SERVICE MANUAL
Ver 1.2 2000.07
The MZ-E70 (Hong Kong) model is approximately the same as MZ-E55 (Hong Kong) model.
Consequently, only difference between MZ-E55 (Hong Kong) model and MZ-E70 (Hong Kong)
model are listed.
For other information, please refer to the MZ-E55 service manual (9-924-958-12) previously issued.
MICROFILM
MZ-E70
Hong Kong Model
PORTABLE MINIDISC PLAYER
Advertisement
Related Manuals for Sony MZ-E70
Summary of Contents for Sony MZ-E70
- Page 1 SERVICE MANUAL Hong Kong Model Ver 1.2 2000.07 The MZ-E70 (Hong Kong) model is approximately the same as MZ-E55 (Hong Kong) model. Consequently, only difference between MZ-E55 (Hong Kong) model and MZ-E70 (Hong Kong) model are listed. For other information, please refer to the MZ-E55 service manual (9-924-958-12) previously issued.
- Page 2 Ver 1.2 2000.07 EXPLODED VIEWS (Service Manual See page 29) : Different portion MAIN SECTION 16 17 – 2 –...
-
Page 3: Exploded Views
Ver 1.2 2000.07 DIFFERENCE PARTS LIST EXPLODED VIEWS (Service Manual See page 29) MAIN SECTION MZ-E55 : Hong Kong Model MZ-E70 : Hong Kong Model Ref. No Part No. Description Part No. Description 4-212-867-01 PANEL, BOTTOM (GOLD) X-4951-611-1 PANEL, BOTTOM (YELLOW) - Page 4 MZ-E70 Sony Corporation 99C0211-1D Printed in Japan © 1999.3 9-926-956-11 Personal A&V Products Company Published by Quality Engineering Dept. – 4 – (Shinagawa)
