If the enclosure uses a mini SAS 4x connector, pull back the tab on the cable connector, insert
o
the cable connector into the enclosure connector, and then release the tab.
Power up the enclosure.
4.
Power up the server.
5.

SAS cable part numbers

To order additional cables, use the option kit part number.
Approximate cable
length
1 m (3 ft)
2 m (6 ft)
—
4 m (13 ft)
—
6 m (20 ft)
—
Type of cable
Mini SAS 4x to standard SAS 4x
Mini SAS 4x to mini SAS 4x
Mini SAS 4x to standard SAS 4x
Mini SAS 4x to mini SAS 4x
Mini SAS 4x to standard SAS 4x
Mini SAS 4x to mini SAS 4x
Mini SAS 4x to standard SAS 4x
Option kit part Cable assembly
number number
419570-B21 408908-002
407339-B21 407344-003
419571-B21 408908-003
432238-B21 407344-004
419572-B21 408908-004
432239-B21 407344-005
419573-B21 408908-005
Installing the controller hardware 11
