LG 84UB9800 Service Manual
  1. Manuals
  2. Brands
  3. LG Manuals
  4. LED TV
  5. 84UB9800
  6. Service manual

LG 84UB9800 Service Manual

Hide thumbs Also See for 84UB9800:

Advertisement

Quick Links

Download this manual
LED TV
SERVICE MANUAL
CHASSIS : LA41U
MODEL : 84UB9800
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL68086410 (1405-REV00)
North/Latin America
Europe/Africa
Asia/Oceania
84UB9800-UA
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com
Printed in Korea

Advertisement

loading

Related Manuals for LG 84UB9800

Summary of Contents for LG 84UB9800

  • Page 1 Internal Use Only North/Latin America http://aic.lgservice.com Europe/Africa http://eic.lgservice.com Asia/Oceania http://biz.lgservice.com LED TV SERVICE MANUAL CHASSIS : LA41U MODEL : 84UB9800 84UB9800-UA CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL68086410 (1405-REV00) Printed in Korea...
  • Page 2 PRODUCT SAFETY ................. 3 SPECIFICATION ..................6 ADJUSTMENT INSTRUCTION .............. 14 EXPLODED VIEW .................. 26 SCHEMATIC CIRCUIT DIAGRAM .............. - 2 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 3 An other abnormality exists that must be corrected before the receiver is returned to the customer. - 3 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 4 - 4 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 5 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. - 5 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 6 - Safety : UL, CSA, CE, IEC specification - EMC : FCC, ICES, CE, IEC specification - Wireless : Wireless HD Specification (Option) - 6 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 7 1.06 B (10-bit) Except FHD 60Hz models 16.7 M (8-bit) Only FHD 60Hz models Surface Treatment Hard coating (2H), Anti-glare - 7 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 8 4096*2160 Only UD Model 4096*2160 56.25 Only UD Model 4096*2160 67.5 Only UD Model 4096*2160 Only UD Model, Port3 - 8 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 9 29.97 296.703 UDTV 2160P 4096*2160 67.5 UDTV 2160P 4096*2160 59.94 UDTV 2160P(HDMI 3 only) 4096*2160 UDTV 2160P(HDMI 3 only) - 9 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 10 29.976 / 30.00 148.35/148.5 Side-by-side(Full) (HDTV 1080P) 67.43 / 67.5 59.94 / 60 148.35/148.50 Top-and-Bottom Primary(HDTV 1080P) Side-by-side(half) Secondary(HDTV 1080P) - 10 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 11 Top & Bottom(half), Side by Side(half), Port3 Only Others 640*350 2D to 3D, 720*400 Side by Side(half), Top & Bottom 640*480 800*600 1152*864 - 11 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 12 3D input proposed mode 1080P 33.75 Side by Side(Half), Top & Bottom, Checker Board, MPO(Photo) 2160p 67.5 MPO(Photo), JPS(Photo) - 12 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 13 **Remark: 3D Input mode Side by Side Top & Bottom Checkerboard Single Frame Frame Packing Line Column Sequential Interleaving Interleaving LLLLL - 13 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 14 ▪ xb 00 06 [Change input source to RGB(1024*768)] ▪ ad 00 10 [Adjust 1920*1080 RGB] ▪ aa 00 90 End adj. - 14 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 15 1) Play the LAN Port Test PROGRAM. 2) Input IP set up for an inspection to Test Program. *IP Number : 12.12.2.2. - 15 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 16 C. Serial number D/L must be conformed when it is produced in production line, because serial number D/L is mandatory by D-book 4.0 - 16 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 17 ⓒ Month, Year: Controlled on production line: ex) Monthly : ‘01’ -> ‘01’ Year : ‘2014’ -> ‘18 ⓓ Model Name(Hex): LGTV ⓔ Checksum(LG TV): Changeable by total EDID data. ⓕ Vendor Specific(HDMI) 5.2.4.1. EDID #DTS HDMI1 (C/S: F7 82) EDID Block 0, Bytes 0-127 2) Select [Start] button by pressing Enter key, HDMI1 / HDMI2 / HDMI3 / HDMI4 are Writing and display OK or NG.
  • Page 18 # AC3 HDMI1 (C/S: E7 8B) EDID Block 0, Bytes 0-127 EDID Block 0, EDID Block 1, Bytes 128-255 - 18 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 19 # AC3 HDMI4 (C/S: E7 5B) # AC3 HDMI3 (C/S: A1 8A) # PCM HDMI1 (C/S: F7 FD) EDID Block 0, Bytes 0-127 - 19 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 20 Camera’s Preview picture appears on TV Set iii) Push Camera Down (3) RS-232C Command RS-232C COMMAND Explanation DATA Camera Function Start. Camera Function End. - 20 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 21 - VAL : FOS Data value - CS : Checksum of sent data - A : Acknowledge Ex) [Send: JA_00_DD] / [Ack: A_00_okDDX] - 21 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 22 - After Aging Start, Keep the Power ON status during 5 Minutes. - In case of LCD, Back-light on should be checked using no signal or Full-white pattern. - 22 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 23 Step 3) confirm the Local Dimming mode Step 4) Press “exit” Key 3) Don’t wear a 3D Glasses, Check the picture like below - 23 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 24 Step 5) Check LED light of Zig and Module of Set Result) If, The LED light is green and The Module shows normal stream -> OK Else -> NG - 24 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 25 EQ On (3) Punch in the number. (Each model has their number.) (8Ω Impedance) AVL On Clear Voice On - 25 - Copyright © LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 26 CAM1 Set + Stand (Option)
  • Page 27 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. H13 D CHIP Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 28 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. MAIN POWER 11/05/31 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 29 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR MAIN AUDIO/VIDEO THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 30 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. MAIN DDR Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 31 2013-12-17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. PCMCIA Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 32 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR POWER THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 33 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 34 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 35 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 36 2014.03.11 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. MICOM Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 37 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. HDMI Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 38 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. HDMI Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 39 JACK HIGH/MID 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 40 IR / KEY 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 41 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 42 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR USB JACK THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 43 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. SCART GENDER Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 44 LAN_VERTICAL 2012.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 45 2013-12-17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR ETHERNET THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 46 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 47 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 48 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 49 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 50 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 51 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 52 SCART AUDIO AMP 2012.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 53 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 54 2012.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. JAPAN_BCAS Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 55 TUNER 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 56 TU_SYMBOL 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 57 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR RS232C THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 58 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 59 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 60 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 61 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. D14_DDR Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 62 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 63 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 64 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR U14 DDR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 65 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR U14 Power THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 66 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR U_LVDS INPUT THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 67 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR Output_wafer THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 68 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR 0.1uF THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. 2013.12.17 4th layer URSA7_DDR Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 69 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 70 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. U_Power Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 71 FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 2013.12.17 ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 73 Overview for ’14 ULTRA HD Model ’14 ULTRA HD M d l (Hardware) Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 74 We offer a HDMI cable for HDMI 1 4 legacy issue We offer a HDMI cable for HDMI 1.4 legacy issue. HDMI2.0 HDMI1.4 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 75 • Lh, Rh • Lh, Rh Front (65,55”) • Woofer 15+15W • Lf / Rf •(Lf+Rf)/2 / (Lf+Rf)/2 : 내장 speaker (woofer/stereo) Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 76 2. Color sensor Adjusts the image quality and brightness based on the surrounding environment. 2014 model : Intelligent sensor + Color sensor Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 77 ’13 Carry 13 Carry 802 11 802.11ac Over UB98 79” 65” 55” 16:9 65” UB95 55” 802.11n (BT Combo) 55” UB85 49” Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 78 LCD TV Repair Guide `14 years New Models Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 79 Main to T-con B/T Wifi Video processor (LGE7411:URSA9), DDR Memory Local Key +IR Flash Memory 4K processor_Digital(LG1512), DDR Memory DDR Memory eMMC Memory Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 80 13. USB / Wi-Fi / M-REMOTE / UART 14. I2C Map (H13) 15. I2C Map (MICOM) 16. GPIO (H13) 17. GPIO (MICOM) Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 81 1920X2160@60p From H13 1920X2160@60p Decoder + Audio 4K@60p 1080p 1920X2160@60p Vby1 16 Lane 32bit(16bitX2) 4K@120Hz Super Resolution MEMC , 3D Function Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 82 Vx1 2Lane 2:1 Mux 16x4 16x2 16x4 DDR3 DDR3 DDR3 1Gb x 2(1600) 1Gb x 4 (1600) 1Gb x 4 (1866) Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 83 HDMI-Rx 1.4 SPLL DPLL (1-port PHY) DDR3 Controller DDR3 Controller DDR3 Controller DDR3 Controller 3D, ARC, 4kx2k DDR3 PHY DDR3 PHY Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 84 Data Path Diagram Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 85 DDR3 PHY (x16) DDR3 PHY (x32) Clock/Reset Gen DDR3-1600 DDR3-1600 DDR3-1600 DDR3 1600 DDR3-1600 DDR3 1600 1Gbit 1Gbit 1Gbit 1Gbit 1Gbit 1Gbit Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 86 M1 DDR DM0-1 D14(2bit) M1_DDR_DM0-1_D14(2bit) HDMI1 TX2P HDMI1_TX2P DDR3 DDR3 HDMI1_TXCN HDMI1_TXCP IC3501 IC3501 1G bit 1G bit M1_U_CLK_D14 DEV_HDMI_MUX1 DEV_HDMI_MUX1 M1_U_CLKN_D14 HDMI1_DDC_DA HDMI1_DDC_CK Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 87 HDMI Switch HDMI Rx Separate OSD 1.4b GPIO JTAG Ready JTAG S i l Fl Serial Flash SPI(M) UART RS-232C Crystal Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 88 HDMI HDMI_1_RX Switch [GPIO[1]] FHD_D9_SET 2560*1080@60p [GPIO[0]] URSA7/9_SET HDMI_U14_1 RXBSCL_U14 1920*1080@60p HDMI_0_RX RXBSDL_U14 U14_UART_RX_1 UART U14_UART_TX_1 HDMI_Splitter HDMI_0_TX HDMI to H13 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 89 UD_V x 1 Lane수 수 UART2_TX DIM5/GPIO[37] URSA_BIT0/1/2 DIM6/GPIO[38] 0/0/0 4K@120P _16Lanes DIM7/GPIO[39] 0/0/1 4K@60P _ 8Lanes 0/1/0 5K@120P _ 20Lanes Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 90 U17 [ADC_I_INP] IF_N ADC_I_INN [IF_N] 7 V17 [ADC_I_INN] TUNER_SIF TU_SIF_TU 9 LG1154AN TU_CVBS TU_CVBS_TU 8 IF AGC IF_AGC IF AGC TU IF_AGC_TU Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 91 [AUAD L/R CH3 IN] [AUAD_L/R_CH3_IN] COMP2_PB_IN_SOC COMP2_Y_IN_SOC Component 1 COMP2_Y_IN_SOC_SOY Phone JACK COMP2_PR_IN_SOC COMP1_Y/Pb/ [PB2/Y2/SOY2/PR2_IN] SPDIF OUT SPDIF_OUT [IEC958OUT] H/P JACK HP_L/ROUT [AUDA_OUTL/R] Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 92 AMP_MUTE(Woofer_mute) AMP_MUTE (Woofer_mute) MICOM SIDE HP MUTE SIDE_HP_MUTE TU_SIF TPA6138A2 [AAD_ADC_SIF] HP_L/ROUT_MAI Headphone H/P Jack [AUDA_OUTL] [HDMI_ARC] [IEC958OUT] HP_L/ROU SPDIF_OUT SPDIF_OUT_ARC Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 93 HPD4 / MHL_CBUS RXBSCL/SDA_U1 CEC_ (SIL9617) MHL_VBUS REMOTE HDMI_U14_2 RXASCL/SDA U1 RXASCL/SDA_U1 HDMI Out 1 DDC_I2C 1 MICOM MICOM CEC_REMOT (R5F100GEAFB) (TPS2553) Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 94 M REMOTE RXD M_REMOTE_RXD [UART1_TXD] M_REMOTE_TXD [UART1_RTS] M_REMOTE_RTS [UART1_CTS] M_REMOTE_CTS [UART0_RXD] [UART0_TXD] SOC_TX SOC_RX SOC_TX SOC_RX MICOM WIFI/BT WIFI/BT RS 232C RS-232C Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 95 33 Ω [SCL5] IC12000 [SCL2/GPIO78 SII9587CNUC LG1132-D13 [CSDA] I2C_SDA5 AF 33 I2C_SDA3 HDMI_SW 33 Ω [SDA5] AN19 B11/B1 33 Ω [SDA2/GPIO7 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 96 HDMI_CEC HDMI Jack HDMI Jack [P74/KR4/INTP8/SI01/SD A01] CAM_SLEEP Camera Camera [P30/INTP3/RTC1HZ/SCK11/SCL1 WOL/ETH_POWER_ON LAN PHY LAN PHY LAN PHY LAN PHY [P50/INTP1/SI11/SDA11] Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 97 [GPIO11] AG7 PCM 5V CTL PCM_5V_CTL P7200 P7200 /FRC FLASH W /FRC_FLASH_W [CAM_INPACK/GPIO74] CAM_WAIT_N [GPIO126] Y7 FI-RE51S-HFK-A CAM_REG_N [CAM_VCCEN_N/GPIO87] [CAM_WAIT_N/GPIO84] [CAM_REG_N/GPIO72] Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 98 USB Wi FI 24P POWER 24P POWER WOL/WOW POWER ON WOL/WOW_POWER_ON [P13/T D2/SO20] [P13/TxD2/SO20] P4301 13 [P50/INTP1/SI11/SDA11] P2301 RL_ON [P140/PCLBUZ0/INTP6] FW20020-24S Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 99 LOGO + IR Jog Key BT MOTION ASSY WIFI ASSY WIFI ASSY WIFI ASSY BT MOTION ASSY BT MOTION ASSY To Main Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 100 Circuit noise, mechanical noise F. Exterior error Exterior defect First of all, Check whether there is SVC Bulletin in GCSC System for these model. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 101 Always check & record S/W Version and White Replace Main Board Re-enter White Balance value Balance value before replacing the Main Board Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 102 Power No Video/ replace voltage? Board ( 3.5V,12V,20V No audio MAIN B/D or 24V…) Replace Power Board and repair parts Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 103 Contact with signal distributor Contact with signal distributor Picture? or broadcaster (Cable or Air) Normal Picture? Replace Main B/D Close Close Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 104 Request repair for external device/cable Check external External device External device device and Replace Main/T-con B/D HDMI /Cable error cable normal Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 105 (Check normal operation of Main /T-con Main /T-con normal? normal? External Input, Component, RGB and HDMI/DVI by connecting Jig, pattern Generator ,Set-top Box etc. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 106 Measure voltage of each output of Power B/D Normal? ※ Normal Replace Main B/D voltage? Close Normal Check ST-BY 3.5V voltage? ☞A18 Replace Power B/D Replace Power Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 107 "POWEROFF_ABNORMAL1" Power off by abnormal status except CPU trouble Abnormal "POWEROFF_CPUABNORMAL" Power off by CPU Abnormal Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 108 Speaker off Board Board Cancel OFF Replace Power Board and repair parts Check Disconnection Replace MAIN Board Speaker disconnection Replace Speaker Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 109 Check and fix external device Check and fix external device Check and fix external device Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 110 (Power B/D don’t have problem) If R/C operate, Normal Close Explain the customer operating? cause is interference from light in room. Replace R/C Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 111 * If you conduct the loop at 3times, change the M4. * INSTART MENU 14.RF Remocon Test 3. Firmware download download Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 112 Main B/D ☞A24 Close Check & Repair Wifi cable connection ☞A4 ☞A4 Wi-Fi Mac value Close is “NG”? Change the Wifi assy Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 113 Main B/D ☞A25 Close Check & Repair Camera cable connection ☞A4 ☞A4 Camera Ver. Close is “NULL”? Change the Camera assy Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 114 S/W Version HDMI/ Check and fix DVI, Optical Replace Main B/D Fix in external device/cable Recognition error accordance with technical information Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 115 “Part related to nose” in the Owner’s l t d t ” i th O ’ provide the description) Manual. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 116 Replace cabinet damage Remote controller controller Replace remote controller Replace remote controller damage Stand Replace stand ep ace sta d dent dent Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 117 A-3/5 Inverter/ Module Exchange Module (1) A-4/5 Exchange Module (2) Exchange Module (2) A-5/5 A 5/5 Continue to the next page Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 118 Wifi operation checking method Camera operation checking method Camera operation checking method Not Used Not Used E. Etc Tool option changing method Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 119 After turning on the power and disassembling the case, check with the naked eye, whether you can see light from locations. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 120 3. After recording the R, G, B (GAIN, Cut) value of Color Temp (Cool/Medium/Warm), re-enter the value after replacing the MAIN BOARD. (Cool/Medium/Warm), re-enter the value after replacing the MAIN BOARD. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 121 Manual Tuning When the signal is strong, use the attenuator (-10dB -15dB -20dB etc ) attenuator ( 10dB, 15dB, 20dB etc.) Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 122 <ALL MODELS> 1. Checking method for remote controller for adjustment Version Press the IN-START with the remote controller for adjustment t ll Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 123 1. Check the signal strength or check whether the screen is normal when the external device is connected. 2. After measuring each voltage from power supply, finally replace the MAIN BOARD. pp y, Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 124 LCD TV connection diagram (1) date <ALL MODELS> As the part connecting to the external input, check the screen condition by signal Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 125 Li k C bl (LVDS) diti date <ALL MODELS> Check the contact condition of the Link Cable, especially dust or mis insertion. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 126 Checking item : 1. Defective pixel 2. Residual image 3. MODULE error (ADD-BAR,SCAN BAR..) 4.Video error (Classification of MODULE or Main-B/D!) Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 127 Solder defect, CNT Broken Solder defect, CNT Broken T-Con Defect, CNT Broken Abnormal Power Section Solder defect, Short/Crack Solder defect, Short/Crack A - 1/5 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 128 Solder defect Short/Crack Solder defect, Short/Crack Abnormal Display Fuse Open, Abnormal power section Solder defect, Short/Crack Noise GRADATION GRADATION A - 2/5 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 129 Appendix : Exchange Power Board (PSU) No Light Dim Light Dim Light Dim Light No picture/Sound Ok A - 3/5 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 130 Panel Mura, Light leakage Press damage Crosstalk Press damage Crosstalk Un-repairable Cases In this case please exchange the module. Press damage A - 4/5 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 131 In this case please exchange the module. Horizontal Block Gate TAB IC Defect Gate TAB IC Defect Gate TAB IC Defect A - 5/5 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 132 Check front Power Indicator I di date <65UB980T-TA> ST BY condition: On or Off ST-BY condition: On or Off Power ON condition: Turn Off Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 133 Maker : Yeonho 28Pin SMAW200-H28S5K ’14년 적용 28Pin map (LPB) PWR ON DVR_ON P_DIM #1 PDIM #2 3.5V 3.5V 3.5V SCLK VSYNC Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 134 Entry method 1. Press the IN-START button of the remote controller for adjustment 2. Check the entry into adjustment item 3 Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 135 1. Press the Setting button on the remote controller 2. Select the Sound function of the Menu 3. Select the Sound Out 4. Select TV Speaker Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 136 ③ Connect the tester RX1 to the speaker terminal and if you hear the Chik Chik sound when you touch the GND and output terminal, the speaker is normal. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only...
  • Page 137 Analog Tester needle moves slowly and defective when it does not move at all Analog Tester needle moves slowly, and defective when it does not move at all. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only...
  • Page 138 Checking order 1, 2. Check Motion cable condition between Motion assy & Main board. Check the 3.3V on the terminal 2. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 139 Checking order 1, 2. Check Wifi cable condition between Wifi assy & Main board. Check the 3.3V on the terminal 2. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 140 Checking order 1, 2. Check Camera cable condition between Camera assy & Main board. Check the 3.5V on the terminal 2. Copyright ⓒ 2014 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
