NOTE If you enter
Save all? (Y/N)
prompt appears, the changes will take effect, but will be lost if the terminal is reset or
powered off.
HP700 VT-100 Mode Configuration
The following procedure outlines the steps to configure the HP700 series terminal for VT-100 operation.
You may use either the arrow keys or the tab key to move between the setting options on the
NOTE
screen.
Be sure to save any configuration changes you make before proceeding to a new menu.
1. Press
[User System]
2. Press
[config keys]
3. Press
[terminal config]
4. Move to Terminal ID and enter "vt100".
5. Move to TermMode and, using the
6. Save the configuration.
7. Press the
[config keys]
8. Press the
[ansi config]
9. Move to multipage and, using the
(Enables screen scrolling).
10. Move to Backspace Def and, using the
11. Move to EM100 ID and, using the
12. Save the configuration.
rp24xx Server Optional PCI Web Console Cable Setup
The following describes how to install the cabling for the optional built in (PCI) web console:
• Connect the 25-pin end of the A5159-63001 adapter cable to the 25-pin connector on the Console/UPS Port
located on the rear of the rp24xx server.
• Connect the 9-pin, "Console", connector of a A5159-63001 adapter to a A5858-63001 adapter.
Plug the other end of the A5858-63001 adapter to the 9-pin connector on the optional built-in PCI web console
card.
Chapter 1
when the
N
key.
function key.
[f8]
function key.
[f5]
and
[Prev]
[f1]
function key.
[f8]
function key.
[f6]
and
[Prev]
[Prev]
and
[Prev]
[f1]
HP rp2400 Series of Servers - Basic Cable Connections
keys, select "EM100".
[Next]
keys, select "yes".
[Next]
and keys, select "Backspace/Del".
[Next]
keys, select "EM100".
[Next]
Console Connection and Configuration
