- Page 1 DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 1 ENGLISH DV387 P/No. : MFL57001875...
-
Page 2: Safety Precaution
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 2 CAUTION concerning the Power Cord Safety Precaution Most appliances recommend they be placed upon a dedicated circuit; That is, a single outlet circuit which powers only that appliance and has no additional CAUTION outlets or branch circuits. Check the specification page of this owner's manual to be RISK OF ELECTRIC SHOCK certain.Do not overload wall outlets. -
Page 3: Table Of Contents
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 3 About the Symbol Display Safety Precaution ........2 “... -
Page 4: Hooking Up The Unit
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 4 Hooking up the unit Hooking up the unit - more you can do Audio and Video Connection S-Video connection The unit Audio/Video jacks are color coded (yellow for video, red for right audio Connect the S-VIDEO OUTPUT jack on the unit to the corresponding input and white for left audio). -
Page 5: Remote Control
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 5 Remote Control OPEN/CLOSE POWER (1) Opens and closes the disc tray. Switches the unit ON or OFF. CLEAR Removes a track number on the Program SCAN (m / M) List. Search backward or forward. -
Page 6: Main Unit
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 6 Main Unit a 1/I (Power) g VOL. Turn the unit ON or OFF. Adjust microphone volume. b Disc Tray h USB Port Insert a disc here. Connect an USB Flash Drive. • N (Play) c Z (Open / Close) Starts playback. -
Page 7: Adjust The Settings
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 7 Display Mode – If you selected 4:3, you’ll need to define how you would like Adjust the settings widescreen programs and films to be displayed on your TV screen. [Letterbox]: This displays a widescreen picture with black bands at the top ON REMOTE and bottom of the screen. -
Page 8: Displaying Disc Information
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 8 Adjust the lock settings Displaying Disc Information You must set the [Area Code] option to use the lock options. Select [Area Code] option then press B. Enter a 4-digit password then press ENTER. Enter it again ON REMOTE then press ENTER to verify. -
Page 9: Playing A Disc
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 9 Pause a playback Playing a Disc Press PAUSE/STEP (X) to pause playback. Press PLAY ( ) to continue playback. ON REMOTE 1 Open the disc tray: OPEN/CLOSE Frame-by-Frame playback DivX 2 Insert a Disc: Press PAUSE/STEP (X) repeatedly to play Frame-by-Frame playback. -
Page 10: Playing A Divx Movie File
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 10 Watching a enlarged video image DivX Playing a DivX movie file During playback or pause mode, press ZOOM repeatedly to select zoom mode. You can move through the zoomed picture using vVb B buttons. -
Page 11: Listening To Music Disc Or Files
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 11 • File extensions: “.mp3”, “.wma” Listening to Music Disc or files • Sampling frequency: within 8 - 48 kHz (MP3), within 32 - 48kHz (WMA) • Bit rate: within 8 - 320kbps (MP3), within 32 - 192kbps (WMA) ON REMOTE •... -
Page 12: Using The Karaoke
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 12 Watching a enlarged photo image KEY – You can change the key. EFFECT – You can use Special Effects. While viewing a photo in full screen, press ZOOM repeatedly to select zoom (Off → HARMONY → FLANGE → CHORUS) mode. -
Page 13: Language Codes
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 13 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar... -
Page 14: Troubleshooting
DV387-P.BLKALLK_1875_ENG 7/1/08 3:33 PM Page 14 Specifications Troubleshooting General Cause Symptom Correction Power requirements AC 200-240V, 50/60 Hz No power. The power cord is disconnected. Plug the power cord into the wall Power consumption outlet securely. Dimensions (Approx.) 430 x 35 x 200 mm...
