APSNUG.book Page vi Tuesday, May 4, 1999 11:13 AM Notices Use Conditions Notice: Canadian Users Remarque à l’intention des utilisateurs canadiens Important Safety Instructions...
Page 7
APSNUG.book Page vii Tuesday, May 4, 1999 11:13 AM...
APSNUG.book Page 5 Tuesday, May 4, 1999 11:13 AM Features Front Panel Component Headphone/Earphone port CD-ROM tray Stop/Eject button Skip/Forward button CD-ROM LED...
APSNUG.book Page 6 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started Component Increase Volume button Decrease Volume button Turbo LED Power LED Hard disk drive LED Power button 3.5-inch floppy disk drive eject button 3.5-inch floppy disk drive 3.5-inch floppy disk drive LED Rear Panel...
Page 17
APSNUG.book Page 7 Tuesday, May 4, 1999 11:13 AM Component System main power switch Voltage selector System power socket USB ports PS/2 mouse port PS/2 keyboard port Serial 2 port Parallel port Serial 1 port Speaker-out/Line-out port Line-in port Game/MIDI portt VGA/Monitor port Microphone-in port Add-on card brackets...
APSNUG.book Page 8 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started Connecting System Components Caution: Do not turn on the system main power switch on the rear panel of the system or plug the system in until you finish connecting all system components.
APSNUG.book Page 12 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started Connecting USB Devices (optional) Note: Most USB devices have a built-in USB port which allows you to daisy-chain other devices.
APSNUG.book Page 14 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started Turning Off Your Computer Note: You do not need to turn off the system main power switch on the rear panel every time you turn off your computer. Turn off the system main power switch only: - if you will not use your system for a long period of time.
APSNUG.book Page 15 Tuesday, May 4, 1999 11:13 AM Troubleshooting General failure Front panel light doesn’t work “Garbage” or nothing appears on the screen Warning! Never open the monitor case. The CRT monitor retains very high voltage levels even after the power is turned off. Refer all monitor service to qualified service technicians.
Page 26
APSNUG.book Page 16 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started Printer doesn’t work Add-on card fails intermittently If you receive an error message...
APSNUG.book Page 17 Tuesday, May 4, 1999 11:13 AM Error Messages Software Error Messages System Error Messages Error Message Corrective Action Memory Error at Replace the DIMMs. MMMM:SSSS:OOOOh (R:xxxxh, W:xxxxh) System Management Memory Replace the DIMMs. Keyboard Interface Error Check the keyboard interface circuit or change the keyboard.
Page 28
APSNUG.book Page 18 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started Error Message Corrective Action Pointing Device Error Reconnect or replace the pointing device. Pointing Device Interface Error Check the pointing device interface circuit. Pointing Device IRQ Conflict Enter Setup and change the IRQ setting of the PS/2 mouse.
Page 29
APSNUG.book Page 19 Tuesday, May 4, 1999 11:13 AM Error Message Corrective Action Parallel Port Conflict Change the onboard parallel port address in Setup or the parallel port address of the add-on card. Real-time Clock Error Check the RTC circuit or replace the battery.
APSNUG.book Page 20 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started Error Message Corrective Action Press Esc to turn off NMI, or Press Esc to reject NMI error or press any key to reboot any other key to reboot the system. Insert system diskette and Insert a bootable disk into the floppy press <Enter>...
Page 31
APSNUG.book Page 21 Tuesday, May 4, 1999 11:13 AM Note: If you do not know how to contact an authorized service center, call your distributor.
Page 32
APSNUG.book Page 22 Tuesday, May 4, 1999 11:13 AM Chapter 1 Getting Started...
APSNUG.book Page 27 Tuesday, May 4, 1999 11:13 AM Board Layout Component USB ports PS/2 mouse port ATX power connector CPU connector PCI-AGP-Memory controller 2-pin CPU fan connector Reset connector 3-pin CPU fan connector DIMM sockets Battery...
Page 38
APSNUG.book Page 28 Tuesday, May 4, 1999 11:13 AM Chapter 2 System Board Information Component Floppy disk drive connector IDE 1 connector IDE 2 connector AGP slot Audio controller PCI-to-ISA bus controller Wake-on LAN connector Power/Suspend LED connector Power button connector Modem ring-in connector PCI slots System BIOS chip...
Page 39
APSNUG.book Page 29 Tuesday, May 4, 1999 11:13 AM Component PS/2 keyboard port...
APSNUG.book Page 30 Tuesday, May 4, 1999 11:13 AM Chapter 2 System Board Information Jumpers and Connectors Jumper Function and Settings Keyboard Turn-on Function Enabled Disabled (default) Audio Line Type 1-3, 2-4 Line out (default) 3-5, 4-6 Speaker out Password Check Disabled (default) Enabled...
Page 41
APSNUG.book Page 31 Tuesday, May 4, 1999 11:13 AM Jumper Function and Settings CPU Core Clock Multiplier Switch 1 Switch 2 Switch 3 Switch 4 Ratio 3.5 (def) Connector Function Wake-on LAN Reserved for USB daughtercard Upper port: mouse; Lower port: keyboard ATX power 2-pin CPU fan Hard disk drive (HDD) light emitting diode (LED)
Page 42
APSNUG.book Page 32 Tuesday, May 4, 1999 11:13 AM Chapter 2 System Board Information Connector Function CN13 IDE 2 CN14 IDE 1 CN15 CD input CN16 Fax-voice-modem CN17 Modem ring in CN18 Power / suspend LED Reset 3-pin CPU fan Power button...
APSNUG.book Page 33 Tuesday, May 4, 1999 11:13 AM Floppy Disk / Hard Disk Support IDE Connector Master Slave IDE 1 (CN14) Hard disk 0 Hard disk 1 IDE 2 (CN13) Hard disk 2/IDE CD-ROM Hard disk 3...
APSNUG.book Page 37 Tuesday, May 4, 1999 11:13 AM Wake-on LAN...
Page 48
APSNUG.book Page 38 Tuesday, May 4, 1999 11:13 AM Chapter 2 System Board Information...
Page 49
APSNUG.book Page 39 Tuesday, May 4, 1999 11:13 AM
Chapter 3...
Page 50
APSNUG.book Page 40 Tuesday, May 4, 1999 11:13 AM
! "
...
Page 51
APSNUG.book Page 41 Tuesday, May 4, 1999 11:13 AM Note: If you repeatedly receive Run Setup messages, the battery may be bad. In this case, the system cannot retain configuration values in CMOS. Ask a qualified technician for assistance.
APSNUG.book Page 42 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Entering Setup Important! You must press Ctrl-Alt-Esc simultaneously while the system is booting. This key combination does not work during any other time.
Page 53
APSNUG.book Page 43 Tuesday, May 4, 1999 11:13 AM Note: The F8 key works only when you are in the main menu. This means that you can activate the Advanced Level only when you are in the main menu. Also, items marked by an ( * ) are only visible in the Advanced Level. !
APSNUG.book Page 44 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information System Information System Information...
Page 55
APSNUG.book Page 45 Tuesday, May 4, 1999 11:13 AM Description Format Parameter Processor Specifies the type of processor currently installed in your system. Processor Specifies the speed of the Speed in MHz Speed processor currently installed in your system. Internal Cache Specifies the first-level or the Cache size in KB Size...
Page 56
APSNUG.book Page 46 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Description Format Parameter IDE Secondary Specifies the current Drive type, Channel Master configuration of the IDE capacity device connected to the master port of the secondary IDE channel. IDE Secondary Specifies the current Drive type,...
Page 57
APSNUG.book Page 47 Tuesday, May 4, 1999 11:13 AM Description Format Parameter PS/2 Mouse Indicates if there is a mouse Displays Installed connected to your system. if there is a mouse This is automatically detected detected; by BIOS. otherwise, it displays None.
APSNUG.book Page 48 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Product Information Product Information Parameter Description Product Name Displays the model name of your system System S/N Displays your system’s serial number Main Board ID Displays the system board’s identification number Main Board S/N Displays your system board’s serial number...
Page 59
APSNUG.book Page 49 Tuesday, May 4, 1999 11:13 AM Parameter Description SM BIOS version Specifies the version of the SM BIOS utility installed in your system. The System Management (SM) BIOS allows you to check your system hardware components without actually opening your system.
APSNUG.book Page 50 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Disk Drives Disk Drives " Parameter Description Options Floppy Drive A / B Allows you to configure None your floppy drive 360 KB, 5.25-inch 1.2 MB, 5.25-inch 720 KB, 3.5-inch 1.44 MB, 3.5-inch 2.88 MB, 3.5-inch...
Page 61
APSNUG.book Page 51 Tuesday, May 4, 1999 11:13 AM Parameter Description Options IDE Primary Lets you configure the hard Channel Slave disk drive connected to the slave port of IDE channel 1. IDE Secondary Lets you configure the hard Channel Master disk drive connected to the master port of IDE channel IDE Secondary...
Page 62
APSNUG.book Page 52 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information " Parameter Description Options Type Lets you specify the type of hard Auto, None, or disk installed in your system. If User. The User you want BIOS to automatically setting allows you configure your hard disk, select to enter your...
Page 63
APSNUG.book Page 53 Tuesday, May 4, 1999 11:13 AM Parameter Description Options Hard Disk Enhances your hard disk Auto or Disabled Block Mode performance by allowing data transfer in blocks (multiple sectors) at a rate of 256 bytes per cycle. This parameter appears only in the Advanced Level.
APSNUG.book Page 54 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Onboard Peripherals " Parameter Description Options Serial Port 1 / 2 Let you enable or disable Enabled or Disabled the serial ports. Base Address Lets you set a logical base 3F8h (for serial port address for each serial 1), 2F8h (for serial...
Page 65
APSNUG.book Page 55 Tuesday, May 4, 1999 11:13 AM Parameter Description Options Parallel Port Lets you enable or disable Enabled or Disabled the parallel port. Base Address Lets you set a logical base 3BCh, 378h, 278h address for the parallel port.
APSNUG.book Page 56 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Onboard Device Settings " Parameter Description Options Floppy Disk Lets you enable or disable Enabled or Disabled Controller the onboard floppy disk controller. IDE Controller Lets you enable or disable Primary, Both, or the onboard primary, Disabled...
Page 67
APSNUG.book Page 57 Tuesday, May 4, 1999 11:13 AM Parameter Description Options USB Legacy Lets you activate or Enabled or Disabled Mode deactivate the USB keyboard connected to your system. When activated, the USB keyboard functions in a DOS environment. Onboard Audio Lets you activate or Enabled or Disabled...
APSNUG.book Page 58 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Power Management " Parameter Description Options Power Allows you to reduce the Enabled or Management Mode system’s power consumption. Disabled When enabled, the IDE hard disk and system timers become configurable.
Page 69
APSNUG.book Page 59 Tuesday, May 4, 1999 11:13 AM Parameter Description Options System Sleep Automatically puts the system 2, 5, 10, 15, 20, Timer to power-saving mode after a 30, 40, 50...120 specified period of inactivity. minutes, or Off Any keyboard or mouse action, or any activity detected from the IRQ channels resumes system operation.
APSNUG.book Page 60 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Boot Options Boot Options " Parameter Description Options Boot Sequence Allows you to specify the Floppy Disk, Hard boot search sequence. Disk, IDECD-ROM First Hard Disk Specifies whether the BIOS IDE or SCSI Drive utility will boot from an IDE...
Page 71
APSNUG.book Page 61 Tuesday, May 4, 1999 11:13 AM Parameter Description Options Silent Boot When enabled, BIOS is in Enabled or graphical mode and Disabled displays only an identification logo during POST and while booting. Then, the screen displays the operating system prompt (as in DOS) or logo (as in Windows 95).
APSNUG.book Page 62 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Date and Time Date and Time Parameter Description Options Date Lets you set the date Weekday: Sun, Mon, following the weekday- Tue, Wed, Thu, Fri, Sat month-day-year format. Month: Jan, Feb...Dec Day: 1 to 31 Year: 1980 to 2079...
APSNUG.book Page 63 Tuesday, May 4, 1999 11:13 AM System Security System Security " Parameter Description Options Setup Password Prevents unauthorized None or Present. The access to the BIOS utility. Present setting allows you to set a Setup password. For instructions on how to set a Setup password, refer to...
Page 74
APSNUG.book Page 64 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Parameter Description Options Power-on Secures your system None or Present. The Password against unauthorized use. Present settings Once you set this allows you to set a password, you have to type Power-on password.
APSNUG.book Page 65 Tuesday, May 4, 1999 11:13 AM Setting a Password You cannot enter the BIOS utility if a Setup password does not exist and JP7 is set to 2-3 (password check enabled). By default, JP7 is set to 1-2 (bypass password).
APSNUG.book Page 66 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information # Changing or Removing the Password "$""%"&!'" System Security. Setup Password Power-on Password Set or Change Password (")"*$!'" Setup Password Power-on Password None...
APSNUG.book Page 68 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Advanced Options Note: The Advanced Options selection is available only in the Advanced Level. Caution: Do not change any settings in the Advanced Options menu if you are not a qualified technician to avoid damaging the system.
APSNUG.book Page 69 Tuesday, May 4, 1999 11:13 AM Memory/Cache Options Memory/Cache Options " Parameter Description Options Internal Cache Lets you enable or disable Enabled or the primary cache memory, (CPU Cache) Disabled i.e., the CPU memory External Cache Lets you enable or disable Enabled or the secondary cache Disabled...
Page 80
APSNUG.book Page 70 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Parameter Description Options Memory at 15MB- To prevent memory System 16MB Reserved for address conflicts between or Add-on card the system and expansion boards, reserve this memory range for the use of either the system or an expansion board.
APSNUG.book Page 71 Tuesday, May 4, 1999 11:13 AM PnP/PCI Options " Parameter Description Options PCI IRQ Setting Allows you to automatically or Auto or Manual manually configure the Plug- and-Play (PnP) devices installed in your system. Refer to your device manual for technical information about the PCI card.
Page 82
APSNUG.book Page 72 Tuesday, May 4, 1999 11:13 AM Chapter 3 BIOS Information Parameter Description Options VGA Palette Enables the palette snooping Enabled or Snoop feature if you installed more Disabled than one VGA card in the system, allowing the control palette register (CPR) to manage and update the VGA RAM DAC (Digital Analog...
APSNUG.book Page 80 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Warning! Not turning off the system properly before you start installing the components may damage your system. Do not attempt the procedures described in the following sections unless you are a qualified service technician.
APSNUG.book Page 81 Tuesday, May 4, 1999 11:13 AM Opening the System Caution: Before you proceed, make sure that you have turned off the system and all peripherals connected to it. Read the preinstallation instructions on page 79. Removing the Housing Cover...
APSNUG.book Page 86 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Installing a DIMM Note: The DIMM socket is slotted to ensure proper installation. If you insert a DIMM but it does not fit easily into the socket, you may have inserted it incorrectly.
APSNUG.book Page 88 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Upgrading the CPU Removing the Pentium II CPU Note: Observe the ESD precautions on page 79 when installing or removing a system component.
APSNUG.book Page 90 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Installing a Pentium II CPU Note: Observe the ESD precautions on page 79 when installing or removing a system component.
APSNUG.book Page 91 Tuesday, May 4, 1999 11:13 AM Installing the Retention Mechanism...
Page 102
APSNUG.book Page 92 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Installing a Pentium II CPU with SEC-type Package...
Page 103
APSNUG.book Page 93 Tuesday, May 4, 1999 11:13 AM # Caution: The heatsink becomes very hot when the system is on. Never touch the heatsink with any metal or with your hands.
Page 104
APSNUG.book Page 94 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Installing a Pentium II CPU with SECC 2-type Package Note: Align the holes on the fan/heatsink with the fastener tabs. To make sure that the orientation of the fan/heatsink is correct, check if the black circular cable connector holder is positioned on top of the processor.
Page 106
APSNUG.book Page 96 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Note: If you find the processor card difficult to insert into the slot, do not force it. The orientation of the fan/heatsink may be incorrect. # Caution: The heatsink becomes very hot when the system is on.
APSNUG.book Page 97 Tuesday, May 4, 1999 11:13 AM Replacing the Hard Disk...
Page 108
APSNUG.book Page 98 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System...
Page 109
APSNUG.book Page 99 Tuesday, May 4, 1999 11:13 AM Make sure that the other ends of the floppy disk drive cables are connected to their corresponding connectors on the system board.
APSNUG.book Page 100 Tuesday, May 4, 1999 11:13 AM Chapter 4 Upgrading the System Installing and Removing Expansion Cards Removing an Expansion Card Installing a PCI Card...
