Speed
Speed
Bake
Oven
Bake
Cl ock
bake
cl ean
ti m e
l i ght
Keep
Start
Cl ear
Broi l
Cl ean
Ti m er
w arm
ti m e
Oven
/ Off
On/Off
Preheat
Control s
Door Locked
FEB30S6DC.eps CFEB30S7DCA.eps BFEB30S6DSA.eps DFEB30S5DCA.eps
318046237.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB30S6DCB
38254381E40S2
Series
30" single
Color
stainless
Market
North America
Wiring Diagram
318046237
Owner's Guide
318200924
Installation Instructions 316201514
Service Data Sheet
316047413
Timer Guide
318200189
Publication No.
5995441010
05/07/06
(EN/SERVICE/ECL)
377
SINGLE ELECTRIC
WALL OVEN
Model No.
FEB30S6D
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FEB30S6DCB
Summary of Contents for Frigidaire FEB30S6DCB
-
Page 1: Wall Oven
Speed Speed Bake Oven Bake Cl ock bake cl ean ti m e l i ght Keep Start Cl ear Broi l Cl ean Ti m er w arm ti m e Oven / Off On/Off Preheat Control s Door Locked Product No. -
Page 2: Control Panel
Publication No: 5995441010 FEB30S6DCB CONTROL PANEL 07/05... - Page 3 FEB30S6DCB Publication No: 5995441010 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257300 Shield, oven top 318260100 Cover, box 318271517 Control Panel Assembly, steel/glass, stainless/black, w/touch pad 20 # 316418523 Clock/Timer, electronic, ES350W2 316021107 Screw, hex head, 8-32, silver 5303211311 Screw, 8 x 0.500 07/05 # Functional Parts * Non-Illustrated Parts...
- Page 4 Publication No: 5995441010 FEB30S6DCB BODY 07/05...
- Page 5 FEB30S6DCB Publication No: 5995441010 BODY POS. NO PART NO. DESCRIPTION 318259202 Back, main 318258900 Shield, insulation, upper 318262502 Rack, oven 5303317977 Pan, broiler 5303317976 Insert, broiler pan 12 # 318089917 Switch, light 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, oven light 3201911...
- Page 6 Publication No: 5995441010 FEB30S6DCB BODY 07/05...
- Page 7 FEB30S6DCB Publication No: 5995441010 BODY POS. NO PART NO. DESCRIPTION 318142100 Washer, motor, RH, convection 318317100 Adapter Assembly, vent tube, w/converter 318272900 Box, vent 318003000 Plate, shield 318123910 Deflector 5303324184 Screw, 8-18 x 5/16, black, (4) 318172904 Support, wire/glass 318014111 Spacer 318014700 Spacer, oven shield, (4)
- Page 8 Publication No: 5995441010 FEB30S6DCB DOOR 07/05...
- Page 9 FEB30S6DCB Publication No: 5995441010 DOOR POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260500 Baffle, door 318285057 Insulation, oven door 318285062 Insulation, oven door 316117500 Glass, oven door, heat barrier 318259605 Liner, door 5303311174 Screw, 10-24 x 3/8...
-
Page 10: Wiring Diagram
Publication No: 5995441010 FEB30S6DCB WIRING DIAGRAM 07/05...
