CHAPTER 3. DISASSEMBLY AND REASSEMBLY
[1] Servicing Concerns . . . . . . . . . . . . . . . . . . 3-1
Parts marked with "!" are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
CONFIDENTIAL
SERVICE MANUAL
DIGITAL MOBILE PHONE
CONTENTS
CHAPTER 5. CIRCUIT DIAGRAM
[4] Schematic diagram/
Parts Guide
SHARP CORPORATION
DRAFT
CODE : 00ZTM150/SM/E
TM150
MODEL
(INTERNAL MODEL NAME: TM150U)
• In the interests of user-safety the set should be restored
to its original condition and only parts identical to those
specified should be used.
Caution:
Risk of explosion if battery is replaced by an incorrect type,
dispose of used batteries according to the instruction.
Wiring side of P.W.Board . . . . . . . . . . . . . . . . . 5-5
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
