Page 1 LFD DISPLAY User Manual ME32C ME40C ME46C ME55C The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. BN46-00098R-04...
Page 2: Table Of Contents
Checking the Contents Before Connecting Removing the Packaging Using MDC Pre-connection Checkpoints (for ME32C ME40C and ME46C models only) Removing the Packaging Connecting to a PC Configuring Settings for Multi Control (for ME55C models only) Connection using the D-SUB cable...
Page 3 Table of contents Getting Started with MDC Aspect Ratio Speaker Settings Main Screen Layout Advanced Settings Reset Sound Menus Dynamic Contrast Screen Adjustment Black Tone Advanced features Flesh Tone Sound Adjustment Channel RGB Only Mode System Setup Color Space Tool Settings Antenna White Balance Other Functions...
Page 4 Table of contents System Power On Adjustment Temperature Control Auto Protection Time Setup Anynet+ (HDMI-CEC) Initial settings (Setup) Screen Burn Protection Anynet+ (HDMI-CEC) Pixel Shift Multi Control Auto Turn Off Timer Troubleshooting for Anynet+ Configuring settings for Multi Control Immediate Display Time DivX®...
Page 5 MagicInfo Lite Player By USB Read the following before using AllShare Play with a USB device Read before using MagicInfo Lite Player Contact Samsung Using a USB device Approving a connected device Connecting to a PC over a network Contents Home...
Page 6 Table of contents MagicInfo Videowall S Troubleshooting Guide Appendix File Formats Compatible with MagicInfo Requirements Before Contacting Samsung Contact SAMSUNG WORLD WIDE Videowall S Player Customer Service Center Responsibility for the Pay Service Read before using Testing the Product (Cost to Customers)
Page 7: Before Using The Product
© 2013 Samsung Electronics Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. Microsoft, Windows are registered trademarks of Microsoft Corporation. VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Page 8: Safety Precautions
Safety Precautions Cleaning ― Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched. ― Take the following steps when cleaning. Caution ― The following images are for reference only. Real-life situations may differ from what is shown in the images.
Page 9: Storage
Storage Connect the power plug to a grounded power socket (type 1 insulated devices only). Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white- • An electric shock or injury may result. colored stains on the product. ―...
Page 10: Installation
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES. • A fire may result. Only use the power cord provided with your product by Samsung. Do not use the power cord with other products. • A fire or electric shock may result.
Page 11 Bend and keep part of the outdoor TV antenna cable hanging downwards Edible oil, such as soybean oil, can damage or deform the product. Do not (the part inside the room) to prevent rainwater from entering the product. install the product in a kitchen or near a kitchen counter. •...
Page 12: Operation
If the product is dropped or the outer case is damaged, turn off the power SAMSUNG switch and disconnect the power cord. Then contact Samsung Customer • Be sure to consult Samsung Customer Service Center if you want to Service Center. install the product at such a place.
Page 13 • Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product. Then contact Samsung Customer Service Center. Do not move the product by pulling the power cord or any cable.
Page 14 Caution Rest your eyes for more than 5 minutes for every 1 hour of product use. • Eye fatigue will be relieved. Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels. •...
Page 15 Be careful that children do not place the battery in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach. • If children have had the battery in their mouths, consult your doctor immediately.
Page 16: Preparations
Chapter 02 Preparations Checking the Contents Remove the styrofoam from the product. Removing the Packaging (for ME32C ME40C and ME46C models only) ― The following images are for reference only. Real-life situations may differ from what is shown in the images.
Page 17: Removing The Packaging (For Me55C Models Only)
Removing the Packaging (for ME55C models only) Using the grooves in the box, lift and remove the top of the box. ― The following images are for reference only. Real-life situations may differ from what is shown in the images. Remove the black locking device at the bottom of the box.
Page 18: Checking The Components
Checking the Components Components - Contact the vendor where you ― Components may differ in different locations. purchased the product if any components are missing. - The appearance of the components and items sold separately may differ from the image shown. - A stand is not provided with the product.
Page 19 Items sold separately - The following items can be purchased at your nearest retailer. Wall-mount Kit Stand RS232C-Stereo cable (P.63) DVI cable (P.48) HDMI-DVI cable (P.48) DP cable (P.49) HDMI cable (P.49) Video cable (P.53) Stereo cable (P.27) Component cable (P.54) - The RS232C adapter can be used to connect to another monitor using the D-SUB (9-pin) type RS232C cable.
Page 20: Parts
Parts ― The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Panel Key Control Panel Buttons Description Power on the product. If you press the button when the product is turned on, the control menu will be displayed.
Page 21 ― If you press the Buttons Description button on the panel key (P.20) when the product is turned on, the control menu will be displayed. Select the connected input source. Control menu Move the panel key right to select Source in the control menu.
Page 22: Reverse Side
Port Description Reverse Side RS232C IN Connects to MDC using an RS232C-stereo adapter. ― The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. RS232C OUT IR / AMBIENT SENSOR IN Supplies power to the external sensor board or receives the light sensor signal.
Page 23: Assembling The Holder-Wire Stand
Assembling the Holder-Wire stand Anti-theft Lock ― An anti-theft lock allows you to use the product securely even in public places. ― The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details. ―...
Page 24: Remote Control
Remote Control ― Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled. Power off the product. Power on the product. Number buttons Enter the password in the OSD menu. Press to select additional channels (digital) being broadcasted by the same station.
Page 25 Display information about the current input TOOLS INFO Quickly select frequently used functions. source. Move to the upper, lower, left or right menu, or adjust an option's setting. Confirm a menu selection. Exit the current menu. RETURN EXIT Return to the previous menu. In TV mode, configure settings such as the HDMI program guide for digital channels.
Page 26 Adjusting the OSD with the Remote Control Remote Control Reception Range Buttons Description Open the OSD menu. Select an option you want to change settings for from Picture, Sound, Channel, Network, System, and Support on the left side of the OSD menu. Change settings as desired.
Page 27: Connection Using An Ir Stereo Cable (Sold Separately)
Connection Using an IR Stereo Cable (sold separately) Make sure to connect the external sensor kit while the product is powered off. POWER POWER Then, power on the product. Controlling more than one display product using IR OUT IR/AMBIENT your remote control SENSOR IN •...
Page 28: Before Installing The Product (Installation Guide)
Tilting Angle and Rotation 15 ˚ ― Contact Samsung Customer Service Center for further details. • The product can be tilted at a maximum angle of 15 from a perpendicular wall surface. • To use the product vertically (portrait), turn it clockwise so that the LED is pointing down.
Page 29: Dimensions
Figure 1.3 Side view Installation on an Indented Wall ― Contact Samsung Customer Service Center for further details. Plane view Minimum 40 mm Minimum 70 mm Minimum 50 mm Minimum 50 mm Ambient temperature: Under 35 C ― When installing the product on an indented wall, allow at least the space specified above between the product and wall for ventilation and ensure that the ambient temperature is kept below 35 C.
Page 30: Installing The Wall Mount
We recommend you contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.
Page 31: Wall Mount Kit Specifications (Vesa)
Samsung is not liable for these kinds of accidents. • Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
Page 32: Remote Control (Rs232C)
Remote Control (RS232C) • Pin assignment 1 2 3 4 5 Cable Connection RS232C Cable Interface RS232C (9 pins) 6 7 8 9 TxD (No.2), RxD (No.3), GND (No.5) Signal Bit rate 9600 bps Detect data carrier Data bits 8 bit Received data Parity None...
Page 33 LAN Cable • RS232C cable Connector: 9-Pin D-Sub to Stereo Cable • Pin assignment 1 2 3 4 5 6 7 8 -P1- -P1- -P2- -P2- Female --------> STEREO <-------- PLUG Pin No Standard Color Signal ---------- (3.5ø) White and orange Orange White and green Blue...
Page 34 Cross LAN cable (PC to PC) • Connector : RJ45 Direct LAN cable (PC to HUB) RJ45 RJ45 RJ45 MDC Signal Signal <--------> <--------> Signal Signal <--------> <--------> <--------> <--------> <--------> <-------->...
Page 35: Connection
Connection • Connection 2 • Connection 1 RJ45 RJ45 RS232C RS232C RS232C RS232C • Connection 3 RJ45 RS232C RS232C RS232C RS232C...
Page 36: Control Codes
Command type Command Value range Control Codes Video Wall On 0x84 Viewing control state (Get control command) Video Wall User Control 0x89 Header Command Data length Checksum • All communications take place in hexadecimals. The checksum is calculated by adding up all 0xAA Command type values except the header.
Page 37: Power Control
Power control Volume control • Function • Function A product can be powered on and off using a PC. The volume of a product can be adjusted using a PC. • Viewing power state (Get Power ON / OFF Status) •...
Page 38: Input Source Control
Input source control 0x24 HDMI2_PC • Function 0x25 DisplayPort The input source of a product can be changed using a PC. ― DVI_video, HDMI1_PC and HDMI2_PC cannot be used with the Set command. They only respond to • Viewing input source state (Get Input Source Status) "Get"...
Page 39 Screen mode control • Ack Header Command Data length Ack/Nak r-CMD Val1 Checksum • Function The screen mode of a product can be changed using a PC. 0xAA 0xFF 0x18 "Screen Screen mode cannot be controlled when the Video Wall function is enabled.
Page 40 Screen size control PIP On/Off control • Function • Function The screen size of a product can be changed using a PC. The PIP mode of a product can be turned on or off using a PC. ― Only available on models that have the PIP function. •...
Page 41 Auto adjustment control (PC and BNC only) Video Wall Mode Control • Function • Function Automatically adjust the PC system screen using a PC. Video Wall mode can be activated on a product using a PC. Video Wall This control is only available on a product whose is enabled.
Page 42: Safety Lock
Safety Lock • Nak Header Command Data Ack/Nak r-CMD Val1 Checksum • Function length Safety Lock PC can be used to turn the function on or off on a product. This control is available regardless of whether or not the power is turned on. 0xAA 0xFF 0x5D...
Page 43 Video Wall On • Nak Header Command Data length Ack/Nak r-CMD Val1 Checksum • Function Turn Video Wall on or off on the product from your computer. 0xAA 0xFF 0x84 • Get Video Wall On/Off Status "ERR": A code showing what error has occurred Header Command Data length...
Page 44 10x10 Video Wall Model 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x1F 0x11 0x12 0x13 0x14 0x15 0x16 0x17 0x18 0x19 0x1A 0x1B 0x1C 0x1D 0x1E 0x2F 0x21 0x22 0x23 0x24 0x25 0x26 0x27 0x28...
Page 45 Wall_SNo: Product Number code assigned to the product 10x10 Video Wall Model : ( 1 ~ 100) Set Number Data 0x01 0x02 0x63 0x64 • Ack Header Command Data length Ack/Nak r-CMD Val1 Val2 Checksum 0xAA 0xFF 0x89 Wall_Div Wall_SNo •...
Page 46: Connecting And Using A Source Device
Chapter 03 Connecting and Using a Source Device Before Connecting Check the following before you connect this product with other devices. Devices that can be connected to this product Pre-connection Checkpoints include PCs, camcorders, speakers, set top boxes and DVD/Blu-ray Disc players. ―...
Page 47: Connecting To A Pc
Connecting to a PC • Do not connect the power cable before connecting all other cables. Ensure you connect a source device first before connecting the power cable. • A PC can be connected to the product in a variety of ways. Select a connection method suitable for your PC.
Page 48: Connection Using A Dvi Cable (Digital Type)
Connection using a DVI cable (Digital type) POWER DVI IN / MAGICINFO IN RGB / DVI / HDMI / AV / COMPONENT / AUDIO IN Connection Using an HDMI-DVI Cable ― When you connect a PC to the product using an HDMI-DVI cable, set Edit Name DVI PC...
Page 49: Connection Using An Hdmi Cable
Connection Using an HDMI Cable POWER HDMI IN 1, HDMI IN 2 Connection Using an DP Cable • Precautions for using DP ― To increase the standby power capacity, the product stops DP POWER communication when it is turned off or in power-saving mode. If the product in dual monitor mode is turned off or goes into power-saving mode, monitor setting changes may not be updated.
Page 50: Changing The Resolution
Changing the Resolution ― Adjust the resolution and refresh rate in Control Panel on your PC to obtain optimum picture quality. ― The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected. Changing the Resolution on Windows XP Go to Control Panel Display Settings, and change the resolution.
Page 51: Changing The Resolution On Windows 7
Changing the Resolution on Windows 7 Go to Control Panel Display Screen Resolution, and change the resolution. Changing the Resolution on Windows 8 Go to Settings Control Panel Display Screen Resolution, and change the resolution.
Page 52: Connecting An External Monitor
Connecting an External Monitor ― Connecting parts may differ in different products. POWER DP OUT DP IN...
Page 53: Connecting To A Video Device
Connecting to a Video Device • Do not connect the power cable before connecting all other cables. Ensure you connect a source device first before connecting the power cable. • You can connect a video device to the product using a cable. ―...
Page 54: Connection Using The Component Cable
Connection Using the component Cable POWER AV IN / COMPONENT IN RGB / DVI / HDMI / AV / COMPONENT / AUDIO IN Connection Using an HDMI-DVI Cable ― Audio will not be enabled if the product is connected to a video device using an HDMI-DVI cable.
Page 55: Connection Using An Hdmi Cable
Connection Using an HDMI Cable Using an HDMI cable or HDMI to DVI Cable POWER (up to 1080p) • For better picture and audio quality, connect to a digital device using an HDMI cable. HDMI IN 1, HDMI IN 2 •...
Page 56: Connecting To An Audio System
Connecting to an Audio System ― Connecting parts may differ in different products. POWER AUDIO OUT Connecting the antenna ― Connecting parts may differ in different products. POWER ― When the product is powered on for the first time, basic settings are configured automatically.
Page 57: Connecting The Network Box (Sold Separately)
Connecting the network box (Sold separately) ― For details on how to connect to a network box, refer to the user's manual provided with the network box upon purchase. MagicInfo To use MagicInfo, a network box (sold separately) must be connected to the product. ―...
Page 58 Enter the IP information. MagicInfo Setup Wizard - v.1.12 Select TCP/IP - step 2 Obtain an IP address automatically Use the following IP address: IP address: 192 . 168 . 0 . 102 Subnet mask: 255 . 255 . 255 . 0 Default gateway: 192 .
Page 59 Select a display mode. MagicInfo Setup Wizard - v.1.12 Select Screen Type - step 4 Landscape Portrait < Back(B) Next(N) > Finish Cancel Double-check the settings you have just configured. MagicInfo Setup Wizard - v.1.12 ― If the execution icon does not appear, double-click the MagicInfo icon on the desktop.
Page 60: Changing The Input Source
Changing the Input source Source allows you to select a variety of sources and change source device names. You can display the screen of a source device connected to the product. Select a source from source list to display the screen of the selected source.
Page 61: Using Mdc
Chapter 04 Using MDC Configuring Settings for Multi Control DisplayPort Daisy Chain • To display the DP IN video input through the DP OUT output port, select a device connection method from Single Stream Transport (SST) and Multi Stream Transport (MST). Clone: In this Single Stream Transport (SST) output mode, the same screen output is displayed on MENU m →...
Page 62: Mdc Program Installation/Uninstallation
MDC Program Installation/Uninstallation Installation MDC installation can be affected by the Insert the installation CD into the CD-ROM drive. graphics card, mother board and network conditions. Click the MDC Unified installation program. Select a language for installation. Next, click "OK". If a software installation window is not displayed on the main screen, install with When the...
Page 63: What Is Mdc
What is MDC? Multiple display control "MDC" is an application that allows you to easily control multiple display devices Connecting to MDC simultaneously using a PC. Using MDC via RS-232C (serial data communications standards) An RS-232C serial cable must be connected to the serial ports on the PC and monitor. POWER Monitor 1 RS232C IN...
Page 64 Using MDC via Ethernet Enter the IP for the primary display device and connect the device to the PC. One display device can connect to another using an RS-232C serial cable. Connection using a direct LAN cable ― Multiple products can be connected using the RJ45 port on the product and the LAN ports on the HUB. POWER Monitor 1 RJ45...
Page 65 Connection using a cross LAN cable ― Multiple products can be connected using the RS232C IN / OUT port on the product. POWER Monitor 1 RJ45 RS232C OUT Monitor 2 Computer...
Page 66: Connection Management
Connection Management Connection management includes the Connection list and Connection list modification options. Connection list - Connection list shows the details of the connections such as connection setting (IP/COM, Port No, MAC, and Connection Type), connection status, Set ID Range, and detected devices. Each connection can contain a maximum of 100 devices connected in serial daisy-chain fashion.
Page 67: User Login
User Login Launching the program displays the user login window. The initial login ID (password: admin) and password (Auto Login: admin) are set to admin. ― After logging in for the first time, make sure to change the password to ensure security. ―...
Page 68: Auto Set Id
Auto Set ID Auto Set ID feature assigns a Set ID for all the LFDs connected in daisy-chain of a selected connection. There can be a maximum of 100 LFDs in a connection. The Set ID is assigned sequentially in the daisychain running from 1 to 99, and then finally to Set ID 0. ―...
Page 69: Cloning
Cloning Using the Cloning feature, you can copy the setting of one LFD and apply it to multiple selected LFDs. You can select specific tab categories or all tab categories for cloning, using the copy setting option window. ― To delete the settings you have configured, click the Paste Settings button.
Page 70: Command Retry
Command Retry This feature is used to specify the maximum number of times the MDC command will be retried in case of there being no reply or a corrupted reply from an LFD. The retry count value can be set using the MDC options window. The retry count value must be between 1-10.
Page 71: Getting Started With Mdc
Getting Started with MDC To start the program, click Start → Programs → Samsung → MDC Unified. The login window appears after the MDC program is launched. Enter the user ID and password. • The default user ID and password are admin.
Page 72: Main Screen Layout
Main Screen Layout Change the status of a display device or the properties of the program. Menu Bar View a list of connected display devices or device groups. Device Category View a list of schedules for display devices. Schedule Category Select the display device you want to adjust.
Page 73 ― The volume can be changed or the sound can be muted only for displays that are turned on. Volume Volume • Adjust the volume of a selected display. • The volume can be adjusted using the slider bar in the range of 0 to 100. Mute •...
Page 74: Screen Adjustment
User Login User Settings • Add, delete or edit login information. Logout • Log out from the current user account as follows. • Click Logout. The message "Do you want to log admin out?" is displayed • Click Yes. The user login window appears. •...
Page 75 Color Color • Adjust the colors for the selected display device. Tint (G/R) • Adjust the tint for the selected display device. Color Tone • Adjust the background color tone for the selected display device. Color Temp. • Adjust the color temperature for the selected display device. ―...
Page 76 MPEG Noise Filter Reduces MPEG noise to provide improved picture quality. Medium High Auto • Smart LED Controls the LED backlight to maximize picture clarity. Cinema Black In Movie mode, this feature dims the top and bottom areas of the video image to provide a more immersive viewing experience.
Page 77: Advanced Features
Advanced features 3D Mode Select the 3D input format. 3D L/R Change Swap the left and right pictures. Displays the image for the left eye only. 3D Auto View 3D Control 3D Auto View Message Notice, a pop up message window appears when the product receives a 3D signal. If you set 3D Optimization The overall adjustment of 3D effect.
Page 78 Advanced Settings Dynamic Contrast Adjust the screen contrast. Gamma Control Adjust the primary color intensity. RGB Only Mode Displays the Red, Green Blue color for making fine adjustments to the hue and saturation. Flesh Tone Emphasize pink “Flesh Tone. ” Motion Lighting Reduces power consumption by reducing screen brightness when the picture on the screen is in motion.
Page 79: Sound Adjustment
Sound Adjustment You can change the sound settings. Choose display devices from the list of sets, and select the Sound tab. Bass • Adjust the bass for the selected display. Treble • Adjust the treble for the selected display. Balance(L/R) Bass Treble - The...
Page 80 Format • Select the number of horizontal display devices. • Select the format to display the split screen. • A maximum of 15 displays can be arranged in a row. ― A maximum of 6 can be assigned to if 15 is assigned to H. •...
Page 81 General User Auto Color • Automatically adjust the screen colors. ― Available only in mode. Auto Power • Set the product to automatically power on. Standby Control • Set the standby mode to activate if an input source is not detected. Fan &...
Page 82: Osd Display
Security Safety Lock • Lock the on-screen menus. ― To unlock the menus, set Safety Lock to Off. Button Lock • Lock the buttons on the display device. ― To unlock the buttons, set Button Lock to Off. OSD Display Source OSD •...
Page 83 Time Clock Set Change the current time on the selected display device according to the time set on a PC. If the time is not set on the display device, null values will be displayed. Timer On Timer • Repeat: Specify the period for which you want to repeat the selected Timer. Once, EveryDay, Mon~Fri, Mon~Sat, Sat~Sun, Manual Holiday...
Page 84: Holiday Management
Holiday Management Holiday Management allows you to prevent devices that are set to be powered on by the Timer from turning on at a specified date. ― The Holiday Management function can be enabled or disabled in the Timer settings menu. •...
Page 85 Screen Saver This function prevents screen burn-in when the screen of the selected display device is left idle for an extended period of time. Timer: You can set the timer for Screen Saver. • • Repeat: Display the image retention-preventive pattern set in Mode at specified time intervals (Period).
Page 86 Safety Screen Safety Screen function can be used to prevent screen burn-in when a stationary image displays on the screen of a display device for an extended period of time. Lamp Control Lamp Control is used to adjust the backlight to reduce power consumption. Automatically adjust the backlight of the selected display device at a specified time.
Page 87 Ticker Input text while a video or image is displayed and display the text on the screen. Ticker Enable or disable Ticker. • Message Enter a message to display on the screen. Timer Start Time End Time Set the to display a message (Message). Position Horizontal and Vertical.
Page 88: Tool Settings
Tool Settings Panel Control: Turn on or off the screen of a display device. • Remote Control: Enable or disable the remote control. • Security Reset Reset Picture: Reset the screen settings. • Reset Sound: Reset the sound settings. • Reset System: Reset the system settings.
Page 89 Edit Column Configure the settings for the items that will be displayed on the list of displays. • Language: Select a language to use in the MDC program. After selecting a language, restart the MDC program to use the selected language. Options Command Retry Count: Specify the number of retry attempts when a command fails.
Page 90 Monitor Window A window appears showing details for data transfer between the computer and display devices. Filter • Information View the program information.
Page 91: Other Functions
Other Functions Resizing a Window Place the mouse pointer on a corner of the program window. An arrow will appear. Move the arrow to customize the size of the program window.
Page 92: Group Management
Group Management Create groups and manage the list of sets on a group basis. ― Duplicate group names cannot be used. Group Edit Creating Groups Right-click and select in the display device list section on the left side of the program window. In the Edit Group window displayed, click...
Page 93 Add on the sub level: Create a sub-group under the selected group. • Enter the group name. Deleting Groups Select a group name, and click Edit. In the Edit Group window displayed, click Delete. Click Yes. The group will be deleted.
Page 94: Schedule Management
Renaming Groups Select a group name, and click Edit. Edit Group window displayed, click Rename. In the If a cursor appears in the old group name, enter a new group name. Rename Schedule Management Creating Schedules Create and register a schedule on a group basis. All Schedule List Click in the schedule section on the left side of the program window.
Page 95 Click the button. The Add Schedule window will appear. Device Group Click below the item, and select the group you want to add a schedule to. Select Date&Time/Action and click OK. The schedule will be added and a list of schedules will appear in the set list window.
Page 96: Troubleshooting Guide
Troubleshooting Guide - This program may malfunction sometimes due to a communication Issue Solution problem between the PC and display or electromagnetic waves emitted from The display you want to control does not Check the connection of the RS232C cable (check that the cable is properly connected to appropriate serial port). nearby electronic devices.
Page 97 How display properties are shown when multiple displays are used When no display is selected: The default value is displayed. When one display is selected: Settings for the selected display are displayed. When two displays are selected (e.g. in sequence of ID 1 and ID 3): The settings for ID 1 are displayed before the settings for ID 3. When the All+Select checkbox is checked and all displays are selected: The default settings are displayed.
Page 98: Screen Adjustment
Chapter 05 Screen Adjustment Picture Color Tone, etc.). Configure the settings (Backlight, Picture - The layout of the menu options may vary depending on the product. Picture Mode If the input source is PC, DVI or DisplayPort • Information: This mode reduces eye fatigue and is suitable for displaying information to the public. MENU m →...
Page 99: Backlight / Contrast / Brightness / Sharpness / Color / Tint (G/R)
Backlight / Contrast / Brightness / Your product has several options for adjusting picture quality. Input source Picture Mode Adjustable options Sharpness / Color / Tint (G/R) PC, DVI, DisplayPort, HDMI1 Information Backlight Contrast Brightness (when a PC is connected), HDMI2 (when a Sharpness...
Page 100: Screen Adjustment
Screen Adjustment choose size and aspect ratio picture displayed on screen. Picture Size MENU m → Picture → Screen Adjustment → ENTER E ― Different Screen Adjustment options are displayed depending on the current input source. • 16:9: Sets the picture to 16:9 wide mode.
Page 101 Picture Sizes available by Input Source. Input Source Picture Size 16:9, Zoom1, Zoom2, Component (480i, 480p) 16:9, Zoom1, Zoom2, 4:3, Custom (1080i) 16:9, Smart View Wide Fit, 4:3, Screen Fit Component (1080i, 1080p) 16:9, Wide Fit, 4:3, Screen Fit, Custom HDMI1, HDMI2 16:9,...
Page 102: Position
Position Adjusts the picture position. Position is only available if Picture Size is set to Zoom1, Zoom2, Wide Fit, Screen Fit or Custom. ― To use the Position function after selecting Zoom1, Zoom2, Wide Fit Screen Fit, follow these steps. button to select Position.
Page 103: Pc Screen Adjustment
PC Screen Adjustment Coarse Fine • Removes or reduces picture noise. If the noise is not removed by Fine-tuning alone, use the Coarse function to adjust the frequency as best as possible Screen Adjustment (Coarse) and Fine-tune again. After the noise has been reduced, re-adjust the picture so that it is aligned with the center of screen.
Page 104: Auto Adjustment
Auto Adjustment Adjust frequency values/positions and fine tune the settings automatically. MENU m → Picture → Auto Adjustment → ENTER E Picture Auto Adjustment - Available in mode only. - The displayed image may differ depending on the model. Rotation Rotate the product screen orientation.
Page 105: Aspect Ratio
Aspect Ratio Set the rotated screen to be either full screen or original. Full Screen: Display the rotated screen in full screen. • • Original: Display the rotated screen in the original aspect ratio. MENU m → → → ENTER E Picture Aspect Ratio ―...
Page 106: Advanced Settings
Advanced Settings Input Source Picture Mode Advanced Settings PC, DVI, DisplayPort, HDMI1 Information White Balance Gamma (when a PC is connected), MENU m → → → ENTER E Picture Advanced Settings HDMI2 (when a PC is Advertisement Dynamic Contrast Black Tone Flesh Tone Color Space connected)
Page 107: Dynamic Contrast
Dynamic Contrast Advanced Settings Adjust the screen contrast. Dynamic Contrast Medium Medium High • Black Tone Black Tone Flesh Tone Select the black level to adjust the screen depth. RGB Only Mode Dark Darker Darkest • Color Space Native Flesh Tone White Balance Emphasize pink Flesh...
Page 108: 10P White Balance
White Balance Advanced Settings Adjust the color temperature for a more natural picture. R-Offset G-Offset / B-Offset: Adjust each color’s (red, green, blue) darkness. • White Balance R-Gain G-Gain / B-Gain: Adjust each color’s (red, green, blue) brightness. • 10p White Balance •...
Page 109: Expert Pattern
Expert Pattern Advanced Settings Use the Expert Pattern function to calibrate the picture. If the OSD menu disappears or a menu other than the Picture menu is opened, the product saves the calibration and the White Balance Expert Pattern screen disappears. •...
Page 110: Picture Options
Picture Options Select an option using the and arrow keys, the press E. Use the arrow keys to change the setting, and then press E. Input source Picture Mode Picture Options MENU m → Picture → Picture Options → ENTER E Information Color Tone Color Temp.
Page 111: Color Tone
Color Tone Picture Options If the input source is PC, DVI, DisplayPort HDMI1 (PC connection), HDMI2 (PC connection). Color Tone Standard Cool Standard Warm • If the input source is AV, Component, HDMI1, HDMI2 or TV. Color Temp. 10000K Cool Standard Warm1 Warm2...
Page 112: Hdmi Black Level
HDMI Black Level Picture Options Selects the black level on the screen to adjust the screen depth. Normal HDMI Black Level Normal • ― Available only in HDMI1, Film Mode HDMI2 mode (AV Timing : 480p, 576p, 720p, 1080i, 1080p). Auto Motion Plus Film Mode Dynamic Backlight...
Page 113: Auto Motion Plus (For Me55C Models Only)
Auto Motion Plus (for ME55C models only) Picture Options Removes blur and judder from scenes with larger amounts of rapid movement to provide a clearer picture. Normal HDMI Black Level The menu names may vary depending on the country. : Switches Auto Motion Plus off.
Page 114: Reset Picture
Reset Picture Resets your current picture mode to its default settings. MENU m → → → ENTER E Picture Reset Picture Picture Reset Picture - The displayed image may differ depending on the model.
Page 115: Sound Adjustment
Chapter 06 Sound Adjustment Sound Configure the sound ( ) settings for the product. Sound Mode You can select a sound mode to suit your personal preferences. • Standard: Selects the normal sound mode. • Music: Emphasizes music over voices. MENU m →...
Page 116: Sound Effect
Sound Effect Configure your preferred sound effect for output sound. ― If Speaker Select is set to External, Sound Effect is disabled. ― Available only when Sound Mode is set to Standard. MENU m → Sound → Sound Effect → ENTER E Virtual Surround (Off / On) •...
Page 117: Broadcast Audio Options
Broadcast Audio Options Preferred Language (for digital broadcasts) • Use the up and down arrow keys to select a language, and then press E Digital-TV broadcasts can simultaneously transmit many audio tracks (for example, simultaneous translations of the program into foreign languages). MENU m →...
Page 118: Speaker Settings
Speaker Settings Speaker Select (External / Internal) • If you are listening to the sound track of a broadcast or movie through an external receiver, you may hear a sound echo caused by the difference in decoding speed between the products speakers and the speakers attached to your audio receiver.
Page 119: Reset Sound
Reset Sound The displayed image may differ depending on the model. Reset all sound settings to the factory defaults. MENU m → Sound → Reset Sound → ENTER E Sound Sound Mode Standard Sound Effect Broadcast Audio Options Speaker Settings Reset Sound - The displayed image may differ depending on the model.
Page 120: Channel
Chapter 07 Channel Channel Configure the settings for the product. Antenna Before your television can begin memorizing the available channels, you must specify the type of signal source that is connected to the LED display. Cable • MENU m → Channel →...
Page 121: Auto Program
Auto Program Auto Program function memorizes all channels that are available over the air or through your cable system and adds them to the Channel List. To start Auto Program, follow these steps: MENU m → Channel → Auto Program →...
Page 122: Clear Scrambled Channel
Clear Scrambled Channel (digital channels only) This function filters out scrambled channels after Auto Program is completed. This process may take up to 20~30 minutes. MENU m → → → ENTER E Channel Clear Scrambled Channel How to Stop the Clear Scrambled Channel function Press the E button to select Stop.
Page 123: Fine Tune
Fine Tune (analog channels only) If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation. If the signal is weak or distorted, fine tune the channel manually. Scroll to the left or right until the image is clear. MENU m →...
Page 124: Crosstalk Noise Reduction
Crosstalk Noise Reduction (analog channels only) This function reduce diagonal noise in picture caused by the crosstalk of signals. If your TV displays with a noise while watching TV, turns on this function. MENU m → Channel → Crosstalk Noise Reduction →...
Page 125: Network
No network cable or Samsung Wireless LAN Adapter The Modem Port on the Wall External Modem connected. RJ45 (ADSL / VDSL) Please plug in a network cable or a Samsung Wireless LAN Start Adapter. Cancel Modem Cable LAN Cable • You can attach your product to your LAN by connecting the LAN port on the back of your product to an IP Sharer which is connected to an external modem.
Page 126 • Depending on how your network is configured, you may be able to attach your product to your LAN by connecting the LAN port on the back of your product directly to a network wall outlet using a LAN cable. See the diagram below.
Page 127: Wired Network Settings
Wired Network Settings Set the network connection to use Internet services such as perform software upgrades. Automatic Network Settings Connect to the network using a LAN cable. Make sure a LAN cable is connected first. How to set up automatically Network Settings screen.
Page 128 Manual Network Settings Offices may use static IP addresses. If this is the case, ask the network administrator for the IP address, subnet mask, gateway and DNS server address. Enter these values manually. Getting the Network Connection Values To view the Network connection values on most Windows computers, follow these steps. Right click the Network icon on the bottom right of the screen.
Page 129: Connecting To A Wireless Network
Auto Setup (Using the Auto Network Search function), Manual Setup, WPS(PBC) ― The product may not recognize the “Samsung Wireless LAN adapter” if you connect it to the product with a USB hub or USB extension cable other than the cable supplied with the product.
Page 130: Wireless Network Setting
Wireless Network Setting Automatic Network Setup Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security key. The Security key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network.
Page 131 Manual Network Setup Offices may use static IP addresses. If this is the case, ask the network administrator for the IP address, subnet mask, gateway and DNS server address. Enter these values manually. Getting the Network Connection Values To view the Network connection values on most Windows computers, follow these steps. Right click the Network icon on the bottom right of the screen.
Page 132 How to set up manually Network Settings screen. Select Start, press E. Go to the Network function searches for available wireless networks. When done, it displays a list of the available networks. In the list of networks, press the ▲ or ▼ button to select a network, and then press the E button twice. ―...
Page 133: Wps(Pbc)
WPS(PBC) How to set up using WPS(PBC) If your router has a WPS(PBC) button, follow these steps. Go to Network Settings screen. Select WPS(PBC), press E, and then press E again. WPS(PBC) Press the button on your router within 2 minutes. Your product automatically acquires all the network setting values it needs and connects to your network.
Page 134: Network Status
Network Status You can check the current network and Internet status. MENUm → → → ENTERE Network Network Status Network Status Your wireless network and Internet connection are setup and ready to use. 00 : 12 : fb : df : 29 : 76 MAC Address ***.
Page 135: Wi-Fi Direct
Wi-Fi Direct - To use this function, your mobile device Wi-Fi should be supported by the MENUm → → → ENTERE Network Wi-Fi Direct Direct. Set to connect the product to wireless mobile devices. Using this function, you can connect wireless mobile devices with your product directly without a router. To connect your mobile device with your product using Wi-Fi Direct, follow these steps: Go to Wi-Fi Direct...
Page 136: Soft Ap
Soft AP MENUm → Network → Soft AP → ENTERE Using this function, you can connect the product on your mobile devices if your mobile devices do not support Wi-Fi Direct. Set the options for connection of Wi-Fi device. Soft AP •...
Page 137: Allshare Settings
AllShare Settings MENUm → → → ENTERE Network AllShare Settings Shows a list of mobile phones or connected devices which have been set up to use the AllShare Play function with this product. Allow / Deny: Allows/Blocks the devices. • Delete from the list: Deletes the devices from the list.
Page 138: Setup
Chapter 09 System Setup Initial settings (Setup) After powering on the product for the first time, configure basic settings such as the language, channel and time. Press the Setup Source is set to TV. button. is available only when MENU m → System →...
Page 139: Multi Control
Multi Control Configuring settings for Multi Control ID Setup • Assign an ID to a set. (Range: 0~99) MENU m → System → Multi Control → ENTERE Press to select a number, and press E. Multi Control ID Input • Enter the ID number of the product connected to the input cable for input signal reception.
Page 140: Time
Time You can configure Clock Set Sleep Timer. You can also set the product to automatically turn on or off at a specified time using the Timer function. Clock MENU m → System → Time → ENTER E Time Clock Mode Set the current time manually or automatically.
Page 141: Sleep Timer
• Switches the DST (Daylight Saving Time) function on or off. ― This function is only available when the Clock Mode is set to Auto. Sleep Timer Automatically shuts off the product after a preset period of time. (Off 30 min. 60 min.
Page 142: On Timer
On Timer Time On Timer so that your product turns on automatically at a time and on a day of your choosing. On Timer The power is turned on with the specified volume or input source. Timer: Set the on timer by making a selection from one of the seven options. Ensure you set the current time first. Off Timer (On Timer1 Timer7)
Page 143: Off Timer
Off Timer Time Set the off timer (Off Timer) by making a selection from one of the seven options. (Off Timer1 Timer7) On Timer ― You must set the clock before you can use Timer. • Setup: Select Off, Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun or Manual.
Page 144: Menu Language
Menu Language Set the menu language. ― A change to the language setting will only be applied to the onscreen menu display. It will not be applied to other functions on your PC. MENU m → → → ENTER E System Menu Language System...
Page 145: Rotate Menu
Rotate Menu Configure the menu screen. • Landscape: Display the menu in landscape mode (default). • Portrait: Display the menu in portrait mode on the right side of the product screen. MENU m → → → ENTER E System Rotate Menu ―...
Page 146: Eco Solution
Eco Solution Energy Saving Reduce the power consumption by adjusting the screen brightness. MENU m → → → ENTER E System Eco Solution Selecting Picture Off switches off the screen. The volume is not disabled. To switch the screen on, press any button other than the volume button. Eco Solution Medium High...
Page 147: Caption
Caption Caption You can switch the caption function on or off. MENU m → System → Caption → ENTER E If captions are not available, they will not be displayed on the screen. • Caption ― The Caption feature does not work with devices connected to the product through the Component, HDMI1, HDMI2 input jacks.
Page 148: Digital Caption Options
Digital Caption Options Caption (digital channels only) Caption Configure the subtitle settings such as size and color. Adjusts the each option. When done, select Close. Caption Mode • Size: Options include Default, Small, Standard and Large. The default is Standard. Digital Caption Options Font Style: Options include...
Page 149: Security
Security Security Every time you access the functions, the PIN screen will appear and the default PIN number is "0-0-0-0" (default password: 0 - 0 - 0 - 0). Safety Lock MENU m → → → ENTER E System Security It sets safe lock function.
Page 150 • All: Lock all TV ratings. / FV: Fantasy violence / V: Violence / S: Sexual situation / L: Adult Language / D: Sexually Suggestive Dialog ― To block certain content, you select a lock, and press E (That is, you “click it”.). For example, click the lock at the intersection of and TV-MA, and you block all programs that are rated violent and for mature adults.
Page 151: Change Pin
Canadian French Rating: You can block TV programs based on their French Canadian rating. Canadian French Rating displays a column with locks and the • following ratings categories. G: General / ans+: Programming generally considered acceptable for children 8 years and over to watch on their own. ans+: Programming may not be suitable for children under the age of 13.
Page 152: Pip
PIP Settings The picture from the external video source will be in the main screen and the picture from the product will be in the PIP sub- picture screen. MENUm → System → → ENTERE Main picture Sub picture System PC, DVI, HDMI1, HDMI2, DisplayPort Auto Protection Time...
Page 153: Auto Protection Time
Auto Protection Time If the screen displays a still image for a certain period of time you define, the product activates the screen saver to prevent the formation of burnt in ghost images on the screen. 2 hours 4 hours 8 hours 10 hours •...
Page 154: Screen Burn Protection
Screen Burn Protection To reduce the possibility of screen burn, this unit is equipped with Pixel Shift screen burn prevention technology. Pixel Shift moves the picture slightly on the screen. Pixel Shift Time setting allows you to program the time between movements of the picture in minutes. MENU m →...
Page 155: Timer
Timer Screen Burn Protection You can set the timer for Screen Burn Protection. Pixel Shift Pixel Shift feature stops automatically after a specified period of time. Timer Timer Immediate Display • • Repeat: Display the image retention-preventive pattern set in Mode at specified time intervals(Period).
Page 156: Immediate Display
Immediate Display Screen Burn Protection Select the screen saver you want to display immediately. Pixel Shift Pixel Rolling Bar Fading Screen • Timer Side Gray Immediate Display When the screen is set to aspect ratio, adjust the brightness of white margins on sides to protect the screen. Side Gray Light Dark...
Page 157: Ticker
Ticker Input text while a video or image is displayed and display the text on the screen. • ― Message, Time, Position, Motion, and Font Options are enabled only when Ticker is set to On. MENU m → System → Ticker →...
Page 158: Video Wall
Video Wall Customize the layout of multiple displays that are connected to form a video wall. In addition, display part of a whole picture or repeat the same picture on each of the connected multiple displays. To display multiple images, refer to MDC Help or the MagicInfo user guide.
Page 159: Vertical
Vertical Video Wall This function automatically divides the screen according to the specified number of vertical displays. Video Wall Enter the number of vertically arranged displays. The vertical screen will automatically be divided according to the number entered. · Format Full A maximum of 15 displays can be assigned to the vertical arrangement.
Page 160: Source Autoswitch Settings
Source AutoSwitch Settings Turning on the display with Source AutoSwitch On, and the previous video source selection is not active, the display will automatically search the different video input sources for active video. Source AutoSwitch MENU m → System → Source AutoSwitch Settings →...
Page 161: General
Auto BD Wise Wise. When Provides the optimal picture quality for Samsung DVD, Blu-ray and Home Theater products which support Wise is turned On, the picture mode is automatically changed to the optimal resolution. - The displayed image may differ depending on the model.
Page 162: Sound Feedback
Sound Feedback General Your product gives sound feedback when you use product. Sound Feedback Sound Feedback Sound Feedback is enabled by default. Turn off or adjust its volume. This function is enabled by default. The volume can be adjusted or muted. Auto Power ―...
Page 163: Lamp Schedule
Lamp Schedule General Enables the lamp value to be adjusted to a user-specified value at a specified time in MDC mode. Sound Feedback • Auto Power OSD Display Standby Control Auto Displays or hides a menu item on the screen. Lamp Schedule ―...
Page 164: Anynet+ (Hdmi-Cec)
Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung product remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your MENU m →...
Page 165: Auto Turn Off
Auto Turn Off Anynet+ (HDMI-CEC) Setting an Anynet+ Device to turn automatically when the product is turned off. Anynet+ (HDMI-CEC) • ― If Auto Turn Off is set to Yes, running external devices will turn off at the same time as the product powers off. Auto Turn Off ―...
Page 166: Troubleshooting For Anynet
Troubleshooting for Anynet+ Problem Possible Solution Anynet+ does not work. • Check if the device is an Anynet+ device. The Anynet+ system supports Anynet+ devices only. • Check if the Anynet+ device power cord is properly connected. • Check the Anynet+ device’s Video/Audio/HDMI cable connections. Anynet+ (HDMI-CEC) •...
Page 167 Problem Possible Solution The connected device is not • Check whether or not the device supports Anynet+ functions. displayed. • Check whether or not the HDMI cable is properly connected. • Check whether Anynet+ (HDMI-CEC) is set to in the Anynet+ Setup menu.
Page 168: Divx® Video On Demand
® Video On Demand DivX Shows the registration code authorized for the product. If you connect to the DivXⓇ web site and register using that code, you can download the VOD registration file. For more information about DivXⓇ VOD, visit “http://vod.divx.com”. MENU m →...
Page 169: Magic Clone
Clone to USB ― The option is available for products with the same Model Code Software Version. Support → Contact Samsung Model Code Software Version. Go to and find the product Clone From USB - The displayed image may differ depending on the model.
Page 170: Reset All
Reset All This option returns all the current settings for a display to the default factory settings. MENU m → System → Reset All → ENTER E System Reset All - The displayed image may differ depending on the model. PC Module Power The PC module can be turned on/off separately from the LFD.
Page 171: Software Update
Chapter 10 Support Software Update MENU m → Support → Software Update → ENTER E Software Update menu lets you upgrade your product software to the latest version. Current Version: This is the software ― Be careful not to turn off the power until the upgrade is complete. The product will turn off and on automatically after completing the software upgrade. version already installed in the product.
Page 172: Contact Samsung
Contact Samsung MENU m → Support → Contact Samsung → ENTER E View this information when your product does not work properly or when you want to upgrade the software. You can find information regarding our call centers and how to download products and software.
Page 173: Contents Home
Contents Home Channel List MENU m → → → → ENTER E Support Contents Home Channel List MENU m → → → ENTER E Support Contents Home Using this function, you can view channel list, program information, favorite channel, and manage schedules of timer viewing. Added Ch.: Shows all added channels.
Page 174: Channel Manager
Channel Manager Add or delete a channel (Channel). Add favorite channels. Change the name of an analog channel. • All: View all incoming channels. Added Ch.: View channels added in the TV. • MENU m → → → → ENTER E Support Contents Home Channel Manager...
Page 175: Adding A Channel (Channel)
Adding a channel (Channel) Channel Select on the screen. Select a grayed out channel from appears on the left of the selected channel ― More than one channel can be selected. ― To deselect a channel, select the channel again. disappears.
Page 176: Using Tools In Channel
Using Tools in Channel Use the following functions from Edit Favorites on the left of the Added Ch. screen. ICON Function Add selected channels to Favorites. Edit Favorites Change Fav. Go to another list of favorite channels. The list of favorite channels switches to MENU m →...
Page 177 Use the following functions from the list of favorite channels on the right of the Edit Favorites screen. Channel Edit Favorites ICON Function Added Ch. Favorites 1 Delete Delete the selected channel. Adde ― More than one channel can be deleted simultaneously appears Favori 11-1...
Page 178: Rename Channel
Rename Channel Using the TOOLS button with Channel MENU m → Support → Contents Home → Channel → TOOLS → Rename Channel → ENTER E A channel name can be 5 characters long (for analog channels only). Add / Delete MENU m →...
Page 179: Adding A Favorite Channel
Adding a favorite channel Added Ch.. Select Select a channel. appears to the left of the selected channel. ― More than one channel can be selected. ― To deselect a channel, select the channel again. disappears. Press TOOLS on the remote control to open Tools. Select Edit Favorites to open the...
Page 180: Deleting A Channel From A List Of Favorite Channels
Deleting a Channel from a list of favorite channels Select a list of favorite channels from Favorites 1 Favorites Select a channel. appears to the left of the selected channel. ― More than one channel can be selected. ― To deselect a channel, select the channel again. disappears.
Page 181: Magicinfo Lite
MagicInfo Lite MENU m → → → → ENTER E Support Contents Home MagicInfo Lite ― MagicInfo Lite can also be accessed by pressing MagicInfo Lite/S on the remote control. ― To launch MagicInfo Lite, select MagicInfo Lite for the Player Mode on the System.
Page 182: Magicinfo Videowall S
MagicInfo Videowall S MENU m → Support → Contents Home → MagicInfo Videowall S → ENTER E ― MagicInfo Videowall S can also be accessed by pressing MagicInfo Lite/S on the remote control. ― To launch MagicInfo Videowall S, select MagicInfo Videowall S Player Mode on the System.
Page 183: Source
Source - The input source can also be changed by using the SOURCE button on the remote control. MENU m → → → → ENTER E Support Contents Home Source You can display the screen of a source device connected to the product. Select a source from Source list to display the screen of the selected source.
Page 184: Allshare Play
• Before connecting a USB device to the product, back up files to ensure your data is not damaged or lost. Samsung Electronics is not liable for any damage or loss of data. • Do not remove a USB device while it is loading.
Page 185 Compatible devices with AllShare Play • Some types of USB devices, digital cameras and audio devices may not be compatible with the product. AllShare Play is only compatible with USB MSC devices. • • MSC device refers to a Mass Storage Class Bulk-Only Transport device. Examples of MSC devices include Thumb drives, Flash card readers and USB HDDs. (USB hubs are not supported.) These MSC devices must be connected directly to a USB port on the product.
Page 186: Using A Usb Device
Using a USB device Connecting a USB device Turn on your product. It is recommended to use a USB HDD that has a power adapter. Connect a USB device containing photo, music and/or movie files to the USB port on the back or side panel of the product. A message New device connected.
Page 187: Connecting To A Pc Over A Network
Settings. • To view content saved on the PC, connect the product and PC to the same wireless router and visit http://www.samsung.com to download the AllShare PC software. • Ensure the product and PC are connected to the same network subnet.
Page 188: Using The Allshare Play Features
• Compatibility with various subtitle formats (SRT, SMI, SUB, TXT, TTXT) • Search with file names • And many others ― A compatibility issue may occur if a video file is played when a server not provided by Samsung Electronics is connected. ― To use AllShare...
Page 189: Using The Basic Allshare Play Features
Using the Basic AllShare Play Sorting the file lists Features To sort files, press on the remote control to specify the sorting criteria. Sort Criteria Operation Videos Photos Music MENUm → Support → Contents Home → AllShare Play → ENTERE Folder view Displays the whole folder.
Page 190: Playing Selected Files
Playing Selected Files Creating a Playlist Select files from the list of Videos, Photos, or Music files. Select files from the list of Videos, Photos, or Music files. Press TOOLS on the remote control and select Selection Play. Press TOOLS on the remote control and select Add to Playlist.
Page 191: My List
My List MENUm → → → → → ENTERE Support Contents Home AllShare Play My List Access desired content more conveniently and quickly. Playlist To play files, select files or a and press E. Recently Played: Display video, photo or music files that were recently played. This mode is suitable when playing files again that were played before. •...
Page 192: Videos
Videos MENUm → → → → → ENTERE Support Contents Home AllShare Play Videos Playing a Video Select the internal memory or a USB device. Select files from the list of files. Press the E button or ∂ (Play) button. •...
Page 193: Photos
Photos MENUm → → → → → ENTERE Support Contents Home AllShare Play Photos Viewing a Photo (or Slide Show) Select the internal memory or a USB device. Select a file from the list of files. Press the E button. •...
Page 194: Music
Music MENUm → → → → → ENTERE Support Contents Home AllShare Play Music Playing Music Select the internal memory or a USB device. Select files from the list of files. Press the E button or ∂(Play) button. • When the music is playing, you can search using the π(REW) and µ(FF) button. ―...
Page 195: Videos / Photos / Music Play Option Menu
Videos / Photos / Music Play Option menu When playing video or photo files, you can press the TOOLS button to display an Options menu. - Pressing the INFO button while a device name is selected will display Option Name Operations Videos Photos...
Page 196 Option Name Operations Videos Photos Music Sound Mode You can change the Sound Mode. Audio Language You can enjoy video in one of supported languages. The function is enabled only when you play stream-type files which support multiple audio formats. Subtitle You can view a subtitle.
Page 197: Supported Subtitle And Allshare Play File Formats
Supported Subtitle and AllShare Play file formats Subtitle External Internal • MPEG-4 timed text (.ttxt) • Xsub Container: AVI • SAMI (.smi) • SubStation Alpha • SubRip (.srt) Container: MKV • SubViewer (.sub) • Advanced SubStation Alpha • Micro DVD (.sub or .txt) Container: MKV •...
Page 198: Supported Music File Formats
Supported music file formats File Extension Type Codec Comments *.mp3 MPEG MPEG1 Audio Layer 3 *.m4a, *.mpa, *.aac, *.3ga MPEG4 *.flac FLAC FLAC The Seek (jump) function is not supported. Supports up to 2 channel Supported Video Formats • Video content will not play, or not play correctly, if there is an error in the content or the container. •...
Page 199 File Container Video Codec Resolution Frame rate Bit rate Audio Codec Extension (fps) (Mbps) *.avi DIVX 3.11 / 4.x / 5.x / 6.x 1920 x 1080 6~30 *.mkv LPCM *.asf ADMPCM MPEG4 SP / ASP *.wmv (IMA, MS) *.mp4 *.mov HE-AAC H.264 BP / MP / HP *.3gp...
Page 200: Magicinfo Lite
Chapter 12 MagicInfo Lite File Formats Compatible with MagicInfo Lite Player MagicInfo Lite, select - To launch MagicInfo Lite for the Player Mode the System. Read before using MagicInfo Lite Player • The file system supports FAT16, FAT32 and NTFS. •...
Page 201 Contents File Extension Container Video Codec Resolution Frame rate Bit rate Audio Codec (fps) (Mbps) *.avi DIVX 3.11 / 4.x / 5.x / 6.x 1920 x 1080 6~30 *.mkv LPCM *.asf MPEG4 SP / ASP *.wmv HE-AAC *.mp4 *.mov H.264 BP / MP / HP *.3gp MPEG(MP3) *.vro...
Page 202 Video Audio Image • 3D video is not supported. • Audio content with a Bit rate or Frame rate • Compatible image file format : Jpeg larger than the rate specified in the table above • Content with a resolution larger than the •...
Page 203 Flash Power Point • Compatible with Flash 10.1 • Compatible document file formats • Flash Animation - Extension : ppt, pptx - Version : Office 97 ~ Office 2007 - Compatible file format : SWF • Functions not supported • Recommended resolution : 960 x 540 - Caution - Animation effect - 3D shapes (which will be displayed in 2D)
Page 204 WORD • Compatible document file formats • Compatible document file formats - Extension : pdf - Extension : .doc, .docx - Version : Office 97 ~ Office 2007 • Functions not supported - Content less than 1 pixel not supported because of performance •...
Page 205: Approving A Connected Device From The Server
Approving a connected device from the Select Lite from the menus on the left. server Unapproved from the sub-menus of Lite. Select Access the server you have assigned to your device. Select the Approve button for your device from the list of unapproved Lite devices. Enter your ID and password to log in.
Page 206: Setting The Current Time
Enter the information required to approve the device. When the device is approved by the server, the schedule registered in the selected group will be downloaded to the device. The schedule will run after it is downloaded. ― For further details on how to configure a schedule, refer to the <MagicInfo Lite Server user's manual>. ―...
Page 207: Magicinfo Lite
MagicInfo Lite Select Network Schedule in the MagicInfo Lite Player menu. MagicInfo Lite Player MENUm → Support → Contents Home → MagicInfo Lite → ENTERE ― To launch Network Schedule MagicInfo Lite, select MagicInfo Lite for the Player Mode on the System. Local Schedule ―...
Page 208: Local Schedule
Local Schedule → Click Create to a schedule → Select the schedule you want to run Go to Local Schedule Manager Create Local Schedule MagicInfo Lite Player Select in the menu screen. MagicInfo Lite Player Run schedules created in Local Schedule Manager.
Page 209: Usb Autoplay
― The option is enabled only when there is at least one content item, except for music files, in the "MagicInfoSlide" folder on USB AutoPlay USB Storage. ― Ensure a USB device is inserted. Be sure to create a folder named "MagicInfoSlide" in the USB device and put content in the MagicInfo Lite Player folder.
Page 210: Local Schedule Manager
Local Schedule Manager Create Local Schedule Manager Select in the screen. Configure the settings for playback from Local Schedule. Local Schedule Manager Alternatively, select and play content from internal or USB memory according to the customized playback Create sequence. Storage Internal Memory Edit No Playing Schedule...
Page 211 Contents Duration Select to specify the content you want to play. Select Contents Direction Internal Memory Contents Duration No Item Folder1 Menu1.jpg 00:00:05 Menu1.jpg Menu2.jpg 00:00:05 Menu2.jpg Deselect All Down Save Cancel Duration Cancel Return Return Specify the sequence and time duration to play content files. - A maximum of 99 content files can be selected.
Page 212: Modifying A Local Schedule
Select Save. Select the memory space you want to save the content to. Modifying a Local Schedule ― Ensure at least one Local Schedule is registered. Create Select Local Schedule Manager in the MagicInfo Lite menu screen. Time --:-- am~ --:-- pm Delete Contents Menu1.jpg Menu2...
Page 213: Deleting A Local Schedule
Deleting a Local Schedule Select Edit. ― Ensure at least one Local Schedule is registered. Edit Select Local Schedule Manager in the MagicInfo Lite menu screen. Time 12:00 am~ 12:00 pm Delete Menu1.jpg Menu2 Contents MagicInfo Lite Save --:-- am~ --:-- pm Time MagicInfo Lite Player Contents...
Page 214: Running A Local Schedule
Running a Local Schedule Stopping a Local Schedule ― Ensure at least one ― This function is enabled only when a schedule is running. Local Schedule is registered. Selecting Stop will change the running mode from Local Schedule Network Schedule. Select Local Schedule Manager in the...
Page 215 Viewing the details of a Local Schedule The details of the schedule will be displayed. Select Local Schedule Manager in the MagicInfo Lite menu screen. Information 2012.01.01_1834.lsch MagicInfo Lite 12:00 am~12:00 pm, 2 File(s) - Menu1.jpg Menu2.jpg MagicInfo Lite Player Local Schedule Manager Close Content Manager...
Page 216 Copying a Local Schedule Select local schedule files and press Copy. Select Local Schedule Manager in the MagicInfo Lite menu screen. Local Schedule Manager Storage Internal Memory Create MagicInfo Lite Edit No Playing Schedule MagicInfo Lite Player Delete All Schedules Local Schedule Manager 2012.01.01_1834.lsch Content Manager...
Page 217: Content Manager
Content Manager Select the content you want to copy. Content Manager Copying content Internal Memory Select Content Manager in the MagicInfo Lite menu screen. Folder1 No Item Menu1.jpg Menu2.jpg MagicInfo Lite Player MagicInfo Lite Player Copy Local Schedule Manager Delete Free Space Free Space 5549.2MB...
Page 218: Deleting Content
Deleting content Select the content you want to delete. Next, select Delete. Internal Memory • Content under memory can be deleted at the same time. Select Content Manager in the MagicInfo Lite menu screen. Content Manager MagicInfo Lite Player Internal Memory MagicInfo Lite Player Menu3.jpg Folder1...
Page 219: Settings
Settings Server Network Settings MagicInfo Lite, connect to a network. To run Settings Server Server Network Settings Enter the MagicInfo Lite server settings. Content Default Duration (E.g.: http://192.168.0.10:7001/MagicInfo/) Content Ratio Close • If the option is enabled, the server is configured to use https and data transfer is encrypted. Image Effect Random ―...
Page 220: Reset Settings
Content Default Duration Screen Layout Specify the duration to play content. Change the screen orientation to landscape or portrait view. Image Viewer Time, PPT Viewer Time, PDF Viewer Time, Flash Viewer Time Landscape Portrait • • ― The duration must be at least 5 seconds. Schedule Name Content Ratio Select a schedule title format when creating a local schedule.
Page 221: When Content Is Running
When Content is Running Press the INFO button on the remote control. Software Version: Displays the software version of a device • Device Name: Displays the name of a device recognized by the server • Viewing the details of the content that is running Device ID: Displays the original identification number of a device •...
Page 222 Changing the settings for the content that is running Press the TOOLS button on the remote control. You can change the Picture Mode Sound Mode setting or safely remove a USB device (Safely Remove USB) while content Tools is playing by pressing the TOOLS button on the remote control. Picture Mode (Dynamic Standard Natural...
Page 223: Magicinfo Premium S
MagicInfo Premium S A License needs to be purchased to use MagicInfo Premium MagicInfo Premium S, select - To launch To download the software, go to the Samsung homepage at http://www.samsunglfd.com. MagicInfo Premium S for the Player Mode on the System.
Page 224 Video Audio Image • 3D video is not supported. • Audio content with a Bit rate or Frame rate • Compatible image file format : Jpeg larger than the rate specified in the table above • Content with a resolution larger than the •...
Page 225 Flash Power Point • Compatible with Flash 10.1 • Compatible document file formats • Compatible document file formats - Extension : ppt, pptx - Extension : pdf • Flash Animation - Compatible file format : SWF - Version : Office 97 ~ Office 2007 •...
Page 226 WORD Template files • Compatible document file formats • Creation/editing/playback are only available in • Supported in USB AutoPlay Network Template Manager. - Extension : .doc, .docx Schedule (Authored in a PC authoring tool for - Version : Office 97 ~ Office 2007 Premium S Player) •...
Page 227 Network Schedule Multiframe Playback restrictions • A maximum of two video (Videos) files can be played. • If mode is enabled, more than one video (Videos) file cannot be played. • More than one Flash file cannot be played. • For Office files (PPT and Word files) and files, only one file type is supported at a time.
Page 228 Playback restrictions • A maximum of two video (Videos) files can be played. • If mode is enabled, more than one video (Videos) file cannot be played. • More than one Flash file cannot be played. • For Office files (PPT and Word files) and files, only one file type is supported at a time.
Page 229: Approving A Connected Device From The Server
Approving a connected device from the Select Premium from the menus on the left. server Unapproved from the sub-menus of Premium. Select Access the server you have assigned to your device. Select the Approve button for your device from the list of unapproved Premium devices. Enter your ID and password to log in.
Page 230 Enter the information required to approve the device. When the device is approved by the server, the schedule registered in the selected group will be downloaded to the device. The schedule will run after it is downloaded. ― For further details on how to configure a schedule, refer to the <MagicInfo Premium Server user's manual>.
Page 231: Magicinfo Premium S
MagicInfo Premium S Network Schedule MagicInfo Premium S Player Select in the menu. MagicInfo Premium S Player → → → → ENTER E MENU m : T Support Contents Home MagicInfo Premium S ― To launch Network Schedule MagicInfo Premium S, select MagicInfo Premium S Player Mode...
Page 232 Local Schedule → Click Create to a schedule → Select the schedule you want to run Go to Local Schedule Manager Create Select Local Schedule in the MagicInfo Premium S Player menu screen. MagicInfo Premium S Player Run schedules created in Local Schedule Manager.
Page 233 ― The option is enabled only when there is at least one content item, except for music files, in Internal AutoPlay Internal Memory. Select Internal AutoPlay in the MagicInfo Premium S Player menu screen. MagicInfo Premium S Player • Play content, which has been copied to Internal Memory, in alphabetical order.
Page 234: Local Schedule Manager
Local Schedule Manager Select Create in the Local Schedule Manager screen. Local Schedule. Configure the settings for playback from Local Schedule Manager Alternatively, select and play content from internal or USB memory according to the customized playback Create sequence. Storage Internal Memory Edit No Playing Schedule...
Page 235 Select Contents to specify the content you want to play. Select Duration Contents Direction Internal Memory Contents Duration No Item Folder1 Menu1.jpg 00:00:05 Menu1.jpg Menu2.jpg 00:00:05 Menu2.jpg Down Deselect All Save Cancel Duration Cancel Return Return Specify the sequence and time duration to play content files. - A maximum of 99 content files can be selected.
Page 236 Select Save. Select the memory space you want to save the content to. Modifying a Local Schedule ― Ensure at least one Local Schedule is registered. Create Select Local Schedule Manager in the MagicInfo Premium S menu screen. Time --:-- am~ --:-- pm Delete Contents Menu1.jpg Menu2...
Page 237 Select Edit. Deleting a Local Schedule ― Ensure at least one Local Schedule is registered. Edit Select Local Schedule Manager in the MagicInfo Premium S menu screen. Time 12:00 am~ 12:00 pm Delete Menu1.jpg Menu2 Contents MagicInfo Premium S Save Time --:-- am~ --:-- pm MagicInfo Premium S Player...
Page 238 Running a Local Schedule Stopping a Local Schedule ― Ensure at least one ― This function is enabled only when a schedule is running. Local Schedule is registered. Selecting Stop will change the running mode from Local Schedule Network Schedule. Select Local Schedule Manager in the...
Page 239 Viewing the details of a Local Schedule The details of the schedule will be displayed. Local Schedule Manager MagicInfo Premium S Select in the menu screen. Information 2012.01.01_1834.lsch MagicInfo Premium S 12:00 am~12:00 pm, 2 File(s) - Menu1.jpg Menu2.jpg MagicInfo Premium S Player Local Schedule Manager Close Template Player...
Page 240 Copying a Local Schedule Select local schedule files and press Copy. Select Local Schedule Manager in the MagicInfo Premium S menu screen. Local Schedule Manager Storage Internal Memory Create MagicInfo Premium S Edit No Playing Schedule Delete MagicInfo Premium S Player All Schedules Local Schedule Manager 2012.01.01_1834.lsch...
Page 241: Template Manager
Template Manager Select Create in the Template Manager screen. Template Manager Registering a Template Create Storage Internal Memory Select Template Manager in the MagicInfo Premium S menu screen. Edit No Playing Schedule Copy MagicInfo Premium S Delete Play MagicInfo Premium S Player Preview Local Schedule Manager Close...
Page 242 Contents Organize a template by inserting text, video, photo, or PDF files as desired. Contents Create Type None Select the position and background. Contents No Item Use background image Size Fit to screen Preview Source Previous Cancel Next Return Cancel •...
Page 243 Select Sound/Background music. Select Save. Select the memory space you want to save the content to. Create Create Select Sound/Background music. Save the template and finish. Storage Internal Background Music Template Name 20130101_2222 Preview Preview Previous Previous Next Cancel Cancel Videos •...
Page 244: Content Manager
Content Manager Select the content you want to copy. Content Manager Copying content Internal Memory Select Content Manager in the MagicInfo Premium S menu screen. Folder1 No Item Menu1.jpg Menu2.jpg MagicInfo Premium S MagicInfo Premium S Player Copy Local Schedule Manager Delete Free Space Free Space...
Page 245 Deleting content Select the content you want to delete. Next, select Delete. Internal Memory • Content under memory can be deleted at the same time. Select Content Manager in the MagicInfo Premium S menu screen. Content Manager MagicInfo Premium S Internal Memory MagicInfo Premium S Player Menu3.jpg...
Page 246: Settings
Settings Server Network Settings MagicInfo Premium S, connect to a network. To run Settings Server Server Network Settings MagicInfo Premium S Enter the server settings. Content Default Duration option is enabled, the server is configured to use https and data transfer is encrypted. •...
Page 247 Content Default Duration Screen Layout Specify the duration to play content. Change the screen orientation to landscape or portrait view. Image Viewer Time, PPT Viewer Time, PDF Viewer Time, Flash Viewer Time Landscape Portrait • • ― The duration must be at least 5 seconds. Schedule Name Content Ratio Select a schedule title format when creating a local schedule.
Page 248: When Content Is Running
When Content is Running Press the INFO button on the remote control. Software Version: Displays the software version of a device • Device Name: Displays the name of a device recognized by the server • Viewing the details of the content that is running Device ID: Displays the original identification number of a device •...
Page 249 Changing the settings for the content that is running Press the TOOLS button on the remote control. Picture Mode Sound Mode (Safely Remove USB) while content You can change the setting or safely remove a USB device Tools is playing by pressing the TOOLS button on the remote control. Picture Mode (Dynamic Standard Natural...
Page 250: Magicinfo Videowall S
MagicInfo Videowall S A license needs to be purchased to use MagicInfo Videowall MagicInfo Videowall - To launch To download the software, go to the Samsung homepage at http://www.samsunglfd.com. select MagicInfo Videowall S for the Player Mode on the System.
Page 251 Video Image • 3D video is not supported. • Compatible image file format : Jpeg, bmp, png • Content with a resolution larger than the resolution specified in the table • Supported maximum resolution : 15,360 x 8,640 above is not supported. - A higher resolution image may take longer to display on the screen.
Page 252 Restrictions • Only one video (Videos) file can be played per client. ― Different content files can be played on the displays of a video wall. Two video (Videos) files cannot be played on a single display of a video wall. Available Available Not available...
Page 253: Magicinfo Videowall S
MagicInfo Videowall S Default Storage Specify the location you want to save content (downloaded from the server) to. Internal Memory: Save the content to the internal memory of the product. • MENUm → Support → Contents Home → MagicInfo Videowall S →...
Page 254: When Content Is Running
When Content is Running Press the INFO button on the remote control. Software Version: Displays the software version of a device • Information Device Name: Displays the name of a device recognized by the server • Device ID: Displays the original identification number of a device •...
Page 255: Troubleshooting Guide
Chapter 15 Troubleshooting Guide Requirements Before Contacting Samsung Customer Service Center Before calling Samsung Customer Service Testing the Product Center, test your product as follows. If the problem persists, contact Samsung Check if your product is operating normally by using the product test function.
Page 256: Check The Followings
Check the followings. Installation issue (PC mode) The screen keeps switching on and off. Check the cable connection between the product and PC, and ensure the connection is secure. Blank spaces are found on all four sides of the screen when The blank spaces found on the screen have nothing to do with the product.
Page 257 Screen issue The screen is not clear. The screen is blurry. Adjust Coarse and Fine. Remove any accessories (video extension cable, etc) and try again. Set the resolution and frequency to the recommended level. The screen appears unstable and shaky. Check that the resolution and frequency of the PC and graphics card are set within a range compatible with the product.
Page 258 Lines (red, green or blue) are displayed on the screen. These lines are displayed when there is a defect in DATA SOURCE DRIVER IC on the monitor. Contact a Samsung Service Center to resolve the issue. The display looks unstable and then freezes.
Page 259 Sound issue There is no sound. Check the connection of the audio cable or adjust the volume. Check the volume. The volume is too low. Adjust the volume. If the volume is still low after turning it up to the maximum level, adjust the volume on your PC sound card or software program.
Page 260 Sound issue There is audible sound when the volume is muted. Speaker Select is set to External, the volume button and mute function are disabled. When Adjust the volume for the external speakers. Audio settings for main speakers are separate from the internal speakers on the product. Changing or muting the volume on the product does not affect an external amplifier(decoder).
Page 261 Other issue Caption is grayed out and not selectable. If the selected input source is not TV, Caption cannot be selected from the System menu. Caption can be enabled from a source device. ― Refer to page 147 for details about the Caption menu.
Page 262 Other issue There is no sound in HDMI mode. Displayed picture colors may not look normal. Video or sound may not be available. This can occur if a source device that only supports an older version of the HDMI standard is connected to the product. If these issues occur, connect an audio cable along with the HDMI cable.
Page 263: Q & A
Q & A Question Answer How can I change the frequency? Set the frequency on your graphics card. • Windows XP: Go to Control Panel → Appearance and Themes → Display → Settings → Advanced → Monitor and adjust the frequency in Monitor Settings. •...
Page 264 Question Answer • Windows XP: Set power-saving mode in Control Panel → Appearance and Themes → Display How do I set powersaving mode? → Screen Saver Settings or BIOS SETUP on the PC. • Windows ME/2000: Set power-saving mode in Control Panel → Display → Screen Saver Settings or BIOS SETUP on the PC.
Page 265: Specifications
Chapter 16 Specifications General Size Model Name ME32C ME40C Panel Size 32 inches (80 cm) 40 inches (101cm) Display area 698.4 mm (H) x 392.85 mm (V) 885.6 mm (H) x 498.15 mm (V) 27.5 inches (H) x 15.5 inches (V) 34.9 inches (H) x 19.6 inches (V)
Page 266 Model Name ME32C ME40C ME46C ME55C Display Color 16.7 M Synchronization Horizontal 31 ~ 80 kHz Frequency Vertical 56 ~ 75 Hz Frequency Resolution Optimum 1920 x 1080 @ 60 Hz resolution Maximum 1920 x 1080 @ 60 Hz resolution Maximum Pixel Clock 148.5 MHz (Analog, Digital)
Page 267 ― Due to the nature of the manufacturing of this product, approximately 1 pixel per million (1ppm) may appear brighter or darker on the panel. This does not affect product performance. ― This device is a Class A digital apparatus. (USA only) Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call, (877) 278 - 0799...
Page 268: Powersaver
PowerSaver Normal Operation Power saving mode Power off Power off (Power Button off) Rating Typical Power Indicator Blinking Power Consumption ME32C 70 W 41 W 0.5 W 0.4 W ME40C 100 W 61 W ME46C 110 W 64 W ME55C...
Page 269: Preset Timing Modes
Preset Timing Modes ― This product can be set to only one resolution for each screen size to obtain the optimum picture quality due to the nature of the panel. Using a resolution other than the specified resolution may degrade the picture quality. To avoid this, it is recommended that you select the optimum resolution specified for your product. Check the frequency when you exchange a CDT product (connected to a PC) for an LCD product.
Page 270 Resolution Horizontal Frequency Vertical Frequency Pixel Clock Sync Polarity (kHz) (Hz) (MHz) (H/V) VESA, 1024 x 768 56.476 70.069 75.000 VESA, 1024 x 768 60.023 75.029 78.750 VESA, 1152 x 864 67.500 75.000 108.000 VESA, 1280 x 720 45.000 60.000 74.250 VESA, 1280 x 800 49.702...
Page 271: Appendix
Chapter 17 Appendix Contact SAMSUNG WORLD WIDE ― If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. NORTH AMERICA U.S.A 1-800-SAMSUNG (726-7864) http://www.samsung.com CANADA 1-800-SAMSUNG (726-7864) http://www.samsung.com/ca (English) http://www.samsung.com/ca_fr (French) MEXICO 01-800-SAMSUNG (726-7864) http://www.samsung.com...
Page 272 LATIN AMERICA COSTA RICA 0-800-507-7267 http://www.samsung.com/latin (Spanish) http://www.samsung.com/latin_en (English) ECUADOR 1-800-10-7267 http://www.samsung.com/latin (Spanish) http://www.samsung.com/latin_en (English) EL SALVADOR 800-6225 http://www.samsung.com/latin (Spanish) http://www.samsung.com/latin_en (English) GUATEMALA 1-800-299-0013 http://www.samsung.com/latin (Spanish) http://www.samsung.com/latin_en (English) HONDURAS 800-27919267 http://www.samsung.com/latin (Spanish) http://www.samsung.com/latin_en (English) JAMAICA 1-800-234-7267 http://www.samsung.com NICARAGUA 00-1800-5077267 http://www.samsung.com/latin (Spanish) http://www.samsung.com/latin_en (English)
Page 273: Responsibility For The Pay Service (Cost To Customers)
― When the service is requested, in spite of in warranty, we may charge you for a visit from a service • Use of supplies or separatly sold product unspecified by Samsung. technician in the following cases. • Repair from a person besides an engineer of outsourcing service company or partner of Samsung Electronics Co., Ltd. Not a product defect •...
Page 274: Optimum Picture Quality And Afterimage Burn-In Prevention
Optimum Picture Quality and Afterimage Burn-in Prevention Optimum Picture Quality • To enjoy the optimum picture quality, go to Control Panel on your PC and adjust the resolution and refresh rate as follows. The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected. - Resolution: 1920 x 1080 - Vertical frequency (refresh rate): 56 ~ 75 Hz •...
Page 275: Prevention Of Afterimage Burn-In
Prevention of Afterimage Burn-in What is afterimage burn-in? Afterimage burn-in should not occur when the LCD panel is operating normally. Normal operation refers to a continuously changing video pattern. If the LCD panel displays a fixed pattern for an extended period of time (more than 12 hours), a slight Black Matrix Color-Filter Common...
Page 276 • Avoid combinations of a text color and background color of contrasting brightness. ― Avoid using grey as it may contribute to afterimage burn-in. ― Avoid using colors of contrasting brightness (black and white; grey). - Brightness: refers to the lightness or darkness of a color which varies TIME TIME...
Page 277: License
License Manufactured under license from Dolby Laboratories. DivX Certified Ⓡ to play DivX Ⓡ video up to HD 1080p, including premium content. Dolby and the double-D symbol are trademarks of Dolby Laboratories. DivXⓇ, DivX CertifiedⓇ and associated logos are trademarks of DivX, Inc. and are used under license.
Page 278: Terminology
Terminology 480i / 480p / 720p / 1080i / Non-interlace Mode and Interlace Vertical Frequency____ The product Component ports (green, blue and DVD (Digital Versatile Disc)____ DVD 1080p____ Each of the scanning Mode____ Non-interlace mode displays a single image many times red)____ The component ports, which refers to a CD-sized mass storage disk rates above refers to the number of...
