Step 2—Installing the 8-port SAS RAID controller card
Introduction
This section describes how to install the 8-port SAS RAID controller card.
Procedure: installing the 8-port SAS RAID controller card
To install the card:
Step
1
2
4 LSI 8344 8-port SAS RAID controller card installation
Antenna House XSL Formatter (Evaluation) http://www.antennahouse.com/
Action
Release the PCI retainer levers by first pressing down on them and then out (1), and remove the applicable PCI slot
cover (2).
Install the 8-port SAS RAID controller card into an unused x4, x8, or x16 PCI Express slot in the chassis. Refer to the
service label on the access panel of your workstation to identify the PCI slots.
