Summary of Contents for Philips CEM2220BT/12
- Page 1 Always there to help you Register your product and get support at www.philips.com/welcome CEM2220BT/12 Question? Contact Philips User manual Mode d’emploi Benutzerhandbuch Manuale utente Manual del usuario Gebruiksaanwijzing...
-
Page 2: Table Of Contents
Contents 1 Important 7 Use Bluetooth devices Safety Connect a device Notice Play audio from a Bluetooth device Make a call 2 Your car audio system 8 Connect external sound source Introduction What's in the box Overview of the main unit 9 Adjust sound 3 Install the car audio 10 Adjust system settings... -
Page 3: Important
Any changes or modifications made to this caused by failure to follow instructions, the device that are not expressly approved by warranty does not apply. Philips Consumer Lifestyle may void the user’s • This apparatus is designed for negative authority to operate the equipment. - Page 4 Microsoft Corporation in the United States and/or other countries. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Philips is under license. This apparatus includes this label:...
-
Page 5: Your Car Audio System
Main unit (with a sleeve) Congratulations on your purchase, and b Front panel welcome to Philips! To fully benefit from the c Trim plate support that Philips offers, register your product at www.philips.com/welcome. d Carrying case for front panel... -
Page 6: Overview Of The Main Unit
Overview of the main unit • Turn the unit on or off. • Tune for radio station. • Confirm selection. • Skip/search for track. • Mute or unmute sound. • Fast backward/forward playback. • Rotate to adjust volume. e ZONE •... - Page 7 n SOURCE/DISPLAY • Eject disc. • Press repeatedly to select source. • Display current status. • Press and hold to select the dimmer • USB socket. high or low. h AUDIO IN • Connect external audio device. • Press repeatedly to select a preset equalizer (EQ).
-
Page 8: Install The Car Audio
If you have any questions regarding installation kits, consult • Consult a professional to connect CEM2220BT as your Philips car audio dealer. instructed below. Caution Check the car's wiring carefully and connect them to the the supplied male •... -
Page 9: Mount Into The Dashboard
ISO male Connect to connectors • The pin arrangement for the ISO connectors depends Ignition key +12V DC on the type of vehicle you drive. Be sure to make when ON/ACC proper connections to prevent damage to the unit. Blue Motor/electric antenna relay control lead Mount into the dashboard... -
Page 10: Attach The Front Panel
Install the sleeve into the dashboard and Slide the unit into the dashboard until you bend the tabs outward to fix the sleeve. hear a click sound. Note • If the unit is not fixed by sleeve but by the supplied screws, skip this step. -
Page 11: Get Started
Always follow the instructions in this chapter in sequence. Pull the front panel outwards to remove it. If you contact Philips, you will be asked for the model and serial number of your apparatus. The model number and serial number are on the bottom of your apparatus. -
Page 12: Set The Time Format
Set the time format Switch music listening zone Press and hold MENU. Philips’ innovative Zone technology enables driver or passengers to enjoy music with the repeatedly until [CLOCK Press best speakers balance and experience more FORMAT] is displayed. vivid spacial effect as the artist is intended to create. -
Page 13: Listen To Radio
5 Listen to radio Select tuner sensitivity To receive more radio stations or only stations with strong signal, you can adjust the tuner sensitivity. Press and hold MENU. Tune to a radio station Press repeatedly until [LOCAL] is displayed. Press SOURCE repeatedly to select radio mode. -
Page 14: Play With Rds
CULTURE Culture, religion and Play with RDS society SCIENCE Science The RDS (Radio Data System) function VARIED Entertainment programs operates only in areas with FM stations POP M Pop music broadcasting RDS signals. If you tune to an RDS station, the station name are displayed. ROCK M Rock music EASY M... - Page 15 Set region for AF tuning Set RDS clock You can define AF tuning region: You can use time signal that is broadcast [REG Only stations in current region can together with the RDS signal to set the clock of be tuned to automatically. the unit automatically.
-
Page 16: Play From Hard Media
6 Play from hard Play from USB media Note • Ensure that the USB device contains playable music. You can use this system to listen to audios that are stored on a compatible disc or USB storage Insert the USB device device. -
Page 17: Switch Tracks
• [SHUF ALL]: start random play for Note all tracks. • Philips does not guarantee the compatibility with all • [SHUF OFF]: cancel shuffle play. Bluetooth devices. • Before pairing a device with this system, read its user manual for Bluetooth compatibility. -
Page 18: Play Audio From A Bluetooth Device
» If the connection fails, [FAILED] is displayed on the LCD screen of this • system. You can also complete the reconnection on your device. Disconnect a device Press and hold MENU to access the Play audio from a Bluetooth system menu. -
Page 19: Connect External Sound Source
8 Connect Redial the last called number external sound Press . » [REDIAL] is displayed. source Press . again to confirm. » [CALLING] is displayed. Connect the external sound source to Pick up an incoming call AUDIO IN socket with a 3.5 mm cable. When the system receives an incoming call, the Press SOURCE repeatedly until [AUDIO phone number or [PHONE IN] is displayed. -
Page 20: Adjust Sound
9 Adjust sound The following operations are applicable to all supported media. Button Function Rotate to increase or decrease the volume level. Press to mute or restore sound. Press to enable or disable the maximum sound feature. DBB/AS Press to enable or disable the Dynamic Bass Boost (DBB) effect. Press again to select a preset EQ setting: [OPTIMAL] (optimal) -
Page 21: Adjust System Settings
10 Adjust system settings Press MENU to access system settings. Press repeatedly until one of the following settings scrolls. • [BEEP TONE], [DIMMER], [DEMO], [BLACK OUT], or [DANCE] Rotate to change the setting. [BEEP TONE] [BEEP ON] Enable the beep sound of buttons. [BEEP OFF] Disable the beep sound of buttons. -
Page 22: Additional Information
• If the new fuse gets damaged again, there may be an internal malfunction. Consult your Philips dealer. Replace fuse If there is no power, check the fuse and replace if it is damaged. -
Page 23: Product Information
12 Product information Note • Product information is subject to change without prior notice. Power supply 12 V DC (11 V - 16 V), negative ground Fuse 15 A Suitable speaker impedance 4 - 8 Maximum power output 50 W x 4 Continuous power output 21 W x 4 RMS (4 10% T.H.D.) -
Page 24: Troubleshooting
MP3/ requesting service. If the problem remains WMA files, and is not be shown in the unsolved, go to the Philips web site (www. display. philips.com/support). When you contact Philips, •... -
Page 25: About The Bluetooth Device
• The paired mobile phone connects and Ensure that the CD is not encoded with copyright protection technologies. disconnects constantly. • The Bluetooth reception is poor. Move The CD skips tracks the mobile phone closer to the system or • Ensure that the CD is not damaged or remove any obstacle between the mobile dirty. -
Page 26: Glossary
14 Glossary A file format with a sound data compression system. MP3 is the abbreviation of Motion Picture Experts Group 1 (or MPEG-1) Audio Layer 3. With the MP3 format, one CD-R or CD-RW can contain about 10 times more data than a regular CD. - Page 27 Specifications are subject to change without notice © 2013 Koninklijke Philips Electronics N.V. All rights reserved. CEM2220BT_12_UM_V1.0...
