original 4:3 aspect ratio, black entire screen(useful for viewing 4:3 formatted bars will appear on both the left and right of the DVDs). screen. - Just Scan : This Selection will allow you view - Zoom : This selection will allow you to view the the picture of best quality without loss of original picture without any alteration, while filling the picture in high resolution image. Note: If there is entire screen. However, the top and bottom of noise in original Picture, You can see the noise the picture will be cropped. at the edge. Just Scan - 1:1 : The aspect ratio is not adjusted from the - Cinema Zoom : Choose Cinema Zoom when original. (Only Display Port PC, HDMI PC, you want to enlarge the picture in correct DVI-D PC, RGB PC) proportion. Note: When enlarging or reducing the picture, the image may become distorted.
-
Page 24: Using The Input List
USING THE MONITOR SET Using the input list Selecting an input source Press INPUT to access the input source list. Press the Navigation buttons to scroll to one of the input sources and press OK. Input source Description AV(CVBS) Watch video from a VCR or other external devices. Component Watch the contents in a DVD or other extemal devices, or through a digital set-top box View a PC display on the screen Display Port View a PC display on the screen DVI-D View a PC display on the screen HDMI Watch contents in a PC, DVD of Digital set-top box other high definition devices... -
Page 25: Entertainment
ENTERTAINMENT ENTERTAINMENT Connecting to a wired network To set up the network seetings: (Even if your dis- play has already connected automatically, running setup again will not harm anything), (Depending on model) Press MENU to access the main menus. Press the Navigation buttons to scroll to NET- Connect the display to a local area network (LAN) WORK and press OK. via the LAN port as shown on the following illustra- tion and set up the network settings. Press the Navigation buttons to select Net- Only supports wired network connection. work Setting and press OK. After making a physical connection, a small If you already set Network Setting, select number of home networks may require the display Resetting. The new connection settings resets network settings to be adjusted. For most home the current network settings. networks, the display will connect to automatically without any adjustments. Select IP Auto Setting or IP Manual Setting. For detail information, contact your internet pro- - If selecting IP Manual Setting, press the vider or router manual. -
Page 26: Network Status
Tips for Network setting Use a standard LAN cable with this display. Cat5 or better with a RJ45 connector. Many network connection problems during set up can often be fixed by re-setting the router or modem. After connecting the display to the home network, quickly power off and/or discon- nect the power cable of the home network router or cable modem. Then power on and/or Network Status connect the power cable again. Depending on the internet service provider (ISP), the number of devices that can receive Press MENU to access the main menus. internet service may be limited by the applica- Press the Navigation buttons to scroll to NET- ble terms of service. For details, contact your WORK and press OK. ISP. LG is not responsible for any malfunction of the Press the Navigation buttons to select Net- display and/or the internet connection feature work Status. due to communication errors/malfunctions as- Press OK to check the network status. sociated with your internet connection, or other connected equipment. When you are finished, press EXIT. LG is not responsible for problems within your internet connection. You may experience undesired results if the network connection speed does not meet the requirements of the content being accessed. Option Description Some internet connection operations may not Setting Return to the network setting menu. -
Page 27: Connecting Usb Storage Devices
ENTERTAINMENT Connecting USB storage devices Tips for using USB storage devices Only a USB storage device is recognizable. Connect USB storage devices such as a USB If the USB storage device is connected flash memory, external hard drive to the display through a USB hub, the device is not recog- and use multimedia features (See "Browsing files" nizable. on page 28). A USB storage device using an automatic Connect a USB flash memory or USB memory recognition programme may not be recog- card reader to the Display as shown on the follow- ing illustration. The My media screen appears. nized. A USB storage device which uses its own driver may not be recognized. The recognition speed of a USB storage device may depend on each device. Please do not turn off the display or unplug the USB device when the connected USB storage device is working. When such device is suddenly separated or unplugged, the stored files or the USB storage device may be damaged. Please do not connect the USB storage device which was artificially maneuvered on the PC. The device may cause the product to malfunction or fail to be played. Never forget to use only a USB storage device which has normal music files, image files or movie files. -
Page 28: Browsing Files
ENTERTAINMENT If the USB HDD does not have an external Browsing files power source, the USB device may not be Access the photo, music, or movie lists and browse detected. So be sure to connect the external files. power source. - Please use a power adaptor for an external Connect a USB storage device. power source. We do not guarantee an USB Press MENU to access the main menus. cable for an external power source. If your USB memory device has multiple Press the Navigation buttons to scroll to My Media and press OK. partitions, or if you use a USB multi-card reader, you can use up to 4 partitions or USB Press the Navigation buttons to choose memory devices. from Movie List, Photo List, Music List or If a USB memory device is connected to a Contents List and press OK. USB multi-card reader, its volume data may not be detected. If the USB memory device does not work properly, disconnect and reconnect it. Movie List Photo List Music List Contents List How fast a USB memory device is detected differs from device to device. If the USB is connected in Standby Mode, specific hard disk will automatically be Page 1/1 Photo List... -
Page 29: Supported File Format
ENTERTAINMENT Supported file format Type Supported file format Music Movie DAT,MPG,MPEG,VOB,AVI,DIVX,MP4,MKV,TS,T Bit rate 32 to 320 RP,TP,ASF,WMV,FLV) y Sampling rate MPEG1 Layer3 : 32 kHz, 44.1 kHz, 48 kHz Movie(*.mpg/*.mpeg/*dat/*.ts/*.trp/*.tp/*.vob/*. y Sampling rate MPEG2 Layer3 : 16 kHz, 22.05 mp4/*.mov/*.mkv/*.divx/*.avi/*.asf/*.wmv/*.flv/*. kHz, 24 kHz avi(motion-jpeg)/*. y Sampling rate MPEG2.5 Layer3 : 8 kHz, mp4(motion-jpeg)/*.mkv(motion-jpeg))supporting 11.025 kHz, 12 kHz file Content File Extensions : *.cts/ *.cse Video format : DivX3.11, DivX4.12, DivX5.x, (when Movie DivX6, Xvid1.00, Xvid1.01, Xvid1.02, Xvid1.03, using File Extensions: *.mpg/*.mpeg/*.dat/*.ts/*. Xvid1.10 beta-1/beta-2, SuperSign trp/*.tp/*.vob/*.mp4/*.mov/*.mkv/*.avi/*.asf/*. Manager) Mpeg-1, Mpeg-2, Mpeg-4, H.264/AVC, VC1, wmv/*.avi(motion JPEG)/*.mp4(motion JPEG)/*. -
Page 30: Viewing Movies
ENTERTAINMENT Viewing movies Play a movie. Play video files on display. Your display shows all NOTE of the video files saved in a USB storage device or shared folder on a PC. Non-supported files are displayed the preview image by icon only Press the Navigation buttons to scroll to My Abnormal files are displayed in the form of bitmap Media and press OK. Press the Navigation buttons to scroll to Movie List and press OK. Press the Navigation buttons to scroll to a Control playback by using the following buttons. folder you want and press OK. Press the Navigation buttons to scroll to a file you want and press OK. 01:02:30 / 02:30:25 Page 1/1 Movie List MENU Option Hide Exit Drive1 Page 1/1 USB1 USB Drive Button Description Stops the playback Move Play... - Page 31 ENTERTAINMENT Tips for using playing video files When you are watching the movie by Movie List function, you can adjust an image by Some user-created subtitles may not work Energy Saving key on the remote control. properly. User setup for each image mode does not Some special characters are not supported operate. in subtitles. HTML tags are not supported in subtitles. Subtitles in languages other than the sup- ported languages are not available. The screen may suffer temporary interrup- Video options tions (image stoppage, faster playback, etc.) when the audio language is changed. Press MENU to access the Pop-Up menus. A damaged movie file may not be played Press the Navigation buttons to scroll to Set correctly, or some player functions may not Video Play., Set Video. or Set Audio. and be usable. press OK. Movie files produced with some encoders may not be played correctly. If the video and audio structure of recorded file is not interleaved, either video or audio is NOTE...
- Page 32 ENTERTAINMENT When you select the Set Video Play,, Repeat Turn on/off repeat function of movie playback. When turned on, the Press the Navigation buttons to scroll to show file within the folder will be played the Picture Size, Audio Language, Subtitle back repeatedly. Even when the Language or Repeat. repeated playback is turned off, it can run the playback if Press the Navigation buttons to scroll to make the file name is similar to the previous file. appropriate adjustments. Menu Description Code Page Support Language Picture Size Selects your desired picture Latin1 English, Spanish, French, format during movie play. German, Italian, Swedish, Finnish, Dutch, Portuguese, Danish, Roma- Audio Changes the Language Group of the Language nian, Norwegian, Albanian, Gaelic, audio during movie play. Files Welsh, Irish, Catalan,Valencian with a single audio track cannot be...
-
Page 33: Viewing Photos
ENTERTAINMENT When you select the Set Video,, Page 1/1 Photo List USB1 USB Drive Drive1 Page 1/1 Press the Navigation buttons to scroll to make appropriate adjustments. When you select the Set Audio,, Move View Page Change Change Numbers Exit To Music List Mark Mode Press the Navigation buttons to scroll to show Page 1/1 the Sound Mode, Clear Voice II or Balance. Photo List Mark Mode USB1 USB Drive Drive1 Page 1/1 Press the Navigation buttons to scroll to make appropriate adjustments. Move Mark Page Change Exit View Marked Mark All Unmark All... - Page 34 ENTERTAINMENT Using photo options ENERGY Press the ENERGY SAVING button SAVING( repeatedly to change the brightness of your screen. Use the following options while viewing photos. Option Slide Speed: Selects a slideshow speed (Fast, Medium, Slow). TransitionEffect: Set the view mode of the slideshow. y BGM: Selects a music folder for the background music. NOTE You cannot change the music folder while the background music is playing. You can only select the MP3 2/13 folder saved on the device that currently displays the photo. Hide MENU Option Exit Slideshow Options...
- Page 35 ENTERTAINMENT When you select the Set Photo View, Press the Navigation buttons to scroll to select Slide Speed,Transition Effect or BGM. Press the Navigation buttons to scroll to make appropriate adjustments. Transition Effect Option Option Description Sliding Pushes the current slide out of view as it plays to the next slide. Stairs Pushes the current slide in a staircase shape as it plays to the next slide. Door Open Pushes the current slide like opening or closing the door as it plays to the next slide. /Close Shutter Pushes the current slide like drawing or pulling down the blind as it plays to the next slide Fade In Fades the slide out slowly before playing to the next slide.
-
Page 36: Listening To Music
ENTERTAINMENT Listening to music When you select the Set Photo View, Press the Navigation buttons to scroll to select Slide Speed or BGM.. Press the Navigation buttons to scroll to My Me- Press the Navigation buttons to scroll to make dia and press OK. appropriate adjustments. Press the Navigation buttons to scroll to Music List and press OK. Press the Navigation buttons to scroll to a folder you want and press OK. Video, When you select the Set Press the Navigation buttons to scroll to a file Press the Navigation buttons to scroll to make you want and press OK. appropriate adjustments. Page 1/1 Music List USB1 USB Drive Drive1 Page 1/1 001. - B01.mp3 002. -B02.mp3 003. B03.mp3... - Page 37 ENTERTAINMENT Tips for playing music files Control playback by using the following buttons. This unit cannot support the ID3 Tag embedded MP3 files. Page 1/1 Music List 3 file(s) Marked Drive1 Page 1/1 NOTE 004. - B04.mp3 005. - B05.mp3 006. - B06.mp3 007. - B07.mp3 008. - B08.mp3 00:00 00:00 00:00 00:00 00:00 005. - B05.mp3 02:30 / 03:25 Non-supported files are displayed the pre- MENU Option Hide Exit Play with Photo view image by icon only Abnormal files are displayed in the form of bitmap Button Description A damaged or corrupted music does not play Stops playing back the file and moves back to the music list.
-
Page 38: Viewing The Contents List
ENTERTAINMENT Viewing the Contents List Music options Press MENU to access the Pop-Up menus. Plays back the stored files using the Export option in SuperSign Manager. Press the Navigation buttons to scroll to Set Au- dio Play. or Set Audio. and press OK. Press the Navigation buttons to scroll to My Media and press OK. Press the Navigation buttons to scroll to Con- NOTE tents List and press OK. Option values changed in Movie List does Press the Navigation buttons to scroll to a not affect Photo List and Music List. folder you want and press OK. Option value changed in Photo List and Mu- List are changed likewise in Photo List Press the Navigation buttons to scroll to a file... -
Page 39: Divx® Vod Guide
ENTERTAINMENT DivX® VOD Guide DivX® VOD Deregistration You should deregister your device with 8 digit DivX deregistration code from your device at www.divx. com/vod. DivX® VOD Registration In order to play purchased or rented DivX® VOD contents, you should register your device with 10 Press MENU to access the main menus. digit DivX registration code from your device at Press the Navigation buttons to scroll to www.divx.com/vod. MEDIA and press OK. Press the Blue button. Press MENU to access the main menus. Press the Navigation buttons to scroll to Deacti- Press the Navigation buttons to scroll to MY vation and press OK. MEDIA and press OK. Press the Navigation buttons to select Yes to Press the Blue button. -
Page 40: Using Pip/Pbp
ENTERTAINMENT Using PIP/PBP Select the PIP or PBP icon from the play list. Displays videos or photos stored in the USB device on a single monitor by dividing it into the main and sub screens. (See p.50) Press the MENU button to move to OPTION and press OK. Press PIP/PBP to select PIP or PBP and then 01:02:30 / 02:30:25 press OK. MENU Option Hide Exit < Movie List > PIP/PBP Prev. Move Mode Off Position PIP Size PBP Select Movie List or Photo List from My Media. (With PIP/PBP selected, the Music List and Contents List are deactivated.) 2/13 MENU Option Hide Exit Slideshow <... -
Page 41: Customizing Settings
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Accessing main menus MARK BRIGHT NESS Press MENU to access the main menus. MUTE AUTO S.MENU MENU Press the Navigation buttons to scroll to one of the following menus and press OK. BACK EXIT TILE Press the Navigation buttons to scroll to the setting or option you want and press OK. When you are finished, press EXIT. When you return to the previous menu, press BACK. PICTURE (See p.42) AUDIO (See p.45) Adjusts the image size, Adjusts the sound quality, quality, or effect. effect, or volume level. TIME (See p.46) Sets the time, date, or Timer feature. PICTURE AUDIO TIME MIDIA (See p.27) OPTION (See p.47) Display and play movie, Customizes the general photo and music content... -
Page 42: Picture Settings
CUSTOMIZING SETTINGS PICTURE settings PICTURE Move • Aspect Ratio : 16:9 ꔋ Press MENU to access the main menus. • Energy Saving : Off • Smart Energy Saving : Off Press the Navigation buttons to scroll to PICTURE and • Picture Mode : Standard press OK. • Backlight • Contrast Press the Navigation buttons to scroll to the setting or • Brightness option you want and press OK. • Sharpness • Color - To return to the previous level, press BACK. • Tint When you are finished, press EXIT. • Color Temp. • Advanced Control When you return to the previous menu, press • Picture Reset BACK. • Screen The available picture settings are described in the following: Setting Description Aspect Ratio Changes the image size to view images at its optimal size (See p.22). - Page 43 CUSTOMIZING SETTINGS Setting Description SCREEN Customizes the PC display options in RGB mode. (In RGB Option Mode Only) Resolution Selects a proper resolution. See “Customizing PC display options”. Auto Configure Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress. Position/Size/ Adjusts the options when the picture is not clear, especially when characters are Phase shaky, after the auto configuration. Reset Restores the options to the default setting. Picture Mode options Setting Description Backlight A djusts the brightness of the screen by controlling the LCD backlight. If you decrease the brightness level, the screen becomes darker and the power consumption will be reduced without any video signal loss. Contrast Increases or decreases the gradient of the video signal. You may use Contrast when the bright part of the picture is saturated. Brightness Adjusts the base level of the signal in the picture. You may use Brightness when the dark part of the picture is saturated. Sharpness Adjusts the level of crispness in the edges between the light and dark areas of the picture.
- Page 44 CUSTOMIZING SETTINGS Advanced Control Setting Description Dynamic Adjusts the contrast to keep it at the best level according to the brightness of the screen. The Contrast picture is improved by making bright parts brighter and dark parts darker. (Function works in the (Off/High/ following mode - AV(CVBS), Component, HDMI-DTV, Display Port-DTV) Medium/Low) Dynamic Color Adjusts screen Colors so that they look livelier, richer and clearer. This feature enhances (Off/High/Low) hue, saturation and luminance so that red, blue, green and white look more vivid. (Function works in the following mode - AV(CVBS), Component, HDMI-DTV, Display Port-DTV) Clear White Make the white area of screen brighter and more white. (Off/High/Low) Skin Color It detects the skin area of video and adjusts it to express a natural skin color. (-5 to 5) Noise educes screen noise without compromising video quality. (Function works in the following mode - Reduction AV(CVBS), Component, HDMI-DTV, Display Port-DTV) (Off/High/ Medium/Low) Digital Noise This option reduces the noise produced while creating digital video signals. Reduction (Off/High/ Medium/Low) Gamma Set your own gamma value. On the monitor, high gamma values display whitish images and low...
-
Page 45: Audio Settings
Mode Standard The most commanding and natural audio. Music Select this option to enjoy the original sound when listening to the music. Cinema Select this option to enjoy sublime sound. Sport Select this option to watch sports broadcasting. Game To enjoy dynamic sound when playing a game. NOTE If sound quality or volume is not at the level you want, it is recommended to use a separate home theater system or amplifier to cope with different user environments. Option Infinite Sound LG's Infinity Sound option provides 5.1 channel stereo sound from two speakers. Treble Controls the dominant sounds in the output. When you turn up the treble, it will increase the output to the higher frequency range. Bass Makes the output sound softer. When you turn up the bass, it will increase the output to the lower Frequency. Reset Resets the sound mode to the default setting. Digital Audio HDMI/Display Port: Outputs the sound of digital signal from HDMI and display ports through the Input monitor speaker. Audio In: Outputs the sound through the monitor speaker by connecting HDMI and display ports to the Audio In port. Speaker ON: Enables sound to the monitor speaker. (* The monitor speaker is sold separately.) -
Page 46: Time Settings
CUSTOMIZING SETTINGS TIME settings TIME Move • Clock ꔋ Press MENU to access the main menus. • Off Time : Off • On Time : Off Press the Navigation buttons to scroll to TIME and press • Sleep Timer : Off • Power On Delay : Off • Auto Off : On Press the Navigation buttons to scroll to the setting or option • Automatic Standby : On you want and press OK. -
Page 47: Option Settings
CUSTOMIZING SETTINGS OPTION settings OPTION Move • Language ꔋ Press MENU to access the main menus. • Power Indicator • ISM Method : Normal Press the Navigation buttons to scroll to OPTION and press • DPM Select : On • Fail Over : Off • Factory Reset Press the Navigation buttons to scroll to the setting or option • Set ID you want and press OK. • Tile Mode •... - Page 48 CUSTOMIZING SETTINGS Setting Description Tile Mode Tile Mode To use this function - Must be displayed with various other products. - Must be in a function that can be connected to RGB Cable by distributor and RS-232C. Tile mode and choose Tile alignment and set the ID of the current product to set location. * Only after pressing the SET button the adjustments made to the settings will be saved. - Tile mode : column x row ( c = 1 to 15 r = 1 to 15) - 15 x 15 available. - Configuration of an integration screen is also available as well as configuration of One by one Display. Auto Config. Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress. Position Moving the screen position horizontally and vertically. Size Adjust the horizontal and vertical size of the screen taking into account the size of the bezel. Natural The image is omitted by the distance between the screens to be naturally shown. Reset Function to initialize and release Tile. All Tile setting are released when selecting Tile recall and the screen returns to Full screen. PIP/PBP Displays videos or photos stored in the USB device on a single monitor by dividing it into the main and sub screens. Option Mode Sets the type of secondary screen.
- Page 49 CUSTOMIZING SETTINGS Tile Mode This monitor can be tiled with additional monitors to create a large tiled display. When using 2 monitors When using 4 monitors When using 9 monitors When the Tile Mode option is disabled ID 2 ID 2 ID 3 ID 2 ID 1 ID 1 ID 1 ID 4 ID 6 ID 5 ID 3 ID 4 Tile ID ID 9 ID 8 ID 7 When using 16 monitors When using 25 monitors ID 3 ID 4 ID 5 ID 1 ID 2 ID 1 ID 3 ID 4 ID 2 ID 8 ID 9 ID 10 ID 6 ID 7 ID 6...
- Page 50 CUSTOMIZING SETTINGS PIP/PBP Displays videos or photos stored in the USB device on a single monitor by dividing it into the main and sub screens. (See p.40) Mode NOTE *PIP(Picture In Picture): Displays the Sub screen in the main screen. The subscreen is only supported when using the USB device. *PBP(Picture By Picture): Displays the Sub screen next to the main screen. Component Main screen screen Main HDMI/DVI-D/Display Port You can only change the size and position in PIP mode. With PBP selected, the Aspect Ratio option in the Position PICTURE menu is disabled (Fixed as 16:9). While running the PBP function, the Tile Mode function Adjusts the position of the subscreen (top left, does not work. bottom left, top right, bottom right) You must select the output sound before running the PIP or PBP functions. (Select either Main or Sub.) If you fail to select Main or Sub from the sound selection box, and if the OSD disappears after either a period of time or when the Exit or Back key is pressed, the PIP/PBP subscreen is not top left top right activated.
-
Page 51: Picture Id
CUSTOMIZING SETTINGS Picture ID Picture ID is used to change the settings of a If you press the left/right buttons or press the specific display using a single IR receiver for ON button repeatedly, the Picture ID cycles multi-vision. The set receiving the IR signal through OFF and 0 to 4. Assign the ID you communicates with another set via an RS232 want. connection. Each set is identified by a Set ID. If you assign the Picture ID using the remote control, Picture ID only displays with the same Picture ID and Set ID can be controlled remotely. POWER POWER ◀ ▶ ENERGY INPUT ENERGY INPUT MONITOR MONITOR Close IR Receiver IR Receiver SAVING SAVING . , ! . , ! If you assign the Set ID to each set with RS232C RS232C... -
Page 52: Network Settings
CUSTOMIZING SETTINGS NETWORK settings NETWORK Move • Player Name ꔋ Press MENU to access the main menus. • Network Setting : Wired • Network Status : Not connected Press the Navigation buttons to scroll to NETWORK and • Server IP Setting press OK. • Server IP Status : Not connected Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available option settings are described in the following: Setting Description... -
Page 53: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Connect various external devices to the ports on the Monitor set’s back panel. Find an external device you want to connect to your Monitor set shown on the following illustration. Check the connection type of the external device. Go to the appropriate illustration and check the connection details. HD Receiver HDMI - See p.54 HDMI - See p.54 AV(CVBS) DVI - See p.54 DVI - See p.54 - See p.55 AV(CVBS) - See p.55 AV(CVBS) - See p.55 Component Component - See p.55 Component - See p.55 - See p.55 Speaker Memory storage – See p.27 Gaming device Camcorder/Camera HDMI - See p.18 HDMI - See p.54 HDMI - See p.54 DVI - See p.18 DVI - See p.54 AV(CVBS) RGB - See p.17 AV(CVBS) - See p.55 - See p.55 LAN - See p.56 Component - See p.55 Component Display Port - See p.19 - See p.55 NOTE... -
Page 54: Connecting To A Hd Receiver, Dvd, Camcorder, Camera, Gaming Device Or Vcr Player
MAKING CONNECTIONS Connecting to a HD receiver, HDMI connection DVD, Camcorder, Camera, Transmits the digital video and audio signals from Gaming Device or VCR player an external device to the Monitor set. Connect the external device and the Monitor set with the HDMI Connect a HD receiver, DVD, or VCR player to the cable as shown on the following illustration. Monitor set and select an appropriate input mode. Back of the product. DVI connection RGB/AV DVI IN AUDIO /COMPONENT OUT RGB/AV Transmits the digital video signal from an external /COMPONENT IN device to the Monitor set. Connect the external device and the Monitor set with the DVI cable as shown in the following illustration. To transmit an audio signal, connect an optional audio cable. (not included) Back of the product. -
Page 55: Component Connection
MAKING CONNECTIONS Component connection AV(CVBS) connection Transmits the analog video and audio signals from Transmits the analog video and audio signals from an external device to the Monitor set. Connect the an external device to the Monitor set. Connect the external device and the Monitor set with the 15 external device and the Monitor set with the 15 pin signal to RCA cable as shown on the following pin signal to RCA cable as shown on the following illustration. To display images by using progressive illustration. scan, make sure to use the component cable. Back of the product. Back of the product. RGB/AV RGB/AV AUDIO AUDIO /COMPONENT OUT /COMPONENT OUT RGB/AV RGB/AV AUDIO AUDIO /COMPONENT OUT /COMPONENT OUT RGB/AV RGB/AV /COMPONENT IN /COMPONENT IN RGB/AV RGB/AV /COMPONENT IN... -
Page 56: Connecting To The Lan
MAKING CONNECTIONS Connecting to the LAN Connecting to a USB Connect a USB storage device such as s USB LAN connection flash memory, external hard drive, MP3 player or a USB memory card reader to the Monitor set and access the USB menu to use various multimedia files. Using a router(Switch) Switch Monitor Set Network Using the Internet. Network Monitor Set... -
Page 57: Daisy Chain Monitors
MAKING CONNECTIONS Daisy Chain Monitors Use this function to share the RGB video signal with other monitors without having to use a separate signal splitter box. • T o use different products connected to each other Connect one end of the signal input cable (15-pin D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN connector of other products RGB Cable RGB/AV RGB/AV RGB/AV RGB/AV 15-pin D-Sub Signal Cable /COMPONENT OUT /COMPONENT OUT /COMPONENT OUT /COMPONENT OUT (Max 3m) RGB/AV RGB/AV RGB/AV RGB/AV /COMPONENT IN /COMPONENT IN /COMPONENT IN /COMPONENT IN RGB/AV RGB/AV RGB/AV... -
Page 58: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING No image is displayed Problem Resolution Is the product power cord y S ee if the power cord is properly connected to the outlet. connected? Is the power indicator light on? y See if the power switch is turned on. y May need service. P ower is on, power indicator y Adjust brightness and contrast again. is blue but the screen appears y Backlight may need repair. extremely dark. The power indicator amber? y I f the product is in power saving mode, move the mouse or press any key. y Turn both devices off and then back on. D oes the 'Out of range' y T he signal from the PC (video card) is out of the vertical or horizontal message appear? frequency range of the product. Adjust the frequency range by referring to the Specifications in this manual. - Page 59 TROUBLESHOOTING 'Key Lock On' message appears. Problem Resolution The 'Key Lock On' message y The Lock function prevents the OSD settings from being changed appears when pressing the inadvertently. To release the lock, go to Menu and Option and disable Menu button. the Key Lock option. The screen image looks abnormal. Problem Resolution Is the screen position wrong? y D-Sub analog signal - Press the "AUTO" button in the remote control to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Position OSD menu. y See if the video card resolution and frequency are supported by the product. If the frequency is out of range, set to the recommended resolution in the Control Panel "Display" Setting menu. Do thin lines appear on the y D -Sub analog signal - Press the "AUTO" button in the remote control background screen? to automatically select an optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Clock OSD menu.
- Page 60 TROUBLESHOOTING The audio function does not work. Problem Resolution No sound? y See if the audio cable is connected properly. y Adjust the volume. y S ee if the sound is set properly. Sound is too dull. y Select the appropriate equalize sound. Sound is too low. y A djust the volume. Screen color is abnormal. Problem Resolution Screen has poor color resolution y S et the number of colors to more than 24 bits (true color) Select (16 colors). Control Panel - Display - Settings - Color Table menu in Windows. S creen color is unstable or y Check the connection status of the signal cable. Or, re-insert the PC mono-colored.
-
Page 61: Specifications
SPECIFICATIONS SPECIFICATIONS 42VS20 42VX30MS LCD Panel Screen Type 1067.31 mm Wide (42 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1067.31 mm Pixel Pitch 0.4845 mm (H) x 0.4845 mm (V) Video Signal Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Recommended Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Horizontal Frequency RGB : 30 kHz to 83 kHz HDMI/DVI/DP : 30 kHz to 83 kHz Vertical Frequency RGB : 56 Hz to 75 Hz HDMI/DVI/DP : 56 Hz to 60 Hz Synchronization Type Separate Sync, Composite Sync, Digital Input Connector 15-pin D-Sub type, HDMI (digital), RS-232C, LAN, DVI, Display port, USB Power Rated Voltage AC 100-240 V~ 50/60 Hz 2.2 A Power Consumption On Mode : 170 W Typ. Sleep Mode : ≤ 1 W Off Mode : ≤ 0.5 W Environmental Operating Temperature 0 °C to 40 °C... - Page 62 SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 967 mm x 561 mm x 125 mm / 17.5 kg 967 mm x 633 mm x 259 mm / 18.8 kg 967 mm x 561 mm x 126.5 mm / 18.25 kg 967 mm x 633 mm x 259 mm / 19.55 kg * Applicable only for models that support the speakers Audio RMS Audio Output 10 W + 10 W (R + L) Input Sensitivity 0.7 Vrms Speaker Impedance 8 Ω Product specifications shown above may be changed without prior notice due to upgrade of product functions.
- Page 63 SPECIFICATIONS 47VS20 47VX30AS LCD Panel Screen Type 1192.87 mm Wide (47 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1192.87 mm Pixel Pitch 0.5415 mm (H) x 0.5415 mm (V) Video Signal Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Recommended Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Horizontal Frequency RGB : 30 kHz to 83 kHz HDMI/DVI/DP : 30 kHz to 83 kHz Vertical Frequency RGB : 56 Hz to 75 Hz HDMI/DVI/DP : 56 Hz to 60 Hz Synchronization Type Separate Sync, Composite Sync, Digital Input Connector 15-pin D-Sub type, HDMI (digital), RS-232C, LAN, DVI, Display port, USB Power Rated Voltage AC 100-240 V~ 50/60 Hz 3.0 A Power Consumption On Mode : 180 W Typ. Sleep Mode : ≤ 1 W Off Mode : ≤ 0.5 W Environmental Operating Temperature 0 °C to 40 °C conditions Operating Humidity 10 % to 80 %...
- Page 64 SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 1079.5 mm x 624.6 mm x 122.9 mm / 22.2 kg 1079.5 mm x 697.7 mm x 298.3 mm / 23.6 kg 1079.5 mm x 624.6 mm x 129.2 mm / 23.0 kg 1079.5 mm x 697.7 mm x 298.3 mm / 24.4 kg * Applicable only for models that support the speakers Audio RMS Audio Output 10 W + 10 W (R + L) Input Sensitivity 0.7 Vrms Speaker Impedance 8 Ω Product specifications shown above may be changed without prior notice due to upgrade of product functions.
- Page 65 SPECIFICATIONS 47VX30AF LCD Panel Screen Type 1192.87 mm Wide (47 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1192.87 mm Pixel Pitch 0.5415 mm (H) x 0.5415 mm (V) Video Signal Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Recommended Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Horizontal Frequency RGB : 30 kHz to 83 kHz HDMI/DVI/DP : 30 kHz to 83 kHz Vertical Frequency RGB : 56 Hz to 75 Hz HDMI/DVI/DP : 56 Hz to 60 Hz Synchronization Type Separate Sync, Composite Sync, Digital Input Connector 15-pin D-Sub type, HDMI (digital), RS-232C, LAN, DVI, Display port, USB Power Rated Voltage AC 100-240 V~ 50/60 Hz 3.0 A Power Consumption On Mode : 180 W Typ. Sleep Mode : ≤ 1 W Off Mode : ≤ 0.5 W Environmental Operating Temperature 0 °C to 40 °C conditions Operating Humidity 10 % to 80 % Storage Temperature...
- Page 66 SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 1079.1 mm x 624.2 mm x 116.3 mm / 22.4 kg 1079.1 mm x 697.5 mm x 298.3 mm / 23.8 kg 1079.1 mm x 697.5 mm x 122.6 mm / 23.2 kg 1079.1 mm x 697.5 mm x 298.3 mm / 24.6 kg * Applicable only for models that support the speakers Audio RMS Audio Output 10 W + 10 W (R + L) Input Sensitivity 0.7 Vrms Speaker Impedance 8 Ω Product specifications shown above may be changed without prior notice due to upgrade of product functions.
- Page 67 SPECIFICATIONS 55VS20 LCD Panel Screen Type 1387.80 mm Wide (55 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1387.80 mm Pixel Pitch 0.630 mm (H) x 0.630 mm (V) Video Signal Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Recommended Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Horizontal Frequency RGB : 30 kHz to 83 kHz HDMI/DVI/DP : 30 kHz to 83 kHz Vertical Frequency RGB : 56 Hz to 75 Hz HDMI/DVI/DP : 56 Hz to 60 Hz Synchronization Type Separate Sync, Composite Sync, Digital Input Connector 15-pin D-Sub type, HDMI (digital), RS-232C, LAN, DVI, Display port, USB Power Rated Voltage AC 100-240 V~ 50/60 Hz 3.3 A Power Consumption On Mode : 260 W Typ. Sleep Mode : ≤ 1 W Off Mode : ≤ 0.5 W Environmental Operating Temperature 0 °C to 40 °C conditions Operating Humidity 10 % to 80 % Storage Temperature...
- Page 68 SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 1251 mm x 722 mm x 104 mm / 34.5 kg 1251 mm x 795 mm x 298 mm / 35.9 kg 1251 mm x 722 mm x 104 mm / 35.2 kg 1251 mm x 795 mm x 298 mm / 36.6 kg * Applicable only for models that support the speakers Audio RMS Audio Output 10 W + 10 W (R + L) Input Sensitivity 0.7 Vrms Speaker Impedance 8 Ω Product specifications shown above may be changed without prior notice due to upgrade of product functions.
- Page 69 SPECIFICATIONS DTV Mode RGB (PC) supported mode HDMI/DVI Horizontal Vertical Resolution Component Resolution (DTV) Frequency(kHz) Frequency(Hz) 480i 31.469 70.8 640 x 350 576i 31.468 70.8 720 x 400 480p 31.469 59.94 640 x 480 576p 37.5 640 x 480 720p 37.879 60.317 800 x 600 1080i 46.875 800 x 600 1080p 49.725 74.55 832 x 624 48.363...
-
Page 70: Ir Codes
IR CODES IR CODES All models do not support the HDMI/USB function. Code (Hexa) Function Note Energy Saving ( R/C BUTTON R/C BUTTON (ON/OFF) POWER INPUT R/C BUTTON Monitor On R/C BUTTON Monitor Off R/C BUTTON MENU R/C BUTTON Up ( ) R/C BUTTON Down ( ) R/C BUTTON Left ( ) R/C BUTTON Right ( ) R/C BUTTON OK( ) R/C BUTTON R/C BUTTON BACK( EXIT R/C BUTTON R/C BUTTON R/C BUTTON Volume... -
Page 71: Controlling The Multiple Product
CONTROLLING THE MULTIPLE PRODUCT CONTROLLING THE MULTIPLE PRODUCT Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 99 without being duplicated. Connecting the cable Connect the RS-232C cable as shown in the picture. The RS-232C protocol is used for communication between the PC and product. You can turn the product on/off, select an input source or adjust the OSD menu from your PC. RS-232C Cable (not included) Monitor 1 Monitor 2 Monitor 3 Monitor 4 RS-232C Configurations 7-Wire Configurations (Standard RS-232C cable) 3-Wire Configurations (Not Standard) D-Sub 9 D-Sub 9 D-Sub 9 D-Sub 9 (Female) (Female) (Female) (Female) NOTE When using 3-wire connections (non-standard), an IR daisy chain cannot be used. -
Page 72: Command Reference List
CONTROLLING THE MULTIPLE PRODUCT Command reference list COMMAND DATA (Hexadecimal) 01. Power 00H to 01H 02. Input Select Refer to ‘02. Input Select’ 03. Aspect Ratio Refer to ‘03. Aspect Ratio’ 04. Energy Saving Refer to ‘04. Energy Saving’ 05. Picture mode 00H to 04H 06. Contrast 00H to 64H 07. Brightness 00H to 64H 08. Sharpness 00H to 64H 09. Color 00H to 64H 10. Tint 00H to 64H 11. Color Temperature 00H to 64H 12. H Position 00H to 64H 13. V Position 23H to 41H 14. H Size 00H to 64H 15. Auto configuration 16. Balance 00H to 64H 17. Sound mode 01H to 05H... - Page 73 CONTROLLING THE MULTIPLE PRODUCT COMMAND DATA (Hexadecimal) 39. Tile ID Refer to ‘39. Tile ID’ 40. Tile H Position 00H to 64H 41. Tile V Position 23H to 41H 42. Tile H Size 00H to 32H 43. Tile V Size 00H to 32H 44. Natural Mode (In Tile mode) 00H to 01H 45. DPM Select 00H to 01H 46. Remote Lock/ key Lock 00H to 01H 47. Key Refer to ‘47. Key’ 48. OSD Select 00H to 01H 49. Elapsed time return 50. Serial No. Check 51. S/W Version Note : During USB operations such as Dvix or EMF, all commands except Power(ka) and Key(mc) are not executed and treated as NG.
-
Page 74: Transmission / Receiving Protocol
CONTROLLING THE MULTIPLE PRODUCT Transmission / Receiving protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] or [Command1][Command2][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] * [Command1]: First command to control the set. * [Command2]: Second command to control the set. * [Set ID]: S et ID with which you want to communicate. Etner [Set ID] = ‘00(0x00’ to communicate with all sets regardless of their Set ID numbers. * [Data]: Information passed to the set. * [Data1]: Information passed to the set. * [Data2]: Information passed to the set. * [Data3]: Information passed to the set. * [Cr]: Carriage Return. ASCII code ‘0x0D’. * [ ]: ASCII code space ‘0x20’ Acknowledgement [Command2][ ][Set ID][ ][OK/NG][Data][x] or [Command2][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x] * In a like manner, if other functions transmit ‘FF’ data based on this format, Acknowledgement data feedback presents status about each function. * Note: In this mode, display will send the acknowledgement after power on processing completion. There might be a time delay between command and acknowledgement. * Refer to ‘Real data mapping’ for hexadecimal data to decimal data. * No acknowledgement signal will be sent from display, if Set ID in transmission signal is set to ‘00’(=0x00). - Page 75 CONTROLLING THE MULTIPLE PRODUCT 01. Power (Command: k a) 04. Energy Saving (Command: j q) To control power On/Off the display. To control the energy saving function. Transmission Transmission [k][a][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Data 00 : Power Off Data 00: Off 01 : Power On 01: Minimum FF : Check status 02: Medium 03. Maximum Acknowledgement 05. Screen Off [a][ ][Set ID][ ][OK/NG][Data][x] * I n a like manner, if other functions transmit ‘FF’ Acknowledgement data based on this format, Acknowledgement data [q][ ][Set ID][ ][OK/NG][Data][x] feedback presents status about each function. * N ote: In this modes, display will send the acknowledgement after power on processing completion. There might be a time delay between command and acknowledgement.
- Page 76 CONTROLLING THE MULTIPLE PRODUCT 07. Brightness (Command: k h) 10. Tint (Command: k j) (Video Timing only) To adjust screen brightness. To adjust screen tint. Transmission Transmission [k][h][ ][Set ID][ ][Data][Cr] [k][j][ ][Set ID][ ][Data][Cr] Data 00 to 64: Brightness 0 to 100 Data 00 to 64: Tint 0 to 100(R50 to G50) Acknowledgement Acknowledgement...
- Page 77 CONTROLLING THE MULTIPLE PRODUCT 13. V Position (Command: f r) 16. Balance (Command: k t) To set the Vertical position. To adjust balance. * Only available for Tile Off mode. Transmission Transmission [k][t][ ][Set ID][ ][Data][Cr] [f][r][ ][Set ID][ ][Data][Cr] Data 00 to 64: Left 50 to Right 50 Data 00 to 64: Bottom Min.
- Page 78 CONTROLLING THE MULTIPLE PRODUCT 19. Bass (Command: k s) 22. Volume Control (Command: k f) To adjust bass. To adjust volume. Transmission Transmission [k][s][ ][Set ID][ ][Data][Cr] [k][f][ ][Set ID][ ][Data][Cr] Data 00 to 64: Bass 0 to 100 Data 00 to 64: Volume 0 to 100 Acknowledgement Acknowledgement [f][ ][Set ID][ ][OK/NG][Data][x] [s][ ][Set ID][ ][OK/NG][Data][x] 23. Time 1(Year/ Month/ Day) (Command: f a) 20. Speaker (Command: d v) To set the Time 1(Year/ Month/ Day) values.
- Page 79 CONTROLLING THE MULTIPLE PRODUCT 25. Off Timer(Repeat Mode/ Time) (Command: f e) 27. On Timer Input (Command: f u) To set the Off Timer(Repeat mode/ Time) function. To set the On Timer Input function. Transmission Transmission [f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [f][u][ ][Set ID][ ][Data][Cr] Data1 00: Repeat Off Data 20: AV 01: Repeat Once 40: Component 02. Repeat Daily 60. RGB 03: Repeat from Monday to Friday 90: HDMI 04: Repeat from Monday to Saturday 70: DVI 05: Repeat from Saturday to Sunday C0: DISPLAY PORT 06. Repeat on Sunday * Check if Time1 and Time2 and On Timer(Repeat Data2 01 to 17: 00 to 23 Hours Mode/Time) functions have been set before setting Data3 01 to 3B: 00 to 59 Minutes this function.
- Page 80 CONTROLLING THE MULTIPLE PRODUCT 30. 4 Hours Off (Command: m n) 33. Power Indicator(Standby Light) (Command: f o) To set the 4 Hours Off function. To set the Power Indicator(Standby Light) function. Transmission Transmission [m][n][ ][Set ID][ ][Data][Cr] [f][o][ ][Set ID][ ][Data][Cr] Data 00: 4 Hours Off Off Data 00: Standby Light Off 01: 4 Hours Off On 01: Standby Light On Acknowledgement Acknowledgement [n][ ][Set ID][ ][OK/NG][Data][x] [o][ ][Set ID][ ][OK/NG][Data][x] 31. Auto Off (Command: f g) To set the Auto Off function.
- Page 81 CONTROLLING THE MULTIPLE PRODUCT 36. Reset (Command: f k) 39. Tile ID (Command: d i) To execute the Picture, Screen, Audio and Factory To set Tile ID. reset function. Transmission Transmission [d][i][ ][Set ID][ ][Data][x] [f][k][ ][Set ID][ ][Data][Cr] Data 01 to E1: Tile ID 01 to 225** Data 00: Picture Reset FF: Read Tile ID 01: Screen Reset ** Data could not be set over (Tile Row) x (Tile 02: Audio Reset Column) 03: Factory Reset Acknowledgement [i][ ][Set ID][ ][OK/NG][Data][x] Acknowledgement [k][ ][Set ID][ ][OK/NG][Data][x] *NG will be return if data is over (Tile Row) x (Tile Column), except 0xFF. 37. Tile Mode (Command: d d) To select a Tile Mode Off/ On and Tile Row/ Column size.
- Page 82 CONTROLLING THE MULTIPLE PRODUCT 42. Tile H Size (Command: d g) 45. DPM Select (Command: f j) To set the Tile Horizontal Size. To set the DPM (Display Power Management) *Set Tile H Position to 0x32 (50) before setting Tile H function. Size. Transmission *Only available when Tile Natural Mode is off. [f][j][ ][Set ID][ ][Data][x] Transmission Data 00: DPM Select Off [d][g][ ][Set ID][ ][Data][x] 01: DPM Select On Data 00 to 32: 0 to 50 Acknowledgement Acknowledgement [j][ ][Set ID][ ][OK/NG][Data][x] [g][ ][Set ID][ ][OK/NG][Data][x] 46. Remote Controller Lock/ Key Lock (Command: k m) To lock the remote control and the front panel control keys on the display.
- Page 83 CONTROLLING THE MULTIPLE PRODUCT 48. OSD Select (Command: k l) 51. S/W Version (Command: f z) To select OSD(On Screen Display) on/off To read the software version. Transmission Transmission [k][l][ ][Set ID][ ][Data][Cr] [f][z][ ][Set ID][ ][Data][Cr] Data 00: OSD Off Data FF: Data should be always ff in hexadecimal. 01: OSD On Acknowledgement Acknowledgement [z][ ][Set ID][ ][OK/NG][Data][x] [l][ ][Set ID][ ][OK/NG][Data][x] 49. Elapsed time return (Command: d l) To read the panel used time. Transmission [d][l][ ][Set ID][ ][Data][x] Data FF: Data should be always ff in hexadecimal.
- Page 84 ENERGY STAR(EPA) can not be supported in 47VX30AF model. ENERGY STAR(EPA) support 42/47/55VS20 42VX30MS 47VX30AS 47VX30AF Make sure to read the Safety Precautions E N E RGY STA R i s a s et of p owe r- before using the product.
