Dell™ PowerVault™ ML6000
Basic SNMP Reference Guide
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

Advertisement

Table of Contents
loading

Related Manuals for Dell PowerVault ML6000

Summary of Contents for Dell PowerVault ML6000

  • Page 1 Dell™ PowerVault™ ML6000 Basic SNMP Reference Guide w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
  • Page 2 Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

  • Page 3: Table Of Contents

    Fibre Channel Port World Wide Node Name......... . 16 Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 4 Fibre Channel Port World Wide Port Name (WWPN) ........16 Fibre Channel Port Loop ID .
  • Page 5 Blade Host Name ............63 Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 6 Dell Library MIB Content ........

  • Page 7: About This Guide And Your Product

    Reliability, Availability, and Serviceability (RAS) ticket system. For information about the ML6000 library itself, refer to the PowerVault ML6000 Tape Library User’s Guide. The ML6000 library supports SNMP by publishing a MIB that can be queried to obtain the status of the library and many of its individual components.

  • Page 8: Other Documents You Might Need

    The following document is also available for this product. This document can be found on the product documentation CD. • Dell PowerVault ML6000 Tape Library User’s Guide Getting More Information or Help More information about this product is available at http://support.dell.com. About This Guide and Your Product...

  • Page 9: Description

    SET commands are currently not enabled on the ML6000 library. All ML6000 MIB variables are supported by Dell for remote management of the library. Specific ML6000 library SNMP characteristics include: •...

  • Page 10: Snmpv3

    Using the library’s SNMP Trap Registrations feature, register the host’s IP address, transport protocol, and UDP port number. Registration informs the ML6000 library to send traps to the host. For additional details about registering a host with the ML6000 library, refer to the PowerVault ML6000 Tape Library User’s Guide. SNMP Queries SNMP queries, or GET queries, can be initiated on a periodic basis by the framework application.

  • Page 11: Snmp Community Strings

    Go to Setup > Network Management > SNMP. Do one of the following: • Click the Authentication traps check box to enable authentication traps. • Remove the check from the Authentication traps check box to disable authentication traps. Click Apply. Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 12 Description...

  • Page 13: Mib Variables - Drive Information

    Physical Drive Information Physical Drive Readiness Name: overallPhDriveReadinessStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).overallPhDriveReadinessStatus(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDrive Next sibling: physicalDriveTable Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: OnlineState Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 14: Physical Drive Serial Number

    Status: current Max access: read-only Description: Overall drive readiness. Physical Drive Serial Number Name: phDriveSerialNumber Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveSerialNumber(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveIndex Next sibling: phDriveModel Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access:read-only...

  • Page 15: Physical Drive Vendor

    Parent: physicalDriveEntry Prev sibling: phDriveVendor Next sibling: phDriveLocation Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Drive generation type. Physical Drive Location Name: phDriveLocation Type: OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 16: Physical Drive Firmware

    OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveLocation(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveType Next sibling: phDriveFirmwareVersion Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Location of the drive in the library. Physical Drive Firmware Name: phDriveFirmwareVersion Type: OBJECT-TYPE OID:1.3.6.1.4.1.3764.1.10.10.11.3.1.7...

  • Page 17: Physical Drive Library Serial Number

    Description: Serial number of the library that this drive resides in as reported in SCSI INQUIRY command. Physical Drive State Name: phDriveState Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveState(10) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 18: Physical Drive Health Status

    Prev sibling: phDriveLibrarySerialNumber Next sibling: phDriveRasStatus Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: OnlineState Status: current Max access: read-only Description: Device SCSI state. Physical Drive Health Status Name: phDriveRasStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveRasStatus(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveState...

  • Page 19: Physical Drive Interface Type

    Name: phDriveScsiLun Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.14 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveScsiLun(14) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveInterfaceType Next sibling: phDriveScsiId Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 20: Physical Drive Scsi Id

    Max access: read-only Description: SCSI LUN of the device. Physical Drive SCSI ID Name: phDriveScsiId Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.15 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveScsiId(15) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prevsibling: phDriveScsiLun Next sibling: phDriveLoads Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only...

  • Page 21: Physical Drive Physical Serial Number

    10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortType(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortIndex Next sibling: fcPortWWNodeName Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FCPortType Status: current Max access: read-only Description: Fibre Channel port type. Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 22: Fibre Channel Port World Wide Node Name

    Fibre Channel Port World Wide Node Name Name: fcPortWWNodeName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortWWNodeName(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortType Next sibling: fcPortWWPortName Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: 8-byte value representing the drive’s World Wide Node Name.

  • Page 23: Fibre Channel Port Loop Id Mode

    Description: Loop ID mode for Fibre Channel drives; undefined for drives of other interface types. Controls negotiation of the port ID on the Fibre Channel connection. Fibre Channel Port ID Name: fcPortId Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.7 Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 24: Fibre Channel Port Negotiated Speed

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortId(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortLoopIdMode Next sibling: fcPortNegotiatedSpeed Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Port ID for fabric attached Fibre Channel drives; undefined for drives of other interface types. Fibre Channel Port Negotiated Speed Name: fcPortNegotiatedSpeed Type: OBJECT-TYPE...

  • Page 25: Fibre Channel Port Firmware Revision

    Max access: read-only Description:Firmware revision number/identifier for this Fibre Channel controller. Fibre Channel Port Frame Size Name: fcPortFrameSize Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortFrameSize(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortFWRev Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 26: Fibre Channel Port Drive Serial Number

    Next sibling: fcPortDriveSerialNumber Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Fibre Channel frame size. Fibre Channel Port Drive Serial Number Name: fcPortDriveSerialNumber Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.12 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortDriveSerialNumber(12) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortFrameSize...

  • Page 27: Library Interfaces - Sas

    SAS Port RAS Status Name: sasPortRasStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.3.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).sasPortTable(3).sasPortEntry(1).sasPortRasStatus(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: sasPortEntry Prev sibling: sasPortAddress Next sibling: sasPortNegotiatedSpeed Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 28: Sas Port Negotiated Speed

    Status: current Max access: read-only Description: Currently not applicable. SAS Port Negotiated Speed Name: sasPortNegotiatedSpeed Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.3.1.4 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).sasPortTable(3).sasPortEntry(1).sasPortNegotiatedSpeed(4) Module: ADIC-TAPE-LIBRARY-MIB Parent: sasPortEntry Prev sibling: sasPortRasStatus Next sibling: sasPortFWRev Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: SASPortSpeed Status: current Max access: read-only...

  • Page 29: Sas Port Drive Serial Number

    OID: 1.3.6.1.4.1.3764.1.10.10.15.3.1.7 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).sasPortTable(3).sasPortEntry(1).sasPortLogicalLibrarySN(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: sasPortEntry Prev sibling: sasPortDriveSerialNumber Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Logical library serial number. Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 30: Library Interfaces - Scsi

    Library Interfaces - SCSI SCSI Controller RAS Status Name: scsiControllerRasStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.2.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerRasStatus(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerIndex Next sibling: scsiControllerSpeed Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Currently not applicable.

  • Page 31: Scsi Controller Role

    10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerIoCard(5) Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerRole Next sibling: scsiControllerMaxIds Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: SCSICtrlCardType Status: current Max access: read-only Description: Type of SCSI controller hardware. Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 32: Scsi Controller Maximum Ids

    SCSI Controller Maximum IDs Name: scsiControllerMaxIds Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.2.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerMaxIds(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerIoCard Next sibling: scsiControllerMaxLuns Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: current Max access: read-only Description: Maximum Number of IDs for this SCSI controller.

  • Page 33: Scsi Controller Firmware Revision

    Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Firmware revision for this SCSI controller. SCSI Controller Drive Serial Number Name: scsiControllerDriveSerialNumber Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.2.1.10 Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 34: Scsi Controller Logical Library Serial Number

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerDriveSerialNumber(10 Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerFWRev Next sibling: scsiControllerLogicalLibrarySN Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Serial number of tape drive. SCSI Controller Logical Library Serial Number Name: scsiControllerLogicalLibrarySN Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.2.1.11...

  • Page 35: Mib Variables - Library System Information

    Library IP Address Name: libraryIpAddress Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryIpAddress(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Next sibling: librarySNMPAgentDescription Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 36: Library Snmp Agent Description

    Description: The IP address this SNMP agent. If the library has only an IPv4 address, or both an IPv4 and an IPv6 address, then the IP address is displayed in IPv4 format (xxx.xxx.xxx.xxx). If the library only has an IPv6 address, then it will report an IPv6 format address. Library SNMP Agent Description Name: librarySNMPAgentDescription Type: OBJECT-TYPE...

  • Page 37: Library Vendor

    Parent: tapeLibrarySystem Prev sibling: libraryVendor Next sibling: libraryDescription Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Library serial number. Library Description Name: libraryDescription Type: OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 38: Library Model

    OID: 1.3.6.1.4.1.3764.1.10.10.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryDescription(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: librarySerialNumber Next sibling: libraryModel Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Description of library. Library Model Name: libraryModel Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.7 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB(...

  • Page 39: Library Url

    Composed syntax: DisplayString Status: current Max access: read-only Description: URL of the library's management application. Library Product Name Name: libraryProductName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryProductName(10) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: libraryURL Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 40: Library Firmware Version

    Next sibling: libraryFirmwareVersion Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Product name of the library. Library Firmware Version Name: libraryFirmwareVersion Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryFirmwareVersion(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: libraryProductName Numerical syntax: Octets Base syntax: OCTET STRING...

  • Page 41: Aggregated Main Door Status

    Name: aggregatedIEDoorStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.14.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalLibrary(14).aggregatedIEDoorStatus(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalLibrary Prev sibling: aggregatedMainDoorStatus Next sibling: numStorageSlots Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: IEDoorStatus Status: current Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 42: Number Of Storage Slots

    Max access: read-only Description: Reports "open" if any door is open. Otherwise, reports "closedandLocked" or "closedandUnlocked." Number of Storage Slots Name: numStorageSlots Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.14.4 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalLibrary(14).numStorageSlots(4) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalLibrary Prev sibling: aggregatedIEDoorStatus Next sibling: numIESlots Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32...

  • Page 43: Number Of Physical Drives

    10).physicalLibrary(14).robot(30).robotState(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: robot Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RoboticsReadiness Status: current Max access: read-only Description: Device SCSI state. Logical Library Number of Logical Libraries Name: numLogicalLibraries Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 44: Logical Library Name

    Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).numLogicalLibraries(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibrary Next sibling: logicalLibraryTable Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Number of existing logical libraries (partitions). Logical Library Name Name: logicalLibraryName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.2...

  • Page 45: Logical Library Model

    Composed syntax: DisplayString Status: current Max access: read-only Description: Logical Library Model Logical Library Assigned LUN Name: logicalLibraryAssignedLun Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.5 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryAssignedLun(5) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryModel Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 46: Logical Library Media Domain

    Next sibling: logicalLibraryMediaDomain Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Assigned LUN of this library's (virtual) SCSI media changer. Logical Library Media Domain Name: logicalLibraryMediaDomain Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryMediaDomain(6) Module: ADIC-TAPE-LIBRARY-MIB...

  • Page 47: Logical Library State

    Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.9 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryNumSlots(9) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryState Next sibling: logicalLibraryNumIE Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 48: Logical Library Number Of I/E Slots

    Description: Number of storage elements. Logical Library Number of I/E Slots Name: logicalLibraryNumIE Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryNumIE(10) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryNumSlots Next sibling: logicalLibraryNumTapeDrives Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Number of Import/Export (I/E) elements.

  • Page 49: Logical Library Storage Element Address

    Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: First import/export element address of the partition. Logical Library Tape Drive Element Address Name: logicalLibraryTapeDriveElemAddr Type: OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 50: Logical Library Changer Device Address

    OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.14 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryTapeDriveElemAddr(14) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryIEElemAddr Next sibling: logicalLibraryChangerDeviceAddr Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: First data transfer element address of the partition. Logical Library Changer Device Address Name: logicalLibraryChangerDeviceAddr Type: OBJECT-TYPE...

  • Page 51: Blade Location

    Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Description: Blade location. Blade IP Name: bladeIP Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeIP(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 52: Blade World Wide Node Name

    Prev sibling: bladeLocation Next sibling: bladeWWNodeName Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Description: Blade IP address. Blade World Wide Node Name Name: bladeWWNodeName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.4 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeWWNodeName(4) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeIP...

  • Page 53: Blade Health Check Level

    5: deviceReady(4) Description: Scrutiny level of health check function. Blade Health Check Interval Name: bladeHealthCheckInterval Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.7 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeHealthCheckInterval(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeHealthCheckLevel Next sibling: bladeFWRev Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 54: Blade Firmware Revision

    Numerical syntax: Gauge (32 bit) Base syntax: Gauge Composed syntax: Gauge Status: mandatory Max access: read-only Description: Health check interval in minutes. Blade Firmware Revision Name: bladeFWRev Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.8 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeFWRev(8) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeHealthCheckInterval Next sibling: bladeSerialNumber Numerical syntax: Octets Base syntax: OCTET STRING...

  • Page 55: Blade Evps Enabled

    Name: bladeMaxHostLun Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeMaxHostLun(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeEVPSEnabled Next sibling: bladeState Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: mandatory Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 56: Blade State

    Max access: read-only Description: The number of devices one host can see. Blade State Name: bladeState Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.12 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeState(12) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeMaxHostLun Next sibling: blHPFLinkDownThreshold Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: BladeState Status: mandatory Max access: read-only...

  • Page 57: Blade Host Port Failover Error Recovery Mode

    Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FcHPFRecoveryType Status: mandatory Max access: read-only Description: Used to set the global recovery mode for failures that happen due to Link Down errors. Values: returnToActive(0), returnToStandby(1), requiresIntervention(2). Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 58: Blade Dev Entry

    Blade Dev Entry Blade Device Index Name: blDevIndex Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevIndex(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: blDevEntry Next sibling: blDevUID Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: mandatory Max access: read-only Description: MIB table index. Blade Device Universal Identifier Name: blDevUID Type: OBJECT-TYPE...

  • Page 59: Blade Device Vendor

    Next sibling: blDevProduct Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Size list: 1: 8 Description: Device vendor. Blade Device Product Name: blDevProduct Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.5 Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 60: Blade Device Serial

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevProduct(5) Module: ADIC-TAPE-LIBRARY-MIB Parent: blDevEntry Prev sibling: blDevVendor Next sibling: blDevSerial Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Size list: 1: 16 Description: Device product identifier. Blade Device Serial Name: blDevSerial Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.6...

  • Page 61: Blade Device Lun

    Max access: read-only Description: SCSI logical unit number of the device. Blade Device Controller Index Name: blDevCtlrIndex Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.9 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevCtlrIndex(9) Module: ADIC-TAPE-LIBRARY-MIB Parent: blDevEntry Prev sibling: blDevLun Next sibling: blDevFWRev Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 62: Blade Device Firmware Revision

    Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: mandatory Max access: read-only Description: Index of this device's controller in the controller’s MIB table and type-specific controller tables. Blade Device Firmware Revision Name: blDevFWRev Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevFWRev(10)

  • Page 63: Blade Controller Table

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blCtlrTable(3).blCtlrEntry(1).blCtlrType(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: blCtlrEntry Prev sibling: blCtlrIndex Next sibling: blCtlrChannelMask Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: InterfaceType Status: mandatory Max access: read-only Description: Communication interface type. Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 64: Blade Controller Channel Mask

    Blade Controller Channel Mask Name: blCtlrChannelMask Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.3.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blCtlrTable(3).blCtlrEntry(1).blCtlrChannelMask(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: blCtlrEntry Prev sibling: blCtlrType Numerical syntax: Gauge (32 bit) Base syntax: Gauge Composed syntax: Gauge Status: mandatory Max access: read-write Description: Specifies access permissions for this initiator in bits 0 through 18, as follows: ************************************************* -* SCSI Channels *- Bit 0 =>...

  • Page 65: Blade Fibre Channel Controller Entry

    Name: blFcCtlrMaxSpeed Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.4.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blFcCtlrTable(4).blFcCtlrEntry(1).blFcCtlrMaxSpeed(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: blFcCtlrEntry Prev sibling: blFcCtlrStatus Next sibling: blFcCtlrWWPortName Numerical syntax: Gauge (32 bit) Base syntax: Gauge Composed syntax: Gauge Status: mandatory Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 66: Blade Fibre Channel Controller World Wide Port Name

    Max access: read-only Description: Maximum transfer speed in MBytes per second. Blade Fibre Channel Controller World Wide Port Name Name: blFcCtlrWWPortName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.4.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blFcCtlrTable(4).blFcCtlrEntry(1).blFcCtlrWWPortName(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: blFcCtlrEntry Prev sibling: blFcCtlrMaxSpeed Next sibling: blFcCtlrLoopID Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory...

  • Page 67: Blade Fibre Channel Controller Loop Id Mode

    Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FibrePortMode Status: mandatory Max access: read-only Description: Fibre Channel port mode. Blade Fibre Channel Controller Connection Options Name: blFcCtlrConnectionOptions Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.4.1.7 Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 68: Blade Host Table

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blFcCtlrTable(4).blFcCtlrEntry(1).blFcCtlrConnectionOptions(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: blFcCtlrEntry Prev sibling: blFcCtlrPortMode Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FibreConnOptions Status: mandatory Max access: read-only Description: Connection options for ISP2200 FC chip. Values 4 – 8 are reserved. Blade Host Table Blade Host Index Name: blHostIndex...

  • Page 69: Blade Host Name

    Max access: read-only Size list: 1: 0..32 Description: Name for this initiator. Blade Host Type Name: blHostType Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.5.1.4 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHostTable(5).blHostEntry(1).blHostType(4) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHostEntry Prev sibling: blHostName Next sibling: blHostPortID Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 70: Blade Host Port Id

    Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Size list: 1: 0..32 Description: The type of host that is connected to the blade. Blade Host Port ID Name: blHostPortID Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.5.1.5 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHostTable(5).blHostEntry(1).blHostPortID(5)

  • Page 71: Blade Host Lun Map

    Blade Host Port Failover Map Virtual Port Name: blHPFMapVirtualPort Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.6.1.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHPFMapTable(6).blHPFMapEntry(1).blHPFMapVirtualPort(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHPFMapEntry Next sibling: blHPFMapPrimaryPort Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 72: Blade Host Port Failover Map Primary Port

    Status: mandatory Max access: read-only Description: The virtual port index. The value is usually the same as the physical port index (see Blade Host Port Failover Map Primary Port), but will be zero if host port failover is not configured. Blade Host Port Failover Map Primary Port Name: blHPFMapPrimaryPort Type: OBJECT-TYPE...

  • Page 73: Blade Host Port Failover Map Active Port

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHPFPhysicalTable(7).blHPFPhysicalEntry(1).blHPFPhysicalPort(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHPFPhysicalEntry Next sibling: blHPFPhysicalPortFailureType Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: mandatory Max access: read-only Description: The physical FC port index. Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 74: Blade Host Port Failover Physical Port Failure Type

    Blade Host Port Failover Physical Port Failure Type Name: blHPFPhysicalPortFailureType Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.7.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHPFPhysicalTable(7).blHPFPhysicalEntry(1).blHPFPhysicalPortFailureType(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHPFPhysicalEntry Prev sibling: blHPFPhysicalPort Next sibling: blHPFPhysicalPortCurrentState Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FcHPFPortFailType Status: mandatory Max access: read-only Description: If this physical port failed, this field provides the type of failure.
  • Page 75 Prev sibling: blHPFPhysicalPortCurrentState Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: Boolean Status: mandatory Max access: read-only Description: Does this physical port require intervention? Values: 1 = true; 2 = false. Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 76 MIB Variables - Library System Information...

  • Page 77: Mib Variables - Ras Subsystem

    Parent: rasSubSystem Next sibling: coolingStatus Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Indicates overall power supply status. Cooling Status Name: coolingStatus Type: OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 78: Control Status

    OID: 1.3.6.1.4.1.3764.1.10.10.12.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).rasSubSystem(12).coolingStatus(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: rasSubSystem Prev sibling: powerStatus Next sibling: controlStatus Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Indicates overall cooling fans status. Control Status Name: controlStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.12.3...

  • Page 79: Robotics Status

    Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Indicates overall robotics status. Media Status Name: mediaStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.12.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).rasSubSystem(12).mediaStatus(6) Dell PowerVault ML6000 Basic SNMP Reference Guide...

  • Page 80: Drive Status

    Module: ADIC-TAPE-LIBRARY-MIB Parent: rasSubSystem Prev sibling: roboticsStatus Next sibling: driveStatus Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Indicates overall media status. Drive Status Name: driveStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.12.7 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).rasSubSystem(12).driveStatus(7) Module: ADIC-TAPE-LIBRARY-MIB...
  • Page 81 Prev sibling: driveStatus Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: current Max access: read-only Value list: 1: yes(1); 2: no(2). Description: Yes, if operator action is required. Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 82 MIB Variables - RAS Subsystem...

  • Page 83: Snmp Traps

    NOTE: The ML6000 library supports SNMP v1 and v2 traps as defined by RFC 1157. Traps defined in the Tape Library Management Information Base (MIB) are issued with enterprise OID “Dell Tape Library MIB”, which resolves to 1.3.6.1.4.1.3764.1.10.10. Table 1...
  • Page 84 Table 1 Status Traps (Continued) Trap ID Trap Description phLibraryStateChange Change in Online State Indicates that the online state of the physical library has changed. moduleDoorStatusChange Module Door Status Change Indicates that a library access door has been opened, closed, locked, or unlocked, interrupting or enabling power to the robot.
  • Page 85 The library issues a trap whenever the aggregate state of one of the Reliability, Availability, and Serviceability (RAS) status groups changes. Listening for these traps (rather than querying for them) is the preferred method of monitoring the health of the library. Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 86 Table 1 Status Traps (Continued) Trap ID Trap Description libraryTapeAlert1 Drive Communication Failure The library set TapeAlert 1, indicating a drive communication failure. libraryTapeAlert2 Library Hardware Failure The library set TapeAlert 2, indicating a library hardware failure. libraryTapeAlert4 Non-mechanical Hardware Failure The library set TapeAlert 4, indicating a non-mechanical hardware failure.

  • Page 87: A Mibs Implemented

    MIBs Implemented The library requires five Management Information Bases (MIBs): the Dell Tape Library MIB and four standard SNMP MIBs. Dell Tape Library MIB The Dell Tape Library MIB provides the following information: • System identification (library model and serial number) •...

  • Page 88: Dell Library Mib Content

    Dell Library MIB Content -- **************************************************** -- ADIC-TAPE-LIBRARY-MIB.mib: Tape Library Platform Specific MIB -- $Date: 2010-03-05 11:07:06 -0700 (Fri, 05 Mar 2010) $ -- Copyright (c) 2005-2010 by Quantum Corporation -- All rights reserved. -- **************************************************** -- Glossary of terms...
  • Page 89 OBJECT IDENTIFIER ::= { tapeLibraryMIBNotificationPrefix 1 } -- Textual conventions FCPortType ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Port type qualifier." SYNTAX INTEGER { nPort( 1 ), nlPort( 2 ), fPort( 3 ), flPort( 4 ), Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 90 unknown( 5 ) SCSICtrlSpeed ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "SCSI Speed." SYNTAX INTEGER { async(0), fast(1), ultra(2) , ultra80(3) , ultra160(4) , ultra320(5), ultra640(6), unknown(7) SCSICtrlCardType ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "SCSI Card type." SYNTAX INTEGER { none(0), differentialNoTermination(1), differentialTerminated(2), singleEndedNoTermination(3), singleEndedTerminated(4), unknown(5), lowVoltageSingleEnded(6), lowVoltageDifferential(7), lowVoltageMultiFunction(8), highVoltageDifferential(9)
  • Page 91 CleaningStatus ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Cleaning Status." SYNTAX INTEGER { required( 1 ), notRequired( 2 ), immediate( 3 ) InterfaceType ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Types of interfaces." SYNTAX INTEGER { scsi( 1 ), Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 92 fibreChannel( 2 ), sas (3), iscsi(4) IEDoorStatus ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Import Export Station Door Status." SYNTAX INTEGER { opened( 1 ), closedAndLocked( 2 ), closedAndUnLocked( 3 ) RASSubSystemStatus ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "RAS status" SYNTAX INTEGER { good( 1 ), failed( 2 ), degraded( 3 ),...
  • Page 93 5 ) SASPortSpeed ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Different port speeds in Gigabits per second." SYNTAX INTEGER { auto( 1 ), threeGbps( 2 ), sixGbps( 3 ) -- Tape Library parameters libraryIpAddress OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 94 SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "The IP address of this SNMP agent. If the library has only an IPV4 address, or both an IPV4 and an IPV6 address, the the IP address is displayed in IPV4 format (xxx.xxx.xxx.xxx). the library only has an IPV6 address, then it will report an IPV6 address."...
  • Page 95 STATUS current DESCRIPTION "URL of the library's management application." ::= { tapeLibrarySystem 9 } libraryProductName OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Product name of the library." ::= { tapeLibrarySystem 10 } Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 96 libraryFirmwareVersion OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Library firmware version." ::= { tapeLibrarySystem 11 } physicalDrive OBJECT IDENTIFIER ::= { tapeLibraryMIB 11 } overallPhDriveReadinessStatus OBJECT-TYPE SYNTAX OnlineState MAX-ACCESS read-only STATUS current DESCRIPTION "Overall Drives readiness." ::= { physicalDrive 1 } physicalDriveTable OBJECT-TYPE SYNTAX SEQUENCE OF PhysicalDriveEntry...
  • Page 97 InterfaceType, phDriveScsiLun Integer32, phDriveScsiId Integer32, phDriveLoads Integer32, phDrivePhysicalSerialNumber DisplayString phDriveIndex OBJECT-TYPE SYNTAX Integer32 (1..1000) MAX-ACCESS not-accessible STATUS current DESCRIPTION "Table entry index value. Index of this Drive" ::= { physicalDriveEntry 1 } Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 98 phDriveSerialNumber OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Device serial number as reported in SCSI Inquiry command." ::= { physicalDriveEntry 2 } phDriveModel OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Device Model as would be reported in a SCSI Inquiry command."...
  • Page 99 ::= { physicalDriveEntry 9 } phDriveState OBJECT-TYPE SYNTAX OnlineState MAX-ACCESS read-only STATUS current DESCRIPTION "Device SCSI State." ::= { physicalDriveEntry 10 } phDriveRasStatus OBJECT-TYPE SYNTAX RASSubSystemStatus MAX-ACCESS read-only STATUS current DESCRIPTION "Drive health status." Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 100 ::= { physicalDriveEntry 11 } phDriveNeedsCleaning OBJECT-TYPE SYNTAX CleaningStatus MAX-ACCESS read-only STATUS current DESCRIPTION "Cleaning status of the Drive." ::= { physicalDriveEntry 12 } phDriveInterfaceType OBJECT-TYPE SYNTAX InterfaceType MAX-ACCESS read-only STATUS current DESCRIPTION "Interface Type of the drive." ::= { physicalDriveEntry 13 } phDriveScsiLun OBJECT-TYPE SYNTAX Integer32...
  • Page 101 STATUS current DESCRIPTION "Indicate overall control subsystem status." ::= { rasSubSystem 3 } connectivityStatus OBJECT-TYPE SYNTAX RASSubSystemStatus MAX-ACCESS read-only STATUS current DESCRIPTION "Indicates overall connectivity Status" ::= { rasSubSystem 4 } roboticsStatus OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 102 SYNTAX RASSubSystemStatus MAX-ACCESS read-only STATUS current DESCRIPTION "Indicates overall robotics Status" ::= { rasSubSystem 5 } mediaStatus OBJECT-TYPE SYNTAX RASSubSystemStatus MAX-ACCESS read-only STATUS current DESCRIPTION "Indicates overall media Status" ::= { rasSubSystem 6 } driveStatus OBJECT-TYPE SYNTAX RASSubSystemStatus MAX-ACCESS read-only STATUS current DESCRIPTION...
  • Page 103 { logicalLibraryIndex } ::= { logicalLibraryTable 1 } LogicalLibraryEntry ::= SEQUENCE { logicalLibraryIndex Integer32, logicalLibraryName DisplayString, logicalLibrarySerialNumber DisplayString, logicalLibraryModel DisplayString, logicalLibraryAssignedLun Integer32, logicalLibraryMediaDomain DisplayString, logicalLibrarySupportedMediaTypes DisplayString, logicalLibraryState OnlineState, logicalLibraryNumSlots Integer32, logicalLibraryNumIE Integer32, logicalLibraryNumTapeDrives Integer32, Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 104 logicalLibraryStorageElemAddr Integer32, logicalLibraryIEElemAddr Integer32, logicalLibraryTapeDriveElemAddr Integer32, logicalLibraryChangerDeviceAddr Integer32 logicalLibraryIndex OBJECT-TYPE SYNTAX Integer32 (1..16) MAX-ACCESS not-accessible STATUS current DESCRIPTION "Table entry index value. Each unique partition has a unique partitionIndex." ::= { logicalLibraryEntry 1 } logicalLibraryName OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION...
  • Page 105 OnlineState MAX-ACCESS read-only STATUS current DESCRIPTION "Status of logical library." ::= { logicalLibraryEntry 8 } logicalLibraryNumSlots OBJECT-TYPE SYNTAX Integer32 MAX-ACCESS read-only STATUS current DESCRIPTION "Number of Storage Elements." ::= { logicalLibraryEntry 9 } Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 106 logicalLibraryNumIE OBJECT-TYPE SYNTAX Integer32 MAX-ACCESS read-only STATUS current DESCRIPTION "Number of Import/Export Elements." ::= { logicalLibraryEntry 10 } logicalLibraryNumTapeDrives OBJECT-TYPE SYNTAX Integer32 MAX-ACCESS read-only STATUS current DESCRIPTION "Number of tape drives in the partition." ::= { logicalLibraryEntry 11 } logicalLibraryStorageElemAddr OBJECT-TYPE SYNTAX Integer32 MAX-ACCESS...
  • Page 107 "The status is 'open' if any door is open." ::= { physicalLibrary 3 } numStorageSlots OBJECT-TYPE SYNTAX Integer32 MAX-ACCESS read-only STATUS current DESCRIPTION "Number of storage slots." ::= { physicalLibrary 4 } numIESlots OBJECT-TYPE SYNTAX Integer32 Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 108 MAX-ACCESS read-only STATUS current DESCRIPTION "Number of Import Export slots." ::= { physicalLibrary 5 } numPhDrives OBJECT-TYPE SYNTAX Integer32 MAX-ACCESS read-only STATUS current DESCRIPTION "Number of drives." ::= { physicalLibrary 6 } robot OBJECT IDENTIFIER ::= { physicalLibrary 30 } robotState OBJECT-TYPE SYNTAX RoboticsReadiness...
  • Page 109 FCPortSpeed, fcPortRasStatus RASSubSystemStatus, fcPortFWRev DisplayString, fcPortFrameSize Integer32, fcPortDriveSerialNumber DisplayString, fcPortLogicalLibrarySerialNumber DisplayString fcPortIndex OBJECT-TYPE SYNTAX Integer32 (1..1000) MAX-ACCESS not-accessible STATUS current DESCRIPTION "Table entry index value." ::= { fcPortEntry 1 } fcPortType OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 110 SYNTAX FCPortType MAX-ACCESS read-only STATUS current DESCRIPTION "Fibre Channel Port Type" ::= { fcPortEntry 2 } fcPortWWNodeName OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "8-byte value representing the drive's World Wide Node Name." ::= { fcPortEntry 3 } fcPortWWPortName OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS...
  • Page 111 STATUS current DESCRIPTION "Currently not applicable" ::= { fcPortEntry 9 } fcPortFWRev OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Firmware revision number/identifier for this Fibre Channel Controller." ::= { fcPortEntry 10 } Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 112 fcPortFrameSize OBJECT-TYPE SYNTAX Integer32 MAX-ACCESS read-only STATUS current DESCRIPTION "Fibre Channel frame size." ::= { fcPortEntry 11 } fcPortDriveSerialNumber OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Tape drive serial number." ::= { fcPortEntry 12 } fcPortLogicalLibrarySerialNumber OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current...
  • Page 113 DisplayString scsiControllerIndex OBJECT-TYPE SYNTAX Integer32 (1..1000) MAX-ACCESS not-accessible STATUS current DESCRIPTION "Table entry index value." ::= { scsiControllerEntry 1 } scsiControllerRasStatus OBJECT-TYPE SYNTAX RASSubSystemStatus MAX-ACCESS read-only STATUS current DESCRIPTION "Currently not applicable." Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 114 ::= { scsiControllerEntry 2 } scsiControllerSpeed OBJECT-TYPE SYNTAX SCSICtrlSpeed MAX-ACCESS read-only STATUS current DESCRIPTION "SCSI Transaction speed." ::= { scsiControllerEntry 3 } scsiControllerRole OBJECT-TYPE SYNTAX INTEGER{ target(0) , initiator(1) } MAX-ACCESS read-only STATUS current DESCRIPTION "SCSI role of the drive (target or initiator)" ::= { scsiControllerEntry 4 } scsiControllerIoCard OBJECT-TYPE...
  • Page 115 STATUS current DESCRIPTION "Serial Number of Tape Drive." ::= { scsiControllerEntry 10 } scsiControllerLogicalLibrarySN OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Logical library serial number." ::= { scsiControllerEntry 11 } sasPortTable OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 116 SYNTAX SEQUENCE OF SasPortEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "SAS Port Table" ::= { libraryInterfaces 3 } sasPortEntry OBJECT-TYPE SYNTAX SasPortEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "SAS Port Table" INDEX { sasPortIndex } ::= { sasPortTable 1 } SasPortEntry ::= SEQUENCE { sasPortIndex Integer32, sasPortAddress...
  • Page 117 OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Firmware revision for this tape drive." ::= { sasPortEntry 5 } sasPortDriveSerialNumber OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Tape drive serial number." Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 118 ::= { sasPortEntry 6 } sasPortLogicalLibrarySN OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Logical library serial number." ::= { sasPortEntry 7 } -- start blade additions -- Reboot Image Agent and Reset Controllers Reset ::= INTEGER { run(0) , reset(1) , reboot(2) } -- Device types DeviceType ::= INTEGER{ directAccess(0), sequentialAccess(1), printer(2),...
  • Page 119 OBJECT IDENTIFIER ::= { tapeLibraryMIB 16 } bladeTable OBJECT-TYPE SYNTAX SEQUENCE OF BladeEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "Data Appliance Blade Table" ::= { bladeInterfaces 1 } bladeEntry OBJECT-TYPE SYNTAX BladeEntry MAX-ACCESS not-accessible STATUS current Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 120 DESCRIPTION "Data Appliance Blade Entry" INDEX { bladeIndex } ::= { bladeTable 1 } BladeEntry ::= SEQUENCE { bladeIndex INTEGER, bladeLocation DisplayString, bladeIP DisplayString, bladeWWNodeName OCTET STRING, bladeHealthCheckValue Gauge, bladeHealthCheckInterval Gauge, bladeHealthCheckLevel INTEGER, bladeFWRev DisplayString, bladeSerialNumber DisplayString, bladeEVPSEnabled INTEGER, bladeMaxHostLun INTEGER, bladeState BladeState,...
  • Page 121 ::= { bladeEntry 5 } bladeHealthCheckLevel OBJECT-TYPE SYNTAX INTEGER{ none(0), system(1) , interface(2) , simpleDevice(3), deviceReady(4) } ACCESS read-only STATUS mandatory DESCRIPTION "Scrutiny level of health check function." ::= { bladeEntry 6 } bladeHealthCheckInterval OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 122 SYNTAX Gauge ACCESS read-only STATUS mandatory DESCRIPTION "Health Check interval in minutes." ::= { bladeEntry 7 } bladeFWRev OBJECT-TYPE SYNTAX DisplayString (SIZE (0..64)) ACCESS read-only STATUS mandatory DESCRIPTION "Blade Firmware Revision information." ::= { bladeEntry 8 } bladeSerialNumber OBJECT-TYPE SYNTAX DisplayString (SIZE (0..64)) ACCESS read-only STATUS mandatory DESCRIPTION "Blade Serial Number."...
  • Page 123 Link Down Errors Values: returnToActive(0), returnToStandby(1), requiresIntervention(2)" ::= { bladeEntry 15 } -- One Level down -- Blade Device Info blDevTable OBJECT-TYPE SYNTAX SEQUENCE OF BlDevEntry MAX-ACCESS not-accessible Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 124 STATUS current DESCRIPTION "Data Appliance Blade Device Table" ::= { bladeInterfaces 2 } blDevEntry OBJECT-TYPE SYNTAX BlDevEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "Data Appliance Blade Device Entry" INDEX { bladeIndex, blDevIndex } ::= { blDevTable 1 } BlDevEntry ::= SEQUENCE { blDevIndex INTEGER, blDevUID...
  • Page 125 DESCRIPTION "This device's type of communication interface." ::= { blDevEntry 7 } blDevLun OBJECT-TYPE SYNTAX INTEGER ACCESS read-only STATUS mandatory DESCRIPTION "SCSI Logical Unit Number of the device." ::= { blDevEntry 8 } blDevCtlrIndex OBJECT-TYPE SYNTAX INTEGER Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 126 ACCESS read-only STATUS mandatory DESCRIPTION "Index of this device's controller in the Controllers MIB table and type-specific controller tables" ::= { blDevEntry 9 } blDevFWRev OBJECT-TYPE SYNTAX DisplayString( SIZE(0..32)) ACCESS read-only STATUS mandatory DESCRIPTION "Device firmware revision number/identifier" ::= { blDevEntry 10 } blDevTargetLun OBJECT-TYPE SYNTAX INTEGER...
  • Page 127 Bit 7 => Is access DISALLOWED to Ultra SCSI channel 4 ? Bit 8 => Is access DISALLOWED to Ultra SCSI channel 5 ? Bit 9 => Is access DISALLOWED to Ultra SCSI channel 6 ? -* Fibre Channel *- Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 128 Bit 10 => Is access DISALLOWED to Fibre Channel 1 ? Bit 11 => Is access DISALLOWED to Fibre Channel 2 ? Bit 12 => Is access DISALLOWED to Fibre Channel 3 ? Bit 13 => Is access DISALLOWED to Fibre Channel 4 ? Bit 14 =>...
  • Page 129 ::= { blFcCtlrEntry 4 } blFcCtlrLoopIDMode OBJECT-TYPE SYNTAX FCPortLoopIdMode ACCESS read-only STATUS mandatory DESCRIPTION "Fibre Channel loop ID mode (soft or hard)" ::= { blFcCtlrEntry 5 } blFcCtlrPortMode OBJECT-TYPE SYNTAX FibrePortMode ACCESS read-only Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 130 STATUS mandatory DESCRIPTION "Fibre Channel port mode." ::= { blFcCtlrEntry 6 } blFcCtlrConnectionOptions OBJECT-TYPE SYNTAX FibreConnOptions ACCESS read-only STATUS mandatory DESCRIPTION "Connection options for ISP2200 FC chip. Values 4 - 8 are reserved." ::= { blFcCtlrEntry 7 } -- EVPS/Host mapping/management blHostTable OBJECT-TYPE SYNTAX SEQUENCE OF BlHostEntry ACCESS not-accessible...
  • Page 131 ::= { blHostEntry 4 } blHostPortID OBJECT-TYPE SYNTAX DisplayString( SIZE( 0 .. 32 ) ) ACCESS read-only STATUS mandatory DESCRIPTION "The ID of the host port " ::= { blHostEntry 5 } blHostITLData OBJECT-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 132 SYNTAX OCTET STRING ( SIZE( 256 ) ) ACCESS read-only STATUS mandatory DESCRIPTION "Initiator-Target-Logical Unit nexus (ITL) Access Control data for this host. There are 256 possible LUNs with 1 byte of data per LUN. " ::= { blHostEntry 6 } blHostLunMap OBJECT-TYPE SYNTAX...
  • Page 133 DESCRIPTION "The comma separated list of ports that are configured as standbys for the virtual port (excluding the primary port)." ::= { blHPFMapEntry 3 } blHPFMapActivePort OBJECT-TYPE SYNTAX INTEGER ACCESS read-only STATUS mandatory Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 134 DESCRIPTION "The physical port that is active on this virtual port" ::= { blHPFMapEntry 4 } blHPFPhysicalTable OBJECT-TYPE SYNTAX SEQUENCE OF BlHPFPhysicalEntry ACCESS not-accessible STATUS mandatory DESCRIPTION "" ::= { bladeInterfaces 7 } blHPFPhysicalEntry OBJECT-TYPE SYNTAX BlHPFPhysicalEntry ACCESS not-accessible STATUS mandatory DESCRIPTION "...
  • Page 135 -- end blade additions -- NotificationOnlyData is a way to get the payload data across without -- relating it to other MIB OID's, a dummy OID faultyLibLocation OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS accessible-for-notify STATUS current DESCRIPTION Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 136 "Place holder for the tape alert traps" ::= { tapeLibraryMIBNotificationOnlyData 1 } Notifications relating to the basic operation of the agent These are generated by the net-snmp code, so we mirror them here so that it has an equivalent for our enterprise OID. tapeLibNotifyStart NOTIFICATION-TYPE STATUS...
  • Page 137 --#TYPE "Change in Online state of the Physical Library" --#SUMMARY "The library %s has changed its online state and is at state %d." --#ARGUMENTS {0,1} --#SEVERITY INFORMATIONAL ::= { tapeLibraryMIBNotifications 103 } moduleDoorStatusChange NOTIFICATION-TYPE Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 138 OBJECTS librarySerialNumber, aggregatedMainDoorStatus STATUS current DESCRIPTION "Notify that the status of the module door changed." --#TYPE "Change in main Chassis door status" --#SUMMARY "The Main chassis door of the library %s has changed status to %d." --#ARGUMENTS {0,1} --#SEVERITY INFORMATIONAL ::= { tapeLibraryMIBNotifications 104 } ieDoorStatusChange NOTIFICATION-TYPE OBJECTS...
  • Page 139 "Notify when connectivity health status changed." --#TYPE "RAS status of the Connectivity SubSystem Changed" --#SUMMARY "The Connectivity Subsystem of the library %s has changed the RAS status and the RAS status is at %d." Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 140 --#ARGUMENTS {0,1} --#SEVERITY INFORMATIONAL ::= { tapeLibraryMIBNotifications 109 } controlStatusChange NOTIFICATION-TYPE OBJECTS librarySerialNumber, controlStatus STATUS current DESCRIPTION "Notify when control health status changed." --#TYPE "RAS status of the Control SubSystem Changed" --#SUMMARY "The Control Subsystem of the library %s has changed the RAS status and the RAS status is at %d." --#ARGUMENTS {0,1} --#SEVERITY INFORMATIONAL ::= { tapeLibraryMIBNotifications 110 }...
  • Page 141 --#SUMMARY "The Power Subsystem of the library %s has changed the RAS status and the RAS status is at %d." --#ARGUMENTS {0,1} --#SEVERITY INFORMATIONAL ::= { tapeLibraryMIBNotifications 114 } roboticsStatusChange NOTIFICATION-TYPE OBJECTS librarySerialNumber, roboticsStatus Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 142 STATUS current DESCRIPTION "Notify robotics health status change." --#TYPE "RAS status of the Robotics SubSystem Changed" --#SUMMARY "The Robotics Subsystem of the library %s has changed the RAS status and the RAS status is at %d." --#ARGUMENTS {0,1} --#SEVERITY INFORMATIONAL ::= { tapeLibraryMIBNotifications 115 } operatorInterventionRequired NOTIFICATION-TYPE OBJECTS...
  • Page 143 --#TYPE "Library hardware failure" --#SUMMARY "Library %s encountered a hardware failure. Global RAS status = %d." --#ARGUMENTS {0,1} --#SEVERITY CRITICAL ::= { tapeLibraryMIBNotifications 122 } libraryTapeAlert4 NOTIFICATION-TYPE OBJECTS { librarySerialNumber, libraryGlobalStatus STATUS current Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 144 DESCRIPTION "Notification that the library set Tape Alert 4, indicating a non-mechanical hardware failure." --#TYPE "A non-mechanical library hardware failure occurred" --#SUMMARY "Library %s encountered a non-mechanical hardware failure. Global RAS status = %d." --#ARGUMENTS {0,1} --#SEVERITY CRITICAL ::= { tapeLibraryMIBNotifications 124 } libraryTapeAlert13 NOTIFICATION-TYPE OBJECTS { faultyLibLocation,...
  • Page 145 STATUS current DESCRIPTION "Notification that the library set Tape Alert 17, indicating a mailbox station mechanical problem." --#TYPE "Mailbox mechanical problem" --#SUMMARY "A mechanical mailbox problem occurred at location %s of library %s." Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 146 --#ARGUMENTS {0,1} --#SEVERITY CRITICAL ::= { tapeLibraryMIBNotifications 137 } libraryTapeAlert23 NOTIFICATION-TYPE OBJECTS { faultyLibLocation, librarySerialNumber STATUS current DESCRIPTION "Notification that the library set Tape Alert 23, indicating that excessive scan retries occurred." --#TYPE "Excessive scan retries" --#SUMMARY "Scan retries occurred in location %s of library %s."...
  • Page 147 MANDATORY-GROUPS { tapeLibraryMIBGroup, tapeLibraryMIBNotifGroup } ::= { tapeLibraryMIBCompliances 1 } -- units of conformance tapeLibraryMIBGroup OBJECT-GROUP OBJECTS { libraryIpAddress, librarySNMPAgentDescription, libraryName, libraryVendor, librarySerialNumber, libraryDescription, libraryModel, libraryGlobalStatus, overallPhDriveReadinessStatus, numPhDrives, phDriveSerialNumber, phDriveModel, phDriveVendor, phDriveType, phDriveLocation, Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 148 phDriveFirmwareVersion, phDriveLogicalLibraryName, phDriveLibrarySerialNumber, phDriveState, phDriveRasStatus, phDriveNeedsCleaning, phDriveInterfaceType, phDriveScsiLun, phDriveScsiId, phDriveLoads, phDrivePhysicalSerialNumber, logicalLibraryName, logicalLibrarySerialNumber, logicalLibraryModel, logicalLibraryAssignedLun, logicalLibraryMediaDomain, logicalLibrarySupportedMediaTypes, logicalLibraryState, logicalLibraryNumSlots, logicalLibraryNumIE, logicalLibraryNumTapeDrives, logicalLibraryStorageElemAddr, logicalLibraryIEElemAddr, logicalLibraryTapeDriveElemAddr, logicalLibraryChangerDeviceAddr, powerStatus, coolingStatus, controlStatus, connectivityStatus, roboticsStatus, mediaStatus, driveStatus, operatorActionRequest, numLogicalLibraries, MIBs Implemented...
  • Page 149 Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 150 -- start blade additions -- blade top-level bladeIndex, bladeLocation, bladeIP, bladeWWNodeName, bladeHealthCheckValue, bladeHealthCheckInterval, bladeHealthCheckLevel, bladeFWRev, bladeSerialNumber, bladeEVPSEnabled, bladeMaxHostLun, bladeState, blHPFLinkDownThreshold, blHPFErrorRecoveryMode, blHPFLinkDownRecoveryMode, -- devices /blade level blDevIndex, blDevUID, blDevType, blDevVendor, blDevProduct, blDevSerial, blDevInterfaceType, blDevLun, blDevCtlrIndex, blDevFWRev, blDevTargetLun, -- controllers /blade level blCtlrIndex, blCtlrType, blCtlrChannelMask,...
  • Page 151 -- HPF blHPFMapVirtualPort, blHPFMapPrimaryPort, blHPFMapStandbyList, blHPFMapActivePort, blHPFPhysicalPort, blHPFPhysicalPortFailureType, blHPFPhysicalPortCurrentState, blHPFPhysicalPortIntervention, -- end blade additions faultLibLocation STATUS current DESCRIPTION "A collection of objects providing Tape Library Management capability." ::= { tapeLibraryMIBGroups 1 } Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 152 tapeLibraryMIBNotifGroup NOTIFICATION-GROUP NOTIFICATIONS { tapeLibNotifyStart, tapeLibNotifyShutdown, tapeLibNotifyRestart, startupSequenceCompleted, shutdownSequenceInitiated, phLibrayStateChange, moduleDoorStatusChange, ieDoorStatusChange, roboticsReady, roboticsNotReady, logicalLibraryStateChange, connectivityStatusChange, controlStatusChange, coolingStatusChange, driveStatusChange, mediaStatusChange, powerStatusChange, roboticsStatusChange, operatorInterventionRequired, driveOnlineStateChange, libraryTapeAlert1, libraryTapeAlert2, libraryTapeAlert4, libraryTapeAlert13, libraryTapeAlert14, libraryTapeAlert15, libraryTapeAlert16, libraryTapeAlert17, libraryTapeAlert23, libraryTapeAlert32 STATUS current DESCRIPTION "A collection of objects providing Tape Library Management MIBs Implemented...
  • Page 153 ::= { tapeLibraryMIBGroups 2 } Dell PowerVault ML6000 Basic SNMP Reference Guide...
  • Page 154 MIBs Implemented...
  • Page 155 Dell ......2 library status and health ....71 content .
  • Page 156 Index...

This manual is also suitable for:

Powervault ml6010

Table of Contents
