Bosch TDA2650GB Operating Instructions

Solving Minor Problems Yourself
Problem Possible Causes Solution
Temperature control (I) Turn the temperature control to
on a very low setting. the desired position.
The iron does
not work or is not
Check that the plug is inserted
heating up.
Connection problems.
into the mains socket correctly.
The clothes tend Temperature control (I) Turn the temperature control to
to stick. setting is too high. a lower setting.
Temperature control (I) Turn the temperature control to
setting is too low. a higher setting.
Steam regulator (A)
is set too high in Turn the steam regulator to a
conjunction with a low lower setting.
temperature.
You have pressed the
Water comes out
shot of steam button Wait 5 seconds between each
of the soleplate
(L) repeatedly wihhout press of the shot of steam
together with
waiting for 5 seconds button.
steam.
between each press.
Tap or part distilled
water has not been used Mix distilled water with tap
(see"Filling the water water as directed in the „Filling
tank" section) or other the water tank" section, and
products such as fragant never add any other products
water have been added to the water tank.
to the tank.
Steam regulator (A) in Turn the steam regulator to "1"
"0" or "calc" position. or "2" position.
No water in tank. Fill the tank.
Iron is not
steaming.
Remove the steam regulator
Scale obstruction of (A) and clean it. If this does not
internal components. help contact an Authorised
Technical Service Centre.
No water in the tank. Add water to the water tank.
Spray does not
Obstructed mechanism. Contact an Authorised
work.
Technical Service Centre.
Water comes
out from the
The steam regulator (A) Place the steam regulator in the
soleplate before
is not properly closed. "0" position.
plugging the
iron in.
Deposits come
Traces of lime scale are Carry out a cleaning cycle "(see
out through
coming out of the steam "Multiple de-scaling system"
the holes in the
chamber. section)
soleplate.
During first use: Certain
components on the
The iron begins appliance have been
This is completely normal and
to smoke when lightly greased at
will stop after a short while.
switched on. the factory and may
produce a little smoke
when initially heated.
Move the iron gently fromside
to side to re-start it.
Flashing lamp on Auto-shut off has been
top of handle (*) activated.
The lamp will then flash once
before it re-heats.
(*) Model dependent
You can download this manual from the local homepages of Bosch
Thank you for buying the TDA26 steam iron from Bosch. This iron has a
lightweight design and is built to perform.
These instructions contain valuable information about the unique features
of this iron and some hints to make ironing easier for you.
Please visit www.bosch-home.co.uk for more product information
or to register your product, just follow the link to the Online
guarantee registration.
Before using the Iron for the first time
Please carry out the following steps:
1. Remove the protective cover from the soleplate before using the iron.
2. While the iron is unplugged, fill the water tank (E) with tap water and
set the temperature control (I) to "max" by lining it up with the pointer
(H).
3. Plug the appliance into the mains and when the iron has reached the
correct temperature (the pilot light [K] goes out), set the steam regulator
(A) to the "2" position.
4. Hold the iron horizontally and repeatedly press the shot of steam button
(L). Any residue should come out of the soleplate (G). It may smoke
and smell – this is normal and will cease after a short while.
5. If necessary, carefully clean the soleplate down with a dry, folded cloth.
Cleaning and Maintenance
! Attention! Risk of burns!
For general cleaning, follow the information below:
Problem Solution
Dirty/lightly marked iron Clean the body of iron or soleplate with a
body or soleplate damp cloth then dry it..
Set the iron to its maximum temperature
Mark develops on
setting. Rub the iron a few times over with
soleplate during use
a dry cotton cloth folded several times.
While the iron is cold, iron a linen cloth
soaked in white vinegar. Then dampen a
Heavily stained soleplate
cloth with water and wipe the soleplate
clean and dry thoroughly.
DO NOT de-scale or clean the water tank with cleaning products or
solvents, as these could cause the iron to drip when using the steam
function.
DO NOT use a "professional steam cleaner" for cleaning the appliance.
DO NOT use sharp objects or abrasive products to clean the soleplate or
any other part of the appliance. To keep the soleplate in good condition,
do not allow it to come into contact with metal objects.
Customer Service
Great Britain
Bosch Customer Service
Grand Union House
Old Wolverton Road
Milton Keynes
MK12 5PT
UK +44 (0)844 892 8923
IRL +353 (0)1450 2655
www.bosch-home.co.uk
GUARANTEE TERMS
The terms of the guarantee for this appliance are in accordance with that
stated by our representative for the country in which it is sold. Details
of those conditions can be obtained from the retailer from whom the
appliance was purchased. The SALES RECEIPT must be presented when
making any claims against the terms of this guarantee. We reserve the
right to make technical modifications.
Environmental Care
This iron has been designed according to ecological criteria related to
sustainable development; analysing its whole lifecycle, from material
selection to its later reuse or recycling; evaluating the improvement
possibilities from a technical, ecological and environmental point of view.
Before throwing a used appliance away, you should make it noticeably
inoperable e.g. cut off the mains lead and be certain to dispose of it in
accordance with current laws and regulations.
Your retailer, town council or local council can give you detailed
information about these.
This appliance is labelled in accordance with
European Directive 2002/96/EG concerning used
electrical and electronic appliances (waste electrical
and electronic equipment – WEEE).
The guideline determines the framework for the
return and recycling of used appliances as applicable
throughout the EU.
Important
This iron has been designed according to ecological criteria,
related to the sustainable development; analyzing its whole
lifecycle, from material selection to its later reusing or recycling;
evaluating the improvement possibilities, from a technical,
economical and environmental point of view.
This appliance has been designed exclusively for domestic use
and must not be used for industrial purposes.
Carefully read through the operating instructions for the appliance
and safeguard them for future reference.

General safety instructions

• The iron must not be left unattended while it is
connected to the supply mains.
• Remove the plug from the socket before filling the
appliance with water or before pouring out the
remaining water after use.
TDA 26..
sensixx B1
Operating instructions
004 TDA26..GB/07/12
• The appliance must be used and placed on a stable
surface.
• When placed on its stand, make sure that the surface
on which the stand is placed is stable.
• The iron should not be used if it has been dropped,
if there are visible signs of damage or if it is leaking
water. It must be checked by an authorized Technical
Service Centre before it can be used again.
• With the aim of avoiding dangerous situations, any
work or repair that the appliance may need, e.g.
replacing a faulty mains cable, must only be carried
out by qualified personnel from an Authorised
Technical Service Centre.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
• Keep the iron and its cord out of reach of children less
than 8 years of age when it is energized or cooling
down.
• This appliance is to be connected and used in accordance with the
information stated on its characteristics plate.
• This appliance must be connected to an earthed socket. If it is
absolutely necessary to use an extension cable, make sure that it is
suitable for 16A and has a socket with an earth connection.
• If the safety fuse fitted in the appliance blows, the appliance will be
rendered inoperative. To restore normal operation the appliance will
have to be taken to an authorised Technical Service Centre.
• In order to avoid that, under unfavourable mains conditions, phenomena
like transient voltage drops or lighting fluctuations can happen, it is
recommended that the iron is connected to a power supply system
with a maximum impedance of 0.27Ω . If necessary, the user can ask
the public power supply company for the system impedance at the
interface point.
• The appliance must never be placed directly under the tap to fill the
water tank.
• Unplug the appliance from the mains supply after each use, or if a fault
is suspected.
• The electrical plug must not be removed from the socket by pulling
the cable.
• Never immerse the iron in water or any other fluid.
• Do not leave the appliance exposed to weather conditions (rain, sun,
frost, etc.)
