BDL3220QL Safety Instructions TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Warnings and Precautions The Socket-outlet should be installed near the apparatus and be easily KNOW THESE SAFETY SYMBOLS accessible.
BDL3220QL Important Safety Instructions CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric 1. Read these instructions. shock,do not perform any servicing other than that contained in the operating instructions unless you are 2.
BDL3220QL Regulatory Information Federal Communications Commission (FCC) Notice (U.S. Only) CE Declaration of Conformity This equipment has been tested and found to comply We declare under our responsibility that the product is in conformity with the limits for a Class B digital device, pursuant to with the following standards: Part 15 of the FCC Rules.
Page 5
BDL3220QL Polish Center for Testing and Certification Information for U.K. only Notice WARNING – THIS APPLIANCE MUST BE EARTHED. The equipment should draw power from a socket with an attached Important: protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source.
Page 7
VARNING: Please find out about the local regulations on how to dispose of your FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG old display from your local Philips dealer. ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.
BDL3220QL Unpacking and Installation 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • Due to the size and weight of this display it is recommended for two people to move it.
BDL3220QL 1.4. Mounting on a Wall To mount this display to a wall, you will have to obtain a standard wall-mounting kit. We recommend using a mounting interface that complies with UL1678 standard in North America. Protective Sheet Table 1. Lay a protective sheet on a table, which was wrapped around the display when it was packaged, beneath the screen surface so as not to scratch the screen face.
BDL3220QL Parts and Functions 2.1. Control Panel ] button Remote control sensor and power status indicator Press to switch the display on or off. • Receives command signals from the remote control. - Lights green when this display is turned on...
BDL3220QL 2.2. Input/Output Terminals AC IN SPDIF OUT AC power input. Digital audio signal output to connect your external AV device. MAIN POWER SWITCH IR OUT / IR IN (3.5 mm) Main power on/off switch. IR signal output/input for the loop-through function.
BDL3220QL 2.3. Remote Control button Confirm an entry or selection. 2.3.1. General functions ADJUST button Access currently available options, picture and sound menus. BACK button Return to the previous menu page or exit from the previous function. VOLUME button Adjust volume.
BDL3220QL 2.3.2. Inserting batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace batteries: 1. Press and then slide the cover to open it. 2. Align the batteries according to the (+) and (–) indications inside the battery compartment.
BDL3220QL Connection NOTE: The peripherals and cables shown are for example purposes only. 3.1. Connecting External Equipments AUDIO IN STEREO AMPLIFIER COMPONENT OUT (YPbPr) AUDIO OUT DVD / VCR / VCD HDMI OUT AC IN HDMI IN DVI IN RJ-45...
BDL3220QL 3.4. Wire-connecting to Network (optional) If you connect this display to a home network, you can play photos, music and videos from your computer. See Play multimedia files (Page 10) for more detail. INTERNET ROUTER [RJ-45] [RJ-45] To setup the network: 1.
BDL3220QL Operation • {Game}: Ideal settings for games. • {News}: Ideal settings for spoken audio, such as the news. NOTE: The control button described in this section is mainly on the remote control unless specified otherwise. 4.5. Play Multimedia Files You can play videos, photos, and music on your display from: 4.1.
BDL3220QL 4.5.2. Play multimedia files from USB device • Do not overload the USB port. If you connect a USB storage device that consumes more than 500mA power, make sure that it is This display can play music, movie, or photo files from your USB device.
BDL3220QL 4.6.2. Playing movie files 4.6.3. Playing photo files 1. Select Movie 1. Select Photo in the top bar. in the top bar. 2. Select a video, then press button. 2. Select a photo thumbnail, then press button. The Movie...
BDL3220QL Change your settings Using this display’s control buttons: Using the remote control: 1. Press button to display the OSD menu. 1. Press button to display the OSD menu. 2. Press[ ] [ ] or [ ] button to select menu item or adjust its 2.
BDL3220QL 5.2.2. Sound menu Backlight contrast Adjust the brightness of this display’s backlight. Colour Picture Sound style Adjust the colour saturation of the picture. Sound Restore style General settings Bass Sharpness Treble Adjust the sharpness of the picture. Surround mode...
BDL3220QL 5.2.3. General settings menu {Lock but volume}: Disable all the button function except the • button. • {Lock but power}: Disable all the button function except the Picture Menu language button. Sound Monitor id NOTE: To disable the lock function from [Local KB lock] or [RC...
BDL3220QL Input mode PC Resolution: Active Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Stand for Mode Resolution H Pixels V Lines 60 Hz 25.175 MHz 72 Hz 31.5 MHz Video Graphic Array 75 Hz 31.5 MHz WVGA 70 Hz 33.75 MHz...
However, pixel or sub-pixel defects on the PDP / TFT panels used in Plasma- & LCD- displays are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any Plasma- & LCD- displays with an unacceptable number of defects will be repaired during the warranty period in line with your local guarantee conditions.
Pixel Defect Tolerances In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a Philips Plasma / LCD- display must have pixel or sub- pixel defects exceeding the tolerances listed in the following table.
BDL3220QL Cleaning and Troubleshooting 8.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.
BDL3220QL 8.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on the back of the 2. Make sure the power switch is switched on.
