Page 1
® 3-3. Using the Bluetooth audio system ® ∗ Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 2
® 3-3. Using the Bluetooth audio system ■ ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Compatible models ● ® Bluetooth specifications: Ver. 1.2 ● Following Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 •...
Page 3
® 3-3. Using the Bluetooth audio system CAUTION ■ FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC/ IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system ■ Audio unit Display Track title, Artist name, Album name, Elapsed time, “Streaming Audio”, etc. is displayed. Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item Bluetooth-Audio...
Page 5
® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable to the operation of the Bluetooth audio sys- tem without the need to check the display or operate ■...
Page 6
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: STEP Press and hold...
Page 7
® 3-3. Using the Bluetooth audio system STEP Input the passkey into the portable player. Refer to the manual that comes with the portable player for the oper- ation of the portable player. Guidance for registration completion is heard. ® If the portable player has a Bluetooth phone, the phone can be reg- istered at the same time.
Page 8
® 3-3. Using the Bluetooth audio system ■ When using a voice command For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. ■ Situations that the system may not recognize your voice ●...
® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Power Volume Selecting a track/ Selector knob fast-forwarding Selecting an album and reversing Playback Displaying text messages Playback/pause Selecting an album Press “∨” or “∧” on Selecting tracks Press “∧”...
Page 10
® 3-3. Using the Bluetooth audio system Fast-forwarding and reversing tracks ∧ Press and hold “ ” or “∨” on Switching the display Press Each time is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed time Using the steering wheel audio switches →P.
® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: ■...
Page 12
® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio Players (Pair audio player)” using a voice com- mand or , and perform the procedure for registering a portable player. (→P. 393) Selecting a portable player to be used STEP Select “Select Audio Player”...
Page 13
® 3-3. Using the Bluetooth audio system STEP Press the talk switch and say “From car” or “From audio”, and select “Confirm” using a voice command or Vehicles with smart key system: If “From car” is selected, the porta- ble player will be automatically connected whenever the “ENGINE START STOP”...
Page 14
® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audio Players” using a voice command or . The list of registered portable players will be read aloud. When listing is complete, the system returns to “BT Audio Setup”. Pressing the talk switch while the name of a portable player is being read aloud selects the portable player, and the following functions will become available:...
Page 15
® 3-3. Using the Bluetooth audio system Deleting a registered portable player STEP Select “Delete Audio Player” using a voice command or STEP Select the portable player to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a.
