ENGLISH
Digital Video Camcorder
VP-D30(i)/D31(i)/D33(i)/
D34(i)/D39(i)
AF
Auto Focus
CCD
Charge Coupled Device
LCD
Liquid Crystal Display
Owner's Instruction Book
Before operating the unit, please read this instruction
book thoroughly, and retain it for future reference.
This product meets the intent of
Directive 89/336 CEE, 73/23 CEE, 93/68 CEE.
VP-D30(i)/D31(i)/D33(i)/
AF
CCD
LCD
ELECTRONICS
CEE
D34(i)/D39(i)
89/336CEE 73/23 CEE 93/68
AD68-00654K
