- Page 1 Operating and installation instructions Refrigerator with Dynamic cooling K 14820 SD K 14820 SD ed/cs en - GB To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time.
-
Page 2: Table Of Contents
Contents Guide to the appliance ..........3 Caring for the environment . - Page 3 Contents Adjusting the interior fittings ........24 Moving the shelves .
-
Page 4: Guide To The Appliance
Guide to the appliance a On/Off sensor f Temperature display b Dynamic cooling sensor g "Cooling" symbol c Super cool sensor h Sensor for setting a higher temperature (Y) d Sensor for setting a lower i Alarm off sensor temperature (X) (only visible when the door alarm e Safety lock indicator light sounds) - Page 5 Guide to the appliance a Dynamic cooling fan b Ceiling lighting c Butter and cheese compartment d Egg tray/Condiment tray e Universal container f Adjustable shelves g Active charcoal filter holder h Bottle rack i Condensate channel and drain hole j Bottle divider k Bottle shelf l Fruit and vegetable containers...
-
Page 6: Caring For The Environment
Caring for the environment Disposal of the packing Disposal of your old appliance material Electrical and electronic appliances often contain materials which, if The transport and protective packing handled or disposed of incorrectly, has been selected from materials which could be potentially hazardous to are environmentally friendly for human health and to the environment. -
Page 7: Warning And Safety Instructions
It must only be used as a domestic appliance to cool and store food. Any other usage is not supported by the manufacturer and could be dangerous. Miele cannot be held liable for damage resulting from incorrect or... -
Page 8: Technical Safety
Warning and Safety instructions Technical safety - disconnect from the mains, - air the room in which the appliance is Before setting up the appliance, located for several minutes and check it for any externally visible - contact the Service Department for damage. - Page 9 Faulty components must only be national and local safety regulations. Repairs and other work by unqualified replaced by genuine Miele original persons could be dangerous. The spare parts. The manufacturer can only guarantee the safety of the appliance manufacturer cannot be held liable for unauthorised work.
- Page 10 Warning and Safety instructions Correct use Do not use defrosting sprays or de-icers, as they might contain Never store explosive materials in substances which could damage the the appliance or any products plastic parts or which could cause a containing propellants (e.g. spray build-up of gases and pose a danger to cans).
-
Page 11: Disposal Of Your Old Appliance
Warning and Safety instructions Stainless steel appliances Do not use sticky notes, transparent adhesive tape, masking tape or other types of adhesive on the surface of the door. These damage the surface, causing it to lose its dirt repellent protective coating. -
Page 12: How To Save Energy
How to save energy Normal energy Increased energy consumption consumption Installation site In a ventilated room. In an enclosed, unventilated room. Protected from direct sunlight. In direct sunlight. Not near to a heat source (radiator, Near to a heat source (radiator, oven). -
Page 13: Switching On And Off
Miele stainless steel conditioner supplied as soon as you have removed the foil. ^ On stainless steel appliances also treat the side panels with the Miele stainless steel conditioning agent supplied as soon as you have removed the protective foil. -
Page 14: Operating The Appliance
Switching on and off Operating the appliance Settings mode A light touch of the finger on the Certain settings on the appliance can sensors is all that is required to operate only be selected in the settings mode. this appliance. How to select the settings mode and how to change the settings is Switching on... -
Page 15: Switching The Sensor Tones On/Off
Switching on and off Switching the sensor tones on/off Activating or de-activating the safety lock The sensor tone which sounds each time a sensor is touched can be The safety lock can be activated to deactivated. prevent the appliance being switched off inadvertently. -
Page 16: Switching Off For Longer Periods Of Time
Switching on and off ^ Touch the On/Off sensor to confirm a Switching off for longer new setting. periods of time ^ Touch the X sensor repeatedly until c If the appliance is not going to be used appears in the display. for a longer period of time, e.g. -
Page 17: The Correct Temperature
The correct temperature Setting the temperature It is very important to set the correct temperature for storing food in the The temperature inside the appliance appliance. Micro-organisms will cause can be selected by touching the arrow food which is not stored at the correct sensors on either side of the temperature to deteriorate rapidly. -
Page 18: Temperature Range
The correct temperature If you have adjusted the temperature, wait for approx. 6 hours if the appliance is not very full and for approx. 24 hours if the appliance is ^ Touch and leave your finger on the X full before checking the temperature display, as it will take this long for the sensor. -
Page 19: Alarm
Alarm To switch off the door alarm Your appliance has been fitted with an alarm to avoid energy being wasted if whilst the door is still open the door is left open and to prevent If you want to keep the door open stored food becoming too warm. -
Page 20: Super Cool And Dynamic Cooling
Super cool and Dynamic cooling Dynamic cooling m Super cool The Super cool function can be used to When the Dynamic cooling function is rapidly reduce the temperature in the not switched on, the natural circulation refrigerator to its lowest setting of air in the appliance will cause (depending on the room temperature). - Page 21 Super cool and Dynamic cooling Switching off Dynamic cooling ^ Touch the Dynamic cooling sensor so that the yellow indicator is dimmed The fan automatically switches off when the door is open.
-
Page 22: Using The Refrigerator Efficiently
Using the refrigerator efficiently Different storage zones – pre-packed vegetables and other fresh food with a label stating it Due to the natural circulation of the air should be kept at a temperature of in the appliance, there are different approx. -
Page 23: Food Which Should Not Be Stored In A Refrigerator
Using the refrigerator efficiently Food which should not be Storing food correctly stored in a refrigerator Food should generally be stored covered or packaged. This will prevent Not all food is suitable for refrigeration, food smells from affecting other foods, as some food is sensitive to cold. -
Page 24: Unpacked Meat And Vegetables
Using the refrigerator efficiently – Examples of fruit and vegetables Meat which react strongly to the natural Meat should be stored unwrapped. gases given off by other types of (Undo wrappings slightly to leave meat fruit and vegetables are: loosely covered, and leave containers Kiwis, broccoli, cauliflower, brussels open). -
Page 25: Adjusting The Interior Fittings
Adjusting the interior fittings Moving the shelves To move the split shelf: ^ Take both halves of the split glass The shelves can be adjusted according to the height of the food. shelf out, ^ Raise the shelf, and pull it forwards slightly until the notch at the side is in line with the shelf support. -
Page 26: Adjusting The Condiment Tray/Bottle Shelf
Adjusting the interior fittings Fruit and vegetable containers Adjusting the condiment on telescopic runners tray/bottle shelf ^ Lift the tray/shelf up and out of the The fruit and vegetable containers are pushed in and out on telescopic stainless steel frame to remove. runners, and can be completely ^ Push up the stainless steel frame, removed if necessary. -
Page 27: Moving The Bottle Divider
Adjusting the interior fittings Universal container Moving the bottle divider The universal container can be used The bottle divider can be moved to the both to store and serve food. left or right to ensure that bottles are held securely in position when the door is opened and shut. -
Page 28: Automatic Defrost
Automatic defrost The refrigerator defrosts automatically. Condensate and frost can build up on the back wall of the refrigerator whilst it is in use. You do not need to remove this, as it will defrost and evaporate automatically with the warmth generated by the appliance. -
Page 29: Cleaning And Care
Cleaning and care A range of Miele branded cleaning Unlike stainless steel cleaning and conditioning products is agents, the conditioning agent does available to order from Miele or not contain any abrasive substances www.miele-shop.com. and will gently remove soiling. Each... -
Page 30: Cleaning The Interior And Accessories
Cleaning and care ^ The bottle shelf and condiment tray in Cleaning the interior and the door can be removed from their accessories stainless steel frames for cleaning. ^ Clean the appliance at least once a To remove the stainless steel trim from month using lukewarm water and a the lid of the butter and cheese little washing-up liquid. -
Page 31: Appliance Door, Side Panels
Stainless steel appliances surface. – Appliance door ^ It is important to treat the stainless steel frames and trim with Miele The appliance door has a high quality, special finish which is resistant to stainless steel conditioning agent each time they are cleaned. This will soiling and is very easy to clean. -
Page 32: Ventilation Gaps
Cleaning and care Ventilation gaps After cleaning ^ The ventilation gaps should be ^ Replace all shelves and accessories cleaned regularly with a brush or in the appliance. vacuum cleaner. A build-up of dust ^ Insert the plug in the socket and will increase the energy consumption switch on at the mains. -
Page 33: Active Charcoal Filters
To delay changing the active charcoal filters If you do not have new active charcoal filters, you can order them from your Miele dealer or from the Miele Spare Parts Department. You can switch off the Change active charcoal filter indicator early, if you would prefer not to have the red indicator showing. - Page 34 ^ At the same time, briefly touch the can be obtained from your Miele On/Off sensor (without letting go of dealer or from the Miele Spare Parts the X sensor). Department. ^ Leave your finger on the X sensor for another 5 seconds until c appears in the display.
-
Page 35: Problem Solving Guide
^ Check that the fuse is not defective and that the mains fuse has not . . . the interior lighting is not working. tripped. If it has, contact the Miele Service Department. ^ Was the door left open for too long? The lighting switches itself off . - Page 36 . . . the change the active charcoal filter indicator is red. ^ Replace the active charcoal filters. You can order replacement filters via your Miele dealer or the Miele Spare Parts Department.."_F" shows in the temperature display.
-
Page 37: Noises
Noises Normal noises What causes them Humming noise made by the motor (compressor). This noise can Brrrrr... get louder for brief periods when the motor is switching on. Blubb, blubb..A gurgling noise can be heard when coolant is circulating through the pipes. -
Page 38: After Sales / Guarantee
– your Miele Dealer – Miele (see back cover for contact details). When contacting your Dealer or Miele, please quote the model and serial number of your appliance. This information is given on the data plate inside your appliance. -
Page 39: Electrical Connection
Electrical connection Electrical connection U.K. Non-rewireable plugs (BS 1363) All electrical work should be carried out The fuse cover must be re-fitted when by a suitably qualified and competent changing the fuse, and if the fuse cover person in strict accordance with current is lost, the plug must not be used until a local and national safety regulations suitable replacement is obtained. -
Page 40: Installation
Should you require further for side-by-side installation with this assistance please contact your refrigerator. Miele customer service centre. Your dealer will be able to advise Climate range you on which models are suitable. The appliance is designed for use... -
Page 41: Ventilation
Installation Ventilation Stainless steel appliances Air at the back of the appliance gets warm. To ensure sufficient ventilation, the ventilation gaps must not be covered over. The air inlet and outlet must not be covered or blocked in any way. They should be dusted on a regular basis. -
Page 42: Appliance Dimensions
Installation Appliance dimensions K 14820 SD 1850 mm 600 mm 630 mm K 14820 SD ed/cs... -
Page 43: Changing The Door Hinging
Changing the door hinging The appliance is supplied right-hand hinged. If left-hand door hinging is required, follow the instructions below. To change the door hinging you will need the following tools: – a cross-slotted screwdriver, – a flat-bladed screwdriver, – a selection of Torx screwdrivers, –... - Page 44 Changing the door hinging ^ Fit restraining clip b (supplied with Removing the soft-close door mechanism the appliance) onto soft-close mechanism c. The soft-close door mechanism is at the bottom of the door. The restraining clip stops the hinge from snapping shut. Do not remove the ^ Open the door.
- Page 45 Changing the door hinging ^ Remove cover b by pulling it upwards. Caution. The door is not secure as soon as the hinge plate is removed. ^ Loosen screws d in upper hinge plate c and pull it upwards and off. ^ Carefully lift the door off and place it to one side.
- Page 46 Changing the door hinging ^ Then fit cover e together with ^ Unscrew part h from hinge plate f, retaining plate f on the opposite rotate it by 180° and refit into the hole side. on the opposite side of the hinge plate.
- Page 47 Changing the door hinging ^ Slide the soft-close mechanism back into the door as far as it will go ^ Fit hinge plate c onto the opposite towards the appliance using a side and secure it with screws d. flat-headed screwdriver. If necessary drill a pilot hole for the The screw holes on the left and right screws.
- Page 48 Changing the door hinging Refitting the handle Please make sure you follow the instructions below carefully when you refit the handle. The door seal will be damaged if the handle is fitted incorrectly. ^ Attach panel b to soft-close mechanism bracket d. ^ Align bracket d to the hinge plate, and insert pin e from above so that the right angle fits into the recess.
- Page 49 Changing the door hinging It is important to check that the side section of the handle d does not come into contact with the door seal when opening the door, as this would damage the door seal permanently. If, after you have refitted the handle, you find that the side section does touch the door seal when the door is opened:...
-
Page 50: Aligning The Appliance Door
Aligning the appliance door The appliance door can be aligned to the housing using the outer long slots in the lower hinge plate. In the following illustration the door is not shown in the closed position to make it easier to see what you have to do. -
Page 51: Building In The Appliance
Building in the appliance The air inlet and outlet must not be covered or blocked in any way. They should be dusted on a regular basis. When built into a kitchen run (max. depth 580 mm) the appliance can be installed directly next to a kitchen furniture housing unit. - Page 52 Alteration rights reserved / 1311 M.-Nr. 09 021 160 / 03 K 14820 SD, K 14820 SD ed/cs...
