  • Page 1: Washing Machine

    WA5471AB* Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register WA5471ABP-03050B_EN.indd 1 WA5471ABP-03050B_EN.indd 1 2012-01-12...
  • Page 2 ® 1. VRT (Vibration Reduction Technology) The Samsung washer performs smoothly at top spin speeds helping to minimize noise and vibration. 2. The large Capacity Even bulky garments and blankets get super clean. The large capacity leaves enough room for a thorough, cleane wash.

  • Page 3: Safety Information

    Congratulations on your new Samsung Washer. This manual contains important information on the installation, use, and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many benefits and features.
  • Page 4 safety information Do not let children (or pets) play on or in your washing machine. The washing machine door does not open easily from the inside, and children may be seriously injured if trapped inside. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been WARNING given supervision or instruction concerning use of the appliance by a person responsible for...
  • Page 5 CRITICAL INSTALLATION WARNINGS WARNING Plug the power cord into an AC 220~240V/50Hz wall socket rated at 15 amps or higher. Use the socket for this appliance only. In addition, do not use an extension cord. - Sharing a wall socket with other appliances, using a power strip, or extending the power cord may result in electric shock or fire.
  • Page 6 safety information INSTALLATION CAUTIONS CAUTION Position the appliance so that the power plug is easily accessible. - Failing to do so may result in electric shock or fire due to electric leakage. Install your appliance on a level and hard floor that can support its weight. - Failing to do so may result in abnormal vibrations, noise, or problems with the product.
  • Page 7 The use for business purposes qualifies as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 8 safety information Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in electric shock, fire, problems with the product, or injury. Do not operate the appliance with wet hands.
  • Page 9 Do not use natural hand-washing soap for the washer. - If it hardens and accumulates inside the washer, it may cause problems with the product, discoloration, rust, or bad odors. Do not wash large laundry items such as bedding in the washing net. - Failing to do so may result in injury due to abnormal vibrations.

  • Page 10: Table Of Contents

    contents INSTALLING YOUR WASHER Unpacking your washer Overview of your washer Electrical Grounding Water Drain facility Flooring Location considerations Alcove or closet installation Required Dimensions for Installation Important note to installer Environment OPERATING INSTRUCTIONS Loading your washer Getting started WASHING A LOAD OF LAUNDRY Overview of the control panel Child Lock Spin Only Adjustment...

  • Page 11: Installing Your Washer

    Unpack your Washer and inspect it for shipping damage. Make sure you have received all the items shown below. If your Washer was damaged during shipping, or you do not have all of the items, contact Samsung Customer Service or your Samsung dealer.

  • Page 12: Electrical Grounding

    installing your washer BASIC LOCATION REQUIREMENTS Electrical • 220~240V / 50Hz fuse or circuit breaker • Individual branch circuit serving only your Washer is recommended. • Your Washer is equipped with a power cord. NEVER USE AN EXTENSION CORD. CAUTION Grounding ELECTRICAL GROUNDING IS REQUIRED FOR THIS APPLIANCE.

  • Page 13: Drain Facility

    Drain facility The recommended height of the standpipe is 39 in/ 99 cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached to the washer at the factory. Flooring For best performance, you must install your washer on a solidly constructed floor.

  • Page 14: Required Dimensions For Installation

    installing your washer Required Dimensions for Installation 28.6in. (72.8 cm) 44.6in. (113.5 cm) 38.4in. (97.6 cm) 44.6in. (113.5 cm) 27in. 27.1in. (68.6 cm) (69.0 cm) 3in. (7.6 cm) 48in.² * (310 cm²) 57.5in. (146.2 cm) 24in.² * (155 cm²) 3in. (7.6 cm) Closet or Door * Required spacing...

  • Page 15: Important Note To Installer

    IMPORTANT NOTE TO INSTALLER Please read the following instructions carefully before installing your Washer. These instructions should be retained for future reference. We recommend you hire a professional to install this washer. STEP 1 Selecting a Location Before you install your washer, make sure the location: •...

  • Page 16: Environment

    installing your washer 2. Check the inlet hoses to ensure a washer is inside the Cold coupling of each fill hose. Thread the inlet hoses onto the HOT and COLD faucet connections. On the other end of the hose, check for one rubber washer per hose and attach each fill hose to the water valve.

  • Page 17: Operating Instructions

    operating instructions LOADING YOUR WASHER • You can fill the tub with dry, unfolded clothes, but DO NOT OVERLOAD the tub, No more than 3/4 full. • Overloading may reduce washing efficiency, cause excess wear, and possibly cause creasing or wrinkling of the load.

  • Page 18: Washing A Load Of Laundry

    washing a load of laundry OVERVIEW OF THE CONTROL PANEL Provides instructions and diagnostics while keeping you updated on the cycle Display status and time remaining. Press these buttons to select different cycle options. Eco Tub Clean - Use to clean dirt and bacteria from the drum. Regular use (after every 21 washes) is recommended.
  • Page 19 Active Wear - Use this cycle to wash exercise wear such as sports jerseys, training pants, shirts/tops and other performance clothing. This cycle provides effective soil removal with gentle action for special fabric care. Delicates/Hand Wash - For sheer fabrics, bras, lingerie, silks, and other handwash-only fabrics.

  • Page 20: Child Lock

    washing a load of laundry Child Lock Child Lock prevents children from playing with your washer. Activating the Child Lock function Press and hold the Spin and Soil Level buttons simultaneously for approximately 3 seconds. • When you activate the Child Lock function, the “Child Lock [ ]”...

  • Page 21: Spin Only Adjustment

    Spin Only Adjustment If you press the Power button, and then press and hold the Spin button for 2 seconds, the spin time is displayed on the display panel. You can then change the spin level independently of any other setting by pressing the Spin button repeatedly until the spin level you want (High, Medium, etc.) is selected on the control panel.

  • Page 22: Washing Clothes Using The Cycle Selector

    Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed.

  • Page 23: Which Detergent To Use

    WHICH DETERGENT TO USE The type of detergent you should use is based on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash temperature, and degree of soiling. Always use “low suds” laundry detergent, which is designed for automatic washing machines. Follow the detergent manufacturer’s recommendations based on the weight of the laundry, the degree of soiling, and the hardness of the water in your area.

  • Page 24: Bleach/Fabric Softener Compartments

    washing a load of laundry Loading the Liquid detergent compartment Liquid detergent compartment 1. Pour the recommended amount of laundry detergent directly into the detergent compartment before starting your Washer. 2. If you are using color-safe bleach, add it with the detergent to the detergent compartment.

  • Page 25: Maintaining Your Washer

    maintaining your washer CLEANING THE EXTERIOR Turn off the water faucets after finishing the day’s washing. This will shut off the water supply to your Washer and prevent the unlikely possibility of damage from escaping water. Leave the door open to allow the inside of your Washer to dry out. Use a soft cloth to wipe up all detergent, bleach or other spills as they occur.

  • Page 26: Cleaning The Dispensers

    maintaining your washer CLEANING THE DISPENSERS The automatic dispenser may need to be cleaned periodically due to laundry additive buildup. 1. Pull the dispenser drawer straight back until it stops. 2. Tilt the dispenser drawer upward and remove it. 3. Remove the inserts from the 2 compartments. Rinse the inserts and the drawer with warm water to remove traces of accumulated laundry products.

  • Page 27: Eco Tub Clean

    ECO TUB CLEAN Eco Tub Clean is a self-cleaning cycle that removes mold that may occur inside the washing machine. 1. Press the Power button. 2. Press the Eco Tub Clean button. • Once the Eco Tub Clean button is pressed, the only function that can be set is Delay Start.

  • Page 28: Troubleshooting

    troubleshooting CHECK THESE SOLUTIONS IF YOUR WASHER… PROBLEM SOLUTION Will not start. • Make sure the door is closed. • Make sure your Washer is plugged in. • Make sure the water source faucets are open. • Make sure to press the Start/Pause Button to start your Washer. •...
  • Page 29 PROBLEM SOLUTION Fills with the wrong • Turn both faucets on fully. temperature water. • Make sure the temperature selection is correct. • Make sure the hoses are connected to the correct faucets. Flush water lines. • Disconnect the hoses and clean the screens. The hose filter screens may be plugged.

  • Page 30: Information Codes

    troubleshooting INFORMATION CODES The Washer may display information codes to help you understand what is occurring with your Washer better. CODE SYMBOL MEANING SOLUTION Unbalanced load prevented your Redistribute the load, press the Start/Pause Washer from spinning. Button. Door is open when Washer is Close the door tightly and restart the cycle.
  • Page 31 Then, the unit will go back into operation. When it finishes washing, End and the SUdS code will blink in turn. For any codes not listed above, call contact Samsung Customer Service or your Samsung dealer. troubleshooting _31 WA5471ABP-03050B_EN.indd Sec10:31 WA5471ABP-03050B_EN.indd Sec10:31...

  • Page 32: Appendix

    appendix FABRIC CARE CHART The following symbols provide garment care direction. The Clothing care labels include symbols for washing, bleaching, drying and ironing, or dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow care label directions to maximize garment life and reduce laundering problems.

  • Page 33: Cycle Chart

    CYCLE CHART Use this chart to set the best cycle and options for your laundry. WA5471* ( : factory setting, : selectable) Functions Temp Spin Soil Level Extra Warm Cold High Medium Heavy Normal Light Warm High Spin Cotton Heavy Duty Perm Press Water Saving Towels...

  • Page 34: Helping The Environment

    appendix HELPING THE ENVIRONMENT • Your Washer is manufactured from recyclable materials. If you decide to dispose of it, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance.
  • Page 35 memo appendix _35 WA5471ABP-03050B_EN.indd Sec4:35 WA5471ABP-03050B_EN.indd Sec4:35 2012-01-12 2012-01-12 5:24:22 5:24:22...
  • Page 36 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT AUSTRALIA 1300 362 603 www.samsung.com Code No. DC68-03050B_EN WA5471ABP-03050B_EN.indd Sec4:36 WA5471ABP-03050B_EN.indd Sec4:36 2012-01-12 2012-01-12 5:24:22 5:24:22...
