- Page 1 Use & Care Guide Model: 415.16135110 ® ® ® P/N G524-001-010801 Sears Brands Management Corporation Hoffman Estates, IL 60179 U.S.A. www.kenmore.com www,sears,com Model 464224411 ° Oct_20_10...
-
Page 2: California Proposition
CALIFORNIA PROPOSITION If you smell gas: 1. Combustion by-products produced when using this |. Shut off gas to the appliance. product contain chemicals known to the State of 2. Extinguish any open flame. California to cause cancer, birth defects, and other reproductive harm. - Page 3 For Your Safety ........KENMORE GRILL WARRANTY Grill Information Center ......2 One Year Full Warranty on Kenmore Grill Product Record Information......2 If this grill fails due to a defect in material or workmanship Safety Symbols ........2 within 9_e year from the date of purchase, carl 1-800-4-MY-...
- Page 4 LP Tank * The LP Tank used with your grill must meet the following requirements: * Use LP Tanks only with these required measurements: 12" (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) x, II capacity maximum.
- Page 5 LP Tank Exchange Connecting Regulator To The LP Tank * Many retailers that sell grills offer you the option of l. LP tank must be properly secured onto grill. (Refer to replacing your empty LP tank through an exchange service. assembly section.) Use only those reputable...
- Page 6 Leak Testing Valves, Hose and Regulator 1. Turn all grill control knobs to OFF. 2. Be sure regulator is tightly connected to LP tank. 3. Completely open LP tank valve by turning OPD hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
- Page 7 Safety Tips LP cylinder valve, check the coupling nut Before opening for tightness. When grill is not in use, turn off all control knobs and LP cylinder valve. For Safe Use of Your Grill and to Avoid Serious Never move grill while in operation or still hot. Injury: Use long-handled barbecue utensils and oven mitts to •...
- Page 8 Burner Flame Check " Remove cooking grates and flame tamers. Light burners, rotate knobs from Hi to LOW. You should see a smaller flame in LOW position than seen on Hi. Perform burner Turn controls and gas source or tank OFF when flame check on sideburner,...
-
Page 9: Spider Alert
3. Remove carryover tubes and burners. CAUTION 4. Detach electrode from burner. NOTE: Removal/Detachment method will depend on the burner configuration. See different configurations illustrations below. SPIDER ALERT! 5. Carefully lift each burner up and away from valve openings. We suggest three ways to clean the burner tubes. - Page 10 Indirect Cooking Food Safety Poultry and large cuts of meat cook slowly to perfection Food safety is a very important part of enjoying the grill by indirect heat. Place food over unlit burner(s); the outdoor cooking experience. To keep food safe from heat from lit burners circulates gently throughout the grill,...
- Page 11 Qty Description Part # Qty Description Part# LOCKING CASTER G515-OO82-W1 SIDEBURNER PAN G515-0083-W2 FIXEDCASTER G350-OO24-W1 G501-0070-W1 LID, F/SIDE BURNER BOTTOM SHELF G524-O600-W1 G508-0033-W1 RUBBER BUMPER, F/SB DOOR MAGNET ASSEMBLY G501-OO16-W1 SIDEBURNER G511-5100-W1 TOWEL HOLDER G524-7000-W1 G515-0039-W1 ELECTRODE, F/SIDEBURNER RIGHTSIDEPANEL G524-O400-W1 G401-0038-W1 ELECTRODE WIRE, F/SIDEBURNER LEFTSIDEPANEL...
- Page 12 12,464224411...
- Page 13 Place bottom shelf upside down. Insert Bent U Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the bottom shelf until secure. Remove the Bent U Pin and repeat for remaining casters.
- Page 14 Attach towel holder to cart right side panel using two 1/4-20xl/2 _' screws, 7mm lock washers 7ram fiat washers and 1/4 _' nut. 7mm lock washer 7mm fiat washer 1/4 _' nut Qty.2 Qty.2 Qty.2 1/4-20xl/2 _' screw Qty.2 Towel holder 1/4-20xl/2 _' screw 14 °464224411...
- Page 15 Attach side panels to bottom shelf using three 1/4-20xl/2" screws, 7mm lock washers, and 7mm fiat washers per panel. IMPORTANT: Panel with Electronic Ignition Module hole must be attached to Left side of bottom shelf. 7mm lock washer 7mm fiat washer Qty.6 Qty.6 1/4-20xl/2"...
- Page 16 Place lower back panel between side panels at rear of bottom shelf. Secure lower back panel to side panels using two 1/4-20xl/2 _ screws, 7mm lock washers and 7mm fiat washers on each side. Secure lower back panel to bottom shelf using one 1/4-20xl/2 _ screw, 7mm lock washer and 7mm fiat washer.
- Page 17 inside of cart, insert tank exclusion wire shelf ends into lower back panel, shown A. Attach front left side of wire shelf to cart left side panel with one #8-32x3/8" screw, 4mm lock washer and 4mm fiat washer. Attach leg to bottom shelf with one #8-32X3/8"...
- Page 18 Insert front brace between cart side panels. Make sure door hinge pins are on the top side and facing the front. Secure using one 1/4-20x11/2 '' screw, 7mm lock washer and 7mm fiat washer on each side. 7mm lock washer 7mm fiat washer Qty.2 Qty.2...
- Page 19 insert tank heat shield tabs(without holes) into slots between upper back panel and lower back panel, shown A. Attach tank heat shield front tabs(with hotes) under front brace using two #8x3/8" self-tapping screws, shown B. #8x3/8" self-tapping screw Qty.2 464224411 °...
- Page 20 This step requires two people to lift and position grill head onto cart. Remove tie wrap holding regulator hose to bottom of grill head. Remove packing material. Loosen tie wrap holding ignition wires to bottom of grill head. Retain tie wrap to bundle ignition wires together. Carefully lower the grill head onto the cart, aligning slots at bottom...
- Page 21 Inside of cart, connect the five wires from burner electrodes into the back of Electronic Ignition module, positions 1 - 5, shown A. Connect the two wires [(a) and (b)] from switch wiring harness into the back of Electronic Ignition module, shown A.
- Page 22 Hang right side shelf onto shelf brackets on right side of firebox, shown A. Putt extended shelf out halfway to create hand space to insert and tighten hardware. You may need an assistant to help you securely tighten shelf into place° Attach right side shelf using two 1/4-20x3/4"...
- Page 23 Hang sideburner shelf onto shelf brackets on left side of firebox, shown Ao Attach sideburner shelf using two 1/4-20x3/4" screws, 7mm fiat washers, 7mm lock washers and 1/4" nuts, shown B/C. You may need an assistant to help you securely tighten shelf into place. Attach front of shelf using two #8x3/8"...
- Page 24 First, remove the two screws and lock washers attached to the sideburner valve bracket. Position sideburner valve bracket beneath sideburner shelf fascia so that valve stem comes through larger center hole in fascia. Align the holes on valve bracket with left and right holes on fascia. Attach using lock washers and screws that were removed from bracket.
- Page 25 On each side of grill head, secure rear side shelf to upper back panel using one 1/4-20x11/2 '' screw, 7mm lock washer and 7mm fiat washer. 7mm flat washer 7mm lock washer Qty.2 Qty.2 1/4-20xl 1/2" screw Qty.2 1/4-20x Upper back panel Place sideburner cooking grate onto sideburner shelf.
- Page 26 Insert the pin on bottom of right door into hole in bottom shelf. Press upper hinge pin in front brace, align hinge hole on top of the door, and release hinge pin into the door. Repeat for left door assembly....
- Page 27 Place cooking grates onto the flrebox as shown. To obtain sear marks in cooked meat, be sure to insert grates so that side with four corner feet faces down. Insert the two wire ends at rear of warming rack into holes in back of fire box. Front wires of warming rack rest on sides of flrebox.
- Page 28 LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use & Care section). Once cylinder has been filled and checked for leaks, place cylinder into hole in bottom shelf. Make sure cylinder valve is facing front of grill. Secure cylinder with cylinder screw under bottom shelf.
- Page 29 Steamer Tray Use I. Remove one grate from grin and replace with steamer tray accessory. 2. Do not fin water above water fin line, 3. Always use Steamer Handle Tool to move Steamer Basket or Steamer Cover when grin is hot. Never move the Steamer Water Tray when grill is hot.
-
Page 30: Electrical Issues
EMERGENCIES: Jf a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Gas leaking from • Damaged hose. • Turn off gas at LP cylinder or at source on natural gas systems. cracked/cut/burned If the hose is cracked or cut but not burned,... - Page 31 Troubleshootlng (continued) ELECTRONIC IGNMON: Burner(s) will not light using ignitor. No spark, no ignition noise. See Section I of Electronic Ignition System. (See Electronic Ignition Troubleshooting also) No spark, some ignition noise. See Section II of Electronic Ignition System. Sparks, but not at electrode or at full See Section III of Electronic...
- Page 32 Troubleshooting - Electronic Ignltion SECTION No sparks appear • Battery not installed • Check battery orientation. • Install battery (make sure that "+" and "-" any electrodes when properly. connectors are oriented correctly, with "÷'_ end up Electronic Ignition and "-" end down.) Button is pressed;...
- Page 33 464224411 o 33...
